SolStar T-55 Assembly instructions

T-55T700 Product Insert
Getting Started
Your T-55 Thrane 700 includes the following:
2.5 mm barrel plug to SAE plug
Closer View
2.5mm barrel plug
Closer View
SAE plug
T-55 SolStar Solar Panel
T-55 Quick Connect Guide
Connecting the SolStar T-55 Solar Charger to Thrane Explorer 700
Connect the 2.5mm barrel plug
side to the Thrane 700 DC
output.
Connect the SAE plug side to
the SolStar T-55 solar charger.
Orient SolStar T-55 solar
charger directly towards the
sun for optimal charging.
The Thrane 700 terminal will
automatically be powered on
and start charging.
*Hughes male cigarette lighter adapter must be purchased
Folding Instructions for the SolStar T-55 Solar Charger
Fold one side of the charger down
the hinge-fold, active solar cells to
the inside.
Fold other side of the
charger down the second
hinge-fold, active solar cells
to the inside.
Starting at the end away from the cable,
fold the charger along its hinge-folds.
Then wrap the flap around until
both the hook and loop sides of
the Velcro are lined up.
Lastly, press the Velcro
together to secure the fold
unit.
www.solstaren
ergy.com
Phone: [phone]
Fax: [phone]

T-55T700 Product Insert
The SolStar T-55 Foldable Solar Charger provides 55 -Watt power. This solar charger is
lightweight and can easily fit into a backpack or carrying case. This product is ideal for Thrane
& Thrane Explorer 700 users who require lightweight portable power.
Important Notes
Please read the following information and instructions prior
to using your SolStar T-55 Foldable Charger.
Although SolStar maybe used to power other electronic devices,
the SolStar T-55 has been optimized to power the Hughes HNS
9201. Other electronic devices may be charged at consumer’s own
risk.
ALWAYS FOLD THE PRODUCT WITH THE SOLAR
PANEL PHOTOVOLTAIC SIDE FACING OUT!
Dimensions and Weight
Folded: 11 " (22.9cm) x 9" (22.9cm) x 1.3" (3.3cm)
Unfolded: 55 " (1402cm) x 32" (81.3cm) x 0.01" (0.25cm)
Weight: 3.7 lb (1.7kg)
Max Power to Weight Ratio: 14.9 watt/lb (32.4 watt/kg)
Electrical & Thermal Specifications
Electrical Characteristics
Nominal Operating Voltage 16V
Nominal Rated Current 2.8-amps
Typical Power at STC* 55-watts
Open Circuit Voltage 30V
Short Circuit Current 3.7-amps
Thermal Characteristics
Power (% / C) -0.5
Voltage (% / C) -0.5
Cell Temperature Operating Range -40
o
F to 176
o
F / -40
o
C to
80
o
C
*Data at Standard Test Conditions (STC)
STC: Irradiance level 1,000W / m2, spectrum AM 1.5
and cell temperature 25
o
C
**Cigarette Lighter Adapter (CLAs) typically operate best
between 11V and 14.5V
FAQs
If I have a problem with this product, whom do I contact?
First, contact the company that sold you the product.
Additional information is available at www.solstarenergy.com.
How do I know if it is working?
Your Hughes HNS 9201 terminal will indicate that charging is
occurring.
Will this product drain my battery at night?
No. It has a reverse diode in the module to prevent battery
discharge.
Can I leave it outside permanently?
No. Although the SolStar T-55 Foldable Charger is weather
resistant, it was not designed for continuous outdoor usage.
Once your application is finished charging, wipe the product
with a clean, dry cloth and allow the product to dry before
folding for storage.
What if the product gets wet?
No problem, just wipe it off and continue using it.
What if the product goes under water?
Simply wipe the product with a dry cloth and allow the
product to dry before use. Prolonged period in or
underwater may result in corrosion in the electronics.
Can I leave it outside in freezing temperature?
Yes. The SolStar T-55 can operate at temperatures down to
–40
o
.
Can I use an extension cord?
You can purchase the 8ft. extension cord accessory (EXT-8).
Total cord length greater than 30 feet likely will result in
reduced power output.
How do I clean the product?
Use a damp cloth with a mild soap solution.
Where can I get more product information?
Contact the company that sold you the product.
Additional information can be found online at
www.solstarenergy.com.
SolStar Limited Warranty
This SolStar T-55 Folding Solar Power Panel carries a one (1) year limited warranty against defects in workmanship and materials affecting performance. SolStar agrees to replace
the defective product free of charge, within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or
breakage due to misuse and/or abuse. In addition, any units that show signs of creasing or folding on the active photovoltaic areas are not covered under this warranty.
SolStarTM is a trademark of SolStar Energy Devices.
© 2008 SolStar Energy Devices
