Sony Ericsson T303 User manual

T303
User guide
This is the Internet version of the User's guide. © Print only for private use.

2
Congratulations on your purchase of the Sony Ericsson T303 .
For additional phone content, go to www.sonyericsson.com/fun.
Register now to get free online storage and special offers
at www.sonyericsson.com/myphone. For product support,
go to www.sonyericsson.com/support.
Instruction symbols
The following instruction symbols appear in this User guide:
> Use a navigation key or a selection key to scroll and
select.
Press the center selection key.
Press the navigation key to the left.
Press the navigation key to the right.
Press the navigation key up.
Press the navigation key down.
Note
Tip
Warning
Indicates that a service or function is network- or
subscription-dependent. All menus or functions may
not be available in your phone. Consult your network
operator for more information.
This is the Internet version of the User's guide. © Print only for private use.

3
Preparing the phone
To insert the SIM card and battery
1Remove the battery cover. Slide the SIM card into its holder
with the contacts facing down.
2Insert the battery with the label side up and the connectors
facing each other. Replace the battery cover as shown in
the picture.
Do not force the battery cover into place. Slide the battery
cover carefully onto the phone and close it.
This is the Internet version of the User's guide. © Print only for private use.

4
To charge the battery
1The phone battery is partly charged when you buy it. Connect
the charger to the phone. It takes approximately 2.5 hours
to fully charge the battery. Press a key to illuminate the
screen.
2To remove the charger, tilt the plug upwards.
You can use the phone during charging. You can charge
the battery for more or less than 2.5 hours. Interrupted
charging will not damage the battery.
This is the Internet version of the User's guide. © Print only for private use.

5
To turn on the phone
1Press and hold down .
2Enter your PIN if requested. To correct mistakes, press .
3Select OK.
4Select a language.
5Enter the time and date and select
Save.
To turn off the phone
•Press and hold down .
Standby
After you have turned on the phone and entered your PIN, the
name of your operator appears on the screen. This is called
standby. You can now make and receive calls.
This is the Internet version of the User's guide. © Print only for private use.

6
SIM and PIN
SIM card
The SIM (Subscriber Identity Module) card, which you
get from your network operator, contains information
about your subscription. Always turn off your phone
and detach the charger and remove the battery before
you insert or remove the SIM card.
PIN code
You may need a PIN (Personal Identification Number) to
activate the services in your phone. Your PIN is supplied by
your network operator. Each PIN digit appears as *, unless it
starts with emergency number digits, for example, 112 or 911.
You can call an emergency number without entering a PIN.
You can save contacts on the SIM card before removing it
from your phone. Contacts may also be saved in the phone
memory. See Contacts on page 17.
If you enter the wrong PIN three times in a row, PIN
blocked. To unblock, enter your PUK code provided by
your service provider. appears. To unblock it, you need
to enter your PUK (Personal Unblocking Key).
This is the Internet version of the User's guide. © Print only for private use.

7
Network coverage
The network bars show the strength of the GSM network in
your area. Try moving to another location if you have trouble
calling and network coverage is poor. No net. coverage means
you are not in range of a network.
Battery status
= Good network coverage
= Average network coverage
= The phone battery is fully charged
= The phone battery is empty
= The phone battery is being charged
Battery
status
Network
coverage
This is the Internet version of the User's guide. © Print only for private use.

8
Phone overview
Navigation key
C key
Strap
hole
Camera
On/off key,
End key
Shortcut key
Call key
Selection key
Ear speaker
Silent key
Selection key
Screen
Connector for
charger and
handsfree
Center
selection key
This is the Internet version of the User's guide. © Print only for private use.

9
Menu overview
Organizer File manager, Alarms, Calendar, Tasks,
Notes, Timer, Stopwatch, Calculator
Internet
Entertainment TrackID™, My Games, FM radio, Sound
recorder
Camera
Messaging Write new, Inbox, Call voicemail, Drafts,
Outbox, Sent messages, Saved msgs,
Templates, Settings
Music player Play view, Artists, Tracks, Playlists
Calls*
All Answered Dialed Missed
Contacts New contact
Settings*
General Sounds &
alerts
Display Calls Connectivity
Some menus and icons in this document may vary depending on
operator, network or subscription.
* You can use the navigation key to select tabs in sub menus.
This is the Internet version of the User's guide. © Print only for private use.

10
Screen icons
These icons may appear on the screen.
Icon Description
Battery icon. A completely green icon means the
battery is fully charged
You have missed a call
Ongoing call
The phone is set to silent
The keypad is locked
You have received a new text message
You have received a new picture message
An alarm is activated
The radio is playing
The music player is playing
A handsfree is connected
The Bluetooth function is activated
A Bluetooth handsfree is connected
The loudspeaker is on
This is the Internet version of the User's guide. © Print only for private use.

11
Navigation
To navigate the menus
1From standby press to select
Menu.
2Press , , , to move
through the menus.
To select items and actions shown
on the screen
•Press either of the selection keys
or .
To select a tab
•Go to the tab by pressing or .
To return to standby
•Press .
To operate the keypad lock
•To lock the keypad, close the slide.
•To unlock the keypad, open the slide.
•To unlock the keypad with closed slide, press any key, then
select Unlock > OK.
Calls to the international emergency number 112 can still
be made, even when the keypad is locked.
This is the Internet version of the User's guide. © Print only for private use.

12
To set the phone to silent
•Press and hold down .
To delete items
•Press to delete items such as numbers, letters and
pictures.
Shortcuts
You can use keypad shortcuts to go directly to a menu from
standby.
To use the navigation key shortcuts
•Press to write a text or picture message, or record
a voice message.
•Press to go to the camera.
•Press to go to the music player.
•Press to go to your contacts.
To use the shortcut key
•Press to Add, Delete, Move or use shortcuts.
This is the Internet version of the User's guide. © Print only for private use.

13
Calling
You must turn on the phone and be within range of a network.
To make a call
1From standby enter the area code and phone number.
2Press .
To activate the slide for answering and ending calls
1From standby select Menu > Settings > the Calls tab.
2Select Open to answer > On to activate answering.
3Select Close to end call > On to activate call ending.
To answer a call
•Press or open the slide.
To end a call
•Press or close the slide.
To reject a call
•Press .
To turn off the ringtone when
receiving a call
•Press to turn off the ringtone without answering
or rejecting the call.
To turn the loudspeaker on during a call
•Select SpkrOn.
Do not hold the phone to your ear when using the
loudspeaker. This could damage your hearing.
This is the Internet version of the User's guide. © Print only for private use.

14
To mute the microphone during a call
•Press and hold to turn the microphone on and off.
To change the ear speaker volume during a call
•Press or .
To make international calls
1From standby press and hold down until a + sign
appears on the screen.
2Enter the country code, area code (without the first zero)
and phone number.
Call list
You can view information about recent calls.
To call a number from the call list
1From standby press .
2Go between the tabs All, Answered, Dialed and Missed.
3Find the name or number and press .
To clear the call list
1From standby press .
2Select the All tab > Options > Delete all.
This is the Internet version of the User's guide. © Print only for private use.

15
Messaging
Text messages (SMS)
You must have a service center number, which is supplied
by your service provider and saved on the SIM card.
You may have to enter the number yourself.
To set a service center number
1From standby select Menu > Messaging > Settings > Text
message > Service center.
2If there is no number shown, enter the service number,
including the international “+” sign and country code.
3Select Save.
To write and send a text message
1From standby press .
2Select Text message. Enter the message and select Cont.
3Select a recipient (Enter phone no. or Contacts lookup)
and select Send.
Received messages are saved in the Inbox.
To read or delete received messages in the Inbox
1From standby select Menu > Messaging > Inbox.
2Scroll to the message you want to read or delete.
3To read the message, select View. To delete the message,
press .
See Entering text on page 24.
This is the Internet version of the User's guide. © Print only for private use.

16
Picture messages (MMS)
Picture messages can contain text, images and sounds.
To create and send a picture message
1From standby press .
2Select Picture msg.
3Press or to switch between writing text and adding
items. Select Options to select writing options.
4When the message is ready, select Cont.
5Select a recipient (Enter email addr., Enter phone no. or
Contacts lookup) and select Send.
You must set an MMS profile and the address of your
message server. You can receive all the settings from your
network operator or at www.sonyericsson.com/support.
Sending and receiving phones must have subscriptions
that support picture messaging.
This is the Internet version of the User's guide. © Print only for private use.

17
Contacts
You can save contacts in the phone memory or on the SIM
card. You can copy contacts from the phone memory to the
SIM card or from the SIM card to the phone memory.
To add a contact
1From standby press .
2Scroll to New contact and select Add.
3Scroll to Name: and select Add.
4Enter the name and select OK.
5Scroll to New number: and select Add.
6Enter the number and select OK.
7Select a number option.
8Navigate between tabs and fields and add information.
9Select Save.
To call a contact
1From standby press .
2Scroll to the contact, or enter the first few letters of the
contact with multitap (see Entering text on page 24).
3Press .
See Entering text on page 24.
You can enter the + sign and country code with all
phonebook numbers. They can then be used abroad
or at home. See To make international calls on page 14.
This is the Internet version of the User's guide. © Print only for private use.

18
To edit a contact
1From standby press .
2Scroll to the contact and select Options > Edit contact.
3Navigate between the tabs, edit the information and select
Save.
To delete a contact
1From standby press .
2Scroll to the contact and press .
To copy all contacts to the SIM card
1From standby press .
2Scroll to New contact and select Options > Advanced
> Copy to SIM > Copy all.
Contacts memory
The number of entries you can save in Contacts depends
on the capacity of your SIM card.
To check the Contacts memory status
1From standby press .
2Scroll to New contact and select Options > Advanced
> Memory status.
This is the Internet version of the User's guide. © Print only for private use.

19
Radio
To listen to the radio
1Connect the handsfree to the phone.
2From standby select Menu > Entertainment
> FM radio.
To control the radio
•Press or to search for channels manually.
•Press or to change the volume.
To save a radio channel in the channels list
•Find the radio channel, then press and hold down
– to save it on the corresponding position.
To listen to a radio channel saved in the channels list
•When the radio is playing, press – to listen to the
radio channel on the corresponding position. You can view
saved channels in Options > Channels > Select position.
To turn off the radio
•Select Options > Turn off or press .
To view radio options
•When the radio is playing, select Options.
To record radio
1Select Options > Record radio to start recording.
2Select Save to stop the recording. The recording is saved
in Menu > Organizer > File manager > My radio recs.
This service is not available in all countries.
This is the Internet version of the User's guide. © Print only for private use.

20
Music player
You can play music files saved in the phone memory. The music
stops when you receive or make a call, and the playing resumes
when the call has ended.
To play a music track
1From standby press .
2Scroll to Tracks and select Open.
3Scroll to the track and select Play.
To change the volume
•When music is playing, press or .
To create a playlist
1From standby press .
2Scroll to Playlists and select Open.
3Scroll to New playlist and select Add.
4Enter a name and select OK.
5Scroll to a track and select Mark to mark the tracks you
want to add. To browse a folder, select Open.
6Select Add.
To minimize the music player on the screen
•When music is playing, select Minim.
To stop the music player when minimized
1From standby press .
2Select Play view > Stop.
This is the Internet version of the User's guide. © Print only for private use.
