Installation Instruction, Mechanical
Applicable for W910
Contents
1
General.............................................................................................................................2
2 Hardware.........................................................................................................................2
2.1 Test Setup ..........................................................................................................2
2.2 Computer ........................................................................................................... 3
2.3 Sony Ericsson programming interface cable – DCU-60 ...................................3
2.4 Bluetooth Device............................................................................................... 3
2.5 Power Supply (optional).................................................................................... 3
2.6 Battery Eliminator (Dummy Battery)................................................................3
2.7 Label Printer ......................................................................................................3
3 Software ...........................................................................................................................4
3.1 EMMA III.......................................................................................................... 4
3.2 Labelmake II software.......................................................................................4
4 Revision History.............................................................................................................. 5

Installation Instruction, Mechanical
1/00021-1/FEA 209 544/129 A
Company Internal
© Sony Ericsson Mobile Communications AB
2(5)
1 General
This document describes the installation procedure for the Mechanical repair package.
The Mechanical repair package consists of a Computer and Interface Cables. A service
card is required for security reasons. A label printer can be installed to be able to print
new labels (optional).
2 Hardware
All hardware must be approved by Sony Ericsson and is documented in the Equipment
List.
2.1 Test Setup
The equipment in this picture is specified in the Equipment List.

Installation Instruction, Mechanical
1/00021-1/FEA 209 544/129 A
Company Internal
© Sony Ericsson Mobile Communications AB
3(5)
2.2 Computer
IBM compatible computer is required. The computer should include at least two USB-
ports. Refer to Equipment List for minimum requirements.
2.3 Sony Ericsson programming interface cable – DCU-60
The cable is the interface between the computer and the phone. The DCU-60 cable
should be connected to a USB-port on the computer.
2.4 Bluetooth Device
Any Bluetooth device such as a headset, other Bluetooth phone or other Bluetooth
device can be used to verify the Bluetooth function in the phone. Set up the connection
according to the chosen equipment manufacturer instructions.
2.5 Power Supply (optional)
A Power Supply according to the Mechanical Equipment List may be used.
Set the output of the Power Supply as follows
•Voltage: 3.8Vdc
•Current: 2.0Amps
2.6 Battery Eliminator (Dummy Battery)
A Battery Eliminator is to be used together with a power supply to power the phone.
Connect the cables from the battery eliminator to the power supply, red cable to positive
output terminal and black cable to negative output terminal. There is a 3-position switch
on the Battery Eliminator that should be set to position “B”.
2.7 Label Printer
A Zebra printer shall be used. Connect the printer with a Null Modem cable [refer to the
Zebra printer manual] to the serial port on the computer. Read the Zebra installation
manual for more information about the installation.

Installation Instruction, Mechanical
1/00021-1/FEA 209 544/129 A
Company Internal
© Sony Ericsson Mobile Communications AB
4(5)
3 Software
3.1 EMMA III
EMMA III contains software upgrades and tools required for servicing this phone. Emma
III is accessible through the CSPN web page. Installation and user manuals are
available at the EMMA III start page.
http://ma3.extranet.sonyericsson.com/ma3/
3.2 Labelmake II software
LabelMake II is an application installed through Java Web Start.
Access the Labelmake II software from the CSPN Web page.
You will find LabelMake II in the dropdown menu on the CSPN web page.
http://cspn.extranet.sonyericsson.com
Press “START LabelMake II “button and you will be directed to the LABELMAKE II client
page.
Product labels are downloaded on-line from a remote server database.

Installation Instruction, Mechanical
1/00021-1/FEA 209 544/129 A
Company Internal
© Sony Ericsson Mobile Communications AB
5(5)
4 Revision History
Rev. Date Changes / Comments
A 2007-10-09 Initial Release
