Soltech SunLike ECO-IAP 30W User manual

01
SunLike ECO—IAP
20W 30W
User Manual
SOLTECH offers Eco-friendly technology
to help users benefit clean energy.

02 03
Sunlike ECO—IAP 20W
Sunlike ECO—IAP 30W
Contents
0 1 Introduction
02 Specification
03 Luminous Distribution
04 Battery Notes
05 Installationand Wiring Compliance
06 Mounting Accessories
07 Installation
08 Panel Angle
09 Remote Control Guide
04
05
06
07
08
09
010
0 1 2
014

04 05
Designation
40%–100%35hrs
Night Owl 28hrs
100% 14hrs
70%15.5hrs
40% 27hrs
20%–80% 55hrs
Early Bird 25hrs
40%–100% 35hrs
Night Owl 28hrs
100% 14hrs
70% 15.5hrs
40%27hrs
20%–80%55hrs
Early Bird 25hrs
°F
)
Lumileds 5050
(215lm-CR>70
Remote control and
One-key Setting
Sunlike ECO—IAP Sunlike ECO—IAP20W
20
18V36W
12.8V 17.4AH
21.4 lbs
4000
4.75
IP65
> 70
Aluminum
200 lm/W
7hrs
14hrs
9 to 16ft
-4 °F to 122 °F
32 to 149 °F
)
30W
Lumileds 5050
(215lm-CR>70
Remote control and
One-key Setting
30
18V 52W
12.8V 29AH
29.8 lbs
6000
6.26
IP65
> 70
Aluminum
200 lm/W
7hrs
14hrs
9 to 20ft
-4 °F to 122 °F
32 °F to 149 °F
LED Nominal Power
Solar Panel
LiFePO4Battery
Weight
Lumen Output@5000K
EPA
Waterproof Rate
CRI
Casting
Efficiency@5000K
LED Chip
* ChargingTime
Autonomy (@Full Power)
Maximum Autonomy
Motion Sensor Mode
Time Control Mode
Constant Mode
Operation Mode
InstallationHeight
* Operating Temperature
* Charging Temperature
01 Introduction 02 Specification
Thank you for purchasing Sunlike ECO—IAP Urban Lighting Products.
Introduction
Outdoorsolar lighting systems use solar cells which convert sunlight
into electricity. Electricity is stored in batteries for use at night. Sunlike
ECO—IAP solar lights are easy to install and virtually maintenance free.
Using them won’t increase your electric bill.
Important
In order to avoid deep discharge of the battery during storage, please
fully recharge your battery every 4 months. Please make sure that the
light is installed in an area with sufficient sunlight irradiance. A strict
minimum of 3.5 hours/day of sunshine on average is recommended. Se-
lect the right operating mode according to the local legislation needs and
the local sunshine conditions. Keep it awayfrom shadows. Self-cleaning
available when the light fixture have minimum angle of 15 degrees.
Please save these instructions. Read all of the instructions carefully
before attempting to carry out any installation or wiring. Do not open or
attempt to repair the product on your own, as it many cause serious
26 inch
36 inch
17 inch
17 inch
4 inch
4 inch
Sunlike ECO—IAP Sunlike ECO—IAP20W 30W
Charging Point DC14.6V 3.75A
Red & GreenIndicator
Light Module
Charging Point DC14.6V 3.75A
Red & GreenIndicator
Light Module
damage and would void the product warranty. Contact your local
distributor for any questions concerning the installation.
Range of the light module on the lighting fixture is 20–26 feet (6–8
meters). The ideal installation spacing is >16 feet(5 meters). When
installing two or more lighting fixtures on one pole, select desired
operating mode before installation. Interference cancause delay or
malfunction when using the remote control to change operating modes
after installation.
Precautions when working with solar panels
When the solar panel is exposed to sunlight, a voltage appears at the
output terminals of the solar panel turning it into a source of electric-
ity. To avoid a shock hazard, make sure the solar panel is covered with
an opaque (dark) layer such as paper or cloth duringthe installation.
Do not make contact with the terminals when the panel is exposed to
sunlight or any other light source.
* The temperature can impact the battery’s charging and normal operation. If your place’s tempera-
ture is under32°F, we advice you to use the Sunlike Pro version to achieve better lighting results.
* The solar charge time data is base on 25 degree Celsius ambient temperature with the panel
pointed vertically at the solar radiation. The standard radiation value is 1000W/Sqm.

06 07
Sunlike ECO—IAP
Sunlike ECO—IAP
Important
Release the safety rope
after disconnecting the
wire connectors.
Make sure the color of the
wires match while connecting.
Battery pack
03 Luminous Distribution
1. The LiFePO4-battery-powered Sunlike ECO—IAP lights are visiblybrighter
than other outdoor solar lights, and theirperformance overall is
more reliable.
2. To charge the battery fully may take up 6 to 12 hours.
3. The rechargeable battery can work continuously for 10 hours at
full power.
4. Output will be reduced to 40% when the battery is below 40% of
its capacity.
5. Battery will stop charging whenthe ambient temperature is below
32°F or above 149°F.
Battery Status is indicated by the red/green indicator on the lighting
fixture as follows:
- Red indicator (Charging)
> Slow red light flashing = Charging
> Red light continuously on = fully charged
> Quick red flashing= charge fault
- Green indicator (not charging)
> Green light continuously on = more than40% of the battery
capacity remaining
> Slow green light flashing =battery capacity below 10%
> Quick green light flashing =battery below 0% mode—Protect
battery does not over discharging
Storage
To avoid over discharge of the battery during storage, please recharge
the lighting fixture every 4 months. Use the dedicated charger to charge,
reset the switch when done.
Battery Replacement
1. Loosen the screws of the
battery pack.
2. Disconnect the wire
connectors.
3. Take out the battery pack.
4. Replace with a new one,
connect the wire connectors.
5. Tighten the screws.
(IAP) Intelligent Adaptive Program Battery
Control Technology
In order to extend the off-grid autonomy of
the Sunlike ECO—IAP under shadytrees, heavy
rain, and thick clouds, our controllers now
integrate an adaptive smart control feature
to actively track battery capacity and adjust
light output accordingly. Before integrating
this feature, selecting a light output percent-
age on the remote would yield an accurate
percentage of max LEDbrightness. Now with
(IAP), the controller actively monitors the
battery and regulates the electrical current
to the LEDs.The controller makes light output
of the selected percentage on the remote
relative to battery capacity rather than max
LED output. This smart-control feature can
increase our off-grid performance by up
to 40%.
01
02
03
04 Battery Notes
20W Type III
30W Type III

08 09
05 Installation and WiringCompliance 06 Mounting Accessories
1. Installation and wiringmust comply with the State and National
ElectricalCodes.
2. The Sunlike ECO—IAP 20W/30W model is intended for outdoor use
only and should not be installed in an unventilated area, and shall be
installed inan environment within the operational temperatures
defined for the product.
3. The average sunshine in the installation area should be above
3.5 hours/day inorder to ensure fullfunction of the lighting fixture.
Avoid areas with shades.
4. Before installation, if applicable, please ensure the light pole and its
foundation are solid enough to withstand the lighting fixture(s).
5. Before installation, please ensure that the battery is fully charged.Install
during sunny days if possible.
6. Before installation, please press the ON/OFF key inthe remote
control and check whether it shows a red light on the indicator.
Please cover the panel and check if the light module turns onnormally
within 1 minute.
After Installation
The lighting fixture will automatically turn on at night and turn off
during daylight.
Important
Always orient the solar panel facing the equator (e.g. facing south if in
northern hemisphere).
Always have a tilt angle of at least 15° to avoid dust accumulation
(0°=horizontal plane).
A. TRUNNION—Wall Mount
B. TRUNNION—Round
C. TRUNNION—Square
D. SLIPFITTER—Rotative AND STRAIGHT ARM
3.9 inch
6.7 inch
0.4 in
0.9 in
0.4 in
3.9 inch
6.7 inch
0.4 in
0.9 in
0.4 in
3.9 inch
6.7 inch
0.4 in
0.9 in
0.4 in
A-b. TLSTC-WM-20W/30W (for Sunlike ECO—IAP 20W/30W)
B-b. TLSTC-TRR-20W/30W (for Sunlike ECO—IAP 20W/30W)
works with 2.0 inch to 4.7 inch poles.
C-b. TLSTC-TRS-20W/30W (for Sunlike ECO—IAP 20W/30W)
works with 2.0 inch to 4.0 inch poles.
Pole Size For Slip Fitter And Straight Arm
Pole Size
1.8 in
2.0 in
2.4 in
4.0 in
Pole Size
2.0 in4.7 in
Ordering Information Chart
Sample Number: TLSTC020XYYZZ
For example: TLSTC0203TRSGY
This means the customer wants a Sunlike ECO—IAP 20 watt, 3000k tempera--
ture, wall mount installation, with a gray finish.
DO NOT send the sample numberdirectly to our salers. Use the
information inthe chart above to create amodel numberwith
the correct series, wattage, temperature, mounting option, and finish
for the product that you want.
SeriesWattage Color
Temperature
Mounting
OptionsFinish
TLSTC=Sunlike 020=20W 4000 Lumens
030=30W 6000 Lumens
X=3=3000K
X=4=4000K
X=5=5000K
X=6=5700K
YY=WM=Wall Mount
YY=TRR=Trunnion Round
YY=TRS=Trunnion Square
YY=SF=Slip Fitter
YY=SA=Straight Arm
ZZ=GY=Gray
ZZ=BZ=Bronze

010 011
05
04
Square Trunnion
07 Installation
Trunnion Mount
01
02
03
B. On Round Pole
A. On Wall
C. On Square Pole
E. On Round Tapered Pole—Straight Arm
Slip Fitter and Straight Arm
D. On Round Tapered Pole—Slip Fitter
01
03
02
04
Straight Arm
01
02
03 04
05
06
Slip Fitter
05
04
Round Trunnion
04
Wall Mount

012 013
Alaska
25° N
0°– 13°
13°– 26°
26°– 37°
37°– 45°
19° N
21° N
26° N
20° N
27° N
28° N
29° N
30° N
31° N
32° N
23° N
34° N
35° N
36° N
37° N
38° N
39° N
40° N
41° N
42° N
43° N
44° N
45° N
46° N
47° N
48° N
60° N
49° N
Washington
Oregon
California
Nevada
Arizona
Utah
New Mexico
Kansas
Colorado
Oklahoma
Texas
North Dakota
South Dakota
Nebraska
Idaho
Montana
Wyoming
61° N
62° N
63° N
64° N
65° N
70° N
66° N
67° N
68° N
69° N
Hawaii
The Solar charge in a battery pack won’t last forever, the off–grid
system relies on stored daylight for autonomy. Angling your solar
panels properly can boost the power intake of your lights. You want
to angle your solar panels at a tilt equal to the area’s latitude.
Tip
You can increase the tilt 15° in the winter or decrease 15° in the summer.
In this way you can get the maximum sunlight to recharge the battrey bank.
Strong sunlight Nromal sunlight Less sunlight
Key
The area will dictate the installation of the fixtures and will sometimes
prevent the lights from facing south. But that’s okay! Panels facing West
& East won’t get as much light as a Southern facing panels but will still
collect a good amount of sunlight. A North–facing panel also works, but
it will take longer to charge than any other direction. This would mean that
the solar charge will be less optimal if installations are facing that way.
0°– 13°
13°– 26°
13°– 26°
37°– 45°
45°
37°– 45°
Arkansas
Louisiana
Mississippi
Alabama Georgia
South
Carolina
North
Carolina
Virginia
West
Virginia
Kentucky
Illinois
Wisconsin
Minnesota
Iowa
Missouri
Michigan
Indiana
Ohio
Pennsylvania
New York
Massachusetts
Rhode Island
Connecticut
New Jersey
Delaware
Maryland
Tennessee
Florida
World Wide Panel Angles
Best Facing Direction of Solar Panel
Best
Work
OKOK
New Hampshire
Vermont Maine
26°– 37°
26°– 37°
09 Panel Angle

014015
09 Remote Control Guide
1. On/Off 2. Connect/Test
4. 20%~80% Motion
Sensor Mode (Default)
6. EarlyBird Mode
8. 70% Constant Mode
10. Timer Mode Disabled
12. Time Mode 8 Hours
3. 40%~100% Motion
SensorMode
5. Night Owl Mode
7. 100% Constant Mode
9. 40% Constant Mode
11. Timer Mode 4Hours
1. On/Off
When off is selected, the light will stop working. Solar panel will not
charge the battery and the battery will not supply electricity to the light.
2. Connect/Test
Remote control device can be connected with any lightingfixture, one
at a time. To connect, press the button once. It alsofunctions as a test
button. To test, press the “Test” button once, the red light will indicate
the fixture is charging, green light indicates that the fixture is operating.
Testinglasts for 10 seconds, thengoes back to the mode previously
in use.
When using the remote for the first time, please remove the plastic
piece at the bottom to make the remote turn on.
3. 40%~100% Motion Sensor Mode
Constant 40% brightness (turn on at dusk, turnoff at dawn);
100% brightness turns on for 30 seconds whenmotiondetected.
4. 20%~80% Motion Sensor Mode (Default)
Constant 20% brightness (turn on at dusk, turnoff at dawn);
80% brightness turns on for 30seconds when motion detected.
5. Night Owl Mode
Changes as natural light decreases/increases (turnon at dusk); 70%
brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness
for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours (turn
off at Dawn).
6. Early Bird Mode
Changes as natural light decreases/increases with increased brightness
near dawn for early risers (turnon at dusk); 70% brightness for 0.5
hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50%
brightness for 1 hour, 20% brightness for 4 hours, 100% brightness
for 1 hour (turn off at Dawn).
Important
Dust and dawn time may be diffrent in other locations and seasons.
The sensors of our products will follow the light patterns of where it is
installed. The time period shown inthe chart above is just an example
to help you understand the different lighting modes only.
(IAP)Intelligent Adaptive Program Battery Control Technology
In order to extend the off-grid autonomy of the Sunlike ECO—IAP under
shady trees, heavy rain, and thick clouds, our controllers now
integrate an adaptive smart control feature to actively track battery
capacity and adjust light output accordingly. Before integrating this
feature, selecting a light output percentage onthe remote would yield
an accurate percentage of max LED brightness. Now with (IAP), the
controller actively monitors the battery and regulates the electrical
current to the LEDs. The controller makes light output of the selected
percentage on the remote relative to battery capacity rather than
max LED output. This smart-control feature can increase our off-grid
performance by up to 40%.
16ft–33ft
The range of the remote control to the
indicator is 16ft (Day time) to 33ft (Night
time). Because the sunlight will impact
the signal of the remote control, we suggest
our users to setup the mode before they
install the light.
30 sec
30 sec
30 sec

016 017
09 Remote Control Guide
8. 70% Constant Mode
70% brightness from dusk to dawn.
9. 40% Constant Mode
40% brightness from dusk to dawn.
10. Timer Mode Disabled
Press this button to turn off Timer Mode; settings go back to before
Timer Mode was last activated.
7. 100% Constant Mode
100% brightness from dusk to dawn.
11. Timer Mode 4 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70%
Constant Mode, if the light turns on at 7pm at dusk, it will turn off at
11pm. It will repeat the same schedule hereafter until it is canceled
by pressing Timer Disabled.
12. Time Mode 8 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70% Con-
stant Mode, if the light turns on at 7pm at dusk, it will turn off at 3am. It
will repeat the same schedule hereafter until it is canceled by pressing
Timer Disabled.
Important
Dust and dawn time may be diffrent in other locations and seasons.
The sensors of our products will follow the light patterns of where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes only.

018019
Sunlike products are covered by a 3 year limited warranty.
Sunlike urban light warrants to the originalpurchaser that
this product is free from defects in materialsand work-
manship for the period of3 years from date of purchase. To
obtain warranty service please contact your local distributor
or sales rep for further instruction.
SOLTECH LLC reserves the right to update all
product data sheets at any time.Consult SOLTECH
marketing specialists for publication updates at
[e-mail]
Copyright©2020–2021 SOLTECH LLC,
All Rights Reserved.
1460 Park Avenue.
Emeryville CA 94608 USA
www.soltechlighting.com

020
SOLTECH offers
Eco-friendly
technology to help
users benefit
clean energy.
