Soltech CEGONIA 8W User manual

01
CEGONIA
8W 20W 30W
Installation Manual
SOLTECH Designs and Manufactures
Advanced, Solar-Powered
LED Technology.

02
CEGONIA 8W
CEGONIA 20W
CEGONIA 30W

03
01 Introduction
02 Luminous Distribution
03 Battery Notes
04 Installation and Wiring Compliance
05 Mounting Accessories
06 Installation
07 Panel Angle
08 Remote Control Guide
Contents
04
06
07
08
09
010
012
014

04
01 Introduction
Thank you for purchasing CEGONIA Urban Lighting Products.
Introduction
CEGONIA combine stylish design with hight efficiency. You can adjust both
the tilt angle and the azimuth to make sure the panel is in the optimal
position to capture the sun’s energy. It is a perfect fit for courtyards, parks,
schools, communities and paths.
Important
In order to avoid deep discharge of the battery during storage, please
fully recharge your battery every 4 months. Please make sure that the
light is installed in an area with sufficient sunlight irradiance. A strict
minimum of 3.5 hours/day of sunshine on average is recommended. Se-
lect the right operating mode according to the local legislation needs and
the local sunshine conditions. Keep it away from shadows. Self-cleaning
available when the light fixture have minimum angle of 15 degrees.
Please save these instructions. Read all of the instructions carefully
before attempting to carry out any installation or wiring. Do not open or
attempt to repair the product on your own, as it many cause serious
damage and would void the product warranty. Contact your local
distributor for any questions concerning the installation.
Range of the light module on the lighting fixture is 20–26 feet
(6–8 meters). The ideal installation spacing is >16 feet(5 meters). When
installing two or more lighting fixtures on one pole, select desired
operating mode before installation. Interference can cause delay or
malfunction when using the remote control to change operating modes
after installation.
Precautions when working with solar panels
When the solar panel is exposed to sunlight, a voltage appears at the
output terminals of the solar panel turning it into a source of electricity.
To avoid a shock hazard, make sure the solar panel is covered with an
opaque (dark) later such as paper or cloth during the installation. Do not
make contact with the terminals when the panel is exposed to sunlight or
any other light source.

05
CEGONIA 8W
22.5 inches
16.8 inches
SOLAR PANEL: 3.9 Lbs
SOLAR LAMP: 5.9 Lbs
BATTERY ASSEMBLY: 6.1 Lbs
5.0 inches
1.0 inches 7.5 inches
13.8 inches
6.0 inches
CEGONIA 20W
SOLAR PANEL: 8.2 Lbs
SOLAR LAMP: 12.1 Lbs
BATTERY ASSEMBLY: 14.3 Lbs
11.0 inches24.0 inches
1.2 inches 9.5 inches
20.1 inches
30.4 inches
8.5 inches
CEGONIA 30W
SOLAR PANEL: 9.9 Lbs
SOLAR LAMP: 13.6 Lbs
BATTERY ASSEMBLY: 16.9 Lbs
31.0 inches 11.0 inches
1.2 inches 9.5 inches
20.1 inches
30.4 inches
8.5 inches

06
02 Luminous Distribution
CEGONIA 8W Type III
CEGONIA 20W Type III
CEGONIA 30W Type III

07
Battery pack
Battery pack screws
Solar panel
1. The LiFePO4-battery-powered CEGONIA lights are visibly brighter
than other outdoor solar lights, and their performance overall is
more reliable.
2. To charge the battery fully may take up 6 to 12 hours.
3. Output will be reduced to 40% when the battery is below 40% of
its capacity.
4. Battery will stop charging when the ambient temperature is below
32°F or above 149°F.
Battery Status is indicated by the red/green indicator on the lighting
fixture as follows:
- Red indicator (Charging)
> Slow red light flashing = Charging
> Red light continuously on = fully charged
> Quick red flashing = charge fault
- Green indicator (not charging)
> Green light continuously on = more than 40% of the battery
capacity remaining
> Slow green light flashing = battery capacity below 10%
> Quick green light flashing = battery below 0% mode—Protect
battery does not over discharging
Storage
To avoid over discharge of the battery during storage, please recharge
the lighting fixture every 3 months. Use the dedicated charger to charge,
reset the switch when done.
Battery Replacement
1. Disconnect the
wire connectors.
2. Loose the screws of the
battey pack and take out
the battey pack.
3. Replace a new one.
4.Tighten the screws of
battery pack.
5. Connect the wire connectors
(Be sure you match the color
when you connect them).
(IAP) Intelligent Adaptive Program Battery
Control Technology
In order to extend the off-grid autonomy
of the CEGONIA under shady trees, heavy
rain, and thick clouds, our controllers now
integrate an adaptive smart control feature
to actively track battery capacity and adjust
light output accordingly. Before integrating
this feature, selecting a light output percent-
age on the remote would yield an accurate
percentage of max LED brightness. Now with
(IAP), the controller actively monitors the
battery and regulates the electrical current
to the LEDs. The controller makes light output
of the selected percentage on the remote
relative to battery capacity rather than max
LED output. This smart-control feature can
increase our off-grid performance by up
to 40%.
03 Battery Notes
Disconnect wires Loose the screws
of the battery
pack and take out
the battery pack.
Replace new
battey pack
and tighten
the screws.
01 02 03

08
04 Installation and Wiring Compliance
1. Installation and wiring must comply with the State and National
Electrical Codes.
2. The CEGONIA 8W, 20W and 30W models are intended for outdoor
use only and should not be installed in an unventilated area, and shall
be installed in an environment within the operational temperatures
defined for the product.
3. The average sunshine in the installation area should be above
3.5 hours/day in order to ensure full function of the lighting fixture.
Avoid areas with shades.
4. Before installation, if applicable, please ensure the light pole and its
foundation are solid enough to withstand the lighting fixture(s).
5. Before installation, please ensure that the battery is fully charged. Install
during sunny days if possible.
6. Before installation, please press the ON/OFF key in the remote
control and check whether it shows a red light on the indicator.
Please cover the panel and check if the light module turns on normally
within 1 minute.
After Installation
The lighting fixture will automatically turn on at night and turn off
during daylight.
Important
Always orient the solar panel facing the equator (e.g. facing south if in
northern hemisphere).
Always have a tilt angle of at least 15° to avoid dust accumulation
(0°=horizontal plane).

09
05 Mounting Accessories
A. TRUNNION—Wall Mount
B. TRUNNION—Round
C. TRUNNION—Square
5.1 inches
4.0 inches 6.8 inches
0.5 inches
A-b. STLSTE-20/30-WM (for CEGONIA 20W/30W)A-a. STLSTE-08-WM (for CEGONIA 8W)
B-b. STLSTE-20W/30W-TRR (for CEGONIA 20W/30W)
works with 2.4 inches to 4.0 inches poles.
C-b. TLSTC-20W/30W-TRS (for CEGONIA 20W/30W)
works with 2.0 inches to 4.0 inches poles.
Pole Size
2.0 inches 4.0 inches
B-a. STLSTE-8W-TRR (for CEGONIA 8W)
works with 2.4 inches to 4.0 inches poles.
Pole Size
2.4 inches 4.0 inches
Pole Size
2.4 inches 4.0 inches
C-a. STLSTC-8W-TRS (for CEGONIA 8W)
works with 2.0 inches to 4.0 inches poles.
Pole Size
2.0 inches 4.0 inches
0.5 inches
0.2 inches
5.1 inches
0.5 inches
5.1 inches
0.5 inches
5.1 inches
0.5 inches
5.1 inches
0.5 inches

010
06 Installation
CEGONIA 8W
Component Kit B
Component Kit A
Loose screws of component kit B to adjust
the angle of solar panel.
Loose screws of component kit A to rotate
solar panel.
180°
±45°
Connect
Connect
Connect
Connect
Connect
Connect
180°
±45°
180°
±45°

011
Component Kit A
Component Kit B
Loose screws of component kit B to adjust
the angle of solar panel.
Loose screws of component kit A to rotate
solar panel.
±45°
270°
CEGONIA 20W 30W
Connect
Connect
±45°
±45°
270°
270°
Connect
Connect
Connect
Connect

012
Alaska
25° N
15°
30°
45°
60°
19° N
21° N
26° N
20° N
27° N
28° N
29° N
30° N
31° N
32° N
33° N
34° N
35° N
36° N
37° N
38° N
39° N
40° N
41° N
42° N
43° N
44° N
45° N
46° N
47° N
48° N
60° N
49° N
Washington
Oregon
California
Nevada
Arizona
Utah
New Mexico
Kansas
Colorado
Oklahoma
Texas
North Dakota
South Dakota
Nebraska
Idaho
Montana
Wyoming
61° N
62° N
63° N
64° N
65° N
70° N
66° N
67° N
68° N
69° N
Hawaii
Minnesota
Iowa

013
Kansas
Oklahoma
Texas
The Solar charge in a battery pack won’t last forever, the off–grid
system relies on stored daylight for autonomy. Angling your solar
panels properly can boost the power intake of your lights. You want
to angle your solar panels at a tilt equal to the area’s latitude.
Tip
You can increase the tilt 15° in the winter or decrease 15° in the summer.
In this way you can get the maximum sunlight to recharge the battrey bank.
Strong sunlight Nromal sunlight Less sunlight
Key
0°
15°
15°
45°
60°
45°
Arkansas
Louisiana
Mississippi
Alabama Georgia
South
Carolina
North
Carolina
Virginia
West
Virginia
Kentucky
Illinois
Wisconsin
Minnesota
Iowa
Missouri
Michigan
Indiana
Ohio
Pennsylvania
New York Massachusetts
Rhode Island
Connecticut
New Jersey
Delaware
Maryland
Tennessee
Florida
World Wide Panel Angles
New Hampshire
Vermont Maine
30°
30°
07 Panel Angle
Best Facing Direction For The Solar Panel
Worst
Best
OKOK
The area will dictate the installation of the fixtures and will sometimes
prevent the lights from facing south. But that’s okay! Panels facing West
& East won’t get as much light as Southern facing panels, but will still
collect a good amount of sunlight. A North facing panel also works, but
it will take longer to charge than any other direction. This would mean that
the solar charge will be less optimal if installations are facing North.

014
08 Remote Control Guide
16ft–33ft
The range of the remote control to the
indicator is 16ft (Day time) to 33ft (Night
time). Because the sunlight will impact
the signal of the remote control, we recom-
mend that users setup the mode before
they install the light.
1. On/Off
When off is selected, the light will stop working. The solar panel will not
charge the battery and the battery will not supply electricity to the light.
2. Connect/Test
Remote control device can be connected with any lighting fixture, one
at a time. To connect, press the button once. It also functions as a test
button. To test, press the “Test” button once, the red light will indicate
the fixture is charging, green light indicates that the fixture is operating.
Testing lasts for 10 seconds, and then it goes back to the mode previously
in use.
1. On/Off 2. Connect/Test
4. 20%~80% Motion
Sensor Mode (Default)
6. Early Bird Mode
8. 70% Constant Mode
10. Timer Mode Disabled
12. Time Mode 8 Hours
3. 40%~100% Motion
Sensor Mode
5. Night Owl Mode
7. 100% Constant Mode
9. 40% Constant Mode
11. Timer Mode 4 Hours

015
Important
Dusk and dawn time may be diffrent in other locations and seasons.
The sensors of our products will follow the light patterns of where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes only.
3. 40%~100% Motion Sensor Mode
Constant 40% brightness (turns on at dusk, turns off at dawn);
100% brightness turns on for 2 minutes when motion is detected.
4. 20%~80% Motion Sensor Mode (Default)
Constant 20% brightness (turns on at dusk, turns off at dawn);
80% brightness turns on for 2 minutes when motionis detected.
(IAP) Intelligent Adaptive Program Battery Control Technology
In order to extend the off-grid autonomy of the CEGONIA under shady
trees, heavy rain, and thick clouds, our controllers now integrate
an adaptive smart control feature to actively track battery capac-
ity and adjust light output accordingly. Prior to including this feature,
selecting a light output percentage on the remote determined the
constant percentage of max LED brightness. Now with (IAP),
the controller actively monitors the battery and regulates the electrical
current to the LEDs. The controller now applies the selected percentage
output on the remote to the battery capacity, rather than the max LED
output. This smart-control feature can increase our off-grid performance
by up to 40%.
5. Night Owl Mode
Changes as natural light decreases/increases (turns on at dusk); 70%
brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness
for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours
(turns off at Dawn).
6. Early Bird Mode
Changes as natural light decreases/increases with increased brightness
near dawn for early risers (turns on at dusk); 70% brightness for 0.5
hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50%
brightness for 1 hour, 20% brightness for 4 hours, 100% brightness
for 1 hour (turns off at Dawn).

016
08 Remote Control Guide
8. 70% Constant Mode
70% brightness from dusk to dawn.
9. 40% Constant Mode
40% brightness from dusk to dawn.
10. Timer Mode Disabled
Press this button to turn off Timer Mode; settings revert back to before
Timer Mode was last activated.
7. 100% Constant Mode
100% brightness from dusk to dawn.

017
11. Timer Mode 4 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70%
Constant Mode. If the light turns on at 7pm at dusk, it will turn off at
11pm. It will repeat the same schedule hereafter until it is canceled
by pressing Timer Mode Disabled.
12. Time Mode 8 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70% Con-
stant Mode. If the light turns on at 7pm at dusk, it will turn off at 3am. It
will repeat the same schedule hereafter until it is canceled by pressing
Timer Mode Disabled.
Important
Dusk and dawn time can vary for different locations and seasons.
The sensors in our products will monitor the light levels where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes.

018
SOLTECH LLC reserves the right to update all
product data sheets at any time. Consult SOLTECH
marketing specialists for publication updates at
[email protected]
Copyright©2022–2023 SOLTECH LLC,
All Rights Reserved.
CEGONIA products are covered by a 5 year limited warranty.
SOLTECH urban light warrants to the original purchaser
that this product is free from defects in materials and
workmanship for the period of 5 years from date of purchase.
To obtain warranty service please contact your local distributor
or sales rep for further instruction.
1460 Park Avenue.
Emeryville, CA 94608 USA
www.soltechlighting.com

019

020
SOLTECH Designs
and Manufactures
Advanced,
Solar-Powered
LED Technology.
