Soltech SunLike 50W User manual

01
SunLike
50W
User Manual
SOLTECH offers Eco-friendly technology
to help users benefit clean energy.

02 03
01 Introduction
02 Specification
03 Luminous Distribution
04 Battery Notes
05 Installation and Wiring Compliance
06 Mounting Accessories
07 Installation
08 Panel Angle
09Remote Control Guide
SunLike 50W
Contents
04
05
06
07
08
09
010
012
014

04 05
01 Introduction
Thank you for purchasing Sunlike 50W Urban Lighting Products.
Introduction
The high-performance Sunlike 50W is a municipal-grade solar outdoor
lighting system that provides bright off-grid light. This heavy-duty com-
mercial dedicated series is ideal for highways, city streets, large parking
lots, and area lighting. It comes in a wide choice of configurations, lighting
outputs, and recommended pole heights. The Sunlike 50W is optimized
to provide years of bright, reliable light. Industry-leading efficiency, dense
batteries, and advanced controls to guarantee the highest possible
off-grid autonomy.
Important
In order to avoid deep discharge of the battery during storage, please
fully recharge your battery every 4 months. Please make sure that the
light is installed in an area with sufficient sunlight irradiance. A strict
minimum of 3.5 hours/day of sunshine on average is recommended. Se-
lect the right operating mode according to the local legislation needs and
the local sunshine conditions. Keep it away from shadows. Self-cleaning
available when the light fixture have minimum angle of 15 degrees.
Please save these instructions. Read all of the instructions carefully
before attempting to carry out any installation or wiring. Do not open or
attempt to repair the product on your own, as it many cause serious
damage and would void the product warranty. Contact your local
distributor for any questions concerning the installation.
Range of the light module on the lighting fixture is 20–26 feet
(6–8 meters). The ideal installation spacing is >16 feet(5 meters). When
installing two or more lighting fixtures on one pole, select desired
operating mode before installation. Interference can cause delay or
malfunction when using the remote control to change operating modes
after installation.
Precautions when working with solar panels
When the solar panel is exposed to sunlight, a voltage appears at the
output terminals of the solar panel turning it into a source of electricity.
To avoid a shock hazard, make sure the solar panel is covered with an
opaque (dark) layer such as paper or cloth during the installation. Do
not make contact with the terminals when the panel is exposed to sunlight
or any other light source.
Sunlike 50W
02 Specification
39.3 inch
7.8 inch 8.7 inch 3.4 inch
26.3 inch
5.59 inch
Designation
Lumileds 5050 (210lm-CR>70)
Remote control and One-key Setting
40%–100% 32hrs
Night Owl 28hrs
100% 13hrs
70% 19hrs
40% 34hrs
20%–80% 55hrs
Early Bird 25hrs
Sunlike 50W
50
18V 115W
691.2WH 12.8V 54AH
58.7 lbs
9000
8.62
IP65
> 70
Aluminum
180 lm/W
11hrs
13hrs
9 to 20ft
-4 °F to 122 °F
32 °F to 149 °F
LED Nominal Power
Solar Panel
LiFePO4Battery
Weight
Lumen Output@5000K
EPA
Waterproof Rate
CRI
Casting
Efficiency@5000K
LED Chip
* Charging Time
Autonomy (@Full Power)
Maximum Autonomy
Motion Sensor Mode
Time Control Mode
Constant Mode
Operation Mode
Installation Height
* Operating Temperature
* Charging Temperature
* The temperature can impact the battery’s charging and normal operation. If your place’s tempera-
ture is under 32°F, we advice you to use the Sunlike Pro version to achieve better lighting results.
* The solar charge time data is base on 25 degree Celsius ambient temperature with the panel
pointed vertically at the solar radiation. The standard radiation value is 1000W/Sqm.

06 07
03 Luminous Distribution
Sunlike 50W Type III 1. The LiFePO4-battery-powered Sunlike lights are visibly brighter
than other outdoor solar lights, and their performance overall is
more reliable.
2. To charge the battery fully may take up 6 to 12 hours.
3. Output will be reduced to 40% when the battery is below 40% of
its capacity.
4. Battery will stop charging when the ambient temperature is below
32°F or above 149°F.
Battery Status is indicated by the red/green indicator on the lighting
fixture as follows:
> Slow red light flashing (Every 2.5s) = Working
> Slow red flashing (Every 5s)= Open circurt
> Red light continuously on = Non-working
> Quick red flashing (Every 0.5s)= Charge fault
> Quick red flashing (Every 0.1s)= Over current or Short circurt
Storage
To avoid over discharge of the battery during storage, please recharge
the lighting fixture every 4 months. Use the dedicated charger to charge,
reset the switch when done.
04 Battery Notes
Battery Replacement
1. Loose the screws of the
solar board and front board,
and remove solar board and
front board.
2. Disconnect all wires of solar
board, LED light and indicator.
3. Loose battery pack screws and
replace the battery pack with a
new one.
4. Tighten the screws of
battery pack.
5. Connect the wire connectors of
LED light and indicator.
6 Install the front board and
solar board.
7. Connect the wire connectors
of solar board.
(Be sure the solar board
wires go out from the back
hole and stay on wire holders
of each side when you
connect them).
Battery pack screws (X4)
Solar board screws (X4)
Front board screws (X4)
Front board
Battery pack
Solar panel
Disconnect wires
(Solar board)
Disconnect wires
(LED light)
Disconnect wires
(Indicator)
Back hole
Wire holder (X2)
Loose the screws of
the solar board and
front board, and
remove solar board
and front board.
Disconnect all
wires of solar
board, LED light
and indicator.
Loose battery pack
screws and replace
the battery pack
with a new one.
01 02 03
(IAP) Intelligent Adaptive Program Battery
Control Technology
In order to extend the off-grid autonomy of
the Sunlike 50W under shady trees, heavy
rain, and thick clouds, our controllers now
integrate an adaptive smart control feature
to actively track battery capacity and adjust
light output accordingly. Before integrating
this feature, selecting a light output percentage
on the remote would yield an accurate
percentage of max LED brightness. Now with
(IAP), the controller actively monitors the
battery and regulates the electrical current
to the LEDs. The controller makes light output
of the selected percentage on the remote
relative to battery capacity rather than max
LED output. This smart-control feature can
increase our off-grid performance by up
to 40%.
ATTENTION
DO NOT recommend replace
battery pack on your own. Please
conntact SOLTECH for any
battery’s questions.

08 09
05 Installation and Wiring Compliance
1. Installation and wiring must comply with the State and National
Electrical Codes.
2. The Sunlike 50W models are intended for outdoor use only
and should not be installed in an unventilated area, and shall be
installed in an environment within the operational temperatures
defined for the product.
3. The average sunshine in the installation area should be above
3.5 hours/day in order to ensure full function of the lighting fixture.
Avoid areas with shades.
4. Before installation, if applicable, please ensure the light pole and its
foundation are solid enough to withstand the lighting fixture(s).
5. Before installation, please ensure that the battery is fully charged. Install
during sunny days if possible.
6. Before installation, please press the ON/OFF key in the remote
control and check whether it shows a red light on the indicator.
Please cover the panel and check if the light module turns on normally
within 1 minute.
After Installation
The lighting fixture will automatically turn on at night and turn off
during daylight.
Important
Always orient the solar panel facing the equator (e.g. facing south if in
northern hemisphere).
Always have a tilt angle of at least 15° to avoid dust accumulation
(0°=horizontal plane).
Ordering Information Chart
Sample Number: TLSTC50XYYZZ
For example: TLSTC503MSGY
This means the customer wants a Sunlike 50 watt, 3000k temperature,
mounting sleeve installation, with a gray finish.
DO NOT send the sample number directly to our sales. Use the
information in the chart above to create a model number with
the correct series, wattage, temperature, mounting option, and finish
for the product that you want.
Series Wattage Color
Temperature
Mounting
Options Finish
TLSTC=Sunlike 50=50W 9000 Lumens X=3=3000K
X=4=4000K
X=5=5000K
X=6=5700K
YY=MS=Mounting Sleeve ZZ=GY=Gray
ZZ=BR=Bronze
06 Mounting Accessories
If your round pole size is over 3.125 inch, or you use square pole, please
connect with pole manufacturer for the tenon adapter.
MOUNTING SLEEVE
POLE ASSEMBLY TENON ADAPTER
MOUNTING SLEEVE—CUTAWAY
Ø2.4 inch–Ø3.125 inch
Ø3.125 inch Ø3.125 inch
Top of Pole—
Round
Tenon Adapter—Round Tenon Adapter—Square
7.2 inch
Pole
3.1 inch
0.37 inch
8.15 inch 5.31 inch 7.08 inch
2.16 inch
3.125 inch

010 011
07 Installation
Sunlike 50W
01
02
03
Mounting Base
Indicator
Mounting Sleeve
±35°
±48°
±35°
±48°
Connect
Please loose the screws to adjust the angle of the light.
±45°
Tenon Adapter—Round Tenon Adapter—Square
If your round pole size is over 3.125 inch, or you use square pole, please
connect with pole manufacturer for the tenon adapter.
TENON ADAPTER
ATTENTION
Be carefull with the solar board when you
put Sunlike 50W on the pole.

012 013
Alaska
25° N
0°– 13°
13°– 26°
26°– 37°
37°– 45°
19° N
21° N
26° N
20° N
27° N
28° N
29° N
30° N
31° N
32° N
23° N
34° N
35° N
36° N
37° N
38° N
39° N
40° N
41° N
42° N
43° N
44° N
45° N
46° N
47° N
48° N
60° N
49° N
Washington
Oregon
California
Nevada
Arizona
Utah
New Mexico
Kansas
Colorado
Oklahoma
Texas
North Dakota
South Dakota
Nebraska
Idaho
Montana
Wyoming
61° N
62° N
63° N
64° N
65° N
70° N
66° N
67° N
68° N
69° N
Hawaii
The Solar charge in a battery pack won’t last forever, the off–grid
system relies on stored daylight for autonomy. Angling your solar
panels properly can boost the power intake of your lights. You want
to angle your solar panels at a tilt equal to the area’s latitude.
Tip
You can increase the tilt 15° in the winter or decrease 15° in the summer.
In this way you can get the maximum sunlight to recharge the battrey bank.
Strong sunlight Nromal sunlight Less sunlight
Key
The area will dictate the installation of the fixtures and will sometimes
prevent the lights from facing south. But that’s okay! Panels facing West
& East won’t get as much light as a Southern facing panels but will still
collect a good amount of sunlight. A North–facing panel also works, but
it will take longer to charge than any other direction. This would mean that
the solar charge will be less optimal if installations are facing that way.
0°– 13°
13°– 26°
13°– 26°
37°– 45°
45°
37°– 45°
Arkansas
Louisiana
Mississippi
Alabama Georgia
South
Carolina
North
Carolina
Virginia
West
Virginia
Kentucky
Illinois
Wisconsin
Minnesota
Iowa
Missouri
Michigan
Indiana
Ohio
Pennsylvania
New York Massachusetts
Rhode Island
Connecticut
New Jersey
Delaware
Maryland
Tennessee
Florida
World Wide Panel Angles
Best Facing Direction of Solar Panel
Best
Work
OKOK
New Hampshire
Vermont Maine
26°– 37°
26°– 37°
08 Panel Angle

014 015
09 Remote Control Guide
1. On/Off 2. Connect/Test
4. 20%~80% Motion
Sensor Mode (Default)
6. Early Bird Mode
8. 70% Constant Mode
10. Timer Mode Disabled
12. Time Mode 8 Hours
3. 40%~100% Motion
Sensor Mode
5. Night Owl Mode
7. 100% Constant Mode
9. 40% Constant Mode
11. Timer Mode 4 Hours
1. On/Off
When off is selected, the light will stop working. Solar panel will not
charge the battery and the battery will not supply electricity to the light.
2. Connect/Test
Remote control device can be connected with any lighting fixture, one
at a time. To connect, press the button once. It also functions as a test
button. To test, press the “Test” button once, the red light will indicate
the fixture is charging, green light indicates that the fixture is operating.
Testing lasts for 10 seconds, then goes back to the mode previously
in use.
When using the remote for the first time, please remove the plastic
piece at the bottom to make the remote turn on.
The range of the remote control to the
indicator is 19ft (Day time) to 26ft (Night
time). Because the sunlight will impact
the signal of the remote control, we suggest
our users to setup the mode before they
install the light.
3. 40%~100% Motion Sensor Mode
Constant 40% brightness (turn on at dusk, turn off at dawn);
100% brightness turns on for 2 minutes when motion detected.
4. 20%~80% Motion Sensor Mode (Default)
Constant 20% brightness (turn on at dusk, turn off at dawn);
80% brightness turns on for 2 minutes when motion detected.
5. Night Owl Mode
Changes as natural light decreases/increases (turn on at dusk); 70%
brightness for 0.5 hour, 100% brightness for 3.5 hours, 70% brightness
for 1 hour, 50% brightness for 1 hour, 20% brightness for 5 hours (turn
off at Dawn).
6. Early Bird Mode
Changes as natural light decreases/increases with increased brightness
near dawn for early risers (turn on at dusk); 70% brightness for 0.5
hour, 100% brightness for 3.5 hours, 70% brightness for 1 hour, 50%
brightness for 1 hour, 20% brightness for 4 hours, 100% brightness
for 1 hour (turn off at Dawn).
Important
Dust and dawn time may be diffrent in other locations and seasons.
The sensors of our products will follow the light patterns of where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes only.
(IAP) Intelligent Adaptive Program Battery Control Technology
In order to extend the off-grid autonomy of the Sunlike 50W under
shady trees, heavy rain, and thick clouds, our controllers now
integrate an adaptive smart control feature to actively track battery
capacity and adjust light output accordingly. Before integrating this
feature, selecting a light output percentage on the remote would yield
an accurate percentage of max LED brightness. Now with (IAP), the
controller actively monitors the battery and regulates the electrical
current to the LEDs. The controller makes light output of the selected
percentage on the remote relative to battery capacity rather than
max LED output. This smart-control feature can increase our off-grid
performance by up to 40%.
19ft–26ft

016 017
09 Remote Control Guide
8. 70% Constant Mode
70% brightness from dusk to dawn.
9. 40% Constant Mode
40% brightness from dusk to dawn.
10. Timer Mode Disabled
Press this button to turn off Timer Mode; settings go back to before
Timer Mode was last activated.
7. 100% Constant Mode
100% brightness from dusk to dawn.
11. Timer Mode 4 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70%
Constant Mode, if the light turns on at 7pm at dusk, it will turn off at
11pm. It will repeat the same schedule hereafter until it is canceled
by pressing Timer Disabled.
12. Time Mode 8 Hours
This is an additional mode which can work with any other modes.
For example: press this button at any time after you turn on 70% Con-
stant Mode, if the light turns on at 7pm at dusk, it will turn off at 3am. It
will repeat the same schedule hereafter until it is canceled by pressing
Timer Disabled.
Important
Dust and dawn time may be diffrent in other locations and seasons.
The sensors of our products will follow the light patterns of where it is
installed. The time period shown in the chart above is just an example
to help you understand the different lighting modes only.

018 019
SOLTECH LLC reserves the right to update all
product data sheets at any time. Consult SOLTECH
marketing specialists for publication updates at
Copyright©2019–2020 SOLTECH LLC,
All Rights Reserved.
Sunlike 50W is covered by a 5 year limited warranty. Sunlike
50W urban light warrants to the original purchaser that
this product is free from defects in materials and work-
manship for the period of 5 years from date of purchase. To
obtain warranty service please contact your local distributor
or sales rep for further instruction.
1460 Park Avenue.
Emeryville CA 94608 USA
www.soltechlighting.com

020
SOLTECH offers
Eco-friendly
technology to help
users benefit
clean energy.
This manual suits for next models
1
Table of contents
Other Soltech Outdoor Light manuals

Soltech
Soltech VIOS User manual

Soltech
Soltech SATELIS STLSTD505SFGY30 User manual

Soltech
Soltech CEGONIA 8W User manual

Soltech
Soltech CEGONIA PRO 30W User manual

Soltech
Soltech BROADWAY 10W User manual

Soltech
Soltech SATELIS PRO 50W User manual

Soltech
Soltech SunLike ECO-IAP 30W User manual

Soltech
Soltech STL-CLF150 Series User manual
Popular Outdoor Light manuals by other brands

Clas Ohlson
Clas Ohlson ZK-6022 instruction manual

LED's light
LED's light 1000434 instruction manual

Light Efficient Design
Light Efficient Design RemPhos RP-SPT-20W-40K-SF-G1 user manual

Quoizel
Quoizel Reece RCE8407EK installation guide

SEBSON
SEBSON MIRROR BL 5W user manual

Quoizel
Quoizel T0272 Assembly and installation instructions
