1 About this manual
1 About this manual
Dear customer,
To ensure reliable and efficient operation of your boi-
ler, the following points are extremely important:
–Professional planning and installation of the hea-
ting system.
–Training of customers in starting up the heating
boiler.
–Regular maintenance by the operator.
–Regular maintenance by qualified personnel.
–Compliance with the specifications and infor-
mation in this manual.
Software version for control
The manual describes the software version 19.040
of the ecomanager-touch control; Main screen of the
control > 13
Language
The language of the original manual is German. Ver-
sions of this manual in all other languages are trans-
lations of the original.
Storage
Keep the manual for the entire service life of the pro-
duct and ready to hand. The manual must be passed
on to the new owner when the product is dis-
mantled/reused. If the manual is lost or destroyed,
request a new copy from the manufacturer.
Instructions and warnings
The instructions used in this manual are highlighted
with symbols and signal words. The signal word indi-
cates the level and nature of the danger.
iIndicates information for correct handling of
the product.
!ATTENTION - Failure to comply with this
instruction could result in damage to property.
DANGER - Failure to comply with this instruc-
tion poses a danger to people.
Manufacturer
SOLARFOCUS GmbH
Werkstrasse 1, A-4451 St.Ulrich
Company register no. 281755x
Tel.: [phone], Fax: [phone]
[email protected]
www.solarfocus.com
Service Hotline
–Email: [email protected]
2 Safety information
Qualification of personnel
–The work procedures described in this manual
must only be carried out by qualified specialist per-
sonnel.
–Work on electrical components must only be per-
formed by trained electricians and in accordance
with the relevant rules and directives.
Installation and commissioning
–System may only be installed and put into ope-
ration by certified qualified personnel
(SOLARFOCUS service technician or
SOLARFOCUS service partner.
Keep unauthorized persons and children away
–Danger of burns due to hot lines and hot com-
ponents, risk of injury from mechanically moving
parts. Keep unauthorised persons away, do not
leave children unattended, and control access to
the boiler room and fuel storage room.
Safety devices
–Never disengage the safety equipment of the hea-
ting system under any circumstances. In case of
failure, arrange for immediate repair.
Maintenance and repair
–Perform maintenance activities at the specified
intervals. No or incorrect maintenance leads to
inefficient operation, higher failure risk of the boi-
ler and increased potential for hazards.
Recommendation: Conclude maintenance con-
tract
–Have repairs done by qualified personnel only.
Improper repairs can lead to risks for the user and
impaired operation.
–Store hot ashes only in metal containers. Never
put hot or warm ash in the dustbin. This poses a
huge fire risk.
–For repairs use only original spare parts or parts
approved by the manufacturer (e.g. standard
parts).
Damage to the system
–If the electrical insulation (cables, plugs, switches)
becomes damaged, switch off the power supply
and have the insulation repaired.
–In the case of visible damage (e.g. thermal defor-
mation, mechanical damage) the operation of the
system must not be continued. The system may
only be operated if it is in perfect technical con-
dition.
Operation manual pelletelegance 3

3 Warranty, guarantee, liability
3 Warranty, guarantee, liability
Warrantyclaims are valid as part of a boiler main-
tenance agreement.
3.1 Technical requirements for warranty
and guarantee claims
The following technical requirements must be obser-
ved as a precondition for a warranty and guarantee
claim.
Further information on the individual points can be
found in the boiler's installation manual.
Regular maintenance and cleaning
–The boiler and the heating system components
must be maintained and checked regularly.
–This is the prerequisite
–for permanently reliable functioning of the boi-
ler,
–for energy-saving and environmentally friendly
operation of the boiler,
–for a long boiler service life.
–Option/recommendation: Conclude maintenance
contract.
–Documentation is crucial: When maintenance is
performed by qualified personnel, the activities
carried out/measures taken are documented in
the maintenance log. It is advisable to keep a sys-
tem book, especially when foregoing main-
tenance by qualified personnel (for
documenting/as proof of one's own activities).
Fuel
–The fuel used must meet the specifications.
–Non-approved fuel may lead to inefficient
combustion and cause damage to the boiler.
Specifications for the heating system's fill-up/-
make-up water
–Check pH value: this must be in the range of
8.2 to 9.5
–Avoiding scale buildup (=limescale on heat
exchanger surfaces):
–Take the water hardness into account
–Soften the fill-up water, or better: desalinate it.
–Avoiding water-side corrosion (is triggered by the
oxygen in the water):
–Correct system planning, correct dimen-
sioning, take material combinations into
account.
–Repair leaks immediately.
–Expansion tank (prevents air suction when the
system cools down): Correctly set the pres-
sure, check it regularly.
–Existing underfloor heating: Take care with
old, diffusion-open plastic pipes (separate the
system).
Return temperature in the boiler
–A temperature below the dew point (leads to cor-
rosion in the boiler) must be prevented by a suf-
ficiently high return temperature in the boiler.
–In the case of the pellet elegance, this is ensured
by the return flow boosting which is integrated as
standard.
Supply air to the heating boiler
–The supply air in the boiler must not contain any
aggressive substances. These substances can
cause corrosion in the boiler and chimney.
–Aggressive substances are, for example, chlorine
or fluorine compounds (used in cleaning agents,
solvents, adhesives, etc.).
3.2 Conditions for claims
For warranty and guarantee claims observe the fol-
lowing points:
–The warranty begins at the time at the time of han-
dover (delivery note, commissioning log).
–The warranty period is calculated from the date of
initial commissioning (according to the control's
operating hour counter).
–The warranty periods are based on the relevant
regulations.
–We must be notified promptly and accurately of
any damage incurred, so that the cause can be
clarified.
–If the system has defects despite correct instal-
lation (in compliance with the technical docu-
mentation), we grant a warranty provided that the
system has been examined by the plant customer
service (commissioning log).
–The guarantee applies to technical, construction-
related faults and faults in the manufacture of the
system that prevent correct and problem-free
usage.
–We are not liable for parts that were not produced
by SOLARFOCUS. However, we are prepared to
transfer our existing claims against the producer
(relating to this defect) to the buyer.
4 Operation manual pelletelegance

4 Product information
–In fulfilling the warranty/guarantee services, we
shall cover only the assembly time and the mate-
rials used, but not any travel or accommodation
costs necessary for the fitters/engineers or any
return transport costs.
–SOLARFOCUS GmbH assumes no liability for
any consequential costs of damages.
–The repair and/or warranty replacement shall be
carried out on site or in the SOLARFOCUS fac-
tory at our discretion.
–The company SOLARFOCUSwill determine whe-
ther such work requires a repair or whether the
parts are to be replaced free of charge.
3.3 Claims rendered void
The warranty and guarantee claims are rendered
void if one of the following points applies:
–Non-compliance with the technical requirements
> 4
–Damage during transport.
–Wilful damage.
–Damage due to force majeure (water, fire, etc.).
–Non-observance of information in the planning,
installation and operation manual.
–Insufficient energy or water, fault in the hydrau-
lics.
–Incorrect operation, failure to perform main-
tenance and cleaning as prescribed.
–Commissioning and maintenance carried out by
non-certified companies.
–Undocumented commissioning (no com-
missioning log) and/or maintenance (main-
tenance log).
–It is almost impossible to produce flawless pain-
ted parts; for this reason, slight defects that do not
adversely affect proper use shall not be deemed
as grounds for complaint.
–No claims can be accepted under the warranty if
unauthorised intervention (or action that has not
been explicitly approved by us the manufacturer)
has been carried out. In addition, the goods must
be paid for within the specified payment time-
frame.
3.4 Limitation of liability
SOLARFOCUS GmbH assumes no liability for injury
or material damage resulting from:
–Failure to observe the instructions in this manual.
–Use of the product for any purpose other than for
its intended use.
–Deployment of unqualified personnel.
–Use of non-approved spare parts.
–Technical modification of the product by the sys-
tem operator.
4 Product information
4.1 Proper use
–The heating boiler pellet elegance is intended for
heating up water in closed heating systems.
–Only use fuel as specified in the next chapter
Fuel.
4.2 Fuel
Pellets
Use wood pellets only in accordance with these spe-
cifications:
–Pellets according to the ISO 17225-2 standard,
class A1.
–Pellets that meet the additional ENplus certifica-
tion.
–Pellets that meet the additional DINplus certifica-
tion.
4.3 Product description
–The pellet elegance is a boiler for the combustion
(gasifier technology) of wood pellets.
–The boiler has an automatic fuel ignition system,
automatic fuel supply and automatic heat exchan-
ger cleaning.
–The ash produced is collected in an ash con-
tainer, which must be emptied at regular intervals.
4.4 Spare parts
For repairs use only original spare parts or parts
approved by the manufacturer (e.g. standard parts).
The manufacturer cannot accept any liability for
damage caused by spare parts not authorised by the
manufacturer.
Operation manual pelletelegance 5

3 Warranty, guarantee, liability
4.5 Accessories
Lifting aid
–Optional accessories for carrying/moving the boi-
ler.
–Item 6144
Abb. 2-1: Lifting aid mounted
Extension pack for operation as a room-sealed
appliance (RS)
–Optional accessories for operation of the boiler as
a room-sealed appliance.
–Item 67250
–Further information can be found in the boiler's
installation manual.
Abb. 2-2_RLUErweiterung
Extension for flue gas pipe connection
–Optional accessories for extension of the connec-
tion to the top of the boiler.
–Further information can be found in the boiler's
installation manual.
4.6 Type plate
4.7 CE declaration of conformity
The conformity of the product is declared by the
manufacturer in accordance with the Machinery Direc-
tive 2006/42/EC; the documents are available for
inspection at the manufacturer.
The product corresponds to Directive 2011/65/EU
(RoHS 2) and does not use any materials containing
asbestos. The product does not contain any PCB or
mercury.
4.8 Safety devices
Heat dissipation
–This function of the boiler control is a safety
device that prevents overheating of the boiler.
–Functioning: If the boiler temperature exceeds the
Heat dissipation maximum boiler temperature[1]
parameter, all pumps relating to the connected
devices (e.g. heating circuit, DHW tank, buffer
tank) will be switched on and the heating circuit
mixing valve opened. In this way, energy is drai-
ned from the boiler and it may be possible to pre-
vent other safety devices tripping.
–If the boiler temperature falls below the set Heat
dissipation maximum boiler temperature minus
1°C again, the pumps and mixing valves will be
operated in standard mode again.
[1] You can find the parameter in Service menu |System para-
meters button | General settings button.
6 Operation manual pelletelegance

3 Warranty, guarantee, liability
Overtemperature reset (OTR)
–The overtemperature reset is a safety device that
prevents overheating of the boiler.
–Functioning: The overtemperature reset stops the
heating process at a boiler temperature ~95°C
(exclusively electrical function; fuel and air supply
are interrupted).
–After tripping, the overtemperature reset must be
manually released again by unscrewing the black
sealing cap 1and pressing the button as soon as
the boiler temperature falls below 60°C.
–If the overtemperature reset trips, this is indicated
on the boiler control display.
Abb. 2-3: Position of the overtemperature reset
Thermal overload protection
iThermal overload protection is only required
for the pellet elegance 24.
–The thermal overload protection prevents an
uncontrolled increase in temperature and pres-
sure inside the boiler.
–Functioning: At a boiler temperature > 95°C, the
valve opens and directs cold water through the
safety heat exchanger (which is placed in the
water jacket of the boiler). This lowers the boiler
temperature.
Abb. 2-4:Schematic diagram
Safety valve (to protect against excess pres-
sure in the system)
–The safety valve 1is a safety device for protecting
against overpressure in the water circuit of the
heating system.
–Functioning: The valve opens when the system
pressure exceeds 3 bar. Water/steam are dischar-
ged into an open drain via a blow-off line, which
avoids consequential damage to the heating sys-
tem. The safety valve is closed during normal ope-
ration.
–For normative specification see EN 12828.
Abb. 2-5
Operation manual pelletelegance 7

3 Warranty, guarantee, liability
Emergency OFF switch
–The emergency OFF switch is a manually ope-
rated safety device. The burner and the fuel sup-
ply to the boiler are stopped. Circulation pumps
remain in operation to dissipate heat and cool the
boiler.
–The switch must be installed outside the boiler
room in a safe place that is easy to access.
4.9 Efficient and low-emission operation
Please note the following recommendations from the
EU Energy Efficiency Directive:
Use of a buffer tank
As the most complete combustion of wood pellets is
possible only when the boiler is in normal operation
and as greater losses and higher emissions occur
during the warm-up and burn-out phases, the use of a
buffer tank is recommended.
This tank stores the water heated by the boiler, allo-
wing the connected devices (heating circuit, DHW
tank, fresh water module, etc.) to access it as requi-
red. This ensures sufficiently long, uninterrupted com-
bustion periods for the boiler.
Use of high-efficiency heating pumps
When using external heating pumps (existing heating
circuit pumps, etc.), high-efficiency pumps with
energy efficiency class A should preferably be used.
This delivers savings potential of up to 80% in drive
energy (compared to conventional heating pumps)
with identical feed results.
4.10 Functional components
1 Buffer tank return / DHW tank return
2 Buffer tank flow / DHW tank flow
3 Suction turbine for pellets
4 Intermediate pellet store
5 Rotary valve
6 Pellet auger
7 Filling chamber
8 Stainless steel combustion grate
9 Combustion chamber
10 Ash container
11 Ash extraction auger
12 Ash extraction auger motor
13 Heat exchanger turbulator
14 ID fan
15 Heat exchanger turbulator motor
8 Operation manual pelletelegance

3 Warranty, guarantee, liability
4.11 Combustion principle
Fuel path
The pellets are sucked by the suction turbine 1into
the intermediate pellet store 2. The pellet auger 5and
rotary valve 4transport the pellets to the filling cham-
ber, where they fall onto the stainless steel com-
bustion grate 6. The pellets are burned using
downfiring combustion technology. The ash pro-
duced during combustion is transported by the ash
extraction auger 7to the ash container 8.
Airflow
The air required for combustion is sucked through the
primary air duct 3into the filling chamber, downwards
through the stainless steel combustion grate into the
combustion chamber, on through the heat exchan-
ger, and leaves the boiler via the ID fan into the flue
gas pipe.
Additional air opening in event of power failure 9.
(fehlender oder ungültiger Codeausschnitt)
(fehlender oder ungültiger Codeausschnitt)
(fehlender oder ungültiger Codeausschnitt)
Operation manual pelletelegance 9

4.12 Technical specifications
pellet elegance 10 15 20 24
Power range [kW] 2.9 - 9.9 4.4 - 14.9 5.9 - 19.8 7.2 - 24
Energy efficiency class A+
Boiler class (acc. to EN305:5 2012) 5
Boiler efficiency - full load [%] 93.80 93.90 94 94.40
Boiler efficiency - partial load [%] 94 92.42 94.30 94.30
Dimensions
Width [cm] 60
Depth [cm] 90.5
Height (H)
- incl. adjustable feet, feet screwed in all the way
- without hydraulic connections on the top of the boiler
[cm] 130 157
Minimum room height [cm] 180 185
Weight
Weight [kg] 288 329
Water side
Water content [l] 25 36
Thermal overload protection [”] not required External thread
1/2”
Drain [”] External thread 1/2”
Max. permissible operating pressure [bar] 3
Electrical connection
Connection, fuse 230 VAC, 50 Hz, C13 A
Fuel
Fuel Wood pellets acc. to EN17225-2, ENplus-A1
Capacity of intermediate pellet store [l] 48 88
Flue gas side
Flue gas pipe diameter [cm] 10 13
Height to centre of flue gas pipe (D) [cm] 70 72
Centre of flue gas pipe - side (A) [cm] 44 47
Capacity of ash container [l] 16.3 16.3
Flue gas mass flow full load [g/s] 5.5 8.4 10.5 12.5
Flue gas mass flow partial load [g/s] 2.5 3 3.5 4.1
Maximum flue gas temperature [1] full load [°C] 140
Maximum flue gas temperature [1] partial
load [°C] 100
Minimum draught requirement [2] [Pa] 5
Emissions according to test report
Flue gas values (in relation to 13% O2) from
test report:testing institute/test report No.
TÜV Austria /14-
UW-Wels-EX-
425-1
TÜV Austria /14-
U-023/ALN
TÜV Austria /14-
UW-Wels-EX-
425-2
TÜV Austria /14-
UW-Wels-EX-425-3
CO full load [mg/m³] 30 30 30 49
CO partial load [mg/m³] 168 132 97 97
NOx full load [mg/m³] 112 112 112 111
NOx partial load [mg/m³] 111 108 105 105
Org. C full load [mg/m³] 3 3 3 3
Org. C partial load [mg/m³] 4 3 3 3
Dust content full load [mg/m³] 11 13 13 12
Dust content partial load [mg/m³] 12 13 14 14
3 Warranty, guarantee, liability
10 Operation manual pelletelegance

3 Warranty, guarantee, liability
Operation manual pelletelegance 11
pellet elegance 10 15 20 24
Regulation (EU) 2015/1187
Nominal heating output [kW] 9.9 14.9 15.5 22
Heating boiler energy efficiency class A+ A+ A+ A+
Energy efficiency class EEI of boiler and con-
trol combined A+ A+ A+ A++
Energy efficiency index EEI of the heating
boiler 114 119 121 122
Energy efficiency index EEI of the boiler and
control combined 118 123 125 126
Space heating annual usage etaS [%] 77 80 82 83
Annual emission values
CO - carbon monoxide [mg/m³] 93 103 112 116
NOX- nitrogen oxide [mg/m³] 140 143 146 145
C - Total (carbon) [mg/m³] 4 4 3 3
Dust [mg/m³] 19 19 20 20
[1] Flue gas temperature can be adjusted electronically
[2] A draught stabiliser must be fitted if the specified draught of 15 Pa is exceeded (Caution:In a boiler with room-sealed operation, use a
room-sealed draught stabiliser)
You can find the technical specifications for the pellet elegance with combustion grate in the boiler's technical
report (DR-0142).

3 Warranty, guarantee, liability
4.13 Dimensions and connections
Flue gas pipe connection aligned backwards
Flue gas pipe connection aligned upwards
1 Buffer tank return / DHW tank return
2 Buffer tank flow / DHW tank flow
âPellet suction
3 Heating circuit 1 return
4 Heating circuit 1 flow
5 Heating circuit 2 return
6 Heating circuit 2 flow
áPellet return air
All hydraulic connections external thread 1" flat
sealing.
12 Operation manual pelletelegance

5 Use and operation
5 Use and operation
Touch display for operation
If the boiler is supplied with a mains power supply, the
ecomanager-touch boiler control starts. The control is
started up to show the main screen.
iOperate the touch display with your fingers,
do not use any hard or pointed objects.
If no inputs are made for 5 minutes (factory setting),
the display will switch to standby mode.
Tapping the display again restarts the display with the
main screen.
Buffer battery in operating element
A replaceable buffer batter (CR2032) ensures that
data (time, settings) are retained in the operating ele-
ment when the power supply is switched off.
5.1 Main screen of the control
Abb. 2-6: Main screen
1 Software version for control
2 Outside temperature
3 Boiler output (rotational speed of ID fan)
4 Boiler temperature and residual oxygen con-
tent in flue gas
5 Boiler operating mode > 13
6 Status line
Tapping the main screen changes to the Selection
menu> 13
5.2 Boiler operating mode
1Chimney sweep function
This function is used to perform the emission mea-
surements prescribed by law.
►Perform emissions measurement > 38
2STOP
The burner is switched off. No connected devices
heating requests are fulfilled.
!ATTENTION - The burner must not start! Only
the automatic start-up of the heating circuit
pump is active to protect against frost.
3START
After pressing the START button, the burner is ready
for operation, and is able to fulfil heating requests
from the connected devices. The burner goes into
standby as soon as a heating request is fulfilled, or
the time release > 14 is no longer available.
5.3 Selection menu
Abb. 2-7:Selection menu
1 Customer menu > 14
2 Output test heating circuit > 14
CAUTION, only to be undertaken by qualified
personnel.
3 Heating circuit > 20
4 Domestic hot water heating > 23
5 Circulation control (optional) > 25
6 Buffer tank (optional) > 27
7 Solar system (optional) > 27
8 Temperature difference, charge control (optio-
nal) > 28
10 Weatherman function (optional) > 31
11 Information
15 Boiler cleaning > 33
Operation manual pelletelegance 13

5 Use and operation
5.3.1 Output test heating circuit
The available electrical outputs can be switched
on/off directly using the button. Can be used to test
the function of individual components.
!ATTENTION - Only to be undertaken by qua-
lified personnel.
Abb. 2-8
Abb. 2-9
5.4 Customer menu
Abb. 2-10
1 Required boiler values > 14
2 Vacuum output > 15
4 User lock > 15
5 Message log [2]: Recording of alarm and noti-
fication messages > 16
6 Operating hour counter > 16
7 Output test boiler (CAUTION, only to be under-
taken by qualified personnel).
8 Qualified personnel menu > 17
[2] Button is only visible if a message is active.
5.4.1 Required boiler values
Abb. 2-11:Required boiler values
Burner release time 1
The burner can start within the release times; outside
of these times, starting does not take place and/or the
burner is stopped. A time release from 00:00 to 23:59
means that no restriction is pending and the burner
can start at any time.
!ATTENTION - In order to protect against frost,
only automatic start-up of the heating circuit
pump is active outside the release time.
14 Operation manual pelletelegance

5 Use and operation
iDomestic hot water heating in summer
If the boiler is used for heating domestic hot
water, then the required chimney draught of 5
Pa may not be present in the summer months
(or outside the heating period). This may
result in smoke escaping in the boiler room.
Reason: High temperature on the chimney
stack (greater than 30°C); as a result the coo-
ler air does not rise (~ 20°C air temperature
when the burner starts)in the chimney.
Remedy: Set the burner release time from
00:00 to 07:00 or from 21:00 to 23:59.
Burner release outside temperature 2
The burner may not start if the outside temperature
exceeds this value.
External boiler release 3
On switches the function to standby. I.e. a connected
external boiler may only start when it receives the
release from the SOLARFOCUS boiler (e.g. on the
basis of a lack of fuel, operating fault).
5.4.2 Vacuum output
Abb. 2-12: Vacuum output
Release 1
Within the release times, the pellet suction turbine
can start. A release time from 00:00 to 23:59 means
that no restriction is pending and suction can start at
any time.
Intermediate pellet store filling 2
Pressing the button starts the suction turbine and the
tank is filled once. (i.e. current level and release times
are not considered). Prerequisite: the boiler must
have the status Switched off or Standby.
Manual filling 4
Pressing the button deactivates the automatic
vacuum output, i.e. the suction turbine cannot start.
(e.g. for manual filling of the intermediate pellet store
through the inspection flap).
Automatic diverter for suction heads 3
Optional, i.e. the button of the same name and the
screen are only visible if this item has been bought.
Abb. 2-13
Probe switching 8
Automatic (recommended setting): After three suc-
cessful suction procedures at a head, the system swit-
ches to the next head. An even reduction of the fill
level in the pellet storage area is achieved.
Selectively: The heads are successively sucked
empty.
Only probe ….: Suction is only performed at the set
head. Switching to the next head must be performed
manually at the boiler control.
Storage area filled 9
–Pressing the button marks all suction heads 10
again as full (e.g. after filling the storage area).
Pressing the Status button changes the head sta-
tus (colour red: Head is empty; colour
green:Head is full).
–Red marking means: Head is sucked empty.
–Green marking means: Head is full.
–The arrow 11 above the heads shows the
currently used head. PositionCmeans that the pel-
let hose has been sucked empty (happens auto-
matically, lasts a few seconds).
5.4.3 User lock
Abb. 2-14
Operation manual pelletelegance 15

5 Use and operation
The function serves as protection against unaut-
horised modification of the control parameters. When
the user lock is active, the parameters of the indi-
vidual screens are displayed but cannot be changed.
The active user lock is indicated by the padlock icon 1
on the screens.
User lock screen
Abb. 2-15
Enter the password 2
To define a new password (maximum 20 characters).
Password 3
The currently valid password is displayed.
User lock 4
Off: The user lock is switched off.
On: Switches on the user lock function. If the display
is not touched for one minute, the user lock is active
in the screens.
Password reset 5
The current password is reset to the value solarfocus.
Adopt as new password 6
Enter a new password in the input field and press the
button. Note on screen keyboard: Confirm input with
the button.
5.4.4 Message log
Abb. 2-16
The messages displayed on the control are recorded
here, with the time that it began and ended. The mes-
sage with the highest priority is highlighted in red, ack-
nowledged messages are highlighted in green.
Press the 2button to quit messages. Button 1opens
the power failure log.
Possible messages > 40
5.4.5 Operating hour counter
Abb. 2-17
16 Operation manual pelletelegance

5 Use and operation
5.4.6 Qualified personnel menu
Abb. 2-18
1 Service menu > 17
2 IP VNC (for remote access) > 17
3 Sending emails > 18
4 mySOLARFOCUS-App > 28
5 Language selection > 19
6 Date and time > 19
5.4.6.1 Service menu
In the Service menu there are technical (factory pre-
defined) settings for an optimum combustion process
in the boiler. These can only be accessed by qualified
personnel (code input required).
5.4.6.2 IP VNC (for remote access)
The ecomanager-touch control allows access to the con-
trol screens from a PC or mobile device (e.g. smart-
phone). To do so, the VNC (Virtual Network
Computing) software is used. The control has an inte-
grated VNC server, while the VNC Viewer, which is
available free of charge on the Internet, is required for
remote access.
A cable connection is required on site for connecting
the control to the router. Use the Ethernet socket
(type RJ45) on the rear of the control panel (Touch
display).
iInstallation and configuration of this function
must be performed by the customer (i.e. not
included in the commissioning, service and
support activities).
The following points are helpful for setting up a PC/-
router to control the VNC server, which requires know-
ledge of networking technology.
IP configuration
►To access the IP-VNC icon, select the following
in the control
–Selection menu screen
–Customer menu screen
–Qualified personnel button
►Enter the data for your router. Recommended
process:
–Select DHCPON.
ÄThe IP address is determined.
–Select the DHCP OFF + Adopt button.
Abb. 2-19
–The IP address must be unique in each Ethernet
network and is dependent on the other network
components (PC, modem/router, etc.).
–Recommendation: Set a fixed IP address
(=DHCP OFF), i.e. the control has a constant IP
address.
Version 1: Install VNC viewer for access from a
local PC (PC in the home network)
►Download the free VNC Viewer from the Internet,
install it on the PC and start the application.
►Enter the previously defined IP address of the
control.
–As soon as the VNC Viewer is able to access
the control, a password must be entered.
–The password predefined by the manufacturer
is solarfocus
–After login, the screen view of the control can
be seen.
Operation manual pelletelegance 17

5 Use and operation
Change the VNC password
Abb. 2-20
►Press the Change VNC password button on the
IP setup view.
►To change it, first enter the old password, then
the new password, then press the Adopt button.
►The new password must be used to log on after
restarting the VNC Viewer on the local PC.
►Press the Reset password button to reset the
password to the default password solarfocus.
Version 2: VNC viewer for access from an exter-
nal PC (PC outside the home network)
–The user's local router does not always have the
same IP address on the Internet (it is allocated by
an Internet Service Provider – ISP).
–Nevertheless, Dynamic Domain Name Systems,
also referred to as DynDNS or DDNS, allows
access to the router.
–These systems allow a unique host name to be
assigned on the Internet; the unique name is then
also entered in the router. If the router is then assi-
gned a different address by the ISP, it enters the
updated IP address as the defined host name on
the DynDNS server. The router and therefore the
home network can then be reached using this
host name.
–To create a connection with the control, a port
diversion is required from the external port of the
router[1] to the IP address and to VNC port 5900
of the control.
[1] Port 5921 is recommended
iAvoid any port forwarding from external port
5900 of the router to IP address and VNC port
5900 of the control.
5.4.6.3 Sending emails
Function: The boiler control ecomanager-touch auto-
matically sends status emails and alarm e-mails (to
stored addresses) if required.
Status email: An automatic email (e.g. sent daily) pro-
vides information on the current boiler status.
Alarm email: a message is sent when a fault occurs.
iInstallation and configuration of this function
must be performed by the customer (i.e. not
included in the commissioning, service and
support activities).
Abb. 2-21
Outgoing mail server 1
Enter the access data for the e-mail server you use.
Abb. 2-22
Use SSL: Select if the e-mail server uses a TLS/SSL
encryption protocol.
Address book 2
A maximum of 10 contacts can be added. If there are
several addresses for a contact, these should be
comma-separated.
18 Operation manual pelletelegance

5 Use and operation
Write e-mail 3
Used to manually send emails. The recipient’s
address can be selected from the address book using
To and CC or manually entered in the recipient line.
Alarm test 4
Used to test the email settings. Pressing the button
sends an email to the recipient status email.
Send alarm email 5
Activates/deactivates the automatic sending of alarm
emails. The sending of status emails is not affected
by this.
Alarm configuration 6
Settings for the alarm emails to be sent automatically.
Abb. 2-23
Alarm subject: is used for all alarm emails and status
emails, therefore it should be as meaningful as pos-
sible (e.g. boiler type / name of system operator; 40
characters available).
Alarm groups: For prioritisation of the alarm mes-
sages (e.g. Alarm group 1 receives all messages,
Alarm group 2 receives only operationally-relevant
messages, such as information on faults).
Status email: Set the time at which the status email is
sent. The automatically generated content of the sta-
tus email is:
–Current status of the heating system
–Fault present, and which
Alarm selection: This is where you define which alarm
group is notified of which event.
5.4.6.4 mySOLARFOCUS app
Pressing the button displays the screen with infor-
mation relating to online registration for the
mySOLARFOCUS app (serial number, PIN,status,
etc.) > Abb. 2-42, > 29
Detailed information about using the
mySOLARFOCUS app > 28
5.4.6.5 Language selection
Abb. 2-24
5.4.6.6 Date and time
Abb. 2-25
Switchover from summer/winter time takes place
automatically when the Switchover Summer-Winter 1
parameter has the value Europe. Switchover takes
place on the last Sunday of the months of March and
October. If America is set, the clock is changed to
summer time on the first Sunday in April.
Operation manual pelletelegance 19

6 Heating circuit
6 Heating circuit
Abb. 2-26
1 Outside temperature
2 Average outside temperature
3 Room temperature (optional)
4 Temperature of the energy source, (e.g.boiler,
buffer tank)
5 Flow temperature of the heating circuit
6 Position of the heating circuit mixing valve
0% - the mixer is closed, the heating circuit is supplied
from the heating circuit return. 100% - the mixer is open,
the heating circuit is supplied from the heating boiler flow.
7 Info line: Heating request (Yes/No) to the
energy source
8 Status line of the heating circuit
9 Heating circuit settings > 20
10 Display of the heating circuit operating mode
set on the optional room temperature con-
troller (Art. no. 6160)
6.1 Heating circuit settings
Abb. 2-27
1 Heating circuit operating mode > 20
2 Room settings
(Button is only visible when the Room influence parameter
is set to On or Sliding;this can be found in the Qualified
personnel system parameters)
3 General settings > 21
4 Heating curve > 21
6.1.1 Heating circuit operating mode
Heating mode
The heating circuit pump is activated. A shutdown
occurs whenever
–the cutoff temperature for heating mode is rea-
ched.
–a room temperature sensor is used and where
inside setpoint temperature for heating mode has
been reached.
The heating circuit is supplied with the calculated
required flow temperature > Abb. 2-28.
Reduced mode
Heating circuit pump is activated. A shutdown occurs
whenever
–the cutoff temperature for reduced mode is rea-
ched.
–a room temperature sensor is used and where
inside setpoint temperature for reduced mode has
been reached.
The heating circuit is supplied with the reduced tem-
perature, i.e. calculated required flow temperature
minus reduction;> Abb. 2-28
20 Operation manual pelletelegance
