Troubleshooting Guide
- mechanical -
C2305
,
S39h

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 2(45)
CONTENTS
1Problem Areas................................................................................4
1.1Power......................................................................................................4
1.1.1Will not power on or will switch off randomly...........................................4
1.2Keys........................................................................................................ 6
1.2.1Back/Home/Multi task Keys........................................................................6
1.2.2Volume Key..................................................................................................6
1.2.3On/Off Key....................................................................................................7
1.2.4Camera Key..................................................................................................8
1.3Touch Screen.......................................................................................10
1.3.1Touch Screen malfunction........................................................................10
1.4Display.................................................................................................. 11
1.4.1Graphics & Illumination ............................................................................11
1.5LED/Illumination..................................................................................12
1.5.1LED/Illumination ........................................................................................12
1.6Speaker ................................................................................................14
1.6.1Speaker.......................................................................................................14
1.7Earphone..............................................................................................17
1.7.1Earphone....................................................................................................17
1.8Microphone.......................................................................................... 18
1.8.1Main Microphone.......................................................................................18
1.9Vibrator.................................................................................................19
1.9.1Vibrator not generating alerts ..................................................................19
1.10Camera.................................................................................................20
1.10.1Camera defects..........................................................................................20
1.10.2Secondary Camera....................................................................................21
1.11Flash LED.............................................................................................22
1.11.1Flash LED not flashing..............................................................................22
1.12Bluetooth and WLAN ..........................................................................24
1.12.1Bluetooth or WLAN connection failure....................................................24
1.13GPS.......................................................................................................25
1.13.1GPS malfunctions......................................................................................25
1.14Compass..............................................................................................26
1.14.1Compass fails ............................................................................................26
1.15Accelerometer .....................................................................................27
1.15.1Accelerometer test fails............................................................................27
1.16Ambient Light Sensor.........................................................................28
1.16.1Ambient Light Sensor ...............................................................................28
1.17Proximity Switch ................................................................................. 29
1.17.1Proximity Switch........................................................................................29
1.18Real Time Clock...................................................................................30
1.18.1Real Time Clock test fails .........................................................................30
1.19Total call time ......................................................................................31

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 3(45)
1.19.1Total call time fails.....................................................................................31
1.20External Memory ................................................................................. 32
1.20.1Memory Card not detected .......................................................................32
1.21Security................................................................................................33
1.21.1Security fails..............................................................................................33
1.22FM Radio.............................................................................................. 34
1.22.1No/Poor FM Radio reception ....................................................................34
1.23Battery Test..........................................................................................35
1.23.1Battery Test Fails.......................................................................................35
1.24Verify Certificates................................................................................36
1.24.1Verify certificates fails...............................................................................36
1.25Network & Signal................................................................................. 37
1.25.1No/Poor signal ...........................................................................................37
1.26SIM........................................................................................................39
1.26.1SIM not detected........................................................................................39
1.26.2Incorrect SIM indicated.............................................................................41
1.27Charging............................................................................................... 42
1.27.1Battery will not charge..............................................................................42
1.28HandsFree by Wire.............................................................................. 43
1.28.1Connection to Portable HandsFree fails..................................................43
1.29Data Communication .......................................................................... 44
1.29.1Data transfer via System Connector fails................................................44
2Revision History...........................................................................45
•You shall always after verifying the problem, start
the trouble shooting with the Emma Service
“Refurbish”.
•Software release information about improvements
are found: www.sonymobile.com/Update
Note: In C2305/S39h product, whenever replacing Front Cover LCM TP Assy or Board swap after
repair, it is mandatory to Calibrate the Proximity sensor/Light sensor (1277-0611)
Trouble Shooting Application – mechanical).

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 4(45)
1 Problem Areas
1.1 Power
1.1.1 Will not power on or will switch
off randomly
Check:
Check whether the phone vibrates by pressing the on/off
key.
Action:
1. If activation of the vibrator is detected, refer to section 1.4
‘Display’.
2. Connect Wall Charger to charge the Embedded battery
30 min at least and check again.
Check:
Inspect the on/off key.
Action:
1. Refer to section 1.2.3 ‘Key On/Off’.
Check:
Inspect the On/Off key dome on Link FPC.
Action:
1. If dirty or oxidized – clean the dome.
Check:
Inspect the Link FPC BtB connection on Main PBA.
Action:
1. If not properly connected – disconnect and reconnect
connectors.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 5(45)
Problem Areas
Check:
Inspect the Battery 2330.0 mAh BtB connector on Main
PBA.
Action:
1. Remove and reconnect Battery 2330.0 mAh BtB
connector, test charging and then test powering on the unit.
2. If not properly connected – disconnect and reconnect
connectors.
3. If dirty or oxidized – clean connectors.
Check:
Inspect the Battery 2330.0 mAh.
Action:
1. If damaged, replace the Battery 2330.0 mAh.
Check:
Inspect the Link FPC.
Action:
1. If damaged, replace the Link FPC.
2. Replace Main PBA
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 6(45)
Problem Areas
1.2 Keys
1.2.1 Back/Home/Multi task Keys
Check:
Inspect the Back /Home/Menu keys on Display.
Action:
1. Refer to the section 1.3 ‘Touch Screen’.
2. Replace Main PBA.
1.2.2 Volume Key
Check:
Inspect the external area of the volume key.
Action:
1. If dirty – clean it.
Check:
Inspect the volume key switch on Battery Cover Assy.
Action:
1. If damaged, replace the Battery Cover Assy.
Check:
Inspect the volume key Dome on Link FPC and its BtB
connector.
Action:
1. If dirty – clean it.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 7(45)
Problem Areas
2. If damaged, replace the Link FPC.
3. Replace Main PBA.
1.2.3 On/Off Key
Check:
Inspect the external area of the on/off key.
Action:
If dirty – clean it.
Check:
Inspect the on/off key on Battery Cover Assy.
Action:
1. If damaged, replace the Battery Cover Assy.
Check:
Inspect the on/off key dome on Link FPC and its BtB
connector.
Action:
1. If dirty or oxidized – clean it.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 8(45)
Problem Areas
2. If damaged, replace the Link FPC.
3. Replace the Main PBA.
1.2.4 Camera Key
Check:
Inspect the external area of the Camera key.
Action:
If dirty – clean it.
Check:
Inspect the Camera key switch on Battery Cover Assy.
Action:
1. If damaged, replace the Battery Cover Assy.
Check:
Inspect the Camera key dome and its BtB connector on Link
FPC.
Action:
1. If dirty or oxidized – clean it.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 9(45)
Problem Areas
2. If damaged, replace the Link FPC.
3. Replace the Main PBA.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 10(45)
Problem Areas
1.3 Touch Screen
1.3.1 Touch Screen malfunction
Check:
Inspect the touch screen on the Front Cover LCM TP Assy
Action:
If dirty – clean it.
If: The end user has complained about unexpected behavior of the
touch screen or the touch keys.
Action:
Update SW and check again.
Check:
Inspect the ZIF connector on SIM Board Assy.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the SIM Board Assy is damaged, replace the SIM Board
Assy.
3. If the Touch Panel is damaged, replace the Front Cover
LCM TP Assy.
4. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 11(45)
Problem Areas
1.4 Display
1.4.1 Graphics & Illumination
Check:
Check whether the phone vibrates after the on/off key has
been pressed.
Action:
1. If the activation described above is not detected, refer to
section 1.1 ‘Power’.
2. Press HW reset Key and check it again.
Check:
Inspect the ZIF connector of the LCM to the main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the display or the LCM FPC is damaged – replace the
Front Cover LCM TP Assy
4. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 12(45)
Problem Areas
1.5 LED/Illumination
1.5.1 LED/Illumination
Check:
Inspect the external window area of the LED on the Front
Cover LCM TP Assy
Action:
1. If dirty – clean it.
2. If the external window area is damaged – replace the
Front Cover LCM TP Assy.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.
Check:
Inspect the LED on the Sub Board Assy and the Front Cover
LCM TP Assy
Action:
1. If dirty or clogged – clean them.
2. If the Sub Board Assy is damaged – replace it.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 13(45)
Problem Areas
Check:
Inspect the BtB connectors of Link FPC on both Sub Board
Assy and Main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the Link FPC is defective, replace it.
4. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 14(45)
Problem Areas
1.6 Speaker
1.6.1 Speaker
Check:
Inspect the Loudspeaker’s external port on the Battery
Cover Assy.
Action:
1. If the Loudspeaker external port is clogged – clean it.
2. If the Loudspeaker external port is damaged – replace the
Battery Cover Assy.
Check:
Inspect the mesh of the Loudspeaker on the Rear Cover
Assy.
Action:
1. If dirty – clean it.
2. If the mesh is damaged – replace the Rear Cover Assy.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 15(45)
Problem Areas
Check:
Inspect the Loudspeaker’s pins and the pads on the Sub
Board Assy.
Action:
1. If dirty – clean them.
2. If the pins of the Loudspeaker are damaged – replace the
Loudspeaker.
Check:
Inspect the BtB connectors of Link FPC on both Sub Board
Assy and Main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the pads or the BtB connector of the Sub Board Assy is
damaged – replace the Sub Board Assy.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 16(45)
Problem Areas
3. If the Link FPC is defective, replace the it.
4. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 17(45)
Problem Areas
1.7 Earphone
1.7.1 Earphone
Check:
Inspect the Receiver’s external port on the Front Cover LCM
TP Assy
Action:
1. If clogged – clean it.
2. If the port is damaged – replace the Front Cover LCM TP
Assy.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.
Check:
Inspect the Receiver’s pins and the contact pads on the
main PBA.
Action:
1. If dirty or oxidized – clean it.
2. If the pins of the Receiver are damaged – replace the
Receiver.
3. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 18(45)
Problem Areas
1.8 Microphone
1.8.1 Main Microphone
Check:
Inspect the Microphone’s external port on the Front Cover
LCM TP Assy
Action:
If clogged or dirty– clean the port.
Check:
Inspect the microphone on the Sub Board Assy and the Mic
mesh on the Front Cover LCM TP Assy
Action:
1. If the port is damaged – replace the Front Cover
LCM TP Assy.
2. If Sub Board Assy is damaged, replace it.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.
Check:
Inspect the BtB connectors of Link FPC on both Sub Board
Assy and Main PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the Link FPC is defective, replace the Front Cover LCM
TP Assy.
4. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 19(45)
Problem Areas
1.9 Vibrator
1.9.1 Vibrator not generating alerts
Check:
Inspect the Vibrator soldered on the Sub Board Assy.
Action:
1. If dirty– clean it.
3. If the vibrator or the BtB connector on the Sub Board
Assy is damaged – replace the Sub Board Assy.
Check:
Inspect the two BtB connectors on the Link FPC.
Action:
1. If dirty or oxidized – clean it.
2. If the Link FPC is defective, replace it.
3. Replace Main PBA.
Note: Calibrate the P-sensor/L-sensor 1277-0611
Trouble Shooting Application – mechanical whenever replacing
Front Cover LCM TP Assy or Main Board swap.

Troubleshooting Guide (mech)
1275-8442 Rev1
©Sony Mobile Communications AB – Company Internal 20(45)
Problem Areas
1.10 Camera
1.10.1 Main Camera defects
Check:
Inspect the external area of camera window.
Action:
1. If dirty – clean it.
2. If the camera window scratched or damaged – replace the
Rear Cover Assy.
Check:
Inspect the BtB connector of the Main Camera to the main
PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
Check:
Inspect the Main Camera.
Action:
1. If the Main Camera is damaged – replace it.
2. Replace Main PBA.
