Soltech STL-CLF150 Series User manual

INSTALLATION INSTRUCTION MANUAL
LED CANOPY LIGHT,
Rev A JUN 2017
SERIES: TLCLF150XYYZZ; TLCLF150HXYYZZ
1. Introduction

An internal power-factor-corrected switch-mode supply allows it to be used from
any nominal
100V- 277V,277-480V 60Hz AC supply without any variation in light output.
Suitable for use in the following
locations:
• Ambient Temp: -2 0~ +40°C
• Wet Locations
Note: Save these instructions for future reference.
2. Installation
For supply connections use wire rated for at least 100°C.
Installation Steps:
1. Mount throughout the roof
1. Use the existing hole on the roof or open a 4” hole. Seee fig. 1.
2. Put silicon sealant around the hole, let the thread on fixture through out the roof, and use the plate, gasket
and 4 screws to secure the fixture. See fig. 2.
3. One side of the pipe thread on the fixture, the other side insert to the driver box and secured by flange nut.
See fig. 3.
4. Connect the wiring to line wires, black-black, white-white and green-green.
5. Close the cover of the driver box.
Item Model Input Voltage Power Factor Watt Input Current Weight
A TLCLF150XYYZZ 120-277VAC
ш0.9 150W 1.8A Max. 7.0 KG
B TLCLF150HXYYZZ 277-480VAC 150W 0.88A Max. 7.0 KG
Warning:
To avoid the risk of fire, explosion, or electric shock, this product should be installed, inspected, and
maintained by a qualified electrician only, in accordance with all applicable electrical codes.
Warning:
To avoid electric shock:
•Be certain electrical power is OFF before and during installation and maintenance.
•Luminaire must be connected to a wiring system with an equipment-grounding conductor.
Warning:
To avoid explosion:
•Make sure the supply voltage is the same as the rated luminaire voltage.
•Do not install where the marked operating temperatures exceed the ignition temperature of the hazardous
atmosphere.
•Do not operate in ambient temperatures above those indicated on the luminaire nameplate.
Rev B JAN 2019
15.4 LBS
15.4 LBS
STL-CLF150XYYZZ
STL-CLF150HXYYZZ
STL-CLF150XYYZZ; STL-CLF150HXYYZZ
FOR MORE LIGHTING INFO CALL
1460 PARK AVENUE, EMERYVILLE, CA 94608
510.891.1056
[e-mail]
SOLTECHLIGHTING.COM

2. Recessed installation
1. Open a 21”-21.25” squre hole on the roof. See fig. 5.
2. Secure the frame by L shape brackets and screws. See fig. 6.
3. Hang the fixture on the frame by security rope. See fig. 7.
4. Connect the wiring to line wires, black-black, white-white and green-green.
5. Secure the fixture to the frame by 4 screws.
3. Replacement for existing housing
1. Remove all of the electrical components from the fixture housing. See fig. 8.
2. Hang the fixture on a firm part of the housing. Connect the wiring to line wires, black-black, white-white
and green-green.
3. Secure the fixture to the housing by screws.
* Use the other holes on the back of the fixture to replace for different traditional fixtures. See fig.9.
Fig. 1 Fig. 2 Fig. 3
Fig. 5 Fig. 5 Fig. 6 Fig. 7
Fig. 8 Fig. 9
After installation, please
¾check whether the lighting fixture is firmly fixed.
¾check whether wires are connected correctly.
At last, turn on the power, and check if the lighting fixture works well. If not, please turn off the power and contact with
local dealer.
Warning: the luminaire shall be installed by qualified electrician.
