Sony XR-CA330 Installation/Connection User manual

Design and Specifications subject to change without notice.
XR-CA330
FM/AM Cassette Car Stereo
Tape track 4-track 2-channel stereo
Wow and flutter 0.1 %(WRMS)
Frequency response 0  15,000 Hz
Signal-to-noise ratio 55 dB
General
Cassette Player Section
FM
Tuning range FM tuning interval:
87.5  107.9 MHz (at 200 kHz step)
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz
Usable sensitivity 11 dBf
Selectivity 75 dB at 400 kHz
Signal-to-noise ratio 62 dB (stereo), 68 dB (mono)
Harmonic distortion at 1 kHz 0.7 %(stereo), 0.5 %(mono)
Separation dB at 1 kHz
Frequency response 0  15,000 Hz
AM
Tuning range AM tuning interval:
5 0  1,710 kHz (at 10 kHz step)
Aerial terminal External aerial connector
Intermediate frequency 10.7 MHz/450kHz
Sensitivity 0 µV)
Outputs Speaker outputs
Speaker impedance 4  8 ohms
Maximum power output 45 W × 4 (at 4 ohms)
Outputs Audio output
Power aerial relay control lead
Power amplifier control lead
Inputs Bus control input terminal
Bus audio input terminal
Antenna input terminal
Tone controls Bass ±10 dB at 20 Hz
Treble ±10 dB at 20 kHz
Power requirements 12 V DC car battery (negative earth)
Dimensions Approx.178 × 50 × 178 mm
(7 1/8 × 2 × 7 1/8 in.) (w/h/d)
Mounting dimensions Approx.182 × 5 × 161 mm
(7 1/4 × 2 1/8 × 6 /8 in.) (w/h/d)
Mass Approx.1.2 kg (2 lb 10 oz.)
Supplied accessories Parts for installation and connections (1 set)
Front panel case (1)
Power Amplifier Section
2002 SONY MOBILE
PRODUCT GUIDE
Tuner Section
Audio Power Specifications
 CD/MD Control
 CD TEXT®
 XM Ready
 Detachable Faceplate
 45W x 4 High Power
 Rear Preout
 D-Bass
 MBP (My Best Position)
 SSIR-EX Tuner
 18FM + 12AM memory presets
 Best Tuning memory
 Active Display w/Demo Mode
 1 -segment LCD
 Quartz clock
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
22 watts per channel minimum continuous average power into 4 ohms, 4 channels
driven from 20 Hz to 20 kHz with no more than 5 % total harmonic distortion.
Plug shown with wires facing viewer.
Pin Number Wire Color Description
1 White Left front +
2 Green Left rear +
Purple Right rear +
4 Gray Right front +
5 Blue/white AMP Remote
6 Blue ANT Remote
7 Red Accessory
8 Black Ground
9 White/black Left front -
10 Green/black Left rear -
11 Purple/black Right rear -
12 Gray/black Right front -
1 Sky blue ATT
14
15
16 Yellow Battery
Harness Plug Configuration
16
1 2 4 5 6 7 8
9 10 11 12 1 14 15
178 mm (7)
2002 SONY MOBILE
PRODUCT GUIDE
XR-CA330
FM/AM Cassette Car Stereo
50 mm (2)
Fuse (10A)
From car antenna BUS Control IN
184 mm (7 1/4)
158 mm (6 1/16)
50 mm (2)
47 mm (1 7/16)
5 mm ( 2 1/16)
88 mm ( 7/16)
Design and Specifications subject to change without notice.
Audio OUT
BUS Audio IN
mm (1 5/16)
27 mm (1 1/16)
