SERVICE MANUAL

DVD RECORDER

SPECIFICATIONS

RDR-HX715

RMT-D218A

US Model

Canadian Model

System

Laser: Semiconductor laser

Channel coverage:

NTSC

VHF: 2 to 13/UHF: 14 to 69/CATV: A-8 to

A-1, A to W, W+1 to W+84

Video reception: Frequency synthesizer system

Audio reception: Split carrier system

Antenna: 75-ohm antenna terminal for VHF/

UHF

Timer: Clock: Quartz locked/Timer indication:

12-hour cycle (digital)/Power back-up

duration: 1 hour

Video recording format: MPEG Video

Audio recording format/applicable bit

rate: Dolby Digital 2 ch/256 kbps

Inputs and outputs

LINE OUT 1/2

(AUDIO): Phono jack/2 Vrms/10 kilohms

(VIDEO): Phono jack/1.0 Vp-p

(S VIDEO): 4-pin mini DIN/Y: 1.0 Vp-p,

C: 0.286 Vp-p

LINE IN 1/2/3

(AUDIO): Phono jack/2 Vrms/more than

22 kilohms

(VIDEO): Phono jack/1.0 Vp-p

(S VIDEO): 4-pin mini DIN/Y: 1.0 Vp-p,

C: 0.286 Vp-p

DV IN: 4-pin/i.LINK S100

DIGITAL OUT(OPTICAL):Optical output jack/

–18 dBm (wave length: 660 nm)

DIGITAL OUT (COAXIAL): Phono jack/

0.5 Vp-p/75 ohms

COMPONENT VIDEO OUT (Y, P

B, PR):

Phono jack/Y: 1.0 Vp-p/PB, PR:

interlace*=0.648 Vp-p, progressive or

interlace**=0.7 Vp-p

COMPONENT VIDEO IN (Y, PB, PR):

Phono jack/Y: 1.0 Vp-p/PB, PR:

interlace*=0.648 Vp-p, progressive or

interlace**=0.7 Vp-p

* “Y/Pb/Pr Out Black Level” is “On”

** “Y/Pb/Pr Out Black Level” is “Off”

SET TOP BOX CONTROL:

Mini jack

HDMI OUT:

Type A (19-pin)

General

Power requirements: 120 V AC, 60 Hz

Power consumption: 57 W

Dimensions (approx.): 430 ×75 ×328 mm

(17 ×3 ×13 in.) (width/height/depth) incl.

projecting parts

Hard disk drive capacity: 160 GB

Mass (approx.): 5.3 kg (11.68 lb)

Operating temperature:

5°C to 35°C (41°F to 95°F)

Operating humidity: 25% to 80%

Supplied accessories:

Audio/video cord (1)

Power cord (1)

Antenna cable (1)

Set top box controller (1)

Remote commander (remote) (1)

Size AA (R6) batteries (2)

Specifications and design are subject to change

without notice.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

— 2 —

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH

MARK 0ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

1. Check the areaofyourrepairforunsolderedorpoorly-soldered

connections. Checkthe entire board surfacefor solder splashes

and bridges.

2. Check the interboard wiring to ensure that no wires are

"pinched" or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly

transistors, that were installed during a previous repair. Point

them out to the customer and recommend their replacement.

4. Look for parts which,through functioning, showobvious signs

of deterioration. Point them out to the customer and

recommend their replacement.

5. Check the B+ voltage to see it is at the values specified.

6. Flexible Circuit Board Repairing

•Keep the temperature of the soldering iron around 270˚C

during repairing.

•Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

•Be careful not to apply force on the conductor when soldering

or unsoldering.

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer.

CAUTION

Use of controls or adjustments or performance of procedures

otherthan those specifiedhereinmay result inhazardous radiation

exposure.

WARNING!!

WHEN SERVICING, DO NOT APPROACHTHE LASER EXITWITH

THE EYE TOO CLOSELY. IN CASE IT IS NECESSARY TO

CONFIRM LASER BEAM EMISSION, BE SURE TO OBSERVE

FROM A DISTANCE OF MORETHAN 25 cm FROMTHE SURFACE

OFTHE OBJECTIVE LENS ONTHE OPTICAL PICK-UP BLOCK.

CAUTION:

The use of optical instrument with this product will increase eye

hazard.

Unleaded solder

Boards requiring use of unleaded solder are printed with the lead-

free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed with

the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

•Unleaded solder melts at a temperature about 40°C higher than

ordinary solder.

Ordinary soldering irons can be used but the iron tip has to be

applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set to

about 350°C.

Caution: The printed pattern (copper foil) may peel away if the

heated tip is applied for too long, so be careful!

•Strong viscosity

Unleaded solder is more viscous (sticky, less prone to flow) than

ordinary solder so use caution not to let solder bridges occur such

as on IC pins, etc.

•Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder may

also be added to ordinary solder.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

—3 —
