MODEL
ET-PFD565
FRAME-EVO-P20 / P20-US
Mounting frame for projectors
The following projectors can be mounted in this frame:
3 Chip DLP
PT-DZ21KU
PT-DZ21K2U
PT-DZ16KU
PT-DZ16K2U
PT-DS20KU
PT-DW17KU
PT-DW17K2U
PT-RQ13KU
PT-RQ22KU
PT-RZ12KU
PT-RZ21KU
PT-RS11KU
PT-RS20KU
These installation instructions must always be provided to the customer

Manual FRAME-EVO-P20 / P20-US
Version 1.6
10.01.2019
Page 1of 39

Manual FRAME-EVO-P20 / P20-US
Version 1.6
10.01.2019
Page 2of 39
Table of content
1. Preamble.................................................................................................... 3
1.1 FRAME-EVO-P20 / P20-US designation......................................................................................... 3
1.2 Optional accessory designation..................................................................................................... 4
1.3 Tools required ............................................................................................................................... 5
2. Safety instructions...................................................................................... 6
3. What’s in the box? ....................................................................................11
4. Optional Accessories .................................................................................12
5. Fitting the projectors in the frame ............................................................15
6. Removing the Upper Ring - Installation Version ........................................17
7. Reinstalling the Upper Ring .......................................................................20
8. Adjustment options...................................................................................22
9. Stacking frames ........................................................................................24
10. Mounting the frame on a truss ................................................................25
11. Maximum stacking information...............................................................27
12. System maintenance and inspection (Re-examination) ...........................33
13. Declaration of Conformity .......................................................................36
14. Dimensions..............................................................................................37
14.1 FRAME-EVO-P20 / P20-US......................................................................................................... 37
14.2 FRAME-EVO-P20 / P20-US Installation Version - without the Upper Ring................................ 38
Imprint..........................................................................................................39

Manual FRAME-EVO-P20 / P20-US
Version 1.6
10.01.2019
Page 3of 39
1. Preamble
Congratulations on your purchase of the FRAME-EVO-P20 / P20-US projector frame from LANG AG.
Please read very carefully the instructions provided in this manual. In the following pages you will
find all the information needed for a safe and fast installation.
After the installation is done properly, you can enjoy all the features of your new product.
Please consider keeping the original box and packaging materials, in case you ever need to ship the
frame.
Model number: FRAME-EVO-P20 / P20-US
1.1 FRAME-EVO-P20 / P20-US designation
European market
Non-European market
Manufacturer m.no.: FRAME-EVO-P20
Panasonic EU m.no.: ET-RFD60
Manufacturer m.no.: FRAME-EVO-P20-US
Panasonic USA m.no.: ET-PFD565
m.no. = model number
Note: In this manual, when reference is made to the manufacturer model number it is also
automatically a reference to the Panasonic EU / USA model number like described in the
table above

Manual FRAME-EVO-P20 / P20-US
Version 1.6
10.01.2019
Page 4of 39
1.2 Optional accessory designation
European market
Non-European market
Manufacturer m.no.: FRAME-PF-UNI-PORAD
Panasonic EU m.no.: ET-CLP-P
Manufacturer m.no.: FRAME-PF-UNI-PORAD
Panasonic USA m.no.: - (non-USA product)
Manufacturer m.no.: FRAME-PF-UNI-CLP5030
Panasonic EU m.no.: ET-CLP50
Manufacturer m.no.: FRAME-PF-UNI-CLP5030
Panasonic USA m.no.: ET-PFD50CLAMP
Manufacturer m.no.: FRAME-PF-UNI-CLP30PT
Panasonic EU m.no.: ET-CLP30
Manufacturer m.no.: FRAME-PF-UNI-CLP30PT
Panasonic USA m.no.: ET-PFD30CLAMP
Manufacturer m.no.: TH-SHORT-150-8
Panasonic EU m.no.: ET-SHT150
Manufacturer m.no.: TH-SHORT-150-8
Panasonic USA m.no.: ET-PFD550TMS2
Manufacturer m.no.: TH-SHORT-350-8/10
Panasonic EU m.no.: ET-SHT350
Manufacturer m.no.: TH-SHORT-350-8/10
Panasonic USA m.no.: ET-PFD750TMS2
m.no. = model number
Note: In this manual, when reference is made to the manufacturer model number it is also
automatically a reference to the Panasonic EU / USA model number like described in the
table above
