Sony Sports Walkman WM-FS473 User manual

Ver 1.0 1998. 05
MICROFILM
WM-FS473
SERVICE MANUAL
SPECIFICATIONS
US Model
Canadian Model
AEP Model
E Model
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type MF-WMFS473
Frequency range FM : 87.5 – 108 MHz
AM : 530 – 1710kHz
(US, Canadian model)
531 – 1602kHz (AEP, E model)
Power requirements 3V DC batteries (AA) R6 x2
Dimensions 104.2 x 127.3 x 51.8 mm (4 1/8 x 51/8x 21/8 inches)
(w/h/d) incl. projecting parts and controls
Mass Approx. 260g (9.2 oz)
Approx.340g (12 oz) incl. batteries and a cassette
Supplied accessory Stereo headphones or Stereo earphones (1)
Design and specifications are subject to change without notice.
RADIO CASSETTE PLAYER

– 2 –
Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 270°C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
TABLE OF CONTENTS
Specifications ........................................................................... 1
1. GENERAL
Location of parts and controls............................................ 2
2. SERVICE NOTE........................................................... 3
3. DISASSEMBLY
3-1. Cover Removal ........................................................... 4
3-2. Display Board Removal ............................................. 4
3-3. Cassette Lid Assy Removal ........................................ 5
3-4. Chassis section, Headphone Jack Board Removal ..... 5
3-5. Mechanism Deck, Main Board, Belt Removal........... 6
4. ADJUSTMENTS
4-1. Mechanical Adjustments ............................................ 7
4-2. Electrical Adjustments ................................................ 7
5. DIAGRAMS
5-1. Explanation of IC Terminals..................................... 10
5-2. Block Diagram...........................................................11
5-3. Printed Wiring Boards (Main Section) ..................... 13
5-4. Schematic Diagram (Main Section) ......................... 15
5-5. Schematic Diagram (Display Section) ..................... 18
5-6. Printed Wiring Boards (Display Section) ................. 21
6. EXPLODEDVIEWS
6-1. Cassette Lid Section ................................................. 23
6-2. Main Board Section .................................................. 24
6-3. Mechanism Deck Section (MF-WMFS473) ............ 25
7. ELECTRICAL PARTS LIST................................... 26
SECTION 1
GENERAL This section is extracted from
instruction manual.

– 3 –
SECTION 2
SERVICE NOTE
WATERPROOFED SECTION
Set the Apositions to corner.
then push down to grove.
Note : In case the parts in the figure are removed for repair, treat them to protect from water drop following the instructions in the figure
(spread grease, bond etc.)
• Sony grease SGL-601 : 7-651-000-10
Note : Clean the attachement portion
and shaded area with cloth.
Paking (cabinet)
A
A
Cassette lid assy
Screw
Joint (VOL. B)
O ring
(Apply sony grease SGL-601)
Knob (VOL)
Cabinet (rear) assy

– 4 –
SECTION 3
DISASSEMBLY
Note:Followthedisassemblyprocedureinthenumericalordergiven.
3-1. COVER REMOVAL
3-2. DISPLAY BOARD REMOVAL
r
Theequipmentcanberemo vedusingthef ollo wingpr ocedure .
Cassette lid assy
3
2
Screws
1 Flexible board
Display board
Cassette lid assy
Arm ass
y
Backle
Cover
5 Screws
4
2
1
3
Claws
Chassis section, Headphone jack board
Cover
Set Diaplay board
Cassette lid assy Mechanism deck, Main board, Belt

– 5 –
3-3. CASSETTE LID ASSY REMOVAL
3-4. CHASSIS SECTION, HEADPHONE JACK BOARD REMOVAL
1 Screws (+P 2x12)
43
3
1
2
Headphone jack board
Chassis section
Cabinet (rear) assy
Cabinet (rear) assy
Knob (VOL)
RV301
Main board
2 Claws
Cassette lid assy
2 Screw
2 Screw
3
1
Flexible board
Note:Wheninstallthec hassissection
1. TurnR V301full ytoarr owdirection.
2. Turnknob(V OL)fullytoarr owdirection.
3. FitRV301toholeofknob(V OL)andthen
installthechassissection.

– 6 –
3-5. MECHANISM DECK, MAIN BOARD, BELT REMOVAL
Main board
2 Screws (2x5)
7
6
4
9
8
Chassis
3 Claw
3 Claw
5 Screw
3 Claw
Belt Mechanism dec
k
Red
Red
1 Remove
solder
Black
Orange
Gray
Black
White

– 7 –
SECTION 4
ADJUSTMENTS
4-2. ELECTRICAL ADJUSTMENTS
PRECAUTION
• Suppliedv olta ge: 2.5V.
• Switchandcontrolposition
SETswitch:NORM
VOLUMEcontrol:maximum
MENUswitch:NORM
TestTape
Type Signal Used for
WS-48A 3kHz, 0dB Tape Speed Adjustment
Tape SpeedAdjustment
Procedure :
1. Pla ybac kWS-48A(tapecenterpar t)intheREVstateandadjust
RV601so thatthefrequenc ycounterreadingbecomes2,990Hz
–3,010Hz.
2. Pla ybac kWS-48A(tapecenter)intheFWDstate .
Checkthatfrequencycounterreadingiswithin1.5%oftheread-
ingofstep1.
Adjustment Location :
set
test tape
WS-48A
(3kHz, 0dB) frequency counte
r
J101 (phones)
16 Ω
4-1. MECHANICAL ADJUSTMENTS
PRECAUTION
1. Cleanthefollowingpartswithadenatured-alcohol-moistened
swab: playbackhead pinchroller
capstan rubberbelt
2. Dema gnetiz ethepla ybac kheadwithaheaddema gnetiz er.
3. Donotuseamagnetizedscrewdriverfortheadjustments.
4. Aftertheadjustments,applysuitablelockingcompoundtothe
partsadjusted.
5. Theadjustmentsshouldbeperformedwiththeratedpowersup-
plyvolta ge(2.5 V)unlessotherwisenoted.
Torque Measurement
Mode Torque Meter Meter Reading
FWD 20 - 42 g • cm
CQ-102C (0.28 -0.58 oz• inch)
FWD less than 2 g • cm
back tension (less than 0.03 oz• inch)
REV 20 - 42 g • cm
CQ-102RC (0.28 -0.58 oz• inch)
REV less than 2 g • cm
back tension (less than 0.03 oz• inch)
FF, REW CQ-201B more than 60 g • cm
(more than 0.83 oz• inch)
RV601

– 8 –
TUNER SECTION
AM Section
BAND : AM
FM Section
BAND: FM
* Repeattheproceduresineachadjustmentseveraltimes,andthe
frequencycoverageandtrackingadjustmentsshouldbefinally
donebythetrimmercapacitors.
Frequency CoverageAdjustment
Setting :
nomark : COM
< > :AEP,Emodelonl y
AM IF ALIGNMENT
Adjust for a maximum reading on level meter.
T1 450kHz
AM FREQUENCY COVERAGE ADJUSTMENT
Adjust part Frequency display Reading on digital
voltmeter.
T2 530kHz 1.25 – 1.35V
< 531kHz>
Confirmation 1,710kHz less than 10V
AMTRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 620kHz < 621kHz>
CT1 1,400kHz< 1,395kHz>
FM FREQUENCY COVERAGE ADJUSTMENT
Adjust part Frequency display Reading on digital
voltmeter.
L3 87.5MHz 3.7 – 3.9V
Confirmation 108MHz less than 10V
FMTRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L2 87.5MHz
Confirmation 108MHz
AM RF signal
generator
30% amplitude modulation by 400Hz
signal.
Output level : as low as possible
Put the lead-wire
antenna close to
the set.
FM RF signal
generator
75kHz frequency deviation by
400Hz signal.
Output level : as low as possible
TP27 (ANT IN
)
(GND)
0.01
µ F
set
16
Ω
J101 (phones)
level mete
r
digital voltmeter
(DC range)
TP19 (VT)
(GND)
[MAIN BOARD] (Conductor side)

– 9 –
Adjustment Location :
L1 : AM Tracking Adjustment CT1 : AM Tracking Adjustment
L2 : FM Tracking Adjustment
T2 : AM Frequency Coverage Adjustment
L3 : FM Frequency Coverage Adjustmen
t
T1 : AM IF Alignment
[MAIN BOARD] (Conductor Side)
Connection Point :
[MAIN BOARD] (Component side)

– 10 –
Pin No. Pin name I/O Description
1 – 3 COM1 – COM3 O Common output terminal.
4 – 20 S1 – S17 O Segment output terminal.
21 – 26 KR0 – KR5 O Key return timing output terminal.
27 – 30 K0 – K3 I Key input.
31 – 36 T0 – T5 O Key return timing output.
37 NOM/METAL O Tape normal/metal selection output.
38 TAPE ON I Tape power (MD power) ON Det terminal.
39 LOCAL/DX O Local/DX selection output.
40 MEGA BASS O Mega bass ON/OFF control output.
41 MONO/ST O Mono/Stereo selection output.
42 BAND O FM/AM band selection output.
43 I Power initial terminal.
44 TAPE & RADIO O Tape & Radio +B ON/OFF control.
45 AVLS O AVLS control terminal.
46 BEEP O Beep signal output terminal.
47 MUTE ON O Mute signal output terminal. H : Mute ON
48 TEST I Test terminal (Connected to ground).
–––––––––––––
49 HOLD I Hold detection terminal.
50 IF IN I IF input terminal.
51 RADIO ON O Radio +B ON/OFF control.
52 DO O PLL error signal output.
53 GND – Ground.
54 FM IN I FM local oscillator input terminal.
55 AM IN I AM local oscillator input terminal.
56 VDD – Power supply terminal (+2.8V).
––––––––––––––
57 RESET I System reset terminal. L : Reset
58 X OUT O Crystal oscillator terminal (75kHz).
59 X IN I Crystal oscillator terminal (75kHz).
60 VXT – Terminal to which external capacitor for stabilization of crystal oscillator power supply is
connected.
61 VLCD – LCD drive power supply set-up terminal.
62 C1 – LCD drive power supply set-up terminal.
63 C2 – LCD drive power supply set-up terminal.
64 VEE – 1.5V constant voltage power supply terminal for LCD drive.
SECTION 5
DIAGRAMS
5-1. EXPLANATION OF ICTERMINALS
IC701 TC9322FB-603 (LCD DRIVE/SYSTEM CONTROL)

– 11 – – 12 –
WM-FS473
5-2. BLOCK DIAGRAM
• Signal path.
F: FM
E: PB

– 15 – – 17 –– 16 –
5-4. SCHEMATIC DIAGRAM (MAIN SECTION)
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
•¢: internal component.
•C: panel designation.
•U: B+ Line.
•H: adjustment for repair.
• Power voltage is dc 3V and fed with regulated dc power
supply from battery terminal.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
• Voltages and waveforms are dc with respect to ground in
playback mode.
no mark : FM (RADIO SECTION)
PLAY (TAPE SECTION)
( ) : AM
• Voltagesaretaken withaVOM(Input impedance10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F: FM
E: PB
rWAVEFORMS
1
VOLT/DIV : 1V AC
TIME/DIV : 0.1 µsec
2
VOLT/DIV : 0.5V AC
TIME/DIV : 0.1 µsec
4.1Vp-
p
0.38
µ
sec
2.8Vp-p
0.38
µ sec
rIC BLOCK DIAGRAM
IC1 TA2137FN (EL)
21222324
235
4678910
111 12
13
14
15
16
17
181920
FM
OSC
AM
OSC
BUFF
IF
BUFF
AF
BUFF
BUFF
AM
MAX
FM
MAX
FM
RF
ST
LEVEL
DET 1/8
AMIF FMIF AGC
SW
IF
RED
AM
DET
FM
DET
AF
ST/MO
FM/AM
MUTE
VCO
DIVIDE DECOOE
FM RF OUT RF VCC AM RF IN FM OSC AM OSC OSC OUT ST LED IF REQ DET OUT DET IN LPF1 LPF2
RF GND
FM RF IN
AM LOW CUT
MIX OUT
VCC
AM IF IN
FM IF IN
GND
AGC
OUAD
R-OUT
L-OUT
WM-FS473

– 18 – – 20 –– 19 –
rWAVEFORM
1
IC701 %• VOLT/DIV : 0.2V AC
TIME/DIV : 5 µsec
1.1Vp-p
75kHz
13.6
µ sec
rIC BLOCK DIAGRAM
23
54
1
+
–
+
–
OUT VCC
NC
SUB
GND
CO1
OP1
IC702 PST9018NL
Note:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ωand 1/4W or less unless otherwise
specified.
•C: panel designation.
•U: B+ Line.
• Power voltage is dc 3V and fed with regulated dc power
supply from battery terminal.
• Voltages and waveforms are dc with respect to ground
under no-signal (detuned) conditions.
• Voltages and waveforms are dc with respect to ground in
playback mode.
no mark : FM (RADIO SECTION)
PLAY (TAPE SECTION)
( ) : AM
• Voltagesaretakenwith aVOM(Input impedance10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
• Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
5-5. SCHEMATIC DIAGRAM (DISPLAY SECTION)
WM-FS473

– 23 – – 24 –
SECTION 6
EXPLODED VIEWS
NOTE :
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference
number in the exploded views are not
supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of this
parts list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
6-1. CASSETTE LID SECTION
1 3-024-917-01 BUCKLE
2 3-024-918-01 PLATE, BUCKLE
3 3-024-930-01 SPRING (LOCK)
4 3-024-929-01 LEVER (LOCK)
5 3-026-912-01 SHAFT (C)
6 3-375-114-71 SCREW
7 3-024-907-01 COVER
8 3-375-114-41 SCREW
9 A-3021-087-A DISPLAY BOARD, COMPLETE (US, Canadian)
9 A-3021-092-A DISPLAY BOARD, COMPLETE (E)
9 A-3021-090-A DISPLAY BOARD, COMPLETE (AEP)
11 X-3375-540-1 LID ASSY, CASSETTE
12 3-386-373-01 SCREW, TAPPING
13 X-3375-542-1 ARM ASSY
14 3-375-114-71 SCREW
15 3-024-931-01 SHAFT (B)
16 3-024-911-01 PLATE, ORNAMENTAL
*CN702 1-694-428-11 CONDUCTIVE BOARD, PRESSURE WEL
LCD701 1-803-131-11 DISPLAY PANEL, LIQUID CRYSTAL
#1
LCD701
not
supplied
CN702
12
3
4
5
6
7
88
9
11
12
12
16
13
14
15
15
3
4
5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
51 3-024-926-01 TERMINAL (M), BATTERY
52 3-934-023-01 JOINT (VOL)
53 1-669-891-11 FLEXIBLE BOARD
54 3-024-925-01 TERMINAL (P), BATTERY
55 A-3021-088-A MAIN BOARD, COMPLETE (US, Canadian)
55 A-3021-091-A MAIN BOARD, COMPLETE (AEP,E)
56 3-024-922-01 BUTTON (FF)
57 3-024-923-01 BUTTON (REW)
58 3-024-920-01 BUTTON (PLAY)
59 3-024-921-01 BUTTON (STOP)
60 3-024-924-01 BUTTON (DIR)
61 3-024-919-01 CHASSIS
62 3-383-671-01 SCREW (2X5)
63 3-934-020-41 LID, BATTERY CASE
64 3-028-087-01 SPRING, TORSION
65 3-351-153-01 SPRING
*66 1-669-890-11 HEADPHONE JACK BOARD
67 3-381-629-11 SCREW
68 3-934-024-01 JOINT (VOL.B)
69 X-3375-539-1 CABINET (REAR) ASSY (AEP)
69 X-3375-541-1 CABINET (REAR) ASSY (Canadian,E)
69 X-3375-538-1 CABINET (REAR) ASSY (US)
70 3-012-927-01 RING, O
71 3-024-906-01 KNOB (VOL)
72 3-024-914-01 PACKING (MD)
73 3-386-371-01 PACKING, HP JACK
74 3-029-161-01 SCREW
*75 3-024-915-01 SHEET (MD), ADHESIVE
76 3-389-713-01 SCREW (2X4)
L1 1-754-005-11 ANTENNA, FERRITE-ROD
6-2. MAIN BOARD SECTION
#2
#3
#4
L1
51
52
53
54
55
56
57
58
59
60
61
74
62 63 64 65
66
67
68
69
70
71
72
73
76
75
not supplied

– 25 – – 26 –
6-3. MECHANISM DECK SECTION
(MF-WMFS473)
HP901
S101
M901
101
102
103 104
134
143
104
105 106
161
107 108
109
110
111 112
113
114
115 116
156
117
118
119
120
121
141
140
122
123
124
125
142 144
126
136
137
135
127
128
129
130
131
139
157
159
158
151
152
153
154
155
146
145
160 147
150
149
148
132
133 134
101 3-025-064-01 SPRING (DIR)
102 X-3375-574-1 CHASSIS ASSY
103 3-025-074-01 ARM PINCH R
104 3-905-717-01 PINCH ROLLER (R)
105 3-025-065-01 SLIDE PLATE
106 3-381-858-01 CAP (H)
107 3-025-069-01 CHASSIS (HEAD)
108 3-025-072-01 UD SPRING
109 3-025-068-01 SCREW (HEAD)
110 1-670-152-11 SWITCH BOARD
111 3-025-070-01 UD SCREW AF
112 3-025-071-01 UD SCREW AR
113 1-783-606-11 LEAD, HEAD
114 3-025-067-01 TAPE GUIDE
115 3-025-066-01 SUB SLIDE
116 3-905-722-01 SPRING (T REEL)
117 3-905-723-01 SPRING (S REEL)
118 3-027-644-01 LUG
119 3-025-055-01 WASHER (FWF STOPPER)
120 3-381-850-01 ARM (PINCH) (F)
121 3-025-052-01 GEAR (REEL)
122 3-025-058-01 PULLEY (IDLER)
123 3-905-702-01 WASHER (IDLER)
124 3-025-051-01 GEAR (TU)
125 3-025-059-01 BELT
126 3-025-054-01 SPRING (UPPER&LOWER)
127 3-905-712-01 SCREW (CLUTCH)
128 X-3375-990-1 CLUTCH ASSY
129 3-381-841-01 GEAR (CAM)
130 3-027-722-01 SPRING (CLUTCH)
131 3-025-056-01 FW (F) ASSY
132 3-025-057-01 FW (R) ASSY
133 3-381-883-01 SCREW (MOTOR)
134 3-025-073-01 SPRING
135 3-025-060-01 WASHER (UPPER&LOWER)
136 3-905-710-01 ARM (TU)
137 3-025-053-01 LEVER (WEDGE)
139 3-025-050-01 GEAR (IDLER) (B)
140 3-025-063-01 SPRING
141 3-381-840-01 GEAR (IDLER) (A)
142 3-025-062-01 ARM (CHANGE)
143 3-025-076-01 SPRING CHANGE
144 3-025-075-01 SCREW
145 3-905-694-01 SPRING (LOCK PLATE)
146 3-905-708-01 PLATE, LOCK
147 3-905-700-01 ARM (SWITCH) (B)
148 3-905-699-01 SPRING (REVERSE)
149 3-381-874-01 SPRING (TU)
150 3-905-697-01 SPRING (CANCEL)
151 3-905-698-01 ARM (SWITCH)
152 3-905-724-01 LEVER (FF)
153 3-905-725-01 LEVER (REW)
154 3-905-726-01 LEVER (STOP)
155 3-905-727-01 LEVER (DIR)
156 3-381-859-01 CAP (REEL)
157 3-905-711-01 SPRING (SENSOR)
158 3-905-716-01 ARM (CANCEL) (R)
159 3-905-713-01 ARM (SENSOR)
160 3-905-715-02 ARM (CANCEL) (D)
161 3-905-721-01 SPRING (CHASSIS HEAD)
HP901 1-500-534-11 HEAD (PLAYBACK)
M901 X-3375-573-1 MOTOR ASSY
S101 1-692-302-11 SWITCH, LEAF (MD POWER)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark

– 27 – – 28 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
• CAPACITORS
uF : µF
• COILS
uH : µH
• Abbreviation
CND : Canadian
When indicating parts by reference num-
ber, please include the board.
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3021-087-A DISPLAY BOARD, COMPLETE (US, CND)
A-3021-090-A DISPLAY BOARD, COMPLETE (AEP)
A-3021-092-A DISPLAY BOARD, COMPLETE (E)
************************
< CAPACITOR >
C701 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C702 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C703 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C704 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C705 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C706 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C707 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C708 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C709 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C710 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C711 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C712 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C713 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C714 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C715 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C716 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
< CONNECTOR >
CN701 1-784-906-21 CONNECTOR, FPC (ZIF) 18P
*CN702 1-694-428-11 CONDUCTIVE BOARD, PRESSURE WEL
< DIODE >
D701 8-719-984-02 LED BR4371F (BATT)
< IC >
IC701 8-759-530-98 IC TC9322FB-603
IC702 8-759-296-60 IC PST9018NL
< JUMPER RESISTOR >
JC701 1-216-864-11 METAL CHIP 0 5% 1/16W
(E)
JC702 1-216-864-11 METAL CHIP 0 5% 1/16W
(AEP)
< COIL >
L701 1-412-010-41 INDUCTOR CHIP 22uH
< LIQUID CRYSTAL DISPLAY >
LCD701 1-803-131-11 DISPLAY PANEL, LIQUID CRYSTAL
< TRANSISTOR >
Q701 8-729-602-36 TRANSISTOR 2SA1602
Q702 8-729-230-38 TRANSISTOR 2SC4215Y
Q703 8-729-028-87 TRANSISTOR DTA143TUA-T106
Q704 8-729-029-15 TRANSISTOR DTC144TUA-T106
< RESISTOR >
R701 1-216-818-11 METAL CHIP 560 5% 1/16W
R702 1-216-813-11 METAL CHIP 220 5% 1/16W
R703 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R704 1-216-809-11 METAL CHIP 100 5% 1/16W
R705 1-216-821-11 METAL CHIP 1K 5% 1/16W
R706 1-216-837-11 METAL CHIP 22K 5% 1/16W
R707 1-216-841-11 METAL CHIP 47K 5% 1/16W
R708 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R709 1-216-845-11 METAL CHIP 100K 5% 1/16W
R710 1-216-837-11 METAL CHIP 22K 5% 1/16W
R711 1-216-821-11 METAL CHIP 1K 5% 1/16W
R712 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R713 1-216-841-11 METAL CHIP 47K 5% 1/16W
R714 1-216-841-11 METAL CHIP 47K 5% 1/16W
R715 1-216-833-11 METAL CHIP 10K 5% 1/16W
R716 1-216-833-11 METAL CHIP 10K 5% 1/16W
R717 1-218-345-11 RES,CHIP 9.1K 5% 1/16W
R718 1-216-853-11 METAL CHIP 470K 5% 1/16W
R719 1-216-815-11 METAL CHIP 330 5% 1/16W
R720 1-216-821-11 METAL CHIP 1K 5% 1/16W
< VIBRATOR >
X701 1-579-615-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
*1-669-890-11 HEADPHONE JACK BOARD
**********************
< JACK >
J101 1-565-376-11 JACK (2)
************************************************************
DISPLAY
HEADPHONE JACK
A-3021-088-A MAIN BOARD, COMPLETE (US, CND)
A-3021-091-A MAIN BOARD, COMPLETE (AEP,E)
*********************
1-669-891-11 FLEXIBLE BOARD
3-934-023-01 JOINT (VOL)
7-627-850-67 SCREW,PRECISION +P 1.4X4
< CAPACITOR >
C1 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C2 1-163-253-11 CERAMIC CHIP 120PF 5% 50V
C3 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C4 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C5 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C6 1-163-087-00 CERAMIC CHIP 4PF 50V
C7 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C8 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C9 1-163-087-00 CERAMIC CHIP 4PF 50V
C10 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
C11 1-163-099-00 CERAMIC CHIP 18PF 5% 50V
C12 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C13 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C14 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C15 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C16 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C17 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C18 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(AEP,E)
C18 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(US,CND)
C19 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(AEP,E)
C19 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(US,CND)
C20 1-104-847-11 TANTAL CHIP 22uF 20% 4V
C21 1-162-282-31 CERAMIC 100PF 10% 50V
C22 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C23 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C24 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C25 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C26 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C27 1-104-394-11 ELECT 4.7uF 20% 50V
C28 1-124-434-00 ELECT 220uF 20% 4V
C29 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C30 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C31 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C32 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C33 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C34 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C35 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C36 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C37 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C38 1-164-346-11 CERAMIC CHIP 1uF 16V
C39 1-104-369-11 ELECT 22uF 20% 16V
C40 1-104-369-11 ELECT 22uF 20% 16V
C42 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C43 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C44 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C46 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C47 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C48 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C49 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C50 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C51 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C101 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C102 1-164-346-11 CERAMIC CHIP 1uF 16V
C103 1-164-821-11 CERAMIC CHIP 3.3uF 10% 16V
C104 1-128-015-11 ELECT CHIP 22uF 20% 4V
C105 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C106 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C107 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C121 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C201 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C202 1-164-346-11 CERAMIC CHIP 1uF 16V
C203 1-164-821-11 CERAMIC CHIP 3.3uF 10% 16V
C204 1-128-015-11 ELECT CHIP 22uF 20% 4V
C205 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C206 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C207 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C221 1-163-007-11 CERAMIC CHIP 680PF 10% 50V
C301 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C302 1-104-369-11 ELECT 22uF 20% 16V
C303 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C304 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C306 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C307 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C310 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C311 1-135-201-11 TANTAL CHIP 10uF 20% 4V
C312 1-104-396-11 ELECT 10uF 20% 25V
C313 1-164-346-11 CERAMIC CHIP 1uF 16V
C314 1-124-434-00 ELECT 220uF 20% 4V
C315 1-128-015-11 ELECT CHIP 22uF 20% 4V
C320 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C321 1-124-434-00 ELECT 220uF 20% 4V
C322 1-125-639-11 DOUBLE LAYER 56000uF 3.5V
C602 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C603 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C604 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
< FILTER >
CF1 1-767-047-11 FILTER, CERAMIC
CF2 1-567-198-11 FILTER, CERAMIC
< COMPOSITION CIRCUIT BLOCK >
CP1 1-236-711-41 FILTER, BAND PASS
< TRIMMER >
CT1 1-141-304-21 CAP, TRIMMER 10PF
< DIODE >
D1 8-719-053-30 DIODE MA2S357-(TX). SO
D2 8-719-055-61 DIODE HVR100-9TRU
D3 8-719-053-30 DIODE MA2S357-(TX). SO
D4 8-719-055-61 DIODE HVR100-9TRU
D5 8-719-016-74 DIODE 1SS352
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN

– 29 –
D6 8-719-420-14 DIODE 02DZ12-TPH3
D301 8-719-049-09 DIODE 1SS367-T3SONY
< IC >
IC1 8-759-544-03 IC TA2137FN(EL)
IC301 8-759-497-06 IC MM1316AFBE
< JUMPER RESISTOR >
JR1 1-216-296-00 METAL CHIP 0 5% 1/8W
JR2 1-216-296-00 METAL CHIP 0 5% 1/8W
JR3 1-216-296-00 METAL CHIP 0 5% 1/8W
JR4 1-216-296-00 METAL CHIP 0 5% 1/8W
JR5 1-216-296-00 METAL CHIP 0 5% 1/8W
JR6 1-216-296-00 METAL CHIP 0 5% 1/8W
JR7 1-216-296-00 METAL CHIP 0 5% 1/8W
JR8 1-216-296-00 METAL CHIP 0 5% 1/8W
JR9 1-216-296-00 METAL CHIP 0 5% 1/8W
JR10 1-216-296-00 METAL CHIP 0 5% 1/8W
JR11 1-216-296-00 METAL CHIP 0 5% 1/8W
JR12 1-216-296-00 METAL CHIP 0 5% 1/8W
JR13 1-216-296-00 METAL CHIP 0 5% 1/8W
JR14 1-216-296-00 METAL CHIP 0 5% 1/8W
JR15 1-216-296-00 METAL CHIP 0 5% 1/8W
JR16 1-216-296-00 METAL CHIP 0 5% 1/8W
JR17 1-216-296-00 METAL CHIP 0 5% 1/8W
JR18 1-216-296-00 METAL CHIP 0 5% 1/8W
JR19 1-216-296-00 METAL CHIP 0 5% 1/8W
JR20 1-216-296-00 METAL CHIP 0 5% 1/8W
JR21 1-216-296-00 METAL CHIP 0 5% 1/8W
JR22 1-216-296-00 METAL CHIP 0 5% 1/8W
JR23 1-216-296-00 METAL CHIP 0 5% 1/8W
JR24 1-216-296-00 METAL CHIP 0 5% 1/8W
JR25 1-216-296-00 METAL CHIP 0 5% 1/8W
JR26 1-216-296-00 METAL CHIP 0 5% 1/8W
JR27 1-216-296-00 METAL CHIP 0 5% 1/8W
JR28 1-216-296-00 METAL CHIP 0 5% 1/8W
JR29 1-216-296-00 METAL CHIP 0 5% 1/8W
JR30 1-216-296-00 METAL CHIP 0 5% 1/8W
< COIL >
L1 1-754-005-11 ANTENNA, FERRITE-ROD (AM)
L2 1-416-677-11 COIL (WITH CORE) (FM-RF)
L3 1-416-678-11 COIL (WITH CORE) (FM-OSC)
L4 1-414-196-41 INDUCTOR 47uH
L5 1-414-196-41 INDUCTOR 47uH
L6 1-410-997-31 INDUCTOR CHIP 2.2uH
L101 1-410-997-31 INDUCTOR CHIP 2.2uH
L201 1-410-997-31 INDUCTOR CHIP 2.2uH
L301 1-410-997-31 INDUCTOR CHIP 2.2uH
< TRANSISTOR >
Q1 8-729-230-38 TRANSISTOR 2SC4215Y
Q2 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q3 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q4 8-729-602-21 TRANSISTOR 2SC4154-F
Q5 8-729-602-21 TRANSISTOR 2SC4154-F
Q6 8-729-602-21 TRANSISTOR 2SC4154-F
Q7 8-729-230-38 TRANSISTOR 2SC4215Y
Q8 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q9 8-729-230-38 TRANSISTOR 2SC4215Y
Q101 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q102 8-729-602-21 TRANSISTOR 2SC4154-F
Q201 8-729-028-97 TRANSISTOR DTC114TUA-T106
Q202 8-729-602-21 TRANSISTOR 2SC4154-F
Q301 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q302 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q304 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q305 8-729-029-15 TRANSISTOR DTC144TUA-T106
Q307 8-729-602-21 TRANSISTOR 2SC4154-F
< RESISTOR >
R1 1-216-853-11 METAL CHIP 470K 5% 1/16W
R2 1-216-853-11 METAL CHIP 470K 5% 1/16W
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R4 1-216-853-11 METAL CHIP 470K 5% 1/16W
R5 1-216-853-11 METAL CHIP 470K 5% 1/16W
R6 1-216-833-11 METAL CHIP 10K 5% 1/16W
R7 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R8 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R9 1-216-821-11 METAL CHIP 1K 5% 1/16W
R10 1-216-821-11 METAL CHIP 1K 5% 1/16W
R11 1-216-833-11 METAL CHIP 10K 5% 1/16W
R12 1-216-833-11 METAL CHIP 10K 5% 1/16W
R13 1-216-809-11 METAL CHIP 100 5% 1/16W
R14 1-216-821-11 METAL CHIP 1K 5% 1/16W
R15 1-216-821-11 METAL CHIP 1K 5% 1/16W
R16 1-216-150-11 METAL CHIP 10 5% 1/8W
R17 1-216-833-11 METAL CHIP 10K 5% 1/16W
R18 1-216-845-11 METAL CHIP 100K 5% 1/16W
R19 1-216-833-11 METAL CHIP 10K 5% 1/16W
R20 1-216-813-11 METAL CHIP 220 5% 1/16W
R21 1-216-821-11 METAL CHIP 1K 5% 1/16W
R22 1-216-845-11 METAL CHIP 100K 5% 1/16W
R23 1-216-814-11 METAL CHIP 270 5% 1/16W
R24 1-216-833-11 METAL CHIP 10K 5% 1/16W
R25 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R26 1-216-833-11 METAL CHIP 10K 5% 1/16W
R27 1-216-805-11 METAL CHIP 47 5% 1/16W
R28 1-216-837-11 METAL CHIP 22K 5% 1/16W
R101 1-216-797-11 RES,CHIP 10 5% 1/16W
R102 1-216-833-11 METAL CHIP 10K 5% 1/16W
R103 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R104 1-216-848-11 METAL CHIP 180K 5% 1/16W
R105 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R106 1-216-811-11 METAL CHIP 150 5% 1/16W
R121 1-216-839-11 METAL CHIP 33K 5% 1/16W
R151 1-216-839-11 METAL CHIP 33K 5% 1/16W
R152 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R201 1-216-797-11 RES,CHIP 10 5% 1/16W
R202 1-216-833-11 METAL CHIP 10K 5% 1/16W
R203 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R204 1-216-848-11 METAL CHIP 180K 5% 1/16W
R205 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R206 1-216-811-11 METAL CHIP 150 5% 1/16W
R221 1-216-839-11 METAL CHIP 33K 5% 1/16W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN

– 30 –
WM-FS473
9-924-900-11 Sony Corporation
Personal A&V Products Company
98E0283-1
Printed in Japan © 1998.5
Published by Quality Engineering Dept.
(Shibaura)
R251 1-216-839-11 METAL CHIP 33K 5% 1/16W
R252 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R301 1-216-841-11 METAL CHIP 47K 5% 1/16W
R302 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-793-11 RES,CHIP 4.7 5% 1/16W
R306 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R603 1-216-819-11 METAL CHIP 680 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-230-593-11 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-238-594-11 RES, ADJ, CARBON 500 (TAPE SPEED)
< TRANSFORMER >
T1 1-431-883-11 TRANSFORMER, IF (AM-IFT)
T2 1-416-679-11 COIL, OSCILLATION (AM-OSC)
T3 1-431-884-11 TRANSFORMER, DDC OSCILLATION
< THERMISTOR >
THP601 1-809-279-11 THERMISTOR, POSITIVE
THP602 1-809-001-11 THERMISTOR, POSITIVE
THP603 1-803-246-21 THERMISTOR, POSITIVE
THP604 1-803-246-21 THERMISTOR, POSITIVE
< FILTER>
X1 1-767-830-11 FILTER, CERAMIC(DISCRIMINATOR)
************************************************************
1-670-152-11 SWITCH BOARD
*************
< SWITCH >
S901 1-771-395-11 SWITCH, SLIDE (FWD/REV)
************************************************************
MISCELLANEOUS
**************
53 1-669-891-11 FLEXIBLE BOARD
113 1-783-606-11 LEAD, HEAD
*CN702 1-694-428-11 CONDUCTIVE BOARD, PRESSURE WEL
HP901 1-500-534-11 HEAD (PLAYBACK)
L1 1-754-005-11 ANTENNA, FERRITE-ROD
LCD701 1-803-131-11 DISPLAY PANEL, LIQUID CRYSTAL
M901 X-3375-573-1 MOTOR ASSY
S101 1-692-302-11 SWITCH, LEAF (MD POWER)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-862-482-11 MANUAL, INSTRUCTION(ENGLISH)(US, CND)
3-862-482-21 MANUAL, INSTRUCTION(FRENCH)(CND)
3-862-482-31 MANUAL, INSTRUCTION (ENGLISH, FRENCH,
GERMAN, ITALIAN) (AEP)
3-862-482-41 MANUAL, INSTRUCTION (SPANISH, DUTCH,
SWEDISH, PORTUGUESE) (AEP)
3-862-482-51 MANUAL, INSTRUCTION (ENGLISH, SPANISH,
CHINESE, KOREAN) (E)
8-952-478-90 HEADPHONE MDR-E215/Y SET (AEP,E)
8-953-142-90 HEADPHONE MDR-W14G//K SET (US, CND)
************************************************************
**************
HARDWARE LIST
**************
#1 7-624-101-04 STOP RING 1.2 (E TYPE)
#2 7-627-850-67 SCREW,PRECISION +P 1.4X4
#3 7-685-104-19 SCREW +P 2X6 TYPE2 NON-SLIT
#4 7-685-107-19 SCREW +P 2X12 TYPE2 NON-SLIT
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN SWITCH
