Sony Ericsson Aspen Mli Quick reference guide

White paper | Sony Ericsson Aspen™
2 October 2010
This document is published by Sony Ericsson Mobile
Communications AB, without any warranty*. Improvements and
changes to this text necessitated by typographical errors,
inaccuracies of current information or improvements to programs
and/or equipment, may be made by Sony Ericsson Mobile
Communications AB at any time and without notice. Such changes
will, however, be incorporated into new editions of this document.
Printed versions are to be regarded as temporary reference copies
only.
This document may reference services or applications provided by
third parties. Use of such programming or services may require
separate registration with the third party provider and may be
subject to additional terms of use. For applications accessed on or
through a third-party website, please review such website’s terms of
use and applicable privacy policy in advance. Sony Ericsson does
not warrant or guaranty the availability or performance of any third-
party websites or offered services.
Some features described in this document are not supported by all
networks and/or service providers in all areas. Please contact your
network operator or service provider to determine availability of any
specific service or feature and whether additional access or usage
fees apply.
*All implied warranties, including without limitation the implied
warranties of merchantability or fitness for a particular purpose, are
excluded. In no event shall Sony Ericsson or its licensors be liable
for incidental or consequential damages of any nature, including but
not limited to lost profits or commercial loss, arising out of the use of
the information in this document.
This White paper is published by:
Sony Ericsson Mobile Communications AB,
SE-221 88 Lund, Sweden
www.sonyericsson.com/
© Sony Ericsson Mobile Communications AB,
2009-2010. All rights reserved. You are hereby
granted a license to download and/or print a
copy of this document.
Any rights not expressly granted herein are
reserved.
Third version (October 2010)
Publication number: 1236-8393
Purpose of this document
Sony Ericsson product White papers are intended to give an overview of a product and provide details in
relevant areas of technology.
Document history
Sony Ericsson Developer World
For the latest Sony Ericsson technical documentation and development tools, go to
www.sonyericsson.com/developer.
Version
February 2010 First released version Version 11
March 2010 Second released version Revision 1
October 2010 Third released version Revision 2

White paper | Sony Ericsson Aspen™
3 October 2010
Table of contents
Product overview ........................................................................................................4
Sony Ericsson Aspen™ – Grow a greener business .............................................4
Facts – dimensions, weight, performance and networks ......................................5
Full feature list – categorized list of features .........................................................7
Technologies in detail .................................................................................................8
Windows mobile support .......................................................................................8
Device-to-device communications (local) .............................................................9
Bluetooth™ wireless technology ........................................................................9
Wi-Fi™ ................................................................................................................9
Messaging ...........................................................................................................10
(MMS) Multimedia Messaging Service..............................................................10
Email .................................................................................................................10
Java™ ..................................................................................................................11
Provisioning (OMA CP, OMA DM) .......................................................................11
Synchronisation (OMA DS, EAS) .........................................................................11
Multimedia ...........................................................................................................12
Audio and Video................................................................................................12
Web browser .......................................................................................................13
Trademarks and acknowledgements ..................................................................14

White paper | Sony Ericsson Aspen™
4 October 2010
Product overview
Sony Ericsson Aspen™ – Grow a greener business
Book meetings between meetings. Share minutes in minute detail. In the street. On the fly. New
directives? One message to all your co-workers, in one go: You’re on it. Keep your business going with
Windows Mobile® and office apps. Use the touchscreen or the full keyboard. And feel good about Sony
Ericsson Aspen™ being an eco-friendly phone.
Work and pleasure served on a panel
CNN for breakfast and Facebook™ at five? Sony Ericsson panels serve you with what you need, when
you need it. From pure pleasure to prime work tools. Drag and drop panels onto the timeline and see them
pop up on your home screen at the times set.
Success can take you anywhere. A-GPS too
Shook the hand? Sealed the deal? Share it. Push the SlideView key for all the apps you can’t do without
when you’re out, up front. Like contacts, call list and emails. Passed that building twice? With A-GPS,
Gokivo™ Navigator, Send My Location and Google Maps™ you can lose yourself in your thoughts,
without getting lost.
Fill it up, please
The music you love, the book you never finished. In your ears anywhere. Hard rock classics for fanatics.
Laidback singback on YouTube™. Enjoy it on Sony Ericsson Aspen™. And refuel.
GreenHeart™ phones help you meet your deadlines
Recycled plastic. Waterborne paint. Sony Ericsson Aspen™ is on good terms with Mother Nature. It’s a
GreenHeart™ phone that helps us reduce our impact on the environment. That’s why we also keep paper
and packaging to a minimum. You find the manual in the phone. It feels great to help, doesn’t it?
One press to consume less
Saving power is easy. Just touch the GreenHeart™ icon of the default panel to activate Power save. More
power for you when you need it. And fewer battery charges.

White paper | Sony Ericsson Aspen™
5 October 2010
Facts – dimensions, weight, performance and
networks
Operating system Windows Mobile® 6.5.3
Size 117 x 60 x 12.45 mm
Weight 130 grams
Available colours Iconic Black
White Silver
Main screen
Colours 65,536-colour TFT
Resolution 240x320 pixels
Size (diagonal) 2.4 inches
Input mechanisms
Touch screen Resistive (single touch)
QWERTY keyboard Yes
Text input Yes, XT9
Memory
Available user flash Up to 100 MB
Total flash 512 MB
RAM 256 MB
Memory card support microSD™ (up to 16 GB)
Networks
M1i UMTS HSPA 900 (Band VIII), 2100 (Band I)
GSM GPRS/EDGE 850, 900, 1800, 1900
M1a UMTS HSPA 850 (Band V), 1900 (Band II), 2100 (Band I)
GSM GPRS/EDGE 850, 900, 1800, 1900
Data transfer speeds
GSM GPRS Up to 85 kbps (downlink)
Up to 42 kbps (uplink)
GSM EDGE Up to 225 kbps (downlink)
Up to 112 kbps (uplink)
UMTS HSPA (upload) Up to 2.0 Mbps (uplink, HSUPA, Cat 5)
UMTS HSPA (download) Up to 7.3 Mbps (downlink, HSDPA, Cat 7)

White paper | Sony Ericsson Aspen™
6 October 2010
* According to GSM Association Battery Life Measurement Technique.
Note: Battery performance may vary depending on network conditions and configuration, and phone
usage.
Talk time (GSM) 6 hours 30 min*
Standby time (GSM) 560 hours*
Talk time (UMTS) 7 hours 30 min*
Standby time (UMTS) 500 hours*
Music listening time Up to 12 hour
Battery 1500 mAh Lithium Polymer

White paper | Sony Ericsson Aspen™
7 October 2010
Full feature list – categorized list of features
Camera
3.2 megapixel camera
4x digital zoom
Self timer
Smart contrast
Music
Album art
Bluetooth™ stereo (A2DP)
Equalizer
PlayNow™
Sony Ericsson media player
Music tones (MP3/AAC)
Windows Media® Player Mobile
Web
Bookmarks
Google™ search
Internet Explorer® Mobile
Pan & zoom
Web feeds
HTML 4.01
XHTML 1.1
Voice
Call list
Conference calls
Polyphonic ringtones
Speakerphone
Vibrating alert
Messaging
Email
Microsoft Exchange ActiveSync®
Handwriting recognition
Instant messaging
Picture messaging (MMS)
Predictive text input
Sound recorder
Text messaging (SMS)
Unified SMS/MMS messaging
composer
Design
Windows Mobile® 6.5.3
Media browser
Picture wallpaper
QWERTY keyboard
Touchscreen
Wallpaper animation
Entertainment
3D games
Adobe™ Flash Lite™ 3.1 support
Capuchin version 1.0
Facebook
FM radio with RDS
Java™
Skype™
Video streaming
Video viewing
YouTube™
Organiser
Alarm clock
Calculator
Calendar
Document readers (Adobe PDF
reader)
Flight mode
Microsoft Office® mobile
Notes
Outlook® Mobile
Phone book
Tasks
Connectivity
3.5 mm audio jack
A-GPS
Bluetooth™ technology
Gokivo™ Navigator
Google Maps™
Micro USB connector
Send My Location
Synchronisation
USB mass storage
USB support
Wi-Fi™

White paper | Sony Ericsson Aspen™
8 October 2010
Technologies in detail
*NOTE: The information outlined below is general and levels of compliance to standards and
specifications may vary between products and markets. For more information, contact Sony Ericsson
Developer World or your Sony Ericsson contact person where applicable.
Windows mobile support
Windows Mobile 6.5.3
Professional
Microsoft Outlook Mobile
Microsoft Office Mobile: Word, Excel®, PowerPoint® and
OneNote®
Microsoft Internet Explorer Mobile
Windows Media Player 10 Mobile
Windows Live™
ActiveSync client
File Explorer
Direct Push email
Platform components .NET CF v2, SQL CE
Windows Mobile Marketplace
Windows Mobile Update

White paper | Sony Ericsson Aspen™
9 October 2010
Device-to-device communications (local)
More information:
www.sonyericsson.com/developer
www.bluetooth.com
Wi-Fi™
Wi-Fi™ is a popular wireless networking technology that uses radio waves to provide wireless high-speed
Internet and network connections. Wi-Fi™ hotspots exist in an increasing number of locations e.g
airports, hotels, cafés and bistros. If a mobile phone supports Wi-Fi™, it can be used to utilize high data
transfer rates and lower calling costs.
Bluetooth™ wireless technology
Bluetooth™ 2.0 profiles
supported
Advanced Audio Distribution Profile
Audio/Video Remote Control Profile
Generic Access Profile
Generic Audio/Video Distribution Profile
Generic Object Exchange Profile
Handsfree Profile
Headset Profile
Object Push Profile
Personal Area Networking Profile
Phonebook Access Profile
Serial Port Profile
Sony Ericsson Watch Profile
ActiveSync over Bluetooth
Core version and supported
core features
2.0+EDR
Connectable devices All products supporting Bluetooth spec. 1.1, or higher,
and at least one of the profiles above
Supported standards Wi-Fi™ certified
Support: 802.11g/802.11b
Connectable devices Wi-Fi™ access points
Wi-Fi™ ad-hoc mode
Frequency band 2.4 GHz
Data transmission rate Up to 54 Mbps
Security Open
Open WEP
Shared WEP
WPA™ Personal and WPA2 Personal
WPA™ Enterprise and WPA2 Enterprise
WAPI
Encryption TKIP and AES

White paper | Sony Ericsson Aspen™
10 October 2010
Messaging
(MMS) Multimedia Messaging Service
According to OMA Multimedia Messaging Service v1.2 + SMIL
Email
More information:
www.sonyericsson.com/developer
www.openmobilealliance.org
Bearer type (IP) GSM Data (IP) GPRS and HSCSD
Character sets USASCII
UTF-7
UTF-8
UTF-16
UTF-17LE
UTF-16BE
UCS-2 / ISO10646 UCS2
ISO-8859-1
ISO-8859-2 Eastern Europe
ISO-8859-5 Cyrillic
ISO-8859-7 Greek
ISO-8859-9 Turkish
ISO-8859-10 Nordic
ISO-8859-11 Thai
ISO-8859-15 Western MR5
KOI8
GB18030 Simplified Chinese
GB2312 Simplified Chinese
BIG5
ISO2022JP
Windows 1251 Cyrillic
Windows 1252
Windows 1254 Turkish
Windows 1255 Hebrew
Windows 1258 Vietnamese
Shift JIS
Note: GB2312 is available in Simplified Chinese
variants only, that is, Mainland China variants.
BIG5 is only available in Traditional Chinese variants,
that is, Hong Kong and Taiwan variants.
OTA provisioning solution OMA Client Provisioning 1.1
Protocols POP3, SMTP, IMAP4 and Microsoft Exchange
Push email OMA Email Notification 1.0 and scheduled checking, Exchange
ActiveSync® (EAS)
Secure email SSL/TLS, both port methods (POPS/IMAPS) and STARTTLS
HTML mail Yes

White paper | Sony Ericsson Aspen™
11 October 2010
Java™
Provisioning (OMA CP, OMA DM)
OMA CP version 1.1
OMA DM version 1.1.2, 1.2
Related information:
www.sonyericsson.com/developer
Synchronisation (OMA DS, EAS)
OMA Data Synchronization protocol versions 1.1.2 and 1.2
OMA Data Formats: vCard 2.1, vCalendar 1.0, vBookmark 1.0, notes as text/plain
Microsoft Exchange ActiveSync® and Windows Mobile Device Center
Java™ Platform, Micro Edition JSR-75 PDA Optional Packages for J2ME™
JSR-118 MIDP 2.1
JSR-120 Wireless Messaging API
JSR-135 Mobile Media API 1.1
JSR-139 CLDC 1.1
JSR-172 J2ME™ Web Services Specification
JSR-177 Security and Trust Services API for J2ME™
JSR-179 Location API for J2ME
JSR-184 Mobile 3D Graphics API for J2ME™
JSR-185 Java™ Technology for the Wireless Industry
JSR-205 Wireless Messaging API 2.0
JSR-211 Content Handler API
JSR-234 Advanced Multimedia Supplements
JSR-238 Mobile Internationalization API
JSR-248 Mobile Services architecture
Nokia UI Extension API
Capuchin version 1.0 (This application framework makes
it possible to bridge Flash technology with Flash.)
Java 3D JSR-184 Mobile 3D Graphics API for J2ME™

White paper | Sony Ericsson Aspen™
12 October 2010
Multimedia
Audio and Video
Audio Playback Decoder format
Audio Decoding MPEG-1/2/2.5,
audio layer 3
AMR-NB
WMA version 2,7,8: Class 1
WMA version 9: Level 3
WMA Pro (profile M0a)
General MIDI (GM)
SP-MIDI
Linear/A-law/.-law PCM
Supported in file format
MP3 (.mp3)
3GP (.3gp); AMR (.amr)
WMA (.wma)
WMA (.wma)
WMA (.wma)
SMF (.mid)
SMF (.mid)
WAV (.wav)
Audio Recording Encoder format
AAC-LC
Supported in file format
MP4 (.mp4)
Video Playback Decoder format
MPEG-4 Visual Simple Profile
H.264 Baseline Profile
H.263 Profile 0
WMV9
DIVX Mobile Profile
Supported in file format
3GP (.3gp); MP4 (.mp4)
3GP/MP4
3GP (.3gp)
WMV (.asf, .wmv)
AVI (.avi)
Video Recording Encoder format
Video: MPEG-4 Visual Simple
Profile
Audio: AAC-LC
Supported in file format
3GP (.3gp); MP4 (.mp4)
Audio/Video Streaming Streaming transport RTSP/RTP/RTCP/SDP
DRM DRM (Digital Rights Manage-
ment) features the rights and
copy protection of downloaded
content.
OMA DRM 1.0, 2.0, 2.1
Microsoft DRM Janus

White paper | Sony Ericsson Aspen™
13 October 2010
Related information:
www.sonyericsson.com/developer
Web browser
Browser version Internet Explorer Mobile
HTML - 4.01
XHTML - Basic, XHTML 1.01
WAP - 1.2.1, 2.0
CSS - Level 1, Level 2 (partial), Mobile Profile 1.0, Wire-
less (WAP) CSS 1.1
Scripting/DOM - JScript 5.6, DOM Level 0, DOM Level 1
(partial), DOM Level 2 (partial)
cHTML - A mobile device adapted version of the standard
Internet communications
protocol HTML
Full HTML support, JScript, Progressive download of
video files
Direct access to Search Internet and Enter address
HTML - 4.01 (with some exceptions)
XHTML - Basic, 1.0, 1.1 (both with some exceptions)
XHTML Mobile Profile 1.0, 1.1, 1.2 (with some exceptions)
WML 1.3, 2.0 (both with some exceptions)
CSS - Level 1, Level 2 (partial), Mobile Profile 1.0, Wire-
less (WAP) CSS 1.0, 1.1
XSLT 1.0, XPath 1.0, XML Namespaces, XML ID, XML
Events
Scripting/DOM - JScript 5.6, DOM Level 0, DOM Level 1
(partial), DOM Level 2 (partial)

White paper | Sony Ericsson Aspen™
14 October 2010
Trademarks and acknowledgements
The Liquid Identity and Liquid Energy logos, Sony Ericsson Aspen, GreenHeart, PlayNow, BestPic, and
TrackID are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB. Sony and
"make.believe" are trademarks or registered trademarks of Sony Corporation. Ericsson is a trademark of
Telefonaktiebolaget LM Ericsson.
The Bluetooth word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by
Sony Ericsson is under licence. PictBridge is a trademark or registered trademark of Canon Kabushiki
Kaisha Corporation. TrackID is powered by Gracenote Mobile MusicID. Gracenote and Gracenote Mobile
MusicID are trademarks or registered trademarks of Gracenote, Inc.
Google, Google Maps and YouTube are trademarks or registered trademarks of Google, Inc. Wi-Fi and
WPA are trademarks or registered trademarks of the Wi-Fi Alliance. microSD is a trademark or registered
trademark of SanDisk Corporation. XHTML is a registered trademark of the W3C.
Facebook is a trademark or registered trademark of Facebook, Inc. Yahoo! is a trademark or registered
trademark of Yahoo!, Inc. Skype is a trademark or registered trademark of Skype Limited. CNN is a
trademark or registered trademark of Cable News Network, LLP. Gokivo, Networks In Motion and their
logos are registered trademarks or trademarks of Networks In Motion, Inc. Certain software or technical
information in this product is provided by and licensed from Networks In Motion, Inc., Copyright Networks
In Motion, Inc. © 2000 - 2010. All rights reserved.
Microsoft, OneNote, Windows, Windows Mobile, Excel, PowerPoint, Windows Live, Outlook, Internet
Explorer, Windows Media and ActiveSync are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Adobe and Flash Lite are trademarks or registered trademarks of Adobe Systems Incorporated in the
United States and/or other countries. 3GPP™ is a trademark of ETSI in France and other jurisdictions.
SyncML is a trademark or registered trademark of Open Mobile Alliance Ltd.
Java and all Java based trademarks and logos are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
End-user license agreement for Sun Java™ J2ME™:
1. Restrictions: Software is confidential copyrighted information of Sun and title to all copies is retained by
Sun and/or its licensors. Customer shall not modify, decompile, disassemble, decrypt, extract, or other-
wise reverse engineer Software. Software may not be leased, assigned, or sublicensed, in whole or in
part.
2. Export Regulations: Software including technical data, is subject to U.S. export control laws, including
the U.S. Export Administration Act and its associated regulations, and may be subject to export or import
regulations in other countries. Customer agrees to comply strictly with all such regulations and acknowl-
edges that it has the responisibility to obtain licenses to export, re-export, or import Software. Software
may not be downloaded, or otherwise exported or re-exported (i) into, or to a national or resident of, Cuba,
Iraq, Iran, North Korea, Libya, Sudan, Syria (as such listing may be revised from time to time) or any coun-
try to which the U.S. has embargoed goods; or (ii) to anyone on the U.S. Treasury Department's list of
Specially Designated Nations or the U.S. Commerce Department's Table of Denial Orders.
3. Restricted Rights: Use, duplication or disclosure by the United States government is subject to the
restrictions as set forth in the Rights in Technical Data and Computer Software Clauses in DFARS
252.227-7013(c) (1) and FAR 52.227-19(c) (2) as applicable.
All other trademarks and copyrights are the property of their respective owners.
