Sony Xperia C2305 User manual

1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal
Working Instructions
- mechanical -
C2305,S39h

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 2(50)
CONTENTS
1Exterior Views.................................................................................4
1.1C2305, S39h...........................................................................................4
2Tools................................................................................................5
3Disassembly....................................................................................6
3.1Battery Cover Assy............................................................................... 6
3.2Rear Cover Assy....................................................................................7
3.3Main PBA (a) & Coaxial Cable (b) ......................................................13
3.4Front Cover LCM TP Assy.................................................................. 15
4Replacement.................................................................................16
4.1Battery Cover Assy............................................................................. 16
4.2Rear Cover Assy.................................................................................. 16
4.3Screw TORX 1.6mm 2.8mm Black .....................................................16
4.4Screw TORX 1.6mm 4.5mm Black .....................................................16
4.5Front Cover LCM TP Assy.................................................................. 17
4.6LCM ZIF MYLAR ..................................................................................17
4.7TP FPC MYLAR....................................................................................17
4.8Battery 2330.0 mA & Embedded Battery Adhesive..........................18
4.9Battery FPC Mylar ...............................................................................20
4.10Core Unit Label....................................................................................20
4.11Camera Module CMOS 0.3M............................................................... 21
4.12Film RF hole......................................................................................... 22
4.13Conductive WIFI Grounding Gasket..................................................23
4.14Loudspeaker & Speaker Adhesive ....................................................24
4.15Camera Module CMOS 8M.................................................................. 26
4.16Link FPC............................................................................................... 28
4.17Receiver & Receiver Adhesive........................................................... 29
4.18Coaxial Cable....................................................................................... 31
4.19SUB Board Assy & Sub PBA Adhesive............................................. 32
4.20Liquid Intrusion Label......................................................................... 34
4.21SIM Board Assy &RF Shielding Cover &SIM conductive adhesive 36
4.22Board Swap – Replacement ..............................................................38
4.23Board Swap – Change Label..............................................................38
4.24Board Swap – Customize of Software...............................................38
5Reassembly...................................................................................39
5.1Front Cover LCM TP Assembly..........................................................39
5.2Main PBA (a) & Coaxial Cable (b) ......................................................40
5.3Rear Cover Assy.................................................................................. 45
5.4Battery Cover Assy............................................................................. 47

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 3(50)
6Country of Origin Barcodes for Brazil/VIVO Labels..................49
7Revision History...........................................................................50
For general information about mechanical repair related issues, refer to
1220-1333: Generic Repair Manual - mechanical

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 4(50)
1 Exterior Views
1.1 C2305, S39h

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 5(50)
2 Tools
SPECIAL TOOLS
1. Torque Screwdriver
2. Flex Film Assembly Tool
3. Bits (T5)
4. Front Opening Tool
5. Guitar Pick
For part no’s on the tools above, refer to the ‘Tools Catalogue/Matrix’!
STANDARD TOOLS
1. Tweezers

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 6(50)
3 Disassembly
The disassembly is done in the following order:
1. Battery Cover Assy
2. Rear Cover Assy
3. Main PBA (a) & Coaxial Cable (b)
4. Front Cover LCM TP Assy
3.1 Battery Cover Assy
Insert Front Opening tool into the gap as shown in picture to
release the hooks of the Battery Cover Assy.
Hold phone Top side at circle area while opening hooks!
Press the other side down as shown in picture.
Hold phone Top side at circle area while opening hooks!
Take Phone bottom side out from Battery Cover Assy.
Hold phone Top side at circle area while opening hooks!
1
2
3a
4
3b

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 7(50)
Remove the Battery Cover Assy.
3.2 Rear Cover Assy
Remove these four Screws(Screw TORX 1.6mm 4.5mm
Black) by using a screwdriver with Bits (T5).
Scrap! Not to be reused!
Remove these four Screws(Screw TORX 1.6mm 2.8mm
Black) by using a screwdriver with Bits (T5).
Scrap! Not to be reused!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 8(50)
Disassembly
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 9(50)
Disassembly
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Turn around the phone to the 3rd side.
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!
Insert Guitar Pick as shown in picture to release this position
hook.
Do not slide Guitar Pick along phone side!

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 10(50)
Disassembly
Remove the Rear Cover Assy.
Battery FPC Mylar is folded under Battery FPC at shown
area.
Turn around the Battery FPC Mylar with Battery FPC from
Main PBA.
Turn around the folded Battery Mylar FPC from Battery FPC.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 11(50)
Disassembly
Remove the Battery Mylar FPC.
Remove the TP FPC MYLAR.
Take out the LCM ZIF MYLAR under SIM Board Assy first.
Remove the LCM ZIF MYLAR.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 12(50)
Disassembly
Open Battery FPC BtB Connector using Front Opening Tool.
The Core unit as shown in picture.
Open the Coaxial Cable connector on SUB Board Assy.
Open the Link FPC connector on SUB Board Assy.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 13(50)
Disassembly
3.3 Main PBA (a) & Coaxial
Cable (b)
Open the Link FPC connector on Main PBA.
Open the LCM ZIF connector.
Pull out the LCM FPC from its ZIF connector.
Open the Front Camera BtB connector.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 14(50)
Disassembly
Open the Touch Panel ZIF connector.
Pull out the Touch Panel FPC.
Turn around the Touch Panel FPC from Main PBA.
Open the Main PBA hook using Front Opening Tool.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 15(50)
Disassembly
Open the other side hook of Main PBA.
Remove the Main PBA and Coaxial Cable.
3.4 Front Cover LCM TP Assy
Front Cover LCM TP Assy as shown in picture.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 16(50)
4 Replacement
4.1 Battery Cover Assy
Follow the 3.1 Disassembly instructions!
Prepare a new Battery Cover Assy.
Follow the 5.4 Reassembly instructions!
4.2 Rear Cover Assy
Follow the 3.1 – 3.2 Disassembly instructions!
Follow the 4.12 Removal instructions!
Prepare a new Rear Cover Assy.
Follow the 4.12, 4.8 Installation instructions!
Follow the 5.3 -- 5.4 Reassembly instructions!
4.3 Screw TORX 1.6mm
2.8mm Black
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new Screws.
Follow the 5.3 – 5.4 Reassembly instructions!
4.4 Screw TORX 1.6mm
4.5mm Black
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new Screws.
Follow the 5.3 – 5.4 Reassembly instructions!

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 17(50)
Replacement
4.5 Front Cover LCM TP Assy
Follow the 3.1 – 3.4 Disassembly instructions!
Follow 4.6, 4.17, 4.14 Removal instructions.
Prepare a new Front Cover LCM TP Assembly.
Follow 4.6, 4.17, 4.14 Installation instructions.
Follow the 5.1 – 5.4 Reassembly instructions!
Note: Calibrate the Proximity sensor/Light sensor 1277-
0611 Trouble Shooting Application – mechanical after
replacement.
4.6 LCM ZIF MYLAR
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new LCM ZIF MYLAR.
Follow the 5.3 – 5.4 Reassembly instructions!
4.7 TP FPC MYLAR
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare new TP FPC MYLAR.
Follow the 5.3 – 5.4 Reassembly instructions!

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 18(50)
Replacement
4.8 Battery 2330.0 mA &
Embedded Battery Adhesive
Follow the 3.1 – 3.4 Disassembly instructions!
Carry out the Removal as described below.
Prepare new Battery 2330.0 Ma $ Embedded Battery
Adhesive.
Carry out the Installation as described below.
Follow the 5.1 – 5.4 Reassembly instructions!
Removal
Pull the white tape on Battery 2330.0 mA as shown in
picture to disassemble Battery 2330.0 mA.
Scrap! Do not reuse it.
Remove the Battery 2330.0 mA carefully.
Scrap! Do not reuse it.
Remove the Embedded Battery Adhesive carefully.
Scrap! Not to be reused.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 19(50)
Replacement
Installation
Attach a new Embedded Battery Adhesive carefully.
Attach a new Battery 2330.0 mA carefully.
Press down its bottom side firstly.
Press down both sides firmly to secure its attachment.

Working Instruction Repair Instruction Mechanical/
1275-8436 Rev2
©Sony Mobile Communications AB – Company Internal 20(50)
Replacement
4.9 Battery FPC Mylar
Follow the 3.1 – 3.2 Disassembly instructions!
Prepare a new Battery FPC Mylar.
Follow the 5.3 – 5.4 Reassembly instructions!
4.10 Core Unit Label
Follow the 3.1 Disassembly instructions!
Carry out the Removal as described below.
Prepare a new Core Unit Label.
Carry out the Installation as described below.
Follow the 5.4 Reassembly instructions!
Removal
Peel off the Core Unit label from Rear Cover Assy.
Installation
Attach a new Core Unit Label carefully.
Align Core Unit Label with the mark on metal cover.
Only one Label is attached.
