User Guide
T

SONOS USER GUIDE
Sub
Sonos Sub takes your audio experience to the next level—
• Instantly adds a dimension of deep bass impact to your audio listening experience.
• Allows placement anywhere because it’s wireless and compact—position it vertically or horizontally on
any floor surface.
• The top of the acoustic slot doubles as a handle so you can lift it.
• Sub (Gen 3) is compatible with only.
• See Getting started when you’re ready to add a Sub to your Sonos system.
Note: Sonos Sub is designed for use with most Sonos speakers, except Sonos Connect, Port and Move.
Make sure you set up at least one speaker before adding Sub.
Join button
Ethernet port AC power (mains) input
Acoustic slot
Status light

SONOS USER GUIDE
Controls and lights
Connector panel
Select a location
Choose a location—it’s designed to provide optimal sound wherever you place it.
• Use the acoustic slot as a handle to lift Sub out of the box. You should always bend your knees when
lifting heavy objects to avoid undue stress on your back.
• Make sure at least one side of the slot is free from obstruction. If you place it vertically against a wall,
don’t block the front opening. If you place Sub horizontally on the floor, don’t put anything on top of it.
• Sub is designed to sit on the floor. You can place it in a corner, against the wall, behind, under, or next
to any piece of furniture on any kind of floor surface.
• Position Sub either vertically or horizontally. If you’re going to use it horizontally, you can attach
permanent felt feet (available for purchase separately). See Attach feet (optional) for more information.
Join button Press to connect during setup.
Status light Indicates the status. Learn more
If the light is distracting, you can turn it off in your room’s
settings.
Ethernet port Use an Ethernet cable to connect Sub to your home
network.
AC power (mains) input Use only the supplied power cord to connect to a power
outlet (using a third party power cord will void your
warranty). Be sure to use the proper power adapter for
your country. Push the power cord firmly into Sub until it
is flush with the surface.
Make sure at least one side of the
rectangular opening (acoustic slot) is
unobstructed.
• If you place Sub vertically flush
against a wall, don’t block the
front acoustic slot.
• If you place Sub horizontally on
the floor, don’t put anything on top
of it. Leave at least 1" clearance
along the top of Sub if placing
under furniture.

SONOS USER GUIDE
Note: Sub contains strong magnets. Don’t place it near equipment that is sensitive to magnetic fields.
Attach feet (optional)
If you’re placing Sub horizontally on a floor, you can attach permanent felt feet (available for purchase
separately) to protect your floor. If you’re putting it on a rug or using it vertically, no need to adhere the felt feet.
Note: The felt feet are not removable—a strong adhesive will keep them permanently attached to Sub.
1. Lay Sub down so the Sonos logo is facing down. Make sure you adhere the felt feet to the side that
doesn’t have the Sonos logo.
2. Place the enclosed guide on one corner of the unit and fold the flaps over the edge.
3. Peel the backing off one of the feet.
4. Press the felt foot (sticky side down) onto the unit inside the circular portion of the guide.
5. Attach the other 3 felt feet the same way.
Connect the cables
Attach the power cord and plug in Sub. Be sure to push the power cord firmly into Sub until it is flush with the
surface.
If you don’t have the app, download it from the app store. You’ll use it to set up and control your Sonos
system. See Getting started. Make sure you set up at least one speaker before adding Sub.
Note: After Sub is paired with a Sonos speaker, you won’t see it displayed separately in . Any changes
you make to that Sonos speaker (volume, mute, music selection) will also affect Sub.
Guide for felt
foot placement
Felt foot

SONOS USER GUIDE
Sub settings
Sub’s settings are set during the initial setup process, but you can make changes anytime.
1. Go to the sound settings for the room that’s associated with your Sub.
It appears as room (+Sub)in your list of rooms.
2. Tap Sub Audio.
3. Choose one of the following options:
•Sub: Choose On or Off to turn the sound from Sub on and off.
•Sub Level: Use the slider to increase or decrease volume. (You can use this setting to match the
subwoofer level to the level of your main speakers.)
•Phase Control: Choose 0° or 180° to set the phase control for your Sonos Sub or third-party subwoofer.
This can help integrate your subwoofer with other speakers in the room. (You’ll see this setting when you
pair a Sonos Sub or third-party subwoofer with a Sonos Amp or Connect:Amp.)
•Crossover Frequency: Adjust the frequency at which the sound transitions to the subwoofer. By default
this is 80 Hz.
You may wish to choose a different crossover frequency if:
• The main speakers sound distorted at high volumes—moving to a smaller speaker size setting can
help.
• Your attention is drawn to Sub’s location while listening to music—moving to a larger speaker size
setting can help.
•Recalibrate Sub. If you move your Sub to another location, purchase new speakers, or just want to
adjust the sound after initial setup, you can recalibrate Sub (Android devices only).
• Select the size of your stereo speakers (Connect:Amp only).
• Press Play to compare the volume of two test sounds, A and B, and then select No Difference,
A is louder or B is louder.
• Press Play to listen to a test sound, and then select the level you prefer.
Pair Sub with a different speaker
You can easily pair Sub with a different Sonos speaker (except the Sonos Connect).
If you’re moving Sub to a new room, wait for the status light to stop flashing after you plug it back in.
1Compact 110 Hz
2100 Hz
390 Hz
4Bookshelf / Ceiling 80 Hz
570 Hz
6Floor 60 Hz
750 Hz

SONOS USER GUIDE
1. Go to the sound settings for the room that’s associated with your Sub.
It appears as room (+Sub) in your list of rooms.
2. Remove Sub.
3. You can pair Sub with a different Sonos product or choose not to use Sub right now. It will appear on
as Sub (unused) until you pair it with another Sonos speaker.
Specifications
Feature Description
Audio
Amplifier Two Class-D digital amplifiers.
Speakers Two force-canceling speakers positioned face-to-face for deeper, richer
sound and zero cabinet buzz or rattle.
Dual Acoustic Ports Tuned to enhance Sub performance.
Frequency Response Plays down to 25 Hz.
All Digital Sound All filter settings, active equalization, and time alignment are done digitally
through state-of-the-art DSP (Digital Signal Processing) circuitry for zero-
loss audio quality and energy.
Automatic Equalization The system automatically adjusts audio settings across all connected
components.
Networking*
Ethernet Port One 10/100 Mbps Ethernet port. You can plug a Sonos product directly into
your router if your WiFi is unstable.
Wireless Connectivity Connects to your home WiFi network with any 802.11b/g/n router.
802.11n only network configurations are not supported—you can either
change the router settings to 802.11b/g/n or connect a Sonos product to
your router.
General
Power Supply Auto-switching 100-240 V, 50-60 Hz 2 A AC universal input.
Dimensions (H x D x W) 15.3 x 6.2 x 15.8 in. (389 x 158 x 402 mm)
Weight 36.3 lb (16 kg)
Operating Temperature 32°F to 104° F (0°C to 40° C)
Storage Temperature -4°F to 158° F (-20°C to 70° C)
Multiple Orientations Stand upright or lay flat for flexible placement.

SONOS USER GUIDE
* Specifications subject to change without notice.
Important Safety Information
Rubber and Felt Feet Built-in rubber feet; optional felt feet.
Supported Devices Sub works with all Sonos products except the non-amplified Sonos
Connect.
Package Contents Sonos Sub, power cord, and Quickstart Guide.
1.Read these instructions.
2.Keep these instructions.
3.Heed all warnings.
4.Follow all instructions.
5.Do not use this apparatus near water.
6.Clean only with dry soft cloth. Household cleaners or solvents can damage the finish on your Sonos components.
7.Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8.Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus that produce heat.
9.Protect the power cable from being walked on or pinched, particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
10.Only use attachments/accessories specified by the manufacturer.
11.Unplug this apparatus during lightning storms or when unused for long periods of time.
12.Refer all servicing to Sonos qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cable or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
13.The Mains plug should be readily available to disconnect the equipment.
14.Warning: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. 
15.Do not expose apparatus to dripping or splashing and do not place objects filled with liquids, such as vases, on the
apparatus.
