Troubleshooting Guide
- mechanical -
ST21i, ST21a
, ST21i2, ST21a2
Xperia
TM
tipo

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
2(44)
CONTENTS
1 Problem Areas................................................................................4
1.1 Power....................................................................................................4
1.1.1 Will not power on or will switch off randomly...........................................4
1.2 Keys ......................................................................................................6
1.2.1 Menu, Home and Back Keys.......................................................................6
1.2.2 Volume Key..................................................................................................6
1.2.3 On/Off key ....................................................................................................6
1.3 Touch Screen .......................................................................................8
1.3.1 Touch Screen malfunction..........................................................................8
1.4 Display..................................................................................................9
1.4.1 Graphics & Illumination ..............................................................................9
1.5 LED/Illumination.................................................................................11
1.5.1 LED/Illumination........................................................................................11
1.5.2 Menu key, Home key and Back key Illumination ....................................12
1.6 Speaker...............................................................................................13
1.6.1 Speaker............................................................. Error! Bookmark not defined.
1.7 Earphone ............................................................................................16
1.7.1 Earphone....................................................................................................16
1.8 Microphone.........................................................................................18
1.8.1 Microphone................................................................................................18
1.9 Vibrator...............................................................................................19
1.9.1 Vibrator not generating alerts ..................................................................19
1.10 Camera................................................................................................20
1.10.1 Camera defects..........................................................................................20
1.11 Flash LED ...........................................................................................21
1.11.1 Flash LED not flashing..............................................................................21
1.12 Bluetooth and WLAN .........................................................................22
1.12.1 Bluetooth or WLAN connection failure....................................................22
1.13 GPS .....................................................................................................23
1.13.1 GPS malfunctions......................................................................................23
1.14 Accelerometer....................................................................................24
1.14.1 Accelerometer test fails............................................................................24
1.15 Ambient Light Sensor........................................................................25
1.15.1 Light Sensor malfunctions .......................................................................25
1.16 Proximity switch.................................................................................26
1.16.1 Proximity switch malfunctions.................................................................26
1.17 Water Proof.........................................................................................27
1.17.1 Water Proof fails........................................................................................27
1.18 Real Time Clock .................................................................................28
1.18.1 Real Time Clock test fails .........................................................................28
1.19 Total call time.....................................................................................29
1.19.1 Total call time fails ....................................................................................29

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
3(44)
1.20 External Memory................................................................................30
1.20.1 Memory Card not detected .......................................................................30
1.21 Security...............................................................................................31
1.21.1 Security fails..............................................................................................31
1.22 FM Radio.............................................................................................32
1.22.1 No/Poor FM Radio reception ....................................................................32
1.23 Battery test .........................................................................................33
1.23.1 Battery test fails.........................................................................................33
1.24 Flip slider counter..............................................................................34
1.24.1 Flip slider counter fails .............................................................................34
1.25 Verify Certificates...............................................................................35
1.25.1 Verify certificates fails...............................................................................35
1.26 IrDA Test.............................................................................................36
1.26.1 IrDA test fails .............................................................................................36
1.27 HDMI Test ...........................................................................................37
1.27.1 HDMI test fails............................................................................................37
1.28 Connector Ground Test.....................................................................38
1.28.1 Connector ground test fails......................................................................38
1.29 Network & Signal................................................................................39
1.29.1 No/Poor signal...........................................................................................39
1.30 SIM ......................................................................................................40
1.30.1 SIM not detected........................................................................................40
1.30.2 Incorrect SIM indicated.............................................................................40
1.31 Charging.............................................................................................41
1.31.1 Battery will not charge..............................................................................41
1.32 HandsFree by Wire.............................................................................42
1.32.1 Connection to Portable HandsFree fails..................................................42
1.33 Data Communication .........................................................................43
1.33.1 Data transfer via System Connector fails................................................43
2 Revision History...........................................................................44

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
4(44)
1 Problem Areas
1.1 Power
1.1.1 Will not power on or will switch
off randomly
Check:
Check whether the phone vibrates after the on/off key is
depressed.
Action:
If activation of the Vibrator is detected, refer to section 1.4
‘Display’.
Check:
Inspect the Battery Cover.
Action:
If not proper assembled – disassemble and reassemble it.
Check:
Inspect the contact pads on the Battery.
Action:
1. If dirty or oxidized – clean the pads.
2. If damaged – replace the Battery.
Check:
Inspect the Battery Contact pins.
Action:
1. If dirty or oxidized – clean the contact pins.
2. If adhesive is detected on the contact pins, use an eraser
to gently rub off the adhesive.
3. If damaged – Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
5(44)
Problem Areas: Power
Check:
Inspect the on/off key (a) on the Battery Cover and the on/off
switch (b) on the PBA.
Action
1. If the on/off key (a) or the on/off switch (b) is dirty or
clogged – clean them.
2. If the on/off key (a) is damaged – replace the Battery
Cover.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
6(44)
Problem Areas
1.2 Keys
1.2.1 Menu, Home and Back Keys
Check:
Inspect the touch area of the menu key, home key and back
key on the Front Assy.
Action
Refer to section 1.3 ‘Touch Screen’.
1.2.2 Volume Key
Check:
Inspect the volume key (a) on the Battery Cover and the
volume switches (b) on the PBA.
Action:
1. If the volume key (a) or the volume switches (b) is dirty or
clogged – clean them.
2. If the volume key (a) is damaged – replace the Battery
Cover.
3. Replace PBA.
1.2.3 On/Off key
Check:
Inspect the on/off key (a) on the Battery Cover and the on/off
switch (b) on the PBA.
Action:
1. If the on/off key (a) or the on/off switch (b) is dirty or
clogged – clean them.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
7(44)
Problem Areas: Keys
2. If the on/off key (a) is damaged – replace the Battery
Cover.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
8(44)
Problem Areas
1.3 Touch Screen
1.3.1 Touch Screen malfunction
Make sure that the Software Version is the latest!
Check:
Inspect the touch screen.
Action:
If dirty – clean it.
Check:
Inspect the BtB connector of the Front Assy to the PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
Check:
Inspect the FPC of the Front Assy.
Action:
1. If the FPC or the touch screen is damaged – replace the
Front Assy.
2. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
9(44)
Problem Areas
1.4 Display
1.4.1 Graphics & Illumination
Check:
Check whether the phone vibrates after the on/off key has
been pressed.
Action:
If the activation described above is not detected, refer to
section 1.1 ‘Power’.
Check:
Inspect the BtB connector of the Front Assy to the PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
Check:
Inspect the FPC of the Front Assy.
Action:
1. If the FPC or the touch screen is damaged – replace the
Front Assy.
2. Replace PBA.
Check:
Inspect the both sides of the ZIF connector on the Main PBA
and the LCD FPC.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
10(44)
Problem Areas: Display
Check:
Inspect the LCD TFT 3.2Inch and its FPC.
Action:
1. If dirty – clean it.
2. If the LCD TFT 3.2Inch or its FPC is damaged – replace
the LCD TFT 3.2Inch.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
11(44)
Problem Areas:
1.5 LED/Illumination
1.5.1 LED/Illumination
Check:
Inspect the external window area of the RGB LED on the
Front Assy.
Action:
1. If dirty – clean it.
2. If the external window area is damaged – replace the
Front Assy.
Check:
Inspect the RGB LED on the PBA and the Rubber Indicator
on the Front Assy.
Action:
1. If dirty or clogged – clean them.
2. If the Rubber Indicator is damaged – replace the Rubber
Indicator.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
12(44)
Problem Areas: Illumination
1.5.2 Menu key, Home key and Back
key Illumination
Check:
Inspect the illumination window of the menu key, home key
and back key on the Front Assy.
Action:
If dirty – clean them.
Check:
Inspect the BtB connector of the Front Assy to the PBA.
Action:
1. If not properly connected – disconnect and reconnect.
2. If dirty or oxidized – clean it.
3. If the illumination window or the FPC of the Front Assy is
damaged – replace the Front Assy.
4. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
13(44)
Problem Areas
1.6 Speaker
1.6.1 Speaker
Check:
Inspect the Speaker’s external port on the Battery Cover.
Action:
1. If clogged – clean the Speaker port.
2. If the Speaker port is damaged – replace the Battery
Cover.
Check:
Inspect the cavity of the Speaker.
Action:
If the protective film of the Speaker is attached – remove it.
Check:
Inspect the Speaker Mesh on the Frame Antenna Assy.
Action:
1. If dirty – clean it.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
14(44)
Problem Areas: Speaker
2. If the Speaker Mesh is damaged – replace it.
Check:
Inspect the Speaker Gasket on the PBA.
Make sure that the Speaker Gasket is attached on its
correct position as shown!
Action:
If damaged – replace it.
Check:
Inspect the Speaker’s pins and the pads on the PBA.
Note the orientation of the Speaker to be installed as
shown!
Action:
1. If dirty – clean them.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
15(44)
Problem Areas: Speaker
2. If the pins of the Speaker are damaged – replace the
Speaker.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
16(44)
Problem Areas
1.7 Earphone
1.7.1 Earphone
Check:
Inspect the Ear Speaker’s external port on the Front Assy.
Action:
1. If clogged – clean it.
2. If the port is damaged – replace the Front Assy.
Check:
Inspect the cavity of the Ear Speaker.
Action:
If the protective film of the Ear Speaker is attached – remove
it.
Check:
Inspect the Ear Speaker pins and the pads on the PBA.
Action:
1. If the Ear Speaker pins or the pads are dirty – clean them.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
17(44)
Problem Areas: Earphone
2. If the Ear Speaker or its pins are damaged – replace the
Ear Speaker.
3. Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
18(44)
Problem Areas
1.8 Microphone
1.8.1 Microphone
Check:
Inspect the Microphone‘s external port on the Battery Cover.
Action:
1. If clogged – clean the port.
2. If the port is damaged – replace the Battery Cover.
Check:
Inspect the Microphone on the PBA and the rubber on the
Front Assy.
Liquid is not allowed!
Action:
1. If dirty or clogged – clean them.
2. If the rubber of microphone is damaged – replace the
Front Assy.
3. If the microphone is damaged – replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
19(44)
Problem Areas
1.9 Vibrator
1.9.1 Vibrator not generating alerts
Action:
Replace PBA.

Troubleshooting Guide (mech)
1266-1682 Rev 4
 Sony Mobile Communications AB –
Company Internal
20(44)
Problem Areas
1.10 Camera
1.10.1 Camera defects
Check:
Inspect the Camera Lens on the Frame Antenna Assy.
Action:
1. If dirty – clean it.
2. If the Camera Lens is scratched or damaged – replace it.
Check:
Inspect the Camera and the pins of the camera socket.
Action:
1. If the Camera is damaged – replace it.
2. If the camera socket or its pins are damaged – Replace
PBA.
