Features
Easily view and print your photos via Cyber-shot Station.
This convenient Cyber-shot Station is supplied with wireless remote cotrol for
effort-less viewing on a TV.
Also attaches to PictBridge enabled printers and USB enabled computers.
In-camera charging while stationed.
The CSS-PHA can be used with the DSC-P100 digital still camera.
The CSS-FEB can be used with the DSC-F88 digital still camera.
*The illustrations of the CSS-PHA are mainly used in this operating
instructions. However, these illustrations are applied to the CSS-FEB.
An AC adaptor is not supplied. Use either the AC adaptor (AC-LS5/LS5B)
comes with the Cyber-shot (DSC-P100/DSC-F88), or an optional AC adaptor
(AC-LS5).
zYou can easily view photos on a TV screen by remote control (p.15).
zThe buttons on the Remote Commander have the same functions as those on
your camera (p.13).
Using the remote control, you can operate the followings;
–Viewing images
–Slide Show
–Trimming images
–Playback zoom
For further details, see the operating instructions supplied with the camera.

5-GB
Precautions .................................................................................................... 6
Notes on using the Cyber-shot Station...................................................... 6
Care and maintenance ................................................................................. 6
Identifying the parts..................................................................................... 7
Before using the Cyber-shot Station .......................................................... 8
Placing the camera on the Cyber-shot Station /
Removing the camera from the Cyber-shot Station ......................... 8
Charging the battery pack .........................................................................10
Connecting the camera to your computer via the Cyber-shot Station..... 11
Using the Remote Commander ................................................................ 13
Viewing images on a TV screen................................................................ 15
Connecting to a PictBridge compliant printer........................................ 16
Printing images using the Remote Commander.................................... 19
Troubleshooting ..........................................................................................22
Specifications ............................................................................................... 25
Trademarks .................................................................................................. 25
Index
zWhen the CSS-PHA or CSS-FEB is connected to a PictBridge enabled printer,
you can easily print images just by pressing PRINT button on the Remote
Commander (p.19). The photo currently shown on the TV can be printed by
remote control.
Note: If you want to print one of the images in a Slide Show, cancel the Slide
Show first, then press PRINT button.
*You must connect an AC adaptor to the Cyber-shot Station for remote control
operations.

6-GB
Precautions
• Do not use or keep the Cyber-shot Station in locations subject to the following
conditions:
–Locations with extremes of temperature
In closed automobiles during summer, the ambient temperature may be
very hot, causing deformation or malfunction of the Cyber-shot Station.
–Locations in direct sunlight or near heaters
This may cause deformation or malfunction of the Cyber-shot Station.
–Locations subject to vibration
–Locations subject to strong magnetism
–Locations subject to dust or sand
If you use the Cyber-shot Station, for example, on a beach or in a desert,
make sure that you keep the Cyber-shot Station away from sand. The
Cyber-shot Station that is covered with sand may malfunction.
• Do not use the Cyber-shot Station in locations that are subject to strong radio
waves or radiation. Images may not be played back properly.
Notes on using the Cyber-shot Station
• Do not connect the supplied USB cable to the multi connector on the bottom of
the camera. This may cause a malfunction of the multi connector.
• Be sure to connect the USB cable to the (USB) jack on the back of the Cyber-
shot Station.
• Use caution when removing the AC adaptor.
• When you disconnect the cable, do not grasp the cable itself.
• Do not bend the cable or add stress to it.
Charging the battery
For the full performance of the battery pack, we recommend that you charge it
at temperatures between 10 °C and 30 °C (50 °F and 86 °F).
Care and maintenance
Clean the Cyber-shot Station with a soft cloth slightly moistened with water,
then wipe the surface with a dry cloth. Do not use any type of solvent such as
thinner, alcohol or benzine as this may damage the surface.

7-GB
6
7
8
1
2
34 5
Identifying the parts
See “Using the Remote Commander” (p.13) to identify parts of your Remote
Commander.
1Multi connector
2Blue illumination
Lights up in blue when the AC adaptor is connected.
Goes off when the camera is placed on the Cyber-shot Station.
3POWER lamp
Lights up in green when the AC adaptor is connected.
4CHARGE lamps
Light up while the battery is charging.
5Remote sensor
6DC IN jack
7(USB) jack
8A/V OUT (MONO) jack

8-GB
Before using the Cyber-shot Station
Refer to the operating instruction for your camera as well as this manual.
Placing the camera on the Cyber-shot Station /
Removing the camera from the Cyber-shot Station
1Connect the AC adaptor to the DC IN jack of the Cyber-shot Station.
You must use either the AC adaptor (AC-LS5/LS5B) comes with the Cyber-
shot, or an optional AC adaptor (AC-LS5).
2Place the camera on the Cyber-shot Station as illustrated.
–Make sure the camera is securely attached to the Cyber-shot Station.
Cyber-shot Station
AC adaptor To a wall outlet
(wall socket)
DC plug Power cord (mains lead)

9-GB
3Remove the camera from the Cyber-shot Station.
Holding both the camera and the Cyber-shot Station, then remove the
camera as illustrated.
–Be sure to turn off the camera before placing it on the Cyber-shot Station
or removing it from the Cyber-shot Station.
–During the USB connection, do not remove the camera from the Cyber-
shot Station. The image data in the camera may be damaged.

10-GB
Charging the battery pack
1Open the battery/“Memory Stick” cover of the camera.
2Install the battery pack into the camera, then close the battery/
“Memory Stick” cover.
3Connect the AC adaptor to the DC IN jack of the Cyber-shot Station.
Connect the power cord (mains lead) to the AC adaptor and to a wall
outlet (wall socket).
–You must use either the AC adaptor (AC-LS5/LS5B) comes with the
Cyber-shot, or an optional AC adaptor (AC-LS5).
–Do not short the DC plug of the AC adaptor with a metalic object, as this
may cause a malfunction.
4Place the camera on the Cyber-shot Station.
Charging starts automatically. Both the /CHG lamp of the camera and the
CHARGE lamps of the Cyber-shot Station light up.
While charging, the CHARGE lamps of the Cyber-shot Station light up one
by one, from the left to the right. When charging is completed, the /CHG
lamp of the camera and the CHARGE lamps of the Cyber-shot Station go off.
Note: The CHARGE lamps do not indicate the charging level of the battery.
–When charging the battery pack, make sure the camera is turned off.
–Make sure the camera is securely attached to the Cyber-shot Station.
