Sonic miniBTE Charm Assembly instructions

Fitting GuideFitting Guide
hearing
hearing
Always
easy-going
135455_CH_Fitting_Guide_UK.indd 1 07.08.13 16:24

135455_CH_Fitting_Guide_UK.indd 2 07.08.13 16:24

Sonic · Charm Always easy-going 3
Table of Contents
Introduction
Charm BTE Overview 4
Charm miniBTE Overview 5
Charm Custom Instruments Overview 6
Acoustic Performance 8
Fitting ranges 8
Charm BTE and miniBTE Hearing Instruments 9
Acoustic options 9
Thin Tube lengths 9
Determining the proper Thin Tube length 9
Installing right and left instrument markers on Charm BTE 10
Installing right and left instrument markers on Charm miniBTE 10
Attaching and removing the Earhook or Thin Tube Adapter 11
Attaching and removing the Thin Tube 12
Changing Thin Tube Domes 12
Charm BTE DAI 13
Attaching the DAI Boot – miniBTE 14
Removing the DAI Boot – miniBTE 14
Charm Custom Hearing Instruments 15
Replacing the ProWax 15
Replacing the microphone protection cap 16
Fitting a Charm IIC 18
Programming Charm with EXPRESSfit 20
Attaching programming cables 20
Programming Charm Using the EXPRESSfit Fitting Software 22
Ordering Information 30
This document introduces you to the Charm hearing instrument family.
Here you will find step-by-step instructions on everything from
exchanging the Thin Tubes and Earhooks, to fine-tuning adjustments
in the EXPRESSfit fitting software. For additional information,
please contact your local Sonic Customer Care Representative.
135455_CH_Fitting_Guide_UK.indd 3 07.08.13 16:24

4 Sonic · Charm Always easy-going
BL_ILLU_BTE_WithThinTube_BW_HI
1
Charm BTE
Overview
Earhook and Earmold
1 Front microphone
2 Thin Tube Adapter
3 Rear microphone
4 Thin Tube
5 Program Button
6 Battery door grip
7 Battery door
8 Sound outlet
9 Dome
10 Volume Control
11 Retention lock
12 DAI Port
5
6
11
9
4
2
1 Front microphone
2 Earhook
3 Rear microphone
4 Program Button
5 Earmold tubing
6 Battery door grip
7 Battery door
8 Volume Control
9 Earmold
10 DAI Port
BL_ILLU_BTE_WithEarhookAndEarmold_BW_HI
2
7
1
4
9
2
5
Thin Tube and Dome
12
3
3
1
8
10
6
8
7
10
135455_CH_Fitting_Guide_UK.indd 4 07.08.13 16:24

Sonic · Charm Always easy-going 5
Charm miniBTE
Overview
BL_ILLU_miniBTE_WithSpeaker_BW_HI
1
Earhook and Earmold
1 Front microphone
2 Thin Tube Adapter
3 Rear microphone
4 Thin Tube
5 Battery door
6 Sound outlet
7 Program Button
8 Dome
9 Tamper-resistant lock
10 Retention lock
11 DAI Port
3
7
10
6
8
5
4
2
1 Front microphone
2 Earhook
3 Rear microphone
4 Earmold tubing
5 Battery door
6 Program Button
7 Tamper-resistant lock
8 Earmold
9 DAI Port
BL_ILLU_miniBTE_WithEarhookAndEarmold_BW_HI
2
7
3
6
8
5
2
4
Thin Tube and Dome
9
1
1
11
9
135455_CH_Fitting_Guide_UK.indd 5 07.08.13 16:24

6 Sonic · Charm Always easy-going
BL_ILLU_ITIPDW_BW
11
Charm Custom Instruments
Overview
1 Sound outlet with wax protection
2 Canal
3 Microphone openings
with O-Cap filter
4 Battery door
5 Air vent
6 Program Button
BL_ILLU_ITCPDW_BW
9
1 Sound outlet with wax protection
2 Canal
3 Program Button
4 Battery door
5 Microphone openings
with O-Cap filter
6 Air vent
3
4
5 6
3
2
1
4
5
6
3
5
2
1
ITEPDW (Charm 60 only) and ITED
ITCPDW (Charm 60 only) and ITCD
Note! Charm ITEPDW and ITED can be built
with an optional Program Button. Charm ITED
can be built with an optional Volume Control.
Note! Charm ITCPDW and ITCD can be built
with an optional Program Button. Charm ITCD
can be built with an optional Volume Control.
135455_CH_Fitting_Guide_UK.indd 6 07.08.13 16:24

Sonic · Charm Always easy-going 7
CICP and CIC
IIC (Charm 60 only)
1 Sound outlet with wax protection
2 Microphone opening
with T-Cap filter
3 Canal
4 Battery door
5 Removal cord
6 Air vent
AR_ILLU_IIC_BW
5
2
4
5
1
3
6
Note! Charm CICP can be built with an optional
Program Button.
1 Sound outlet with wax protection
2 Microphone opening
with T-Cap filter
3 Canal
4 Battery door
5 Removal cord
6 Air vent
3BL_ILLU_CIC_BW
2
4
5
1
3
6
135455_CH_Fitting_Guide_UK.indd 7 07.08.13 16:24

8 Sonic · Charm Always easy-going
Acoustic Performance
Fitting ranges
The fitting ranges below will help you select the appropriate hearing instrument model and acoustic configuration
for your patient’s specific hearing needs.
Hearing Level in decibels (dB)
Fitting Range ITCPDW
Frequency in Hertz (Hz)
500 250 125 750
1000 1500 2000 3000 4000
6000
8000
0
10
20
30
40
50
60
70
80
90
100
110
120
Fitting Range BTE | miniBTE
Frequency in Hertz (Hz)
Hearing Level in decibels (dB)Hearing Level in decibels (dB)
Fitting Range ITED | ITCD
Frequency in Hertz (Hz)
Hearing Level in decibels (dB)
Fitting Range CIC | IIC
Frequency in Hertz (Hz)
Hearing Level in decibels (dB)
Fitting Range CICP
Frequency in Hertz (Hz)
Hearing Level in decibels (dB)
Fitting Range ITEPDW
Frequency in Hertz (Hz)
135455_CH_Fitting_Guide_UK.indd 8 07.08.13 16:24

Sonic · Charm Always easy-going 9
Charm BTE and miniBTE
Hearing Instruments
Acoustic options
All Charm BTE and miniBTE instruments are available with either a conventional Earhook or Thin Tube
with Adapter and Dome system.
Available Acoustic Options Custom
Fit
Conventional
Earhook
Thin Tube
Adapter
Thin Tube
0.9 mm
Thin Tube
1.3 mm
Thin Tube
Domes
6 mm
(XS)
8 mm
(S)
10 mm
(M)
12 mm
(L)
Various
Custom
Molds
available
Open Dome ●●●
Tulip Dome ●
Dome,
Large Vent ●●●
Dome,
Small Vent ●●●
Power
Dome ●●●
Thin Tube lengths
To ensure a secure fitting with maximum patient comfort, the proper
Thin Tube length should be selected for each patient before fitting a
Charm BTE or miniBTE. Sonic Thin Tubes come in four different lengths,
and a red (Right) or blue (Left) marker on the Thin Tube identifies
the orientation.
Length Size Code
XShort 0
Short 1
Medium 2
Long 3
Determining the proper Thin Tube length
To determine which Thin Tube length is most appropriate for your patient,
use the fitting tool from your Sonic BTE Dispensing Kit.
Note! Right and left markings on the fitting tool indicate which
hand to use and which ear to measure. Four sightlines (0-1-2-3)
indicate the proper tubing length, according to the table above.
0
1
2
3
4
0
1
2
3
890-21-222-00
BL_ILLU_BTE_ThinTubeAdapter_BW_HI
11
135455_CH_Fitting_Guide_UK.indd 9 07.08.13 16:24

10 Sonic · Charm Always easy-going
Installing right and left instrument markers
on Charm miniBTE
1 Locate the space on the back of the instrument which shows
the receptacle for the right and left marker.
2 Insert the end of the red (Right) or blue (Left) marker into
the slot until it firmly fits as shown.
3 Twist and break off the long post of the marker tool, ensuring
that the marker remains in the instrument’s opening.
Installing right and left instrument markers
on Charm BTE
1 Locate the space inside the battery
compartment which shows the receptacle
for the right and left marker.
2 Line up the end of the red (Right) or blue (Left)
marker and slide the tip into the slot until it firmly
fits as shown.
3 Twist and break off the long post of the marker tool,
ensuring that the marker remains in position.
BL_ILLU_BTE_Insert_Left_Right_Marking3_CMYK_Hi
13.3
3
BL_ILLU_BTE_Insert_Left_Right_Marking4_CMYK_Hi
13.4
4
BL_ILLU_BTE_Insert_Left_Right_Marking1_CMYK_Hi
13.1
1
BL_ILLU_BTE_Insert_Left_Right_Marking2_CMYK_Hi
13.2
2
BL_ILLU_miniBTE_Insert_Left_Right_Marking1_CMYK_Hi
1
BL_ILLU_miniBTE_Insert_Left_Right_Marking2_CMYK_Hi
2
2
3
135455_CH_Fitting_Guide_UK.indd 10 07.08.13 16:24

Sonic · Charm Always easy-going 11
Attaching and removing the Earhook
or Thin Tube Adapter
1 Remove the Earhook or Thin Tube Adapter from the hearing instrument
by unscrewing it (counter-clockwise).
2 Replace the Earhook or Thin Tube Adapter with the desired part.
3 To attach either the Earhook or Thin Tube Adapter, screw it (clockwise)
onto the hearing instrument.
BL_ILLU_miniBTE_Removing_ThinTube_Adapter_BW_Hi
5
BL_ILLU_miniBTE_Removing_Earhook _BW_Hi
3
BL_ILLU_miniBTE_Attaching_Earhook _BW_Hi
4
Note! Be careful not to over-rotate (more than 3 full rotations)
the Earhook or Thin Tube Adapter. The BTE Thin Tube Adapter
may have a small space between it and the casing, so do not
over-rotate.
1
3
1
3
BL_ILLU_miniBTE_Attaching_ThinTube_Adapter_BW_Hi
6
135455_CH_Fitting_Guide_UK.indd 11 07.08.13 16:24

12 Sonic · Charm Always easy-going
Attaching and removing the Thin Tube
If the Thin Tube becomes discolored, stiff or brittle, it should be replaced.
1 Pull firmly to remove the old Thin Tube.
2 Hold the instrument by the Thin Tube Adapter and grasp the Thin Tube
close to the threaded connector.
3 Attach the new Thin Tube by pushing it firmly into the Thin Tube Adapter.
Changing Thin Tube Domes
The soft Domes are a disposable part. The patient should be supplied
with spare Domes and shown how to change them.
1 Pull the used Dome off the Thin Tube and discard.
2 With clean hands, firmly push a new Dome onto the Thin Tube
as far as it will go.
Note! If the Dome is not pushed all the way onto the Thin Tube,
it could fall off into the ear canal.
BL_ILLU_miniBTE_ExchangeThinTube_BW_HI
14
1
2
135455_CH_Fitting_Guide_UK.indd 12 07.08.13 16:24

Sonic · Charm Always easy-going 13
Charm BTE DAI
1 Locate the DAI pins at the bottom of the hearing instrument.
2 Insert the DAI/Euro Plug or FM Receiver of the assistive
listening device into this area.
BL_ILLU_BTE_AttachingDAIBoot_BW_HI
9
BL_ILLU_BTE_AttachingDAIBoot2_BW_HI
15
BL_ILLU_BTE_AttachingDAIBoot3_BW_HI
16
1 2 2
135455_CH_Fitting_Guide_UK.indd 13 07.08.13 16:24

14 Sonic · Charm Always easy-going
Removing the DAI Boot – miniBTE
1 Pull the DAI/Euro Plug or FM Receiver out of the DAI Boot.
2 Grasp the DAI Boot as shown. Pull the miniBTE up and out of the Boot
with your other hand. A slight twisting motion will help free the DAI Boot
from the miniBTE.
BL_ILLU_miniBTE_RemoveDAIBoot_BW_HI
13
Attaching the DAI Boot – miniBTE
1 Slip the DAI Boot over the miniBTE.
When it is fully seated you will feel it click into place.
2 Insert the DAI/Euro Plug or FM Receiver of the assistive
listening device into the DAI Boot.
BL_ILLU_miniBTE_AttachingDAIBoot1_BW_HI
12.1
135455_CH_Fitting_Guide_UK.indd 14 07.08.13 16:24

Sonic · Charm Always easy-going 15
Replacing the ProWax
All Charm custom models are supplied with the ProWax system.
1 Take a new removal tool from the package.
2 Insert the removal prong of the tool into the instrument’s existing
ProWax and extract the old ProWax.
3 Insert the new ProWax into the instrument and pull out the removal tool.
4 Discard the removal tool and old ProWax.
1 2 3
Note! Charm custom instruments must be used with the ProWax
system. Using other wax protection systems could damage
the instrument.
Charm Custom
Hearing Instruments
135455_CH_Fitting_Guide_UK.indd 15 07.08.13 16:24

16 Sonic · Charm Always easy-going
Replacing the microphone protection cap
All Charm custom models are supplied with either the T-Cap or O-Cap
for microphone protection.
O-Cap filter for ITCD, ITCPDW, ITED, and ITEPDW
The tool has two ends, one for removal of the O-Cap (A) and
one with the new O-Cap attached (B).
1 Using the removal end (A), insert it into the opening of the used O-Cap
and pull it out slowly. Keep the stick straight.
2 Using the other end of the tool (B), insert the new O-Cap into
the opening and gently remove the stick.
3 Discard the tool and the used O-Cap filter.
BL_ILLU_miniBTE_O_Cap2_BW_Hi
12
A
BL_ILLU_miniBTE_O_Cap3_BW_Hi
13
A
BL_ILLU_miniBTE_O_Cap4_BW_Hi
14
B
1
2
1
BL_ILLU_miniBTE_O_Cap1_BW_Hi
11
AB
135455_CH_Fitting_Guide_UK.indd 16 07.08.13 16:24

Sonic · Charm Always easy-going 17
T-Cap filter for IIC, CIC, and CICP
The tool has two ends, one for removal of the T-Cap (A) and
one with the new T-Cap attached (B).
1 Using the removal end (A), place it under the T-Cap edge,
and push it under the top edge of the used T-Cap.
2 Lift the used T-Cap up and out.
3 Using the other end of the tool (B), insert the new T-Cap into
the opening and slightly twist the handle so that the new T-Cap is free.
4 Discard the tool and the used T-Cap filter.
BL_ILLU_miniBTE_T_Cap1_BW_Hi
7
A
B
BL_ILLU_miniBTE_TCap2_BW_Hi
8
A
BL_ILLU_miniBTE_T_Cap3_BW_Hi
9
A
BL_ILLU_miniBTE_T_Cap4_BW_Hi
10
B
1 2
3
135455_CH_Fitting_Guide_UK.indd 17 07.08.13 16:24

18 Sonic · Charm Always easy-going
Fitting a Charm IIC
The IIC hearing instrument is designed to sit deep in the canal after
the first bend. Candidacy depends on the patient’s ear canal anatomy.
In order to determine if an IIC is possible for your patient, follow
the fitting guidelines and illustrations below.
Impression evaluation
The candidacy evaluation for an IIC hearing instrument requires a quality
ear impression that extends beyond the second bend of the ear canal.
The size and fit of the IIC is determined by the ear impression. Use the ear
impression tool to determine if the size and shape of the ear canal are
appropriate for an IIC.
The IIC hearing instrument can be built with the microphone on the side (A)
or on the top (B) of the faceplate. The ear impression tool can be used
to determine which configuration is most suitable for the given ear
impression.
Using the ear impression tool
1 Canal length
The length of the canal determines if there is enough room between the tip
of the instrument and the faceplate. To determine if the canal length is
sufficient, use the red line and measure from the tip of the ear impression
to the first (1) bend. In order to make the IIC invisible, the edge of the tool
should not reach the first bend.
≤a
12
Not ok
≤a
12
Ok
2
1
c
a
b
≤b
≤c
≤a
A
2
1
b
c
a
≤a
≤b
≤c
B
135455_CH_Fitting_Guide_UK.indd 18 07.08.13 16:24

Sonic · Charm Always easy-going 19
2 Canal height
The height of the canal determines if there is enough space for the IIC
to pass through the canal to the final ear canal placement. The height
of the ear impression measured at a point between the first (1) and
second (2) bends must be larger than the pink line on the ear impression
tool.
≤b
1
2Not ok
≤b
1
2Ok
≤c
≤c
Not ok
≤c
1
Ok
Canal widens
after 2nd bend
Canal too narrow then bells out
Not ok
C
3 Canal width
The width of the canal determines if the faceplate will fit past the first
bend. The width of the ear impression measured at a point after the first (1)
bend must be greater than the grey line on the ear impression tool.
The canal should be wider than the notch and not fit within the notch.
4 Canal shape
It is important to visually inspect the ear impression for proper canal
shape. An ear canal that widens at the end is not suitable for an IIC (C).
135455_CH_Fitting_Guide_UK.indd 19 07.08.13 16:25

20 Sonic · Charm Always easy-going
Programming Charm
with EXPRESSfit
Charm can be programmed using EXPRESSfit fitting software version
2013.2 or later, and may be used with the EXPRESSlink 3, HI-PRO,
NOAHlink, or nEARcom wireless programming interfaces.
The New Standard (no.2) programming cables are required.
Note! A fresh battery must be inserted into all Charm miniBTE
and custom hearing instruments (not necessary
for Charm BTEs) prior to programming.
Attaching programming cables
Charm BTE hearing instruments
1 Open the battery door fully to reveal the programming socket.
2 Plug the end of the cable into the programming socket as pictured.
BL_ILLU_BTE_Attaching_Programming_Cable_BW_Hi
14
135455_CH_Fitting_Guide_UK.indd 20 07.08.13 16:25
