Sony EVI-R10 User manual

COMMUNICATION CAMERA MODULE
EVI-R10/R11
R50/R51
Component/OEM
●High-Quality Picture using DSP
●Multi-Purpose Color Camera for Communication
●Elastic Arm
●Close up to 10mm
●Microphone included
●Adjustable Focus, Adjustable Iris Lens
●AC Adapter, AV Cable Supplied

DEMENSIONS
CONNECTION
SPECIFICATIONS
EVI-R10(NTSC)EVI-R11(PAL)EVI-R50(NTSC)EVI-R51(PAL)
Image Sensor
Effective Pixels
H. Resolution
Lens
H. Angle of View
S/N Ratio
Focus
Iris
White Balance
Electronic Shutter
Video Out
(75ΩTermination)
Audio Out
Min. illumination
Power Requirement
Dimensions(W/H/D)
Weight
Supplied Accessory
1/4" Hyper HAD Color CCD
510(H)
×
494(V)500(H)
×
582(V)500(H)
×
582(V) 510(H)
×
494(V)
1/601/100sec. 1/50sec. 1/50sec.1/60/1/100sec.
more than 300TV lines
f=3.9mm, F=1.8, 10mm to ∞
50˚
more than 46dB
Manual
Manual
-10dBs 245m Vrms, 10kΩ, Monaural
9lx/F1.8
DC6.0V, 1.8W
Auto
Y:VS1.0Vp-p sync negative
C:Burst 0.286Vp-p
VBS:1.0Vp-p Composite
Y:VS1.0Vp-p sync negative
C:Burst 0.300Vp-p
VBS:1.0Vp-p Composite
Y:VS1.0Vp-p sync negative
C:Burst 0.286Vp-p
VBS:1.0Vp-p Composite
Y:VS1.0Vp-p sync negative
C:Burst 0.300Vp-p
VBS:1.0Vp-p Composite
Body 93
×
43
×
134mm
Camera Head 25
×
22
×
73mm
Arm 248mm
Body 93
×
43
×
134mm
Camera Head 25
×
22
×
73mm
Arm 500mm
650g 700g
AC Adapter, AV Cable
Design and specifications are subject to change without notice
●
Sony Electronics Inc. (USA) HQ
●
Sony of Canada Ltd. (CANADA)
●
Sony Broadcast & Professional Europe HQ
Germany
France
UK
Nordic
Italy
●
Sony Corp. B&P Systems Co. ISP Dpt. (JAPAN)
1 Sony Drive Park Ridge, NJ 07656
411 Gordon Baker Road, Willowdale, Ontario M2H 2S6
15, rue Floreal 75831 Paris Cedex 17, France
Hugo-Eckener-Str. 20, 50829 Koln
15, rue Floreal 75831 Paris Cedex 17
The Heights, Brooklands, Weybridge, Surrey KT13 0XW
Per Albin Hanssons vag 20 S-214 32 Malmo Sweden
Via Galileo Galilei 40 I-20092 Cinisello Balsamo, Milano
4-16-1 Okata, Atsugi-shi, Kanagawa-Ken, 243-0021
(TEL:[phone])(
FAX:[phone])
http://www.sony.com/professional
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
http://www.bpe.sony-europe.com
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
(TEL:[phone])(
FAX:[phone])
http://www.sony.co.jp/ISP/
98B
EVI-R10/R11 EVI-R50/R51
73
215(Aluminum pipe) 285(Flexible arm)
