Sony XPERIA Z5 COMPACT E5803 Quick reference guide

E5803/E5823
White paper
February 2016
Xperia™ Z5 Compact

White paper | Xperia™ Z5 Compact
February 2016
This document is published by Sony Mobile
Communications Inc., without any warranty*.
Improvements and changes to this text
necessitated by typographical errors,
inaccuracies of current information or
improvements to programs and/or equipment
may be made by Sony Mobile Communications
Inc. at any time and without notice. Such
changes will, however, be incorporated into new
editions of this document. Printed versions are to
be regarded as temporary reference copies only.
*All implied warranties, including without
limitation the implied warranties of
merchantability or fitness for a particular
purpose, are excluded. In no event shall Sony or
its licensors be liable for incidental or
consequential damages of any nature, including
but not limited to lost profits or commercial loss,
arising out of the use of the information in this
document.
This White paper is published by:
Sony Mobile Communications Inc.,
1-8-15 Konan, Minato-ku, Tokyo108-0075, Japan
www.sonymobile.com
© Sony Mobile Communications Inc., 2009-2016.
All rights reserved. You are hereby granted a
license to download and/or print a copy of this
document.
Any rights not expressly granted herein are
reserved.
First released version (September 2015)
Purpose of this document
Sony product white paper are intended to give an overview of a product and provide details in relevant
areas of technology.
NOTE: The illustration that appears on the title page is for reference only. All screen images and elements
are subject to change without prior notice.
Document history
Sony Mobile Developer World
For the latest technical documentation and development tools, go to www.sonymobile.com/developer.
Version
September 2015 First released version Version 1
September 2015 Second released version Version 2
February2016 Third released version Version 3

White paper | Xperia™ Z5 Compact
1 February 2016
Table of contents
Product overview ........................................................................................................2
Highlights ...............................................................................................................2
Facts - dimensions, weight, performance and networks ......................................3
Categorised feature list ..........................................................................................6
Technologies in detail .................................................................................................9
Accessibility and Usability ...............................................9
Device-to-device communications (local) ...........................................................10
ANT+™ wireless technology.............................................................................10
Bluetooth® wireless technology .......................................................................11
Wi-Fi® ...............................................................................................................12
DLNA Certified™ (Digital Living Network Alliance) ...........................................13
Messaging ...........................................................................................................14
MMS (Multimedia Messaging Service)..............................................................14
Email .................................................................................................................14
Positioning – location based services .................................................................15
Provisioning (OMA CP) ........................................................................................15
Multimedia (audio, image and video) ...................................................................16
Synchronisation (OMA DS, EAS, Google Sync™) ...............................................18
Web browser .......................................................................................................18
Memory in Android™ devices .............................................................................19
Trademarks and acknowledgements ..................................................................23

White paper | Xperia™ Z5 Compact
2 February 2016
Product overview
Highlights
• Camera: 23 MP Exmor RS™ Hybrid Autofocus main camera and a 5.1 MP Exmor R™ front camera
• Battery: Ultra STAMINA Mode and Qualcomm® Quick Charge™ compatibility
• Water and dust protection IP65/68
• Power button fingerprint sensor*
Sony’s next-generation camera technologies
Xperia™ Z5 Compact features Sony’s latest large 1/2.3 Exmor RS™ for mobile 23 MP sensor, F2.0 G
Lens and Bionz for mobile designed in collaboration with Sony’s Alpha engineers for clear, vivid imagery
every time, and better photos even under poor lighting conditions.
The Xperia™ Z5 Compact is equipped with Hybrid Autofocus, which lets you capture action and
movement accurately in various shooting conditions. Hybrid Autofocus uses two technologies to produce
crisp and clear photos: Phase detection AF (PDAF) for faster shutter speed response and Contrast
detection AF for added precision. With Hybrid Autofocus, you can take sharp photographs at a shutter
speed of <0.1 seconds.
5.1 MP front camera
Thanks to Superior Auto and SteadyShot with Intelligent Active Mode, the Xperia™ Z5 Compact’s 5.1-
megapixel front camera delivers sharper selfies in any situation and shake-free videos.
High-quality audio
The Xperia™ Z5 Compact supports High-Resolution Audio and Digital Noise Cancellation (DNC) for full,
high-quality audio playback with clarity and depth.
Extended battery life
With Sony’s Battery STAMINA mode, the Xperia™ Z5 Compact enables you to have a long-lasting
standby time on a single charge. In addition, The Xperia™ Z5 Compact is compatible with Qualcomm®
Quick Charge™ technology, which lets your device last for hours on only 10 minutes of charging time.
Water and dust protection
The Sony Xperia™ Z5 Compact is designed for both functionality and durability. You can carry your
device in the beach or during harsh weather and trust that it is protected from dust and moisture.
Integrated fingerprint sensor*
The Xperia™ Z5 Compact’s power button has an integrated fingerprint sensor and can be used for both
locking and unlocking the device. The fingerprint sensor can also be used as an additional security option
for applications that support the feature.
* This feature is not available in the US market.

White paper | Xperia™ Z5 Compact
3 February 2016
Facts - dimensions, weight, performance and
networks
Operating system Google™ Android™ 5.1 (Lollipop)
Processor 2 GHz / 1.5 GHz Qualcomm MSM8994 Snapdragon 810 Octa
Core 64-bit CPU
GPU Adreno 430
Size 127 x 65 x 8.9 mm
Weight 138 grams
Available colours Graphite Black, White, Yellow and Coral
SIM card Nano SIM
Main screen
Colours 16,777,216 colour TFT
Resolution 1280x720p HD
Size (diagonal) 4.6 inches
Scratch-resistant Chemical tempered glass + Anti-fingerprint coating
Input mechanisms
Text input On-screen QWERTY keyboard
Touch screen Capacitive
Touch gesture Yes – multi-touch, up to 10 fingers
Memory
RAM 2 GB
Flash memory Up to 32 GB*
Expansion slot microSD™ card, up to 200 GB (SDXC supported)
Memory card speed class Class 10**
Memory card UHS speed
class
Class 1**
Camera
Camera resolution 23 MP
Digital zoom 8x
Clear image zoom 5x
Photo light Yes – Pulsed LED
Video recording Yes – 4K

White paper | Xperia™ Z5 Compact
4 February 2016
Front Camera Yes – Full HD 1080p for video chat and 5.1 MP for camera
capture
ISO ISO 3200 maximum in manual mode
ISO 12800 maximum in Low Light mode for photos
ISO 4000 maximum in Night scene mode for video
Minimum focus distance*** 120 mm
Sensors
Accelerometer Yes
Ambient light sensor Yes
Barometer sensor Yes
eCompass™ Yes
Fingerprint Sensor Yes*****
Game rotation vector Yes
Geomagnetic rotation vector Yes
Gyroscope Yes
Magnetometer Yes
Step counter Yes
Step detector Yes
Significant motion detector Yes
Proximity sensor Yes
Networks
E5803 UMTS HSPA+ 850 (Band V), 900 (Band VIII), 1900 (Band II),
2100 (Band I) MHz
GSM GPRS/EDGE 850, 900, 1800, 1900 MHz
LTE (Bands 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 28, 38, 40)
E5823 UMTS HSPA+ 850 (Band V), 900 (Band VIII), 1900 (Band II),
2100 (Band I) MHz
GSM GPRS/EDGE 850, 900, 1800, 1900 MHz
LTE (Bands 1, 2, 3, 4, 5, 7, 8, 12, 17, 20, 28, 38, 40)
Data transfer speeds
GSM GPRS Up to 107 kbps
GSM EDGE Up to 296 kbps
HSUPA (upload) Cat 6, up to 5.8 Mbps
HSDPA (download) Cat 24, up to 42 Mbps
LET Cat 4 (E5803) Up to 50 Mbps (upload), up to 150 Mbps (download)

White paper | Xperia™ Z5 Compact
5 February 2016
* Memory comprises approximately 10.3 GB of firmware, plus 21.7 GB of “Internal storage” for music, pic-
tures and movies, and downloaded applications and their data. For more details about memory, see
“Memory in Android™ devices” on page 19.
** This device meets the minimum hardware requirements to support Class 10 / UHS Speed Class 1 Flash
memory. Flash memory performance is dependent on the application and task being performed on the
device. If you would like to know more about your memory card, refer to the technical specifications that
came with the card.
*** This specification applies only to the Main camera.
**** Values are according to GSM Association Battery Life Measurement Technique as performed in con-
trolled laboratory conditions. Actual time may vary.
***** This feature is not available in the US market.
NOTE: Battery performance may vary depending on network conditions and configurations, as well as
device usage.
NOTE: All performance metrics are measured under laboratory conditions.
LTE Cat 6 (E5823) Up to 50 Mbps (upload), up to 300 Mbps (download)
Battery performance
Talk time (GSM) Up to 11 hours 30 min****
Standby time (GSM) Up to 520 hours****
Talk time (UMTS) Up to 14 hours 50 min****
Standby time (UMTS) Up to 520 hours****
Standby time (LTE) Up to 490 hours****
Music listening time Up to 77 hours****
Video playback time Up to 8 hours 20 min****
Battery (Embedded) 2700 mAh minimum

White paper | Xperia™ Z5 Compact
6 February 2016
Categorised feature list
Call
Answering machine*
Noise suppression
Slow talk
Smart call handling
Talk equaliser
Voice enhancement
Messaging
Email
Multimedia messaging (MMS)
Text messaging (SMS)
Applications
Small Apps
What's new
Xperia™ Lounge*
Facebook™ application*
Xperia™ Socialife*
Lifelog
PC Companion
Media Go™
Introduction to Xperia™
Entertainment
3D games
Movie creator
PlayMemories
PS4™ Remote Play
Radio (FM radio with RDS)*
Reader mode*
Sony Entertainment Network*
Organiser
ActiveSync®
Airplane mode
Alarm clock
Battery STAMINA mode
Calculator
Calendar
Contacts
Document readers/editors
Queue background data
Setup guide
Sketch
Stopwatch
Timer
Google
Gmail™*
Google+*
Google Chrome™*
Google Play™*
Google™ search*
Google Voice™ Search*
Google voice typing
Google Maps™ for Mobile with
Street view*
Google Wallet™*
Hangouts™*
Smart Lock
YouTube™*

White paper | Xperia™ Z5 Compact
7 February 2016
Camera
- Photo
23 MP camera with Sony Exmor
RS™ for mobile image sensor*****
24 mm wide-angle*****
25 mm wide-angle****
Hybrid Auto focus*****
Quick Launch*****
Flash/Pulsed LED*****
Flash/Photo light*****
Red-eye reduction*****
Touch capture
Touch focus*****
Superior Auto
Image stabiliser
Face detection
Geotagging
Self-timer
8x digital zoom*****
5x clear image zoom*****
Smile Shutter™
Object tracking*****
HDR
Scene recognition
White balance
5.1 MP Front-facing camera with
Sony Exmor R™ for mobile image
sensor****
- Video
Auto focus*****
Front-facing camera (1080p)****
Geotagging
8x digital zoom*****
Smile Shutter™
Object tracking*****
Self-timer
SteadyShot™
Scene recognition*****
Video recording (4K)*****
White balance*****
- Add-on applications
AR Effect
AR mask
Creative effects
Face in picture
Multi-camera
Sound Photo
Timeshift video*
Style editor
Style portrait
Sweep Panorama
Music
3D Surround Sound (VPT)
Album art
Automatic headset compensation
Bluetooth® stereo (aptX®, A2DP,
LDAC)
ClearAudio+
Clear Bass™
DSEE HX***
Dynamic normalizer
High-Res Audio (LPCM, FLAC,
ALAC, DSD)
High-Res Audio via 3.5 mm audio
jack and USB
Low power audio playback***
Music application
S-Force Front Surround
Stereo speakers
TrackID™ music recognition*
Connectivity
aGNSS
ANT+™ sport, fitness, health sup-
port
Bluetooth® 4.1 wireless technol-
ogy
Screencasting
DLNA Certified™
HDCP
Media Transfer Protocol support
MHL 3.0 support + 5-pin support
Micro USB support
MirrorLink
Native USB tethering
NFC
One Touch Setup
Screen mirroring
Smart Connect
Throw
USB charging
USB High speed 2.0 support
USB Host
Wi-Fi®
Wi-Fi® Hotspot functionality
Wi-Fi CERTIFIED Miracast™

White paper | Xperia™ Z5 Compact
8 February 2016
* This service is not available in all markets.
** The Xperia™ Z5 Compact is waterproof and protected against dust, so don’t worry if you get caught in
the rain or want to wash off dirt under a tap, but remember: all ports and attached covers should be firmly
closed. You should not: put the device completely underwater; or expose it to seawater, salt water,
chlorinated water or liquids such as drinks. Abuse and improper use of device will invalidate warranty. The
device has Ingress Protection rating IP65/IP68. For more info, see www.sonymobile.com/waterproof. Note
the Xperia™ Z5 Compact has a capless USB port to connect and charge. The USB port needs to be
completely dry before charging.
*** This feature is only available when you play music using the Music application.
**** This feature is only supported by the front camera.
***** This feature is not supported by the front camera.
*****This feature is not available in the US market.
Text Input
Gesture input*
Handwriting recognition
On-screen QWERTY keyboard
Predictive text input
Voice input*
Display
Auto rotation
Glove mode
Screenshot capturing
Screen video recording
Smart backlight control
Super-vivid mode
TRILUMINOS™ Display for mobile
Wet finger tracking
X-Reality™ for mobile
Hardware
3.5 mm audio jack Digital Noise
Cancelling (DNC)
Fingerprint Sensor*****
IPX5 and IPX8 (waterproof)**
IP6X (Dust tight)
Live Color LED

White paper | Xperia™ Z5 Compact
9 February 2016
Technologies in detail
The information presented in this section is a general overview of the technology incorporated into the
product. However, hardware and software levels of compliance to standards and specifications vary
between products and markets. For more information, contact Sony Mobile Developer World or the
relevant Sony representative.
Accessibility and Usability
* This feature is subject to change in future releases of Google™ Android™.
** The TTY feature is for deaf or hearing-impaired users.
Talkback* Yes
Captions* Yes
Magnifications gestures* Yes
Large Text* Yes
High Contrast Text* Yes
Power button ends call* Yes
Auto-rotation* Yes
Speak Passwords* Yes
Accessibility Shortcuts* Yes
Text – to – Speech* Yes
Touch and hold delay* Yes
Color Inversion* Yes
Color correction* Yes
Hearing Aid Compatibility (HAC) Yes
Teletypewriter (TTY)** Yes

White paper | Xperia™ Z5 Compact
10 February 2016
Device-to-device communications (local)
ANT+™ wireless technology
Compatible devices Some ANT+™ compatible devices may require installation of addi-
tional software.
Frequency band 2.4 GHz
Data transfer rate Up to 60 Kbps
Encryption AES-128
Topologies One to Many, Many to One, Peer to Peer, Star, Practical Mesh

White paper | Xperia™ Z5 Compact
11 February 2016
Bluetooth® wireless technology
More information:
www.sonymobile.com/developer
www.bluetooth.com
Bluetooth® profiles supported Advanced Audio Distribution Profile v1.2
Audio/Video Remote Control Profile v1.3
Device Identification Profile v1.3
Generic Access Profile
Generic Attribute Profile Client/Server over LE
Handsfree Profile v1.7 (Wide band speech)
Headset Profile v1.2
HID over GATT Profile v1.0
Human Interface Device Profile, Host role v1.0
Messaging Access Profile v1.2
Object Push Profile v1.2
Personal Area Networking Profile v1.0
Phonebook Access Profile v1.1
Serial Port Profile v1.2
Core version and supported
core features
Version 4.1
Bluetooth Low Energy
Other supported features aptX® CD quality audio streaming over Bluetooth®
LDAC High sound quality audio streaming over Blue-
tooth®
Connectable devices Products that support at least one of the Bluetooth® pro-
files listed above.
Bluetooth® 4.1 accessories generally require the installa-
tion of a supporting application.

White paper | Xperia™ Z5 Compact
12 February 2016
Wi-Fi®
Supported standards IEEE 802.11a/b/g/n/ac Wi-Fi®
Wi-Fi Direct™, Wi-Fi Protected Setup, Wi-Fi CERTIFIED
Passpoint™, Wi-Fi CERTIFIED Miracast™
Connectable devices Wi-Fi® access points
Wi-Fi Direct™ compatible devices
Frequency band 2.4 GHz/5 GHz
Data transfer rate Up to 433 Mbit/s
Security Open Authentication
Shared Authentication
EAP-SIM
EAP-AKA
EAP-TLS
EAP-TTLS/MSCHAPv2
PEAPv0/EAP-MSCHAPv2
PEAPv1/EAP-GTC
WPA Personal and WPA2 Personal
WPA Enterprise and WPA2 Enterprise
Encryption WEP 64 bit, WEP 128 bit, TKIP and CCMP (AES)
Power save WMM-UAPSD
QoS WMM

White paper | Xperia™ Z5 Compact
13 February 2016
DLNA CertifiedTM (Digital Living Network Alliance)
Supported Device Classes M-DMS – Mobile Digital Media Server
Media Types: image, video and music
Summary: The digital media server exposes the media
files in your device to a Wi-Fi® network. The files can
then be accessed from other DLNA Certified™ clients or
Sony devices which support home networks.
M-DMP – Mobile Digital Media Player
Media Types: image, video and music
Summary: Play content stored on another device, for
example, a server or a PC, directly on your device.
M-DMC – Mobile Digital Media Controller
Media Types: image, video and music
Summary: A remote controller that locates media files and
plays them on your device.
+PU+
Media Types: image, video and music
Summary: Play media in your device on another device,
such as a TV or a PC using 2 box push technology. +PU+
is integrated in the Album, Videos and Music applications.
+DN+
Media Types: image, video and music
Summary: Download content stored on another device,
for example, a server or a PC, and play the downloaded
content directly on your device.
+UDO+
Media Types: image, video and music
Summary: The digital media server also has the capability
to get uploaded files from other DLNA Certified™ clients.
Supported Bearers Wi-Fi®
Wi-Fi Direct™
DRM Support The DLNA Certified™ implementation does not support
DRM-protected content.

White paper | Xperia™ Z5 Compact
14 February 2016
Messaging
MMS (Multimedia Messaging Service)
According to OMA Multimedia Messaging Service v1.0 + SMIL
Email
More information:
www.sonymobile.com/developer
www.openmobilealliance.org
Bearer type (IP) GPRS, EGPRS, UMTS, LTE, Wi-Fi®
Character sets BIG5 Traditional Chinese
GB18030
ISO-2022-JP Japanese
ISO-8859-1
ISO-8859-2 Eastern Europe
ISO-8859-5 Cyrillic
ISO-8859-7 Greek
ISO-8859-9 Turkish
ISO 8859-11
KOI8-R Cyrillic
Shift_JIS Japanese
US-ASCII
UTF-16
UTF-8
Windows® 874
Windows® 1251 Cyrillic
Windows® 1252
Windows® 1254 Turkish
Windows® 1258 Vietnamese
Protocols POP3 and IMAP4
Push email Microsoft® Exchange ActiveSync® (EAS)
IMAP4 IDLE (RFC2177)
Secure email SSL/TLS, both port methods (POPS/IMAPS) and
STARTTLS
HTML mail Yes (read only)

White paper | Xperia™ Z5 Compact
15 February 2016
Positioning – location based services
Supported standards:
• OMA Secure User Plane Location (SUPL) v1.0 and v2.0
• 3GPP™ Control Plane location (incl. Emergency location)
• Qualcomm® GPSOneXtra™
Supported satellite systems:
•GPS
• GLONASS
•BeiDou*
NOTE1: When needed, the device automatically uses a combination of all available satellite system to
accurately provide location information.
* BeiDou satellites are not used for providing location information in U.S. territory.
Provisioning (OMA CP)
OMA CP version 1.1

White paper | Xperia™ Z5 Compact
16 February 2016
Multimedia (audio, image and video)
Audio Playback Decoder format Supported file format
AAC-LC MP4(.mp4), M4V(.m4v),
3GPP(.3gp, .3gpp), MPEG-2
TS(.ts, .m2ts, .tts), AVI(.avi),
ADTS(.aac), M4A(.m4a)
AAC+ MP4(.mp4), 3GPP(.3gp, .3gpp),
MPEG-2 TS(.ts, .m2ts, .tts),
AVI(.avi), ADTS(.aac)
eAAC+ MP4(.mp4), 3GPP(.3gp, .3gpp),
MPEG-2 TS(.ts, .m2ts, .tts),
AVI(.avi), ADTS(.aac)
AAC-ELD MP4(.mp4), 3GPP(.3gp, .3gpp)
ALAC M4A(.m4a)
AMR-NB 3GPP(.3gp, .3gpp), AMR(.amr)
AMR-WB 3GPP(.3gp, .3gpp), AWB(.awb)
DSD DSF(.dsf), DSDIFF(.dff)
FLAC Matroska(.mkv), FLAC(.flac),
MatroskaAudio(.mka)
MIDI SMF(.mid), XMF(.xmf), Mobile
XMF(.mxmf), RTTTL(.rtttl),
RTX(.rtx), OTA(.ota), iMel-
ody(.imy)
MP3 MP3 (.mp3)
PCM AVI(.avi), Matroska(.mkv),
MatroskaAudio(.mka),
WAVE(.wav), AIFF(.aiff, .aif, .aifc)
Opus Matroska(.mkv), WebM(.webm),
MatroskaAudio(.mka)
Vorbis Matroska(.mkv), WebM(.webm),
MatroskaAudio(.mka),
Ogg(.ogg)
WMA ASF (.wma)
Audio Recording Encoder format Supported file format
AAC-LC MP4(.mp4), ADTS(.aac)
AAC+ MP4(.mp4)
AAC-ELD MP4(.mp4)
AMR-NB 3GPP(.3gp), AMR(.amr)
AMR-WB 3GPP(.3gp), AWB(.awb)

White paper | Xperia™ Z5 Compact
17 February 2016
Image Playback Decoder format Supported file format
BMP BMP (.bmp)
GIF GIF (.gif)
JPEG JPEG (.jpg, .jpeg)
PNG PNG (.png)
WebP WebP (.webp)
Image Capture Encoder format Supported file format
JPEG JPEG (.jpg)
PNG PNG(.png)
WebP WebP(.webp)
Video Playback Decoder format Supported file format
MPEG-4 Video MP4(.mp4), M4V(.m4v),
3GPP(.3gp, .3gpp)
H.263 MP4(.mp4), 3GPP(.3gp, .3gpp)
H.264 MP4(.mp4), M4V(.m4v),
3GPP(.3gp, .3gpp), MPEG-2
TS(.ts, .m2ts, .tts), AVI(.avi),
Matroska(.mkv)
H.265 MP4(.mp4), Matroska(.mkv)
VP8 Matroska(.mkv), WebM(.webm)
VP9 Matroska(.mkv), WebM(.webm)
Xvid AVI(.avi)
Video Recording Encoder format Supported file format
MPEG-4 Video MP4(.mp4), 3GPP(.3gp)
H.263 MP4(.mp4), 3GPP(.3gp)
H.264 MP4(.mp4), 3GPP(.3gp)
H.265 MP4(.mp4)
VP8 WebM(.webm)

White paper | Xperia™ Z5 Compact
18 February 2016
Synchronisation (OMA DS, EAS, Google Sync™)
OMA Data Synchronisation protocol versions 1.1.2 and 1.2
OMA Data Formats: vCard 2.1, vCalendar 1.0
Microsoft® Exchange ActiveSync® protocol version 2.5
Microsoft® Exchange ActiveSync® protocol version 12
Microsoft® Exchange ActiveSync® protocol version 12.1
Microsoft® Exchange ActiveSync® protocol version 14
Microsoft® Exchange ActiveSync® protocol version 14.1
Google Sync™
Related information:
www.sonymobile.com/developer
Web browser
Google Chrome™ for Android™ is pre-installed in markets/regions where no restrictions apply.
Related information:
https://play.google.com/store/apps/details?id=com.android.chrome
