Sony CD Mavica MVC-CD250 User manual

SERVICE MANUAL
DIGITAL STILL CAMERA
LEVEL 2
Link
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
ADJUSTMENTS
REPAIR PARTS LIST
SPECIFICATIONS
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
ADJUSTMENTS
REPAIR PARTS LIST
SPECIFICATIONS
Link
Revision History
Revision History
Ver 1.0 2002. 04
On the SY-76 board
This service manual procides the information that is premised
the circuit board replacement service and not intended repair
inside the SY-76 board.
Therefore, schematic diagram, printed wiring board and
electrical parts list of the SY-76 board are not shown.
The following pages are not shown.
SY-76 board
Schematic diagram ......................... Pages 4-15 to 4-40
Printed wiring board ........................ Pages 4-57 to 4-60
Electrical parts list ........................... Pages 6-15 to 6-23
The above-described information is shown in service
manual Level 3.
MVC-CD250/CD400
US Model
Canadian Model
E Model
Chinese Model
Australian Model
Japanese Model
MVC-CD250/CD400
AEP Model
UK Model
Korea Model
Tourist Model
MVC-CD400
•For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (992996841.pdf).
•This service manual contains information for Japanese model as well.
•Table for differences of function of each model
Photo: MVC-CD400

— 2 —
MVC-CD250/CD400
SPECIFICATIONS
COVER
COVER
System
Image device
MVC-CD400
8.98 mm (1/1.8 type) color CCD
Primary color filter
MVC-CD250
6.64 mm (1/2.7 type) color CCD
Primary color filter
Total pixels number of camera
MVC-CD400
Approx. 4 130 000 pixels
MVC-CD250
Approx. 2 110 000 pixels
Lens MVC-CD400
3 ×zoom lens
f = 7.0 – 21.0 mm (9/32 – 27/32 inches)
(34 – 102 mm (1 3/8 – 4 1/8 inches)
when converted to a 35 mm still camera)
F2.0 – 2.5
MVC-CD250
3 ×zoom lens
f = 6.4 – 19.2 mm (9/32 – 25/32 inches)
(41 – 123 mm (1 5/8 – 4 7/8 inches)
when converted to a 35 mm still camera)
F3.8 – 3.9
Camera
Effective pixels number of camera
MVC-CD400
Approx. 3 950 000 pixels
MVC-CD250
Approx. 1 980 000 pixels
Exposure control
MVC-CD400
Automatic exposure, Shutter speed
priority, Aperture priority,Manual
exposure, Scene selection (4 modes)
MVC-CD250
Automatic exposure, Scene selection
(3 modes)
White balance
Automatic, Daylight, Cloudy,
Fluorescent, Incandescent, One-push*
* MVC-CD400 only
Data formats
Moving images: MPEG1
Still images: JPEG, GIF (for Clip
Motion), TIFF
Audio with still image: MPEG1
(Monaural)
Recording media
8 cm CD-R/CD-RW
Flash MVC-CD400
Recommended distance (ISO set to
Auto): 0.5 m to 5.0 m (19 3/4 inches to
196 7/8 inches)
MVC-CD250
Recommended distance (ISO set to
Auto): 0.8 m to 3.5 m (31 1/2 inches to
137 7/8 inches)
AC-L10A/L10B AC power adaptor
Power requirements
100 to 240 V AC, 50/60 Hz
Rated output voltage
DC 8.4 V, 1.5 A in operating mode
Operating temperature
0°C to +40°C (32°F to +104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions
125 ×39 ×62 mm
(5 ×1 9/16 ×2 1/2 inches) (w/h/d,
excluding maximum protrusions)
Mass Approx. 280 g (10 oz)
NP-FM50 battery pack
Used battery
Lithium-ion battery
Maximum voltage
DC 8.4 V
Nominal voltage
DC 7.2 V
Capacity 8.5 Wh (1 180 mAh)
Operating temperature
0°C to +40°C (32°F to +104°F)
Dimensions
38.2 ×20.5 ×55.6 mm
(1 9/16 ×13/16 ×2 1/4 inches) (w/h/d)
Mass Approx. 76 g (3 oz)
Accessories
•AC-L10A/L10B AC power adaptor (1)
•Power cord (mains lead) (1)
•USB cable (1)
•NP-FM50 battery pack (1)
•A/V connecting cable (1)
•8cm CD adaptor (1)
•Mavica disc (7) (CD-R (6), CD-RW (1))
•Shoulder strap (1)
•Lens cap (1)
•Lens cap strap (1)
•CD-ROM (SPVD-009) (1)
•Operating instructions (1)
Design and specifications are subject to change
without notice.
Drive
Readout Non-contact optical readout (using
semiconductor laser)
Laser Wavelength: 779 to 789 nm
Maximum output: 23 mW
Input and Output connectors
A/V OUT (MONO) (Monaural)
Minijack
Video: 1 Vp-p, 75 Ω, unbalanced,
sync negative
Audio: 327 mV (at a 47 kΩload)
Output impedance 2.2 kΩ
ACC jack Mini-minijack (ø 2.5 mm)
USB jack mini-B
LCD screen
Used LCD panel
6.2 cm (2.5 type) TFT drive
Total number of dots
123 200 (560 ×220) dots
General
Used battery pack
NP-FM50 (supplied)
Power requirements
7.2 V
Power consumption (during shooting
with LCD backlight on)
MVC-CD400
3.0 W
MVC-CD250
2.5 W
Operating temperature
0°C to +40°C (32°F to +104°F)
Storage temperature
–20°C to +60°C (–4°F to +140°F)
Dimensions
MVC-CD400
Approx. 138 ×95 ×103 mm
(5 1/2 ×3 3/4 ×4 1/8 inches)
(W/H/D, excluding maximum
protrusions)
MVC-CD250
Approx. 138 ×95 ×101 mm
(5 1/2 ×3 3/4 ×4 inches)
(W/H/D, excluding maximum
protrusions)
Mass MVC-CD400
Approx. 638 g (1 lb 7 oz) (including
battery pack NP-FM50, disc, and lens
cap)
MVC-CD250
Approx. 608 g (1 lb 6 oz) (including
battery pack NP-FM50, disc, and lens
cap)

— 3 —
MVC-CD250/CD400
Table for differences of function
Model MVC-CD250 MVC-CD400
US, Canadian, E, Japanese, US, Canadian, AEP, UK, E,
Destination Australian, Chinese Japanese, Australian, Chinese,
Korea, Tourist
Carl Zeiss lens a
Lens Movable lens a
Optical zoom 3 ×
Digital zoom 6 ×
CCD imager Size 1/2.7 type 1/1.8 type
Pixels 2.1 mega 4.1 mega
AF optical system AF illuminator (LED) Hologram AF (Laser diode)
2272 ×1704
2272 (3:2)
Still 1600 ×1200
1600 (3:2)
Image size 1280 ×960
640 ×480
320 (HQ)
Movie 320 ×240
160 ×112
CD board CD-394 CD-393
FS board FS-85 FS-84
JK board JK-225 JK-224
PK board PK-66 PK-65
LS board LS-61

— 4 —
MVC-CD250/CD400
1. Checkthe area of your repair forunsolderedorpoorly-soldered
connections. Checkthe entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for partswhich, through functioning,show obvious signs
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270˚C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
SAFETY-RELATED COMPONENTWARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
WARNING!!
WHEN SERVICING, DO NOT APPROACH THE LASER
EXIT WITH THE EYE TOO CLOSELY. IN CASE IT IS
NECESSARY TO CONFIRM LASER BEAM EMISSION,
BE SURE TO OBSERVE FROM A DISTANCE OF MORE
THAN 30 cm FROM THE SURFACE OF THE
OBJECTIVE LENS ON THE OPTICAL PICK-UP BLOCK. CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous
radiation exposure.
CAUTION:
The use of optical instrument with this product will increase eye
hazard.

— 5 —
MVC-CD250/CD400
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Note for Repair ································································1-1
1-2. Discharging of the FLASH unit’s Charging Capacitor ···1-1
1-2-1.Preparing the Short Jig ····················································1-1
1-2-2.Discharging the Capacitor ···············································1-1
1-3. Notes on Handling the Laser Diode
[Laser Unit (D9001: MVC-CD400) and
Base Unit (DDX-G3000)] ··················································1-2
1-3-1.Precautions for Checking Emission of Laser Diode
[Base Unit (DDX-G3000)] ··············································1-2
1-3-2.Soldering Conditions of Laser Unit
(D9001: MVC-CD400) ···················································1-2
1-4. Description on Self-diagnosis Display ····························1-3
1-5. Power Supplying Method ················································1-3
2. DISASSEMBLY .........................................................2-1
2-1. Side Cabinet Block Assembly ·········································2-2
2-2. Cabinet (Rear) Block Assembly ······································2-2
2-3. Lens Block Assembly ······················································2-3
2-4. Stroboscope Block Assembly ··········································2-4
2-5. Flash Unit ········································································2-5
2-6. BT Holder Assembly ·······················································2-5
2-7. SY-76 Board ····································································2-6
2-8. DDX-G3000 Complete Assembly ···································2-7
2-9. Base Unit ·········································································2-7
2-10. PK-65/66 Board·······························································2-8
2-11. LCD Module····································································2-9
2-12. Circuit Boards Locaion ·················································2-10
2-13. Flexible Boards Locaion ···············································2-11
3. BLOCK DIAGRAMS
3-1. Overall Block Diagram ···················································3-1
3-10. Power Block Diagram 1 ················································3-19
3-11. Power Block Diagram 2 ················································3-21
4. PRINTEDWIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagrams
Frame Schematic Diagram (1/2) ·····································4-1
Frame Schematic Diagram (2/2) ·····································4-3
4-2. Schematic Diagrams························································4-5
CD-393 (1/2) (CCD IMAGER)
(MVC-CD400)································································4-7
CD-393 (2/2) (CAMERA MODULE)
(MVC-CD400)································································4-9
CD-394 (1/2) (CCD IMAGER)
(MVC-CD250)······························································4-11
CD-394 (2/2) (CAMERA MODULE)
(MVC-CD250)······························································4-13
PK-65/66 (1/2)
(LCD DRIVE, TIMING GENERATOR) ·····················4-41
PK-65/66 (2/2) (BACK LIGHT DRIVE) ·····················4-43
FS-84/85 (DC IN, CONTROL SWITCH) ····················4-45
JK-224/225 (JACK) ······················································4-47
LS-61 (LENS CAP SWITCH) (MVC-CD400) ············4-49
CONTROL SWITCH BLOCK (ZK-860/880) ·············4-50
4-3. Printed Wiring Boards ···················································4-51
CD-393 (MVC-CD400) ················································4-53
CD-394 (MVC-CD250) ················································4-55
PK-65/66 ·······································································4-61
FS-84/85 ········································································4-65
JK-224/225 ····································································4-67
LS-61 (MVC-CD400) ···················································4-69
FP-482/489/490 ·····························································4-71
4-4. Waveforms ·····································································4-73
Section Title Page Section Title Page
4-5. Mounted Parts Location ················································4-78
5. ADJUSTMENTS
1-1. Adjusting Items when Replacing
Main Parts and Boards ····················································5-2
5-1. Camera Section Adjustments···········································5-3
1-1. Preparations Before Adjustment
1-1-1.List of Service Tools ························································5-3
1-1-2.Preparations ·····································································5-4
1-1-3.Discharging of the Flashlight Power Supply···················5-4
1-1-4.Precaution
1. Setting the Switch····························································5-6
2. Order of Adjustments ······················································5-6
3. Subjects ···········································································5-6
4. Preparing the Flash Adjustment Box·······························5-7
1-2. Initialization of A, B, D, E, F, 7, 9 Page Data
1-2-1.Initialization ofA, D Page Data
1. Initializing A, D Page Data··············································5-8
2. Modification ofA, D Page Data ······································5-8
3. A Page Table····································································5-8
4. D Page Table····································································5-8
1-2-2.Initialization of B, E, F, 7, 9 Page Data
1. Initializing B, E, F, 7, 9 Page Data ··································5-9
2. Modification of B, E, F, 7, 9 Page Data···························5-9
3. B Page Table ····································································5-9
4. E Page Table ····································································5-9
5. F Page Table ··································································5-10
6. 7 Page Table···································································5-12
7. 9 Page Table···································································5-12
1-3. Video System Adjustment
1. Video Output LevelAdjustment ····································5-13
1-4. Camera System Adjustments ·········································5-14
Data Setting During Camera SystemAdjustments········5-14
Picture Frame Setting ····················································5-15
Check on the Oscilloscope ············································5-15
1. Hall Adjustment (MVC-CD250 only) ···························5-16
2. Flange Back Adjustment
(Using the minipattern box) ··········································5-17
3. Flange Back Adjustment
(Using the flange back adjustment chart
and subject more than 500 m away) ······························5-18
4. Flange Back Check························································5-19
5. F No. Compensation······················································5-19
6. Mechanical Shutter Adjustment ····································5-20
7. Light Value Adjustment ·················································5-20
8. Mixed Color CancelAdjustment ···································5-21
9. Auto White Balance 3200K Standard Data Input 1 ······5-21
10. Auto White Balance 3200K Standard Data Input 2 ······5-22
11. Auto White Balance 3200K Standard Data Input 3 ······5-22
12. Auto White Balance 3200K Check 1 ····························5-23
13. Auto White Balance 3200K Check 2 ····························5-24
14. Auto White Balance 3200K Check 3 ····························5-24
15. Auto White Balance 5800K Standard Data Input 1 ······5-25
16. Auto White Balance 5800K Standard Data Input 2 ······5-26
17. Auto White Balance 5800K Standard Data Input 3 ······5-26
18. Auto White Balance 5800K Check 1 ····························5-27
19. Auto White Balance 5800K Check 2 ····························5-28
20. Auto White Balance 5800K Check 3 ····························5-29
21. Color Reproduction Adjustment ····································5-30
22. CCD White Defect Compensation ································5-31
23. CCD Black Defect Compensation·································5-32
24. CCD Linearity Check ····················································5-33
25. Strobe White Balance Adjustment·································5-34
26. AF Illumination Check (MVC-CD250 only) ················5-36
1-5. LCD System Adjustments ·············································5-37

— 6 —
MVC-CD250/CD400
1. LCD Initial Data Input (1)·············································5-38
2. LCD Initial Data Input (2)·············································5-38
3. Back Light Adjustment (PK-65/66 Board)····················5-39
4. VCO Adjustment (PK-65/66 Board) ·····························5-39
5. D Range Adjustment (PK-65/66 Board) ·······················5-40
6. Contrast Adjustment (PK-65/66 Board) ························5-40
7. V-COM LevelAdjustment (PK-65/66 Board)···············5-41
8. V-COM Adjustment (PK-65/66 Board)·························5-41
9. White Balance Adjustment (PK-65/66 Board) ··············5-42
1-6. System Control System Adjustments
1. Battery Down Adjustment ·············································5-43
2. Serial No. Input ·····························································5-44
5-2. Service Mode
2-1. Adjusting Remote Commander ·····································5-45
1. Used the Adjusting Remote Commander ······················5-45
2. Precautions upon Using the Adjusting
Remote Commander······················································5-45
2-2. Data Process ··································································5-46
2-3. Service Mode
1. Setting the Test Mode ····················································5-47
2. Bit Value Discrimination ···············································5-47
3. Switch Check (1) ···························································5-48
4. Switch Check (2) ···························································5-48
5. Switch Check (3) (MVC-CD400 only) ·························5-48
6. Switch Check (4) ···························································5-49
7. Switch Check (5) ···························································5-49
8. Switch Check (6) ···························································5-49
9. LED Check ····································································5-50
10. Self Diagnosis Log Check·············································5-50
11. Record of Use Check·····················································5-50
6. REPAIR PARTS LIST
6-1. Exploded Views ·······························································6-1
6-1-1.Overall Assembly ····························································6-1
6-1-2.Cabinet (Front) Block Assembly (MVC-CD250) ···········6-2
6-1-3.Cabinet (Front) Block Assembly (MVC-CD400) ···········6-3
6-1-4.Lens Block Assembly (MVC-CD250) ····························6-4
6-1-5.Lens Block Assembly (MVC-CD400) ····························6-5
6-1-6.Stroboscope Block Assembly ··········································6-6
6-1-7.DDX-G3000 Complete Assembly ···································6-7
6-1-8.Side Cabinet Assembly····················································6-8
6-1-9.Cabinet (Rear) Block Assembly ······································6-9
6-2. Electrical Parts List ·······················································6-10
Section Title Page
*The color reproduction frame is shown on page 147.

1-1
SECTION 1
SERVICE NOTE
MVC-CD250/CD400
COVER
COVER
The charging capacitor of the Flash unit is charged up to the
maximum 300 V potential.
There is a danger of electric shock by this high voltage when the
battery is handled by hand. The electric shock is caused by the
charged voltage which is kept without discharging when the main
power of the unit is simply turned off. Therefore, the remaining
voltage must be discharged as described below.
1-2-1. Preparing the Short Jig
To preparing the short jig, a small clip is attached to each end of a
resistor of 1 kΩ/1 W (1-215-869-11).
Wrap insulating tape fully around the leads of the resistor to prevent
electrical shock.
1 kΩ/1 W
Wrap insulating tape.
1-2-2. Discharging the Capacitor
Short-circuit between the positive and the negative terminals of
charged capacitor with the short jig about 10 seconds.
1-1. NOTE FOR REPAIR
Make sure that the flat cable and flexible board are not cracked of
bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
When remove a connector, don’t pull at wire of connector.
It is possible that a wire is snapped.
When installing a connector, don’t press down at wire of connector.
It is possible that a wire is snapped.
Capacitor
Capacitor retainer
R: 1 kΩ/1 W
(Part code:
1-215-869-11)
1-2. DISCHARGING OFTHE FLASH UNIT’S CHARGING CAPACITOR

1-2
MVC-CD250/CD400
1-3. NOTES ON HANDLINGTHE LASER DIODE
[LASER UNIT (D9001: MVC-CD400) AND BASE UNIT (DDX-G3000)]
The laser diode may suffer electrostatic breakdown because of the
potential difference generated by the charged electrostatic load, etc.
on clothing and the human body.
During repair, pay attention to electrostatic breakdown and also use
the procedure in the printed matter which is included in the repair
parts.
The flexible board is easily damaged and should be handled with
care.
1-3-1. Precaution for Checking Emission of Laser
Diode [Base Unit (DDX-G3000)]
Laser light of the equipment is focused by the object lens in the
optical pick-up so that the light focuses on the reflection surface of
the disc. Therefore, be sure to keep your eyes more then 30 cm
apart from the object lens when you check the emission of laser
diode.
Optical pick-up
(Laser diode)
Laser unit
(D9001)
[MVC-CD400]
1-3-2. Soldering Conditions of Laser Unit
(D9001: MVC-CD400)
Temperature of 350 °C
the Soldering Iron
Time to Solder 3 seconds
Interval to Solder Next terminal is soldered after
waiting for 1 second

1-3
MVC-CD250/CD400
1-4. DESCRIPTION ON SELF-DIAGNOSIS DISPLAY
Self-diagnosis display
• C: ss: ss
You can reverse the camera
malfunction yourself. (However,
contact your Sony dealer or local
authorized Sony service facility
whenyou cannot recoverfromthe
camera malfunction.)
• E: ss: ss
Contact your Sony dealer or local
authorized Sony service facility.
1-3E
Note: The error code is cleared if the battery is removed.
*1 : The error display is given in two ways.
1-5. POWER SUPPLYING METHOD
Use the AC power adaptor (AC-L10A/L10B) when supplying the power to this set.
Display Code
C:32:01
C:13:01
E:91:01
*1
E:61:00
*1
E:61:10
Countermeasure
Change the disk and turn off the main
power then back on.
Replace the CD-R/RW disk.
Checking of flash unit or replacement of
flash unit
Checking of lens drive circuit
Cause
Defective base unit.
• The type of CD-R/RW disk that cannot
be used by this machine, is inserted.
• Data is damaged.
Abnormality when flash is being
charged.
When failed in the focus initialization.
Caution Display During Error
DRIVE ERROR
DISK ERROR
Flash LED
Flash display
Flashing at 3.2 Hz
—

2-1
SECTION 2
DISASSEMBLY
MVC-CD250/CD400
COVER
COVER
•This set can be disassembled in the order shown below.
MVC-CD250/CD400
2-3. LENS BLOCK
ASSEMBLY
(Page 2-3)
2-4. STROBOSCOPE
BLOCK ASSEMBLY
(Page 2-4)
2-8. DDX-G3000 COMPLETE
ASSEMBLY
(Page 2-7)
2-2. CABINET (REAR)
BLOCK ASSEMBLY
(Page 2-2)
2-1. SIDE CABINET
BLOCK ASSEMBLY
(Page 2-2)
2-6. BT HOLDER
ASSEMBLY
(Page 2-5)
2-5. FLASH UNIT
(Page 2-5)
2-7. SY-76 BOARD
(Page 2-6)
2-10.PK-65/66 BOARD
(Page 2-8)
2-11.LCD MODULE
(Page 2-9)
2-9. BASE UNIT
(Page 2-7)
SERVICE POSITION
(CD-393/394 BOARD,
SY-76 BOARD: SIDE A)
(Page 2-4)
SERVICE POSITION
(SY-76 BOARD: SIDE B)
(Page 2-6)
SERVICE POSITION
(PK-65/66 BOARD:
SIDE B) (Page 2-9)
SERVICE POSITION
(PK-65/66 BOARD:
SIDE A) (Page 2-8)

2-2
MVC-CD250/CD400
2-1. SIDE CABINET BLOCK ASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3Open the CD cabinet.
1Screw (M2)
2Screw (M2)
4Two screws (M2)
5Side cabinet block assembly
Note:Remove it while taking care as
the flexible board is connected.
6FP-482 flexible board
(CN718)
2-2. CABINET (REAR) BLOCK ASSEMBLY
5Open the battery lid.
6Cabinet (rear) block assembly
3Two screws (M2)
4Screw
(M2)
1FP-484 flexible board
(CN724)
7Harness (SS-084)
(CN719)
8Harness (microphone)
(CN702)
2FP-485/FP-486 flexible board
(CN651)

2-3
MVC-CD250/CD400
2-3. LENS BLOCK ASSEMBLY
(MVC-CD250)
(MVC-CD400)
1FP-489 flexible board
(CN502)
2Two screws
(M1.7 × 5)
6Screw
(M1.7 × 5)
7Two screws
(M1.7 × 5)
4Screw
(M1.7 × 5)
5Capacitor
3AF/self timer illuminator
8Lens block assembly
1FP-490 flexible board
(CN502)
2Two screws
(M1.7 × 5)
6Screw
(M1.7 × 5)
7Two screws
(M1.7 × 5)
4Screw
(M1.7 × 5)
5Capacitor
3Laser unit
8Lens block assembly

2-4
MVC-CD250/CD400
2-4. STROBOSCOPE BLOCK ASSEMBLY
[SERVICE POSITION (CD-393/394 BOARD, SY-76 BOARD: SIDE A)]
2Four screws
(M1.7)
5Screw
(M1.7
× 5)
8Screw
(M1.7
× 5)
9Three screws
(M1.7
× 5)
0Stroboscope block
assembly
1Shoe spring
4Stroboscope terminal conector
(MVC-CD400 only)
6Earth lug
(MVC-CD400 only)
7Shoe stiffner
3Shoe Note:High-voltage cautions.
(See page 1-1)
Adjustment remote
commander
Lens block assembly
(MVC-CD250)
Lens block assembly
(MVC-CD400) CD-393 board
CD-394 board
AA
A
B
BB
Side cabinet block assembly
Monitor
S307, S308
(Note 3)
CPC-9 jig
(J-6082-393-C)
(Note 1, 2)
118
1
18
DC-IN AC power
adaptor
Note 1: Don’t use the 12 pin flexible board of CPC-9 jig.
It causes damage to the unit.
Note 2: The old CPC-9 jig (Parts code: J-6082-393-B) Cannot be used,
because it cannot operate the adjustment remote commander.
Note 3: Must be pressed lid open/close detect switch (S307, S308 on
PK-65/66 board) when using the CD-R/RW drive unit.
SY-76 board

2-5
MVC-CD250/CD400
2-5. FLASH UNIT
2-6. BT HOLDER ASSEMBLY
Note:High-voltage cautions.
(See page 1-1)
1Screw
(M1.7 × 4)
2Screw
(M1.7 × 4)
3St roof cover
4Two screws
(M1.7 × 4)
6Three screws
(M1.7 × 4)
8Flash unit
7Harness cover
5ST solenoid cover
2BT holder assembly
3Connector
(CN003)
1Open the battery lid.

2-6
MVC-CD250/CD400
2-7. SY-76 BOARD
4FS-141 harness
(CN001)
1Control switch block
(CN720)
2FP-481 flexible board
(CN721)
6Ferrite core
5FP-488 flexible board
(CN901)
qs Flexible board
(base unit) (CN902)
7Harness (microphone)
(CN902)
3FP-483 flexible board
(CN717)
8Screw (M2)
9Two claws
0Four claws
qa SY-76 board
Note:Don't pull at harness of
connector.
[SERVICE POSITION (SY-76 BOARD: SIDE B)]
Adjustment remote
commander
Lens block assembly
(MVC-CD250)
Lens block assembly
(MVC-CD400)
AA
A
B
BB
Side cabinet block assembly
Monitor
S307, S308
(Note 3)
CPC-9 jig
(J-6082-393-C)
(Note 1, 2)
118 118
DC-IN AC power
adaptor
Note 1: Don't use the 12 pin flexible board of CPC-9 jig.
It causes damage to the unit.
Note 2: The old CPC-9 jig (Parts code: J-6082-393-B) Cannot be used,
because it cannot operate the adjustment remote commander.
Note 3: Must be pressed lid open/close detect switch (S307, S308 on
PK-65/66 board) when using the CD-R/RW drive unit.
Setting the "Forced Power ON mode"
[Forced CAMERA mode]
1) Select page: 0, address: 01, and set
data: 01.
2) Select page: D, address: 2F, set data:
00, and then press the PAUSE button
of adjustment remote commander.
3) Select page: D, address: 21, set data:
07, and then press the PAUSE button
of adjustment remote commander.
4) Turn the power off, then on again.
[Forced PLAY mode]
1) Select page: 0, address: 01, and set
data: 01.
2) Select page: D, address: 2F, set data:
00, and then press the PAUSE button
of adjustment remote commander.
3) Select page: D, address: 21, set data:
08, and then press the PAUSE button
of adjustment remote commander.
4) Turn the power off, then on again.
Exiting the "Forced Power ON mode"
1) Select page: 0, address: 01, and set
data: 01.
2) Select page: D, address: 2F, set data:
E0, and then press the PAUSE button
of adjustment remote commander.
3) Select page: D, address: 21, set data:
00, and then press the PAUSE button
of adjustment remote commander.
4) Select page: 0, address: 01, and set
data: 00.
SY-76 board

2-7
MVC-CD250/CD400
2-8. DDX-G3000 COMPLETE ASSEMBLY
2-9. BASE UNIT
4FS-141 harness
(CN001)
1Control switch block
(CN720)
2FP-481 flexible board
(CN721)
3FP-483 flexible board
(CN717) 5Two screws
(M1.7 × 5)
6Screw (M2)
7DDX-G3000 complete assembly
1Screw (M2)
3Tape
2Flexible board
4Three special
head screws
5Base unit

2-8
MVC-CD250/CD400
2-10.PK-65/66 BOARD
[SERVICE POSITION (PK-65/66 BOARD: SIDE A)]
1Open the CD cabinet.
4CD cabinet lid assembly
3Claw
5FP-483 flexible board
(CN303)
6LCD flexible board
(CN302)
7Back light flexible board
(CN201)
2Five screws
(M1.7 × 5)
8Two screws
(M1.7 × 4)
9PK-65/66 board
Adjustment remote
commander
PK-65/66 board
Monitor
S307, S308
(Note 3)
CPC-9 jig
(J-6082-393-C)
(Note 1, 2)
118
1
18
DC-IN
AC power
adaptor
Note 1: Don’t use the 12 pin flexible board of CPC-9 jig.
It causes damage to the unit.
Note 2: The old CPC-9 jig (Parts code: J-6082-393-B) Cannot be used,
because it cannot operate the adjustment remote commander.
Note 3: Must be pressed lid open/close detect switch (S307, S308 on
PK-65/66 board) when using the CD-R/RW drive unit.

2-9
MVC-CD250/CD400
2-11.LCD MODULE
[SERVICE POSITION (PK-65/66 BOARD: SIDE B)]
4BL retainer
5Back light unit
6LCD module
2Three screws
(M1.7
× 4)
3Two screws
(M1.7
× 4)
1Screw
(M1.7 × 5)
Adjustment remote
commander
PK-65/66 board
LCD module
Back light unit
Lens block assembly
(MVC-CD250) Lens block assembly
(MVC-CD400)
AA
A
B
BB
Side cabinet block assembly
Monitor
S307, S308
(Note 3)
CPC-9 jig
(J-6082-393-C)
(Note 1, 2)
118
1
18
DC-IN AC power
adaptor
Note 1: Don’t use the 12 pin flexible board of CPC-9 jig.
It causes damage to the unit.
Note 2: The old CPC-9 jig (Parts code: J-6082-393-B) Cannot be used,
because it cannot operate the adjustment remote commander.
Note 3: Must be pressed lid open/close detect switch (S307, S308 on
PK-65/66 board) when using the CD-R/RW drive unit.
SY-76 board

2-10E
MVC-CD250/CD400
2-12.CIRCUIT BOARDS LOCATION
CD-393 (MVC-CD400)
CD-394 (MVC-CD250)
LS-61 (MVC-CD400)
FS-84 (MVC-CD400)
FS-85 (MVC-CD250)
JK-224 (MVC-CD400)
JK-225 (MVC-CD250)
SY-76
PK-65 (MVC-CD400)
PK-66 (MVC-CD250)
Board Name Function
CD-393 (MVC-CD400) CCD IMAGER, CAMERA PROCESS
CD-394 (MVC-CD250)
FS-84 (MVC-CD400) DC IN, CONTROL SW
FS-85 (MVC-CD250)
JK-224 (MVC-CD400) JACK
JK-225 (MVC-CD250)
LS-61 (MVC-CD400) LENS CAP SWITCH
PK-65 (MVC-CD400) LCD DRIVE, TIMING GENERATOR, BACK LIGHT DRIVE
PK-66 (MVC-CD250)
SY-76 CAMERA DSP, VIDEO, MEMORY, LENS DRIVE, SH DSP,
CD-R/RW SIGNAL PROCESS, CD DRIVE, CD DRIVE DSP,
AUDIO, LASER/IR LED DRIVE, HI CONTROL,
DC/DC CONVERTER
2-10

2-11E
MVC-CD250/CD400
(MVC-CD400)
2-13.FLEXIBLE BOARDS LOCATION
(MVC-CD250)
FP-490
FP-483
FP-481
FP-248
FP-484
FP-482
FP-485
FP-489
FP-483
FP-481
FP-248
FP-484
FP-482
FP-486
