Sony CDX-M3DI (XT-XM1) User manual

1
Ver 1.0 2003. 03
Model Name Using Similar Mechanism CDX-MP40
CD Drive Mechanism Type MG-393MC-121
Optical Pick-up Name KSS-721A
SERVICE MANUAL
US Model
Canadian Model
CDX-M3DI
AEP Model
UK Model
CDX-M1000TF
CDX-M3DI/M1000TF
AUDIO POWER SPECIFICATIONS (US Model)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
23.2 watts per channel minimum continuous average power into
4 ohms, 4 channels driven from 20 Hz to 20 kHz with no more
than 5% total harmonic distortion.
CD player section
Signal-to-noise ratio 90 dB
Frequency response 10 – 20,000 Hz
Wow and flutter Below measurable limit
Tuner section
FM
Tuning range 87.5 – 107.9 MHz (US, Canadian Model)
87.5 – 108.0 MHz (AEP, UK Model)
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity 9 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation 35 dB at 1 kHz
Frequency response 30 – 15,000 Hz
AM (US, Canadian Model)
Tuning range 530 – 1,710 kHz
Antenna terminal External antenna connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity 30 µV
SPECIFICATIONS
MW/LW (AEP, UK Model)
Tuning range MW : 531 – 1,602 kHz
LW : 153 – 279 kHz
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity MW : 30 µV
LW : 40 µV
Power amplifier section
Outputs Speaker outputs
(sure seal connectors)
Speaker impedance 4 – 8 ohms
Maximum power output 52 W ×4 (at 4 ohms)
General
Outputs Audio outputs (front/rear)
Subwoofer output (mono)
Power antenna relay control terminal
Power amplifier control terminal
Inputs Telephone ATT control terminal
Illumination control terminal
BUS control input terminal
BUS audio input/AUX IN terminal
Remote controller input terminal (CDX-M1000TF only)
Antenna input terminal
• The tuner and CD sections have no adjustments.
Sony Corporation
e Vehicle Company
Published by Sony Engineering Corporation
9-877-152-01
2003C0400-1
© 2003. 03
– Continued on next page –
FM/AM COMPACT DISC PLAYER
US, Canadian Model
FM/MW/LW COMPACT DISC PLAYER
AEP, UK Model
Photo: CDX-M1000TF

2
CDX-M3DI/M1000TF
optical pick-up bloc
k
semi-fixed resistor
If the optical pick-up block is defective, please replace the whole
optical pick-up block.
Never turn the semi-fixed resistor located at the side of optical
pick-up block.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LASÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
Tone controls Bass: ±8 dB at 100 Hz
Treble: ±8 dB at 10 kHz
Loudness +8 dB at 100 Hz
+2 dB at 10 kHz
Power requirements 12 V DC car battery
(negative ground)
Dimensions Approx. 178 ×50 ×181 mm
(7 1/8 ×2 ×7 1/4 in.) (w/h/d)
Mounting dimensions Approx. 182 ×53 ×160 mm
(7 1/4 ×2 1/8 ×6 3/8 in.) (w/h/d)
Mass Approx. 1.6 kg
(3 lb. 8 oz.)
Supplied accessories Card remote commander RM-X131 (1) (CDX-M3DI)
Card remote commander RM-X132 (1) (CDX-M1000TF)
Parts for installation and connections
Front panel cover (1)
Note
This unit cannot be connected to a digital preamplifier or an equalizer
which is Sony BUS system compatible.
Design and specifications are subject to change without
notice.
NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK
OR BASE UNIT
The laser diode in the optical pick-up block may suffer electrostatic
breakdown because of the potential difference generated by the
charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic breakdown and also use
the procedure in the printed matter which is included in the repair
parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused on
the disc reflective surface by the objective lens in the optical pick-
up block. Therefore, when checking the laser diode emission, ob-
serve from more than 30 cm away from the objective lens.
Notes on Chip Component Replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
TEST DISCS
This set can playback CD-R and CD-ROM discs. The following
test discs should be used to check the capability:
CD-R test disc TCD-R082LMT (Part No. J-2502-063-1)
CD-RW test disc TCD-W082L (Part No. J-2502-063-2)
SERVICE NOTES
•US, Canadian model
•AEP, UK model
This label is located on the bottom of the chassis.

3
CDX-M3DI/M1000TF
Notes on CD-Rs (recordable CDs)/CD-RWs (rewritable
CDs)
This unit can play the following discs:
Type of discs Label on the disc
Audio CD
MP3 files
•Some CD-Rs/CD-RWs (depending on the equipment used for
its recording or the condition of the disc) may not play on this
unit.
•You cannot play a CD-R/CD-RW that is not finalized∗.
•You can play MP3 files recorded on CD-ROMs, CD-Rs, and
CD-RWs.
•A CD-R/CD-RW to which a session can be added can be played.
∗A process necessary for a recorded CD-R/CD-RW disc to be
played on the audio CD player.
EXTENSION CABLE AND SERVICE POSITION
Whenrepairingor servicingthisset, connectthejig (extensioncable)
as shown below.
•Connect the MAIN board (CN402) and the SERVO board (CN1)
with the extension cable (Part No. J-2502-062-1).
NOTE FOR THE OPENING OF THE FRONT PANEL
In this set, the front panel is lowered to below the bottom face when
it is opened.
When servicing the set, place it on a stand having a height of about
2 cm.
FORCED FRONT PANEL OPEN/CLOSE
The front panel is forced to OPEN/CLOSE at the timing that the
power (ACC) is turned off.
If the Zbutton for the front panel is not effective, the following
method is used:
With the front panel open: The front panel is closed whenACC is
switched from ON to OFF edge.
With the front panel closed: The front panel is opened when ACC
is switched from ON to OFF edge.
NOTE FOR REPLACEMENT OF THE DIGITAL BOARD
When repairing, the complete DIGITAL board should be replaced
since any parts in the DIGITAL board cannot be repaired.
MAIN BOARD CN402
SERVO BOARD CN1
stand

4
CDX-M3DI/M1000TF
TABLE OF CONTENTS
1. GENERAL
Location of Controls (CDX-M3DI) ........................................ 5
Location of Controls (CDX-M1000TF) .................................. 5
Connections (CDX-M3DI) ...................................................... 6
Connections (CDX-M1000TF) ............................................... 7
2. DISASSEMBLY
2-1. Front Panel Assy ............................................................... 10
2-2. Sub Panel (CD)Assy ......................................................... 10
2-3. CD Mechanism Block ....................................................... 11
2-4. Digital Board ..................................................................... 11
2-5. Cam Block Assy, Motor Block Assy ................................. 12
2-6. Main Board ....................................................................... 12
2-7. Fan, Chassis Back ............................................................. 13
2-8. Chassis (T) Sub Assy ........................................................ 13
2-9. Lever Section..................................................................... 14
2-10. Servo Board....................................................................... 14
2-11. Shaft Roller Assy, Load SW Board ................................... 15
2-12. Floating Block Assy .......................................................... 16
2-13. Optical Pick-up Block .......................................................16
3. PHASE ALIGNMENT
3-1. Gear (Cam L) .................................................................... 17
3-2. Gear (Cam R) .................................................................... 17
4. DIAGRAMS
4-1. IC Pin Descriptions ........................................................... 18
4-2. Block Diagram –CD Section–........................................... 22
4-3. Block Diagram –Main Section–........................................ 23
4-4. Block Diagram –Display Section–.................................... 24
4-5. Circuit Boards Location .................................................... 25
4-6. Printed Wiring Board –CD Mechanism Section (1/2)– .... 26
4-7. Printed Wiring Boards –CD Mechanism Section (2/2)–... 27
4-8. Schematic Diagram –CD Mechanism Section (1/2)– ....... 28
4-9. Schematic Diagram –CD Mechanism Section (2/2)– ....... 29
4-10. Printed Wiring Board –Main Section (1/2)– ..................... 30
4-11. Printed Wiring Boards –Main Section (2/2)–.................... 31
4-12. Schematic Diagram –Main Section (1/4)– ........................ 32
4-13. Schematic Diagram –Main Section (2/4)– ........................ 33
4-14. Schematic Diagram –Main Section (3/4)– ........................ 34
4-15. Schematic Diagram –Main Section (4/4)– ........................ 35
4-16. Printed Wiring Boards –Display Section– ........................ 36
4-17. Schematic Diagram –Display Section–............................. 37
4-18. IC Block Diagrams............................................................ 38
5. EXPLODED VIEWS
5-1. Chassis Section ................................................................. 42
5-2. Cam Section ...................................................................... 43
5-3. Main Board Section .......................................................... 44
5-4. Front Panel Section ........................................................... 45
5-5. CD Mechanism Section (1) ............................................... 46
5-6. CD Mechanism Section (2) ............................................... 47
5-7. CD Mechanism Section (3) ............................................... 48
6. ELECTRICAL PARTS LIST ........................................ 49

5
CDX-M3DI/M1000TF
SECTION 1
GENERAL This section is extracted
from instruction manual.
(CDX-M3DI) (CDX-M1000TF)

6
CDX-M3DI/M1000TF
Connections (CDX-M3DI)

77
CDX-M3DI/M1000TF
Connections (CDX-M1000TF)

88
CDX-M3DI/M1000TF

9
CDX-M3DI/M1000TF
SECTION 2
DISASSEMBLY
Note : This set can be disassemble according to the following sequence.
2-1. FRONT PANEL ASSY
(Page 10)
2-2. SUB PANEL (CD) ASSY
(Page 10)
SET
2-3. CD MECHANISM BLOCK
(Page 11)
2-5. CAM BLOCK ASSY,
MOTOR BLOCK ASSY
(Page 12)
2-6. MAIN BOARD
(Page 12)
2-4. DIGITAL BOARD
(Page 11)
2-7. FAN, CHASSIS BACK
(Page 13)
2-8. CHASSIS (T) SUB ASSY
(Page 13)
2-9. LEVER SECTION
(Page 14)
2-11. SHAFT ROLLER ASSY,
LOAD SW BOARD
(Page 15)
2-12. FLOATING BLOCK ASSY
(Page 16)
2-13. OPTICAL PICK-UP BLOCK
(Page 16)
2-10. SERVO BOARD
(Page 14)

10
CDX-M3DI/M1000TF
Note : Follow the disassembly procedure in the numerical order given.
2-1. FRONT PANEL ASSY
2-2. SUB PANEL (CD) ASSY
1 screws (thin head M1.4)
2 screws (thin head M1.4)
4 CN201
5 front panel assy
3 cover (FPC)
(Take care not to pull the
flexible board excessively)
1 PTT 2.6x6
4 sub panel (CD) assy
2 claws
3 claws

11
CDX-M3DI/M1000TF
2-4. DIGITAL BOARD
2-3. CD MECHANISM BLOCK
2 PTT 2.6x4
5 PTT 2.6x6
1 PTT 2.6x4
3 CN402
4 CD mechanism block
6 bracket (CD)
3 DIGITAL board
1 CN801
2 PTT 2.6x6
ground point

12
CDX-M3DI/M1000TF
2-5. CAM BLOCK ASSY, MOTOR BLOCK ASSY
2-6. MAIN BOARD
1 PTT 2.6x6
5 cover (protection)
4 PTT 2.6x6
6 motor block assy
2 cam block assy
3 CN601
1 PTT 2.6x
8
2 PTT 2.6x8
3 PTT 2.6x6
ground point
4 PTT 2.6x6
ground point
5 MAIN board

13
CDX-M3DI/M1000TF
2-8. CHASSIS (T) SUB ASSY
2-7. FAN, CHASSIS BACK
qf duct (fan) assy
qg fan
qh CN802
3 CN302
7 CN201
1 PTT 2.6x8
4 PTT 2.6x8
8 PTT 2.6x8
qd PTP 2x18
0 PTT 2.6x8
qa PTT 2.6x
8
qs PTT 2.6x8
9 PTT 2.6x12
2 cord
5 cord
6 Removal the solder.
qj heat sink
1 Unsoldering three lead wires.
4 chassis (T) sub ass
y
black
SERVO board
(SIDE A)
red
white
2 P 2x3
3 P 2x3

14
CDX-M3DI/M1000TF
2-10. SERVO BOARD
2-9. LEVER SECTION
4 two claws
1 special screw
7 lever (L)
6 lever (R)
3 tension spring (LR)
2 DISC IN SW board
5 guide (disc)
1 CN3
3 Removal the solders.
7 special screws
8 special screw
2 CN2
optical pick-up block
9 SERVO board
5 P2x3
6 loading motor assy
4 Unsolder the
lead wires.
black
yellow

15
CDX-M3DI/M1000TF
2-11. SHAFT ROLLER ASSY, LOAD SW BOARD
•When installing, take note of the positions
arm (roller) and washers. (Fig. 1)
Fig. 1
1 tension spring (RA)
2 arm (roller)
3 retaining ring (RA)
4 shaft retainer (roller)
5 shaft roller assy
shaft retainer (roller) shaft retainer (roller)
retaining ring (RA) arm
arm
washer washer
6 special screw
7 LOAD SW board

16
CDX-M3DI/M1000TF
2-12. FLOATING BLOCK ASSY
2-13. OPTICAL PICK-UP BLOCK
3 P 2x3
1 P 2x3
2 sled motor assy (M902)
5 optical pick-up (KSS-721A)
7 PICK-UP FLEXIBLE board
4 plate spring (feed)
6 shaft (feed) assy
1 tension spring (KF1)
7 compression spring (FL)
8 compression spring (FL)
6 floating block assy
5 Turn loading ring in the
direction of the arrow.
4 Fit lever (D) in the direction of the arrow.
2 damper (T)
3 damper (T)

17
CDX-M3DI/M1000TF
SECTION 3
PHASE ALIGNMENT
3-1. GEAR (CAM L)
3-2. GEAR (CAM R)
1 motor block assy
center mark
gear (cam L) position setting hole
2 PTT 2.6x
6
g
ear (cam R) position setting hole center mark
cam block ass
y
•Align the gear (cam L) position setting hole with the center mark on
thebracket before screwing the motor block assy to the mechanism
chassis.
1Align the gear (cam R) position setting hole with the center mark
on the bracket before screwing the cam block assy to the
mechanism chassis.
2Touch the gear (cam R) with fingers in the direction of rotation
and make sure that there is no phase difference with the R-side
position setting hole.

18
CDX-M3DI/M1000TF SECTION 4
DIAGRAMS
4-1. IC PIN DESCRIPTIONS
• IC5 CXD9684R-005 (DSP) (SERVO Board (1/2))
Pin No. Pin Name I/O Pin Description
1/RESET I Reset signal input (L: reset)
2MIMD I Microcomputer interface mode selection signal input (H: I2C, L: TSB) (Fixed at H)
3, 4 AD0, AD1 O External S-RAM address signal output 0, 1
5MIDIO (I2C_SDA) I/O Serial data input/output
6MICK (I2C_SCL) I Serial clock signal input
7AD2 O External S-RAM address signal output 2
8VDDT (3.3V) — Power supply pin (+3.3V) for digital circuit
9SDO O Data output 0
10, 11 AD3, AD4 O External S-RAM address signal output 3, 4
12 SDI0 I Data input 0
13 BCKIA I Bit clock signal input A
14 LRCKIA I LR clock signal input A
15 AD5 O External S-RAM address signal output 5
16 CE O External S-RAM chip enable signal output
17 OE O External S-RAM output enable signal output
18 VDD (2.5V) — Power supply pin (+2.5 V) for digital circuit
19 STANDBY I Standby mode control signal input (H: STB, L: normal)
20 VSS (2.5GND) — Ground for digital circuit
21 VSSL (2.5GND) — Ground for DAC L-ch
22 VRAL — Reference voltage pin for DAC L-ch
23 LO O DAC L-ch signal output (Open)
24 VDAL (2.5V) — Power supply pin (+2.5 V) for DAC L-ch
25 VDAR (2.5V) — Power supply pin (+2.5 V) for DAC R-ch
26 RO O DAC R-ch signal output (Open)
27 VRAR — Reference voltage pin for DAC R-ch
28 VSSR (2.5GND) — Ground for DAC R-ch
29 TESTP I Test pin (H: test mode, L: normal) (Fixed at L)
30 CKS I VCO selection signal input (H: VCO, L: X1 input) (Fixed at H)
31 to 34 AD12 to AD9 O External S-RAM address signal output 12 to 9
35 VDDT (3.3V) — Power supply pin (+3.3 V) for digital circuit
36 to 38 AD8 to AD6 O External S-RAM address signal output 8 to 6
39 REQ O Interrupt request signal output for CD master control IC
40 VSS — Ground for digital circuit
41, 42 AD13, AD14 O External S-RAM address signal output 13, 14
43 WR O External S-RAM write signal output
44, 45 AD16, AD15 O External S-RAM address signal output 16, 15
46, 47 IO0, IO1 I/O External S-RAM data input/output 0, 1
48 VSS — Ground for digital circuit
49 to 51 IO2 to IO4 I/O External S-RAM data input/output 2 to 4
52 VDD (2.5V) — Power supply pin (+2.5 V) for digital circuit
53 to 55 IO5 to IO7 I/O External S-RAM data input/output 5 to 7
56 VSSP — Ground for VCO circuit
57 PDO O PLL phase error detection signal output
58 VCOI I VCO control voltage input
59 VDDP — Power supply pin (+2.5 V) for VCO circuit
60 XRDE I/O External clock input/audio clock output (Open)
61 VDDX (2.5V) — Power supply pin (+2.5 V) for oscillation circuit
62 XI I Resonator input
63 XO O Resonator output
64 VSSX — Ground for oscillation circuit

19
CDX-M3DI/M1000TF
• IC3 HD6432238RWN35TEI (CD MASTER CONTROL) (SERVO Board (2/2))
Pin No. Pin Name I/O Pin Description
1TEST I Test mode selection signal input (Open)
2 DECXRST O Reset signal output for DSP IC (L: reset)
3 DECSTBY O Standby mode control signal output for DSP IC (H: standby)
4 to 7 NC O Not used (Open)
8PH3 I CD PH3 photo sensor detection signal input (Open)
9INSW/PH2 I CD mechanism disc in switch detection signal input
10 LIMIT_SW I CD mechanism limit switch detection signal input
11 D_SW I CD mechanism down switch detection signal input
12 CVCC — System power supply pin (+3.3 V)
13 NC O Not used (Open)
14 VSS — Ground
15 NC O Not used (Open)
16 PH1 I CD PH1 photo sensor detection signal input (Open)
17 EJECT O CD mechanism loading motor control signal output (Eject direction)
18 LOAD O CD mechanism loading motor control signal output (Load direction)
19 to 26 NC O Not used (Open)
27 FLAG I Correction unable detection signal input
28 RFOK I RFOK signal input from digital servo IC
29, 30 NC O Not used (Open)
31 TXD O UART TXD PC connection output (Open)
32 RXD I UART RXD PC connection input (Open)
33 XTALEN O Crystal oscillation control signal output for digital servo IC
34 TSTB O CD text parameter strobe signal output for digital servo IC
35 STB O Data strobe signal output for digital servo IC
36 A0 O Command/parameter identification signal output for digital servo IC (L: command,
H: parameter)
37 CD_RST O Reset signal output for digital servo IC
38 PACK I CD text pack sync signal input from digital servo IC
39 NC O Not used (Open)
40 SELF_SW I CD mechanism self switch detection signal input
41 NC O Not used (Open)
42 AVSS — Analog ground
43, 44 NC O Not used (Open)
45, 46 NC I Not used (Open)
47, 48 KEY0, KEY1 I Key switch signal input 0, 1 (Open)
49 to 52 NC I Not used (Open)
53 AVREF — A/D converter reference voltage pin (+3.3 V)
54 AVCC — A/D converter power supply pin (+3.3 V)
55, 56 MD0, MD1 I Operation mode input 0, 1 (Fixed at H)
57 X1A I Sub clock oscillation signal input (Open)
58 X0A O Sub clock oscillation signal output (Open)
59 RSTX I Microcomputer reset signal input
60 NMI — Not used (Fixed at H)
61 STBY — Not used (Fixed at H)
62 VCC — Power supply pin (+3.3 V)
63 XTAL I Main clock oscillation signal input (12.288 MHz)
64 VSS — Ground
65 EXTAL O Main clock oscillation signal output (12.288 MHz)
66 FWE I Flash write enable signal input
67 MD2 I Operation mode input 2
68 FL_BOOT I Flash write selection signal input (L: flash write mode)
69 FL-W O Flash write control signal output

20
CDX-M3DI/M1000TF
Pin No. Pin Name I/O Pin Description
70 NC O Not used (Open)
71 CDMON O CD mechanism power supply control signal output
72 DECINT I Interrupt signal input from DSP IC
73 CLOSE O Front panel operation request signal output (Close)
74 OPEN O Front panel operation request signal output (Open)
75 LINKOFF O LINK OFF signal output (L: link on, H: link off)
76 UNI_SO O SONY-BUS serial data output
77 UNI_SI I SONY-BUS serial data input
78 UNI_CK I SONY-BUS serial clock signal input
79 NC O Not used (Open)
80 SDA I/O I2C interface data input/output
81 SCL O I2C interface clock signal output
82 NC O Not used (Open)
83 TSO O Serial data output for digital servo IC
84 TSI I Serial data input from digital servo IC
85 TSCK O Serial clock signal output for digital servo IC
86 LEDDAT O LED data output (Open)
87 LEDCLK O LED clock signal output (Open)
88 LEDLAT O LED latch signal output (Open)
89,90 NC O Not used (Open)
91 BUSON I SONY-BUS BUS ON signal input
92 BUCHK I Back-up power supply detection signal input
93 A-ATT O Audio mute control signal output
94 CDON O Power control signal output (L: during loading, H: servo on)
95 NC O Not used (Open)
96 U/J_SEL I Destination selection signal input (Fixed at L)
97 TEXTSEL I CD text function setting signal input (Fixed at L)
98 NC O Not used (Open)
99 CFSEL I Custom file function setting signal input (Fixed at L)
100 DOUT_SEL I Digital output selection setting signal input (H: digital out available)
