Sony Cfd-e55l User manual

MICROFILM

SERVICE MANUAL

CD RADIO CASSETTE-CORDER

AEP Model

UK Model

SPECIFICATIONS

CFD-E55L

CD Model Name Using Similar Mechanism CFD-Z500

Section CD Mechanism Type KSM-213CDM

Optical Pick-up Name KSS-213C

TAPE Model Name Using Similar Mechanism CFD-Z500

Section Tape Transport Mechanism Type MF-Z500-117

IF

FM: 10.7 MHz

MW/LW: 450 kHz

Aerials

FM: Telescopic aerial

MW/LW: Built-in ferrite bar aerial

Cassette-cordersection

Recording system

4-track 2 channel stereo

Fast winding time

Approx. 120 sec. with Sony cassette C-60

Frequency response

TYPE I (normal): 70 - 13,000 Hz

General

Speaker

Full range: 8 cm (3

1

⁄

4

in.) dia.,

3.2 ohms, cone type (2)

Outputs

Headphones jack (stereo minijack)

For 16 - 68 ohms impedance headphones

Maximum power output

2 W + 2 W

Power requirements

For CD radio cassette-corder:

230 V AC, 50 Hz

9 V DC, 6 R20 (size D) batteries

For memory back-up:

4.5 V DC, 3 R6 (size AA) batteries

CD playersection

System

Compact disc digital audio system

Laser diode properties

Material: GaAlAs

Wave length: 780 nm

Emission duration: Continuous

Laser output: Less than 44.6 µW

(This output is the value measured at a distance of

about 200 mm from the objective lens surface on

the optical pick-up block with 7 mm aperture.)

Spindle speed

200 r/min (rpm) to 500 r/min (rpm) (CLV)

Number of channels

2

Frequency response

20 - 20,000 Hz +0/–0.5 dB

Wow and flutter

Below measurable limit

Radio section

Frequency range

FM 87.5 - 108 MHz

MW 531 - 1,611 kHz

LW 153 - 279 kHz

Power consumption

AC 17 W

Battery life

For CD radio cassette-corder:

FM recording

Sony manganese SUM-1 (N): approx. 9 h

Sony alkaline AM-1 (N): approx. 19 h

Tape playback

Sony manganese SUM-1 (N): approx. 5 h

Sony alkaline AM-1 (N): approx. 14 h

CD playback

Sony manganese SUM-1 (N): approx. 1.5 h

Sony alkaline AM-1 (N) : approx. 7 h

Dimensions

Approx. 304 ×169 ×262 mm (w/h/d)

(12 × 6

3

⁄

4

×10

3

⁄

8

inches)

(incl. projecting parts)

Mass

Approx. 3.6 kg (7 lb. 15 oz) (incl. batteries)

Supplied accessories

AC power cord (1)

Design and specifications are subject to change

without notice.

Ver 1.0 1999. 11

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 2 –

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED

LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS

AND IN THE PARTS LIST ARE CRITICAL TO SAFE

OPERATION. REPLACE THESE COMPONENTS WITH

SONY PARTS WHOSE PART NUMBERS APPEAR AS

SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-

LISHED BY SONY.

CAUTION

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous ra-

diation exposure.

1. SERVICING NOTES.............................................. 3

2. GENERAL .................................................................. 4

3. DISASSEMBLY ........................................................ 7

4. MECHANICAL ADJUSTMENTS...................... 12

5. ELECTRICAL ADJUSTMENTS

Tape Deck Section ......................................................... 12

Tuner Section ................................................................. 13

CD Section ..................................................................... 15

6. DIAGRAMS

6-1. Block Diagram – CD Section – .................................... 17

6-2 Block Diagram – TUNER Section – ............................ 19

6-3. Block Diagram – MAIN Section – ............................... 21

6-4. Block Diagram – POWER SUPPLY Section – ............ 23

6-5. Printed Wiring Boards – CD Section – ........................ 27

6-6. Schematic Diagram – CD Section – ............................. 29

6-7. Printed Wiring Boards

– MAIN/POWER SUPPLY Section – ........................... 32

6-8. Schematic Diagram – MAIN (TUNER) Section – ...... 35

6-9. Schematic Diagram

– MAIN (AUDIO)/POWER SUPPLY Section – .......... 40

6-10. IC Pin Function Description .......................................... 43

6-11. Printed Wiring Boards – DISPLAY Section – ............. 45

6-12. Schematic Diagram – DISPLAY Section – .................. 47

7. EXPLODED VIEWS ............................................... 54

8. ELECTRICAL PARTS LIST .............................. 61

This appliance is classified as a CLASS 1 LASER product.

The CLASS 1 LASER PRODUCT MARKING is located on

the rear exterior.

Laser component in this product is capable of emitting radiation

exceeding the limit for Class 1.

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 3 –

SECTION 1

SERVICING NOTES

CHUCK PLATE JIG ON REPAIRING

On repairing CD section, playing a disc without the CD lid, use

Chuck Plate Jig.

• Code number of Chuck Plate Jig: X-4918-255-1

The laser diode in the optical pick-up block may suffer electro-

static break-down because of the potential difference generated

by the charged electrostatic load, etc. on clothing and the human

body.

During repair, pay attention to electrostatic break-down and also

use the procedure in the printed matter which is included in the

repair parts.

The flexible board is easily damaged and should be handled with

care.

NOTES ON LASER DIODE EMISSION CHECK

The laser beam on this model is concentrated so as to be focused

on the disc reflective surface by the objective lens in the optical

pick-up block. Therefore, when checking the laser diode emis-

sion, observe from more than 30 cm away from the objective lens.

Notes on chip component replacement

• Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be dam-

aged by heat.

LASER DIODE AND FOCUS SEARCH OPERATION

CHECK

1. Turn POWER switch on with no disc inserted and make Func-

tion switch to CD position.

2. Open the lid for CD.

3. Turn on S701 as following figure.

4. Press the ubutton.

5. Confirm the laser diode emission while observing the object-

ing lens. When there is no emission, Auto Power Control cir-

cuit or Optical Pick-up is broken.

Objective lens moves up and down three times for the focus

search.

NOTES ON HANDLING THE OPTICAL PICK-UP

BLOCK OR BASE UNIT

S701

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 4 –

SECTION 2

GENERAL This section is extracted from

instruction manual.

Basic Operations

4

GB

Playing a CD

Basic Operations

Display

Playing timeTrack number

With the label side up

31, 2

Connect the supplied AC power cord (see page 26).

1

Press ZPUSH OPEN/CLOSE

down to open the CD

compartment and place the CD

on the CD compartment.

2

Close the lid of the CD

compartment.

3

Press u.

The player turns on (direct

power-on) and plays all the tracks

once.

O

P

E

N

/

C

L

O

S

E

Z

P

U

S

H

O

P

E

N

/

C

L

O

S

E

Z

P

U

S

H

T

U

N

E

T

I

M

E

S

E

T

Basic Operations

5

GB

Use these buttons for additional operations

To Press

adjust the volume VOL +, –

stop playback x

pause playback u

Press the button again to

resume play after pause.

go to the next track >

go back to the previous track .

remove the CD ZPUSH OPEN/CLOSE

turn on/off the player OPERATE

(or POWER, see page 2)

Tip

Next time you want to

listen to a CD, just press

u. The player turns on

automatically and starts

playing the CD.

OPERATE

x

u

., >

VOL –, +

ZPUSH

OPEN/CLOSE

Basic Operations

6

GB

Listening to the radio

Connect the supplied AC power cord (see page 26).

1

Press RADIO BAND until the

band you want appears in the

display (direct power-on).

2

Hold down TUNE TIME SET + or

– until the frequency digits begin

to change in the display.

The player automatically scans

the radio frequencies and stops

when it finds a clear station.

If you can't tune in a station,

press the button repeatedly to

change the frequency step by

step.

Display

Indicates an FM stereo

broadcast

1

2

B

A

N

D

R

A

D

I

O

VOL

T

U

N

E

T

I

M

E

S

E

T

Basic Operations

7

GB

Use these buttons for additional operations

To Press

adjust the volume VOL +, –

turn on/off the radio OPERATE

To improve broadcast reception

Reorient the antenna for FM. Reorient the player itself

for MW/LW.

for FM for MW/LW

Tips

• If the FM broadcast is

noisy, press PLAY

MODE •MONO/ST ISS

until “Mono” appears in

the display and the

radio will play in

monaural.

• Next time you want to

listen to the radio, just

press RADIO BAND.

The player turns on

automatically and starts

playing the previous

station.

OPERATE

VOL –, +

PLAY MODE

MONO/ST ISS

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 5 –

Basic Operations

8

GB

Playing a tape

Connect the supplied AC power cord (see page 26).

1

Press xZ to open the tape

compartment and insert a

recorded tape. Use TYPE I

(normal) tape only. Close the

compartment.

2

Press N.

The player turns on (direct

power-on) and starts playing.

With the side you want

to play facing you

Display

12

STOP/EJECT

PLAY

Basic Operations

9GB

Use these buttons for additional operations

To Press

adjust the volume VOL +, –

stop playback xZ

fast-forward or rewind the tape Mor m

pause playback X

Press the button again to

resume play after pause.

eject the cassette xZ

turn on/off the player OPERATE

Tip

Next time you want to

listen to a tape, just

press N. The player

turns on automatically

and starts playing the

tape.

xZ

X

m, M

OPERATE

VOL –, +

Basic Operations

10

GB

Recording on a tape

Connect the supplied AC power cord (see page 26).

1

Press xZ to open the tape

compartment and insert a blank

tape. Use TYPE I (normal) tape

only.

2

Select the program source you

want to record.

To record from the CD player,

insert a CD (see page 4) and press

xon the CD section.

To record from the radio, tune in

the station you want (see page 6).

31

With the side you want to

record on facing you

Display

STOP/EJECT

OPERATE

OPR/BATT

B

A

N

D

R

A

D

I

O

VOL

Basic Operations

11

GB

3

Press zto start recording

(Nis depressed automatically).

Use these buttons for additional operations

Tips

• Adjusting the volume or

the audio emphasis (see

page 28) will not affect

the recording level.

• If the MW/LW program

makes a whistling

sound after you've

pressed zin step 3,

press PLAY MODE•

MONO/ST ISS

(Interference Suppress

switch) repeatedly until

the noise is at a

minimum.

• For the best results, use

the AC power as a

power source.

• To erase a recording,

proceed as follows:

1 Insert the tape whose

recording you want to

erase.

2 Press X.

3 Press N.

4 Press z.

5 Press X.

To Press

stop recording xZ

pause recording X

Press the button again to

resume recording.

turn on/off the player OPERATE

xZ

X

OPERATE

PLAY MODE

MONO/ST ISS

N

REC

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 6 –

The Timer

20

GB

Before you set the clock, connect the power source (see

page 26).

1

Press CLOCK for 2 seconds until the hour digit

flashes.

2

Press TUNE TIME SET + or – until you set the

current hour. Then press DSPL ENT MEM.

The minute digits flash. Set the minutes by

pressing TUNE TIME SET + or – until the correct

minute is displayed.

3

Press DSPL ENT MEM.

The clock starts from 00 seconds.

Setting the clock

“– –:– –” indication appears in the

display until you set the clock.

The Timer

Tip

The time display

system:

24-hour system

,

CLOCK

DSPL

ENT MEM

TUNE

TIME SET –, +

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 7 –

SECTION 3

DISASSEMBLY

• This set can be disassembled in the order shown below.

Note: Follow the disassembly procedure in the numerical order given.

LOWER CABINET SECTION

Set Lower cabinet

section MAIN board

Tape mechanism

deck section Cassette lid assy

and cassette holder

Head (HRP301), Motor assy (M301)

and belt

CD board Optical pick-up

section

Front cabinet

section

CD lid

section

2

three screws

(BTP3

×

12)

3

lower cabinet section

4

connector

(CNP310)

2

five screws

(BTP3

×

12)

1

battery case li

d

4

two connectors

(CNP704, CNP308)

4

connector

(CNP307)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 8 –

FRONT CABINET SECTION

MAIN BOARD

2

two screws

(BTP3

×

12)

A

1

three connectors

(CNP302, 303, 309)

2

two screws

(BTP3

×

12)

3

Remove the front

cabinet section in

the arrow

A

direction.

rear cabinet

section

2

two screws

(BVTP3

×

10)

1

two connectors

(CNP304, 305)

1

three connectors

(CNP306, 311, 312)

2

two screws

(BVTP3

×

10)

3

MAIN board

1

connector

(CNP1)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 9 –

CD BOARD

OPTICAL PICK-UP SECTION

1

two screws

(BVTP3

×

10)

2

CD board

1

two screws

(BVTP3

×

10)

3

connector

(CNP702)

4

flat wire (16 core)

(CNP701)

3

connector

(CNP703)

1

two screws

(PWH2.6

×

10)

2

optical pick-up

section

1

two screws

(PWH2.6

×

10)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 10 –

CD LID SECTION

TAPE MECHANISM DECK SECTION

1

screws

(BVTP3

×

10)

5

Remove the boss.

6

CD lid section

2

damper

3

spring (CD)

4

Open the CD lid section

1

Push the button (ST/EJ).

2

Open the cassette lid assy.

4

tape mechanism deck section

3

two screws

(BVTP3

×

10

)

3

two screws

(BVTP3

×

10)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 11 –

CASSETTE LID ASSY AND CASSETTE HOLDER

HEAD (HRP301),MOTOR ASSY (M301) AND BELT

7

spring

(cassette)

8

boss

8

boss

3

two screws

(BVTP3

×

10

)

4

speaker (R ch)

1

two screws

(BVTP3

×

10)

2

bracket (SP)

5

screw

(BVTP3

×

10)

6

damper

9

cassette lid assy and

cassette holder

3

two screws

(B2.6

×

5)

1

connector

(CNP301)

4

motor assy (M301

)

5

belt

2

head (HRP301)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 12 –

SECTION 4

MECHANICAL ADJUSTMENTS SECTION 5

ELECTRICAL ADJUSTMENTS

Mode Tension Meter Meter Reading

FWD CQ-403A more than 100 g

(more than 3.53 oz)

• TapeTension Measurement

PRECAUTION

1. Clean the following parts with a denatured-alcohol-moistened

swab :

record/playback head pinch roller

erase head rubber belts

capstan idlers

2. Demagnetize the record/playback head with a head demagne-

tizer. (Do not bring the head magnetizer close to the erase head)

3. Do not use a magnetized screwdriver for the adjustments.

4. After the adjustments, apply suitable locking compound to the

parts adjusted.

5. The adjustments should be performed with the rated power

supply voltage unless otherwise noted.

• Torque Measurement

Mode Torque Meter Meter Reading

FWD CQ-102C 30 – 70 g•cm

(0.42 – 0.97 oz•inch)

FWD CQ-102C 1.5 – 5.5 g•cm

Back Tension (0.021 – 0.076 oz•inch)

FF CQ-201B more than 60 g•cm

(more than 0.83 oz•inch)

REW CQ-201B more than 60 g•cm

(more than 0.83 oz•inch)

Tape Speed Adjustment

Setting:

Function: TAPE

Procedure:

1. Playback WS-48A (tape center) in the FWD state.

2. Adjust the volume in CAPSTAN/REEL motor (M301) so that

the frequency counter reading becomes 3,000 Hz.

Specified Value: 2,985 to 3,015 Hz

3. Confirm that the frequency at the beginning and that at the

end of tape winding are between 2,955 to 3,045 Hz.

Adjustment Location:

PRECAUTION

Setting:

SOUND control : OFF

MEGA BASS control: OFF

TAPE DECK SECTION 0 dB=0.775 V

Test tape

Type Signal Used for

WS-48A 3 kHz, 0 dB Tape Speed Adjustment

Tape speed

Adjustment

CAPSTAN/REEL motor

(M301)

– TAPE deck block –

+

–

set

Test tape

WS-48A

(3 kHz, 0 dB) frequency counte

r

3.2

Ω

MAIN board

CNP311 pin

3

MAIN board

CNP311 pin

4

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 13 –

TUNER SECTION 0 dB=1 µV

[MW/LW]

Setting:

Function : RADIO

BAND button : MW or LW

[FM]

Setting:

Function : RADIO

BAND button: FM

• Repeat the procedures in each adjustment several times, and the

tracking adjustments should be finally done by the trimmer ca-

pacitors.

• Remove FM antenna in FM adjustment.

AM RF signal

generator

30% amplitude

modulation by

400 Hz signal

Output level: as low as possible

Put the lead-wire

antenna close to

the set.

+

–

level mete

r

set

3.2

Ω

MAIN board

CNP311 pin

3

MAIN board

CNP311 pin

4

FM RF signal

generator

22.5 kHz frequency

deviation by 400 Hz

signal

Output level: as low as possible

+

–

level meter

MAIN board

CNP311 pin

3

MAIN board

CNP311 pin

4

set

3.2

Ω

0.01

µ

F

MAIN board

TP (GND)

MAIN board

TP (ANT)

digital voltmete

r

TP (VT)

TP (GND)

100 k

Ω

MAIN board

AM IF ADJUSTMENT

Adjust for a maximum reading on level meter

T1 450 kHz

MW VCO VOLTAGE CONFIRMATION

Frequency Display Reading on Digital Voltmeter

531 kHz 1.0 ± 0.3 V

1,611 kHz 5.0 ± 0.4 V

MW TRACKING ADJUSTMENT

Adjust for a maximum reading on level meter

L3-1 621 kHz

CT2 1,404 kHz

LW VCO VOLTAGE ADJUSTMENT

Adjustment Part Frequency Display Reading on Digital Voltmeter

L4 153 kHz 0.6

Confirmation 279 kHz 4.7 ± 0.5 V

LW TRACKING ADJUSTMENT

Adjust for a maximum reading on level meter

L3-2 162 kHz

CT3 261 kHz

FM VCO VOLTAGE ADJUSTMENT

Adjustment Part Frequency Display Reading on Digital Voltmeter

L2 108 MHz 4.0 ± 0.1 V

Confirmation 87.5 MHz 1.6 ± 0.2 V

FM TRACKING ADJUSTMENT

Adjust for a maximum reading on level meter

L1 87.5 MHz

CT1 108 MHz

Adjustment Location: MAIN board (See page 14)

+ 0.1 V

– 0.05 V

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 14 –

Adjustment Location:

– MAIN BOARD (Component Side) –

T1

AM IF Adjustment

L1

CT1

FM Tracking

Adjustment LW Tracking

Adjustment

MW Tracking

Adjustment

L2

FM VCO Voltage

Adjustment

L4

LW VCO Voltage

Adjustment

CT2

L3-1

L3-2

CT3

CNP311

14

TP (GND)

TP (VT)

TP (ANT)

– MAIN BOARD (Conductor Side) –

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 15 –

CD SECTION

CD section adjustments are done automatically in this set.

In case of operation check, confirm that focus bias.

Focus Bias Check

1. Connect the oscilloscope to TP (RFO) and TP (GND) on the

CD board.

2. Insert the disc (YEDS-18). (Part No. : 3-702-101-01)

3. Press the [ ] (CD) button.

4. Confirm that the oscilloscope waveform is as shown in the

figure below. (eye pattern)

A good eye pattern means that the diamond shape (◊) in the

center of the waveform can be clearly distinguished.

• RF signal reference waveform (eye pattern)

VOLT/DIV: 0.2 V (with the 10: 1 probe in use)

TIME/DIV: 500 ns

1.2

±

0.1 Vp-p

When observing the eye pattern, set the oscilloscope

for AC range and raise vertical sensitivity.

Adjustment Location:

TP (RFO)

IC701

TP (GND)

– CD BOARD (Conductor Side) –

u

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

CFD-E55L

– 17 – – 18 –

SECTION 6

DIAGRAMS

6-1. BLOCK DIAGRAM – CD Section –

A

B

D4

7

6

4

7

6

F

E

C

I-V AMP

DETECTOR

39

38

17

18

26

27

2SL+

SL– SLO

F–

F+

T+

T–

SPINDLE

MOTOR DRIVE

M701

(SPINDLE)

S701

(LIMIT)

SLED

MOTOR DRIVE

1

M702

(SLED)

FOCUS

COIL DRIVE

TRACKING

COIL DRIVE

SP+ SPO

MUTE

SP– 9 1514

3

19

25

FIN

TIN

SLIN

SPIN SPI

SLP

FOCUS/TRACKING COIL DRIVE,

SPINDLE/SLED MOTOR DRIVE

IC702

16 14

SLED

AMP

LD

PD

LASER DIODE

OPTICAL PICK-UP

BLOCK

(KSS-213C)

2-AXIS

DEVICE

(FOCUS)

(TRACKING)

33

32

27

35

18

22

20

21

19

23

RF AMP,

FOCUS/TRACKING

SERVO

IC701 (1/2)

FOCUS OK

COMPARATOR

MIRR

AMP

DEFECT

AMP

FOCUS OK

AMP

IIL DATA REGISTER

3129

FILTER

3330

FILO

PCO

CLTV

FILI

XPCK

DIGITAL PLL

ASYMMETRY

CORRECTION EFM

DEMODULATOR

DIGITAL

OUT

ERROR

CORRECTOR 16K

RAM

INTERNAL BUS

SUB-CODE

PROCESSOR

OSC

CLOCK

GENERATOR

SERVO AUTO SEQUENCER

DIGITAL

CLV

14

12

41

43

39

13

79

5 4 6 7 9 8 57 58 59 62 70

11

10

41

42

36

37

1

40

45

2

47

12

11

6

25

24

13

PD1

PD1 I-V AMP

RFO RF

37 ASYI

38

48

ASYO

FOK

DATO

CLKO

XLTO

SEIN

CNIN

MDP

SQSO

SQCK

SENS

DATA

CLOK

XLAT

XLON

SPOA

SCOR

SBSO

EXCK

XUGF

WFCK

EMPH

EMPHI

SYSM

XTAI

71

XTAO

RFI

FOK

DATA

CLK

SENS1

26

SENS2

C.OUT

XLT

LOCK

PD2 I-V AMP

PD2

TTL

IIL

FEO

TEO

PD

FEI FEO

TAO

TEI

TTL

IIL

TTL

IIL

XRST

FOCUS

ERROR

AMP

RF

SUMMING

AMP

TRACKING

ERROR

AMP

TRACKING PHASE

COMPENSATION

FOCUS PHASE

COMPENSATION

AUTOMATIC

POWER CONTROL

Q701

I-V

AMP

LD

AMP PD

AMP

FE BIAS

F

E

LD

PCMD

53

DOUT

BCK

LRCK

PCMDI

BCKI

LRCKI

42

44

40

50

C2PO

SLED SERVO

IC701 (2/2)

05

DIGITAL SIGNAL PROCESSOR,

CLV SERVO, D/A CONVERTER

IC703

SYSTEM CONTROLLER

IC501 (1/3)

• SIGNAL PATH

: CD PLAY

21

CPU INTERFACE

D/A INTERFACE

SERIAL

INPUT

INTERFACE

PWM

OVER

SAMPLING

DIGITAL

FILTER

NOISE

SHAPER

56

54 55

AOUT2 65

XTSL 51

C4M 52

AOUT1

AIN2

AIN1

LOUT2

LOUT1

76

75 66

74 67

GFS

X701

16.9344MHz

49

47

8

3

8

3

10

12

10

12

14

15

14

15

13

16

13

16

55

CNP701

33

44

CNP702CNP707

+

CD BOARD (1/2)

CD MOTOR BOARD

M

11

22

55

66

M

XRST

C-SCOR

C-DOOR

1

78

C-LATCH

11

C-CLOCK

10

C-DATA

12

C-SENS

5

C-SQCK

7

C-SQSO

89

C-SENS2

6

C-RST

C-SCOR

C-XLAT

C-CLOK

C-DATA

C-SENS

C-SQCK

C-SQSO

C-SENS2

C-XRST

17 15

7

S701

(CD LID OPEN/CLOSE DET)

BH505

BH701 (1/2)

2

431

1

CNP703 74 56 8 132 9

BH503 74 56 8 132 9

R-CH

L-CH

B

TO MAIN

SECTION

(Page 21)

FROM MAIN

SECTION

(Page 21)

C-MUTE

A

LCD BOARD (1/3)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

CFD-E55L

– 19 – – 20 –

6-2. BLOCK DIAGRAM – TUNER Section –

2

24

4 7

20 21

FM

RF AMP FM

MIX

FM

OSC

FM IF

AMP

IF

BUFFER

AF

BUFFER AF

AMP MPX MUTE

STEREO/

MONO,

FM/AM

AM IF

AMP

FM

DET

AM

DET

6

FM RF

IN

22 AM

RF AMP

CONSTANT

CURRENT

Q3

LW BAND

SELECT SWITCH

Q9

MW BAND

SELECT SWITCH

Q8

AM

MIX

AM RF

IN

MIX OUT

OSC

OUT

CF1, 2

10.7MHz

CF3

10.7MHz

FM/AM PLL

IC2

CF4

450kHz

FM

RF OUT

10

QUAD

FM

IF IN 12

15 11

L-OUT

MPX

IN R-OUT

13

AM

IF IN

LPF1/BAND

AM OSC

FM OSC

FM/AM RF AMP, MIX, OSC,

FM/AM IF AMP, DET, MPX

IC1

L2

FM VCO VOLTAGE

L4

LW VCO VOLTAGE

CT1, L1

FM TRACKING T1

IFT

B.P.F.

FL1

LOW-PASS

FILTER

• SIGNAL PATH

: FM

: MW/LW

05

X1

75kHz

CT2

L1

FM RF

XOUT

XIN

AM IN

IF IN

ST-IND

MW

LP-OUT

LP-IN

FM IN

21

20

1213197

LW

6

CT1 D1

L4

MW/LW OSC L2

FM OSC

LEVEL

DET

ST

IND

14

LPF2/MO-ST

AM

OSC BUFFER

BUFFER

SWALLOW

COUNTER

UNIVERSAL

COUNTER

CCB

INTERFACE

REFERENCE

DIVIDER

UNLOCK

DETECT

12 BIT

PROGRAMMABLE

DIVIDER

PHASE

DETECTOR/

CHARGE PUMP

SHIFT REGISTER & LATCH

1/2

BAND

DI

CL

CE

DO

B-MUTE

R-DATA

R-CLOCK

R-LATCH

R-COUNT

R-CH

CNP1

CNP312

1DET

OUT

ANT1

FM TELESCOPIC

ANTENNA

PD

IF OUT

ST IND

3

4

2

5

11 10

LPF1/BAND

8

LPF2/MO/ST

14918 17

17 18

16

19

CT3

D2

D3

(1/2)

D3

(2/2)

IF REQUEST

SWITCH

Q2

AM HIGH

CUT

SWITCH

Q1

2

3

1

4

MAIN BOARD (1/3)

T1

AM IF

C

TO MAIN SECTION

(Page 21)

TUNER L-CH

FROM MAIN SECTION

(Page 21)

D

TO MAIN

SECTION

(Page 21)

E

R-CH: Same as L-CH.

Q6

Q4

Q5

B+

Q4, 5

MW SWITCH

L3-1

MW

L3-2

LW

L3

MW/LW FERRITE-ROD

ANTENNA

MW

TRACKING

CT2, L3-1 LW

TRACKING

CT3, L3-2

Q7

LW

SWITCH

Q6

LW SWITCH

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

CFD-E55L

6-3. BLOCK DIAGRAM – MAIN Section –

REC/PB EQ AMP

IC301

SOUND CONTROL,

ELECTRICAL VOLUME

IC302

POWER

AMP

IC303

05

C

FROM

TUNER SECTION

(Page 20)

G

FROM POWER

SUPPLY SECTION

(Page 24)

•SIGNAL PATH

: CD PLAY

: TUNER (FM/AM)

: TAPE PLAY

: TAPE RECORD

R-CH: Same as L-CH.

SHIFT

CLOCK

Q503

Q503, 504

SHIFT CLOCK

Q504

MODE CHECK

SWITCH

Q505

X501

4.19MHz

R-CH

MEGA BASS

CONTROL SWITCH

Q303

IN2

OUT2

L IN L OUT

S609, 610

Q313

Q312, 313

ISS SWITCHING

VREF

L.LO

MIC IN

L.CD

L.RAD

VREF

COM 5V

L.IN

L-CH

R-CH

XTAL

EXTAL

DATA

CLK

LAT

KEY1

KEY2

KEY3

RADIO

TAPE

REC

29

32 31

19 20 18

VC

23

BC

21

2725

LED

4 26

R-DATA

R-CLOCK

R-LATCH

R-COUNT

R-DATA

R-CLOCK

R-LATCH

R-COUNT

17

15

16

B-MUTE

67

C-MUTE

68

ISS2

77

ISS1

76

14

17 15 21

6

20 31 24

PORT1

12

8

5

L.RO

4

22

24

13

L-CH

R-CH

TUNER L-CH

R-CH

MUTE

P-CON

MUTE

CNP304 (1/2)

1

3

CNP301 BH301

HRP301

(REC/PB)

HE301

(ERASE)

2

CNP304 (2/2)

5

BH302

(1/2)

2

BH302 (2/2)

43

CNP303 (2/2)

43

CNP305 (1/4)

125

BH501 (1/4)

12

5

7

TAPE

69

6

A-MUTE

66

10

71

3

CNP306 (1/3) 2

BH502 (1/3) 2

7

9

6

1

CNP303

(1/2)

2

55

B

FROM

CD SECTION

(Page 18)

CD-ON

F

TO POWER

SUPPLY

SECTION

(Page 23)

TO CD

SECTION

(Page 18)

TO TUNER SECTION

(Page 20)

C-MUTE

B-MUTE

A D

TO

TUNER

SECTION

(Page 20)

E

MAIN BOARD (2/3)

KEY 1 BOARD (1/2) KEY 1 BOARD (2/2)

POWER BOARD (1/2)

REC SW BOARD

LCD BOARD (2/3) LED BOARD

4

3

1

2

CNP302

2

4

3

PB

EQ AMP

MONITOR

AMP

MATRIX

SOUND

CIRCUIT

TONE

CONTROL

CIRCUIT

LINE MUTE

SWITCH

Q301

MIXING

AMP

Q302

CONTROL

BUZZER

MUTE

3

POWER

AMP

STANDBY

SWITCH

RIPPLE

FILTER

VOLUME

CONTROL

CIRCUIT

MIC

AMP

REC

EQ AMP

BIAS OSC

Q311

CD ON

SWITCHING

Q363

REFERENCE VOLTAGE

GENERATOR

LOGIC CIRCUIT

DET

ALC

BUFFER

T311

BIAS OSC

Q312

BH603

(1/2)

4

52

6

3

1

2

BH602

(1/3)

4

33

BH605

(1/3)

67

4

BH605

(2/3)

1

4

3

61

CNP307

(1/2) BH353

(1/2)

1

9

1

9

BH352

SP101

(L-CH)

SP201

(R-CH)

1

2

J301

(HEADPHONE)

i

4

3

CNP310 43

43

1

2

1

2

CNP311

X502

32.768kHz

TX

TEX

73 74

MODE CHECK

28

MUTE

SWITCH

Q341

SEG0 – SEG22

LIQUID CRYSTAL

DISPLAY

LCD501

LED DRIVE

Q502

42 – 64

COM0 – COM3

38 – 41

SYSTEM CONTROLLER

IC501 (2/3)

BH504

2

4

1

3

4

S617

S601 – 606

S619 – 624

S614, 615

S611 – 613

OPR/BATT B+

CNP501 BH601

A-MUTE

B+

R-CH

D321

D322

S301 (1/2)

(REC/PB)

L-CH

REC

VCC

R-CH

VREF

FILTER

STANDBY

REC

V-DATA

V-CLOCK

V-LATCH

BUZZER

ISS 2

ISS 1

5

7

13 19 20 18 3

RECPB

S301 (2/2)

(REC/PB)

RECPB

CD

+

D602

ALARM

S601

S602

ALARM

S619 RADIO

BAND

S620 VOL

S621

S622

S623 PRESET

S624 AUTO PRESET

OPERATE

–

+

–

+

TUNE

TIME SET

TIMER

S603

S606

S604

SLEEP

S611

S612

CLOCK

MEGA BASS

S613

START/STOP

SOUND

S609 x

S610 u

S614 .

S615 >

DSPL

ENT MEM

S605 PLAY MODE

MONO/ST

ISS

D601

OPR/BATT

BH603

(2/2)

1

BH602

(2/3)

1

CNP601 1

22

BH607

BH604 1

BH602

(3/3)

2

BH606

2

BH605

(3/3)

2

KEY 2

BOARD KEY 3

BOARD

– 21 – – 22 –

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

– 23 – – 24 –

6-4. BLOCK DIAGRAM – POWER SUPPLY Section –

05

T901

POWER

TRANSFORMER

P-CON

RST

RADIO

BACK UP B+

D909

POWER AMP

(IC303) B+

D908

MOTOR BRAKE

SWITCH

Q366

S303

(MOTOR ON/OFF)

S304

(TAPE PLAY)

M301

(CAPSTAN/REEL)

B+ (VDD S.W)

30

21

REG CHK 80

DC1 22

DC2 23

DC3 24

70

79

CNP309

BH501

(4/4)

1

2

11 5

6

RECT

D901 – 904

+5V

REGULATOR

Q354

B+ SWITCH

Q351, 352

CD B+ SWITCH

Q702, 703

+6V

REGULATOR

Q353

+5V

REGULATOR

IC502

AC, BATTERY

CHECK

Q501

RESET SIGNAL

GENERATOR

IC503

AC, BATTERY

CHECK

Q373

AC, BATTERY

CHECK

Q375

REGULATOR

Q374

TC-PLAY

65 9

MOTOR ON

TC-PLAY

MOTOR ON 3

4

MM

6

5

BH354

1

4

3

6

5

CNP308

1

4

3

J901

-AC IN

CNP351

9V

4.5V

DC2

DC3

GND

2

3

4

5

1

2

1

BH901

BH902

1

2

3

BATT (+)

BOARD

BATT (–)

BOARD

D363

D362

D361

D910

D907

AC-HI

BH353

(2/2)

7

CNP307

(2/2)

76V

BH351

3

CNP704

PVDD

CD MOTOR/COIL

DRIVER (IC702) B+

DVDD

CD SECTION B+

ELECTRICAL VOLUME,

SOUND CONTROL

(IC302) B+

RADIO 6V

TUNER SECTION B+

COM 5V

REC/PB EQ AMP (IC301),

TUNER SECTION B+

VT B+

PLL L.P.F. CIRCUIT B+

3

BH701

(2/2)

5

6V

1

15V

88 5V

5

5VDD (S.W)

6

CNP305

(4/4)

11

9

6P-CON

U-COM (VDD)

DC1

DC2

DC3

DRY BATTERY

SIZE “D”

(IEC DESIGNATION R20)

6PCS. 9V

(FOR POWER SUPPLY)

DRY BATTERY

SIZE “AA”

(IEC DESIGNATION R6)

3PCS. 4.5V

(FOR BACK UP)

DC LEVEL DETECT

Q367, 370

DC LEVEL DETECT

Q368, 371

DC LEVEL DETECT

Q369, 372

MOTOR DRIVE

Q364, 365

SYSTEM CONTROLLER

IC501 (3/3)

POWER BOARD (2/2)

CD BOARD (2/2)

MAIN BOARD (3/3)

G

TO MAIN SECTION

(Page 22)

P-CON

CD-ON

TUNER B+

SWITCH

Q361, 362

CNP305

(2/4)

4

8

RADIO

F

FROM MAIN SECTION

(Page 21)

CNP305

(3/4)

REG

CNP306

(2/3)

8

P-CON

5

OPR/BATT

OPR/BATT B+

CNP306

(3/3)

3

U-COM (VDD)

10

DC1

11

DC2

12

DC3

BH501

(2/4)

4

8

BH501

(3/4)

BH502

(2/3)

8

5

BH502

(3/3)

3

10

11

12

LCD BOARD (3/3)

CFD-E55L

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

CFD-E55L

– 26 – – 27 – – 28 –

• Circuit Boards Location

6-5. PRINTED WIRING BOARDS – CD Section –

KEY 2 board

KEY 1 board

LCD board

REC SW board

BATT (–) board

BATT (+) board

MAIN board KEY 3 board

POWER board

CD MOTOR board

CD board

LED board

• Semiconductor

Location

Ref. No. Location

Note on Printed Wiring Boards:

•X: parts extracted from the component side.

•Y: parts extracted from the conductor side.

•b: Pattern from the side which enables seeing.

IC701 C-6

IC702 E-5

IC703 B-4

Q701 D-5

Q702 A-6

Q703 A-3

1-658-023-

S701

(LIMIT)

M701

(SPINDLE)

CNP707

1

6

31

(31)

M

M702

(SLED)

M

12345678

A

B

C

D

E

05

(Page 33)

(Page 45)

(Page 34)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Sony CFD-E55L User manual

Popular Cassette Player manuals by other brands
