Kenroy Home Canterbury 93277 User manual

USE AND CARE GUIDE
1LIGHTLANTERN-#93277,#93276
Questions,problems,missingparts?Beforereturningtothestore,
callKenroyHomeCustomerService
8a.m.-6p.m.,EST,Monday-Friday
904-642-4340
THANKYOU
Weappreciatethe trustandconfidence you have placedinKenroy Homethroughthepurchaseofthislantern.
We strivetocontinuallycreatequalityproductsdesignedtoenhance your home.
Thankyouforchoosingus!
Above image represents 93277, 93276,
your lantern mayvaryinstyle.

TableofContents
SafetyInformation.......................................................................................................................................2
Warranty......................................................................................................................................................2
Pre-Installation............................................................................................................................................3
Planning Installation.............................................................................................................................3
PackageContents..................................................................................................................................4
Installation............................................................................................................................................5,6,7
CareandCleaning........................................................................................................................................7
Troubleshooting ............................................................................................................................................7
SafetyInformation
Consulta qualifiedelectricianwithany
electricalquestionsyoumayhave.
Warranty
1-YEARLIMITEDWARRANTY
WHATISCOVERED
Themanufacturerwarrantsthislanterntobefreefromdefectsinthematerialsandworkmanshipforaperiod
ofone(1)yearfromdateofpurchase.Thiswarrantyappliesonlytotheoriginalconsumerpurchaserand
onlytoproductsusedinnormaluse.Ifthis productisfoundtobe defective,themanufacturer'sonly
obligation,andyourexclusiveremedy,istherepairorreplacementoftheproductatthemanufacturer's
discretion,providedthattheproducthasnotbeendamagedthroughmisuse,abuse,accident,modifications,
alterations,neglectormishandling.Thiswarrantyshallnotapplytoanyproductthatisfoundtohavebeen
improperlyinstalled,assembled,orusedinanywaynotinaccordancewiththeinstructionssuppliedwiththe
product.Thiswarrantyshallnotapplytoafailureofthe productasaresultofanaccident,misuse,abuse,
negligence,alteration,faultyinstallation,oranyotherfailurenotrelatingtofaultymaterialorworkmanship.
WHATISNOTCOVERED
Thiswarrantyshallnotapplytothefinishonanyportionoftheproductduetoweathering,asthisis
considerednormalwear.Themanufacturerdoesnotwarrantandspecificallydisclaimsanywarranty,whether
expressedorimplied,otherthanthe warrantycontainedherein.Themanufacturerspecificallydisclaimsany
liabilityandshallnotbe liableforanyconsequentialorincidentallossordamage,includingbutnotlimited
to,anylabororexpensecosts involvedinthe replacementorrepairoftheproduct.
ContacttheCustomerServiceTeamat904-642-4340.
IMPORTANT:Inspectthewire insulationfor
anycuts,abrasions,orexposedcopperthatmay
haveoccurredduringshipping.Ifthereisa
defectinthe wire,do notcontinuethe assembly
process.PleasecallourCustomerServiceTeam
at904-642-4340.
2

Pre-Installation
PLANNINGINSTALLATION
Readallinstructionsbeforeassembly.
Toavoiddamagingthisproduct,assembleitonasoft,non-abrasivesurfacesuchas carpet
orcardboard.Inspecteachpartfordefectsthatmayhaveoccurredduringshipping.
Keepyourreceiptandtheseinstructionsforproofofpurchase.
NOTE: Thislanternrequirestheuseofone120V, 60Hz,
60-Watt max,medium-basetypeAbulb(notincluded).
Do notexceed therecommended wattage.
TOOLSREQUIRED
Wire
strippers Wirecutters
Flathead
screwdriver
Phillips
screwdriver
Ladder
Electrical
tape
HARDWAREINCLUDED
NOTE:Hardwarenotshowntoactualsize.
AA BB CC EE
DD
Part
AA
BB
CC
DD
EE
Description
Mounting plateassembly
Wirenut
Outlet boxscrew
Finial
Groundscrew
Quantity
3
1
2
1
2
3
NOTE: Thisitem isratedfor wetlocation:IP03.

Pre-Installation(continued)
PACKAGECONTENTS
Part
A
B
Description Quantity
2
C
1
Finial
Lanternbody
Roofassembly
4
B
C
A
1

1. Assemble the lantern
Carefullyorganizeandplaceallpartsona
smooth,flatsurface.lineupalloftheparts
accordingtotheassemblydiagram.
Place thelanternbody(B)tobottom ofthe roof
assembly(C)andsecurewithtwofinials(A).
Assemblyinstructions
5
1. Remove themounting plate
Removethemountingplateassembly(BB)from
theroofassembly(C)byunscrewingthetwo
finials(DD).
DANGER:Ensurethepowerisoff atthemain
fusebox priorto beginning installation.
2. Installingthemounting plate
Turnoff the switchatthe wall.
Turnthepoweroffatthemainfusebox.
Attachthe mounting plate (BB)tothe outletbox
usingtheoutletboxscrews (CC).
CC
BB
Installationinstructions
BB
C
DD
B
A
C

Installationinstructions(continued)
3. Connectingthe wires
Installthefixturebare coppergroundwire(1)
underthegroundscrew(EE)on themounting
plate(BB).
Connectthefixturebare copperground wire (1)
tothegreen(orbare,orgreen&yellow)supply
groundwire(2)intheoutletboxusingawire
nut(AA).
Connectthewhitefixture wire (3)tothe white
(orribbed)supplywire (4)inthe outletbox
usingawirenut(AA).
Connecttheblackfixture wire (5)tothe black
(orred,orblue)supplywire (6)inthe outletbox
usingawirenut(AA).
4. Installingthefixture
Raisefixturebodytothewallandcarefully
tuckthewiresinsidetheoutletbox.spreadthe
electricalsplicessothattheblackwires are on
onesideoftheoutletboxandthewhite wires
areontheotherside.lineupscrewswithholes
inbackplateandsecurewithtwofinials (DD).
Housewire
black
(orred,orblue)
(HOT)
Fixturewire
black
(HOT)
Housewire
white
(NEUTRAL)
Fixturewire
white
(NEUTRAL)
Housewire
green
(orbare wire,
orgreen& yellow)
(GROUND)
Fixturewire
barewire
(GROUND)
6
5. Sealingthe mounting surface
ApplysiliconorRTVcompoundbetweenthe
edgesofbackplateand wall.
Backplate
2
EE
1
6
1
5
3AA 4
DD
Backplate

Careand Cleaning
Clean the lightfixture witha soft, drycloth. Donotuse any cleaners withchemicals, solvents, orharshabrasives.
Troubleshooting
PossibleCause
Thebulb isburned out.
Thepowerisoff.
Thereisafaultywireconnection.
Thecircuitbreakerisoff.
Thereisan exposedwire.
Therearetoo many itemson
onecircuit.
Discontinueuseofthelight
fixture.
Contactaqualifiedelectrician or
calltheCustomerServiceTeamat
904-642-4340.
Unplugotheritemsonthecircuit.
Ensurethatthecircuitbreaker
issetintheonposition.
Check thewiring.
Ensurethatthepowersupply
isturnedon.
Replacethelightbulb.
Solution
Thebulbwillnotlight.
Thefuseblowsora
circuitbreaker tripswhen
thelightisturned on.
Problem
7
Bulb
(notincluded)
Installationinstructions(continued)
6. Installing the bulb
Priortoinstallingthebulb,pleaseinspectsocket
forsilicapacket.ifpacketispresent,removeand
throwaway. donotexposetochildrenandpets.
Install one 120V,60Hz, 60-wattmax.medium-base
typeAbulb(notincluded)intothesocket.

904-642-4340
@KenroyHome
[e-mail]
CUSTOMERSUPPORTTEAM
Foranyadditionalquestionsorconcernsplease contactour
CustomerSupportTeam:
www.kenroyhome.com
