LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL FIX2 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-764-04
KDL-40VL130 RM-YD014 US
KDL-52W3000 RM-YD017 US/CND
KDL-52WL130 RM-YD017 US
KDL-52WL135 RM-YD014 US
HISTORY INFORMATION FOR THE FOLLOWING MANUAL:
ORIGINAL MANUAL ISSUE DATE: 8/2007
☛
:UPDATED ITEM
REVISION DATE SUBJECT
8/2007 No revisions or updates are applicable at this time.
9/2007 Updated Self Check illustration. Replaced page 12.
Added PNs for LCD Panels and FB1 Boards for S/N 8,100,001 to 8,499,999 and
8,600,001 on up. Replaced page 100 & 103.
10/2007 Updated schematic diagrams to correct connector pins #s that were up side down.
Replaced pages 29, 36, 39, 42, 45, 47, 62, 64, 78, 81, 89, & 94.
12/2007 Updated entire manual to include KDL-52WL135 model.

LCD DIGITAL COLOR TELEVISION
SERVICE MANUAL FIX2 CHASSIS
MODEL NAME REMOTE COMMANDER DESTINATION
9-883-764-04
KDL-40VL130 RM-YD014 US
KDL-52W3000 RM-YD017 US/CND
KDL-52WL130 RM-YD017 US
KDL-52WL135 RM-YD014 US
Self Diagnosis
Supported model
KDL-40VL130 RM-YD014

3
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
TABLE OF CONTENTS
SECTION TITLE PAGE SECTION TITLE PAGE
Specifications ................................................................................. 5
Warnings and Cautions .................................................................. 7
Safety-Related Component Warning .............................................. 8
Safety Check-Out ......................................................................... 10
Self-Diagnostic Function................................................................11
SECTION 1: DISASSEMBLY............................................................... 13
1-1. Rear Cover Removal............................................................ 13
1-2. Arm (Bracket) and Stand Removal ..................................... 13
1-3. Speakers, HW3 Board, and AC Inlet Removal .................... 14
1-4. HW1 Board Removal ........................................................... 14
1-5. UB2 Board Removal (KDL-52WL135 Only) ........................ 14
1-6. HV2 Board Removal (KDL-40VL130 Only)
or HW2 Board Removal (ALL EXCEPT KDL-40VL130)....... 15
1-7. AU Board and FB1 Board (ALL EXCEPT KDL-40VL130)
or FB3 Board (KDL-40VL130 Only) Removal ...................... 15
1-8. TUU2 Board Removal .......................................................... 16
1-9. DF1 Board and GF1 Board Removal
(KDL-40VL130 Only)............................................................ 16
1-10.DF4 Board, DF5 Board, and GF2 Board Removal
(All Except KDL-40VL130) ................................................... 17
1-11. Stay Removal....................................................................... 17
1-12.LCD Panel Removal ............................................................ 18
1-13.(Balancer Boards) ETC-Inverter MT Board Removal........... 19
SECTION 2: SERVICE ADJUSTMENTS............................................. 20
2-1. Remote Adjustment Buttons and Indicators......................... 20
2-2. Accessing Service Adjustments ........................................... 20
2-3. Updating Model Information after
Replacing the FB1 Board or FB3 Board............................... 22
SECTION 3: DIAGRAMS..................................................................... 23
3-1. Circuit Boards Location ........................................................ 23
3-2. Printed Wiring Boards and
Schematic Diagrams Information ......................................... 24
3-3. Block Diagram...................................................................... 25
3-3-1. Block Diagram (KDL-40VL130 Only)....................... 25
3-3-2. Block Diagram (KDL-52W3000/52WL130 Only)...... 26
3-3-3. Block Diagram (KDL-52WL135 Only)...................... 27
3-3-4. Connector Diagram (KDL-40VL130 Only) ............... 28
3-3-5. Connector Diagram
(KDL-52W3000/52WL130 Only) .............................. 29
3-3-6. Connector Diagram (KDL-52WL135 Only) .............. 30
3-4. Schematics and Supporting Information .............................. 31
AU Board Schematic Diagram (1 of 6)................................. 31
AU Board Schematic Diagram (2 of 6)................................. 32
AU Board Schematic Diagram (3 of 6)................................. 33
AU Board Schematic Diagram (4 of 6)................................. 34
AU Board Schematic Diagram (5 of 6)................................. 35
AU Board Schematic Diagram (6 of 6)................................. 36
DF1 Board Schematic Diagram
(KDL-40VL130 Only) ............................................... 38
DF4 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) ................................. 41
DF5 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) ................................. 44
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (1 of 16)................... 47
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (2 of 16)................... 48
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (3 of 16)................... 49
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (4 of 16)................... 50
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (5 of 16)................... 51
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (6 of 16)................... 52
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (7 of 16)................... 53
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (8 of 16)................... 54
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (9 of 16)................... 55
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (10 of 16)................. 56
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (11 of 16) ................. 57
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (12 of 16)................. 58
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (13 of 16)................. 59
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (14 of 16)................. 60
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (15 of 16)................. 61
FB1 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (16 of 16)................. 62

4
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SECTION TITLE PAGE SECTION TITLE PAGE
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (1 of 15)................................. 64
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (2 of 15)................................. 65
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (3 of 15)................................. 66
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (4 of 15)................................. 67
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (5 of 15)................................. 68
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (6 of 15)................................. 69
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (7 of 15)................................. 70
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (8 of 15)................................. 71
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (9 of 15)................................. 72
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (10 of 15)............................... 73
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (11 of 15) ............................... 74
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (12 of 15)............................... 75
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (13 of 15)............................... 76
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (14 of 15)............................... 77
FB3 Board Schematic Diagram
(KDL-40VL130 Only) (15 of 15)............................... 78
GF1 Board Schematic Diagram
(KDL-40VL130 Only) ............................................... 80
GF2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) ................................. 83
HV2 Board Schematic Diagram
(KDL-40VL130 Only) ............................................... 85
HW1 Board Schematic Diagram .......................................... 88
HW2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (1 of 2)..................... 90
HW2 Board Schematic Diagram
(ALL EXCEPT KDL-40VL130) (2 of 2)..................... 91
HW3 Board Schematic Diagram .......................................... 94
TUU2 Board Schematic Diagram (1 of 2) ............................ 96
TUU2 Board Schematic Diagram (2 of 2) ............................ 97
3-5. Semiconductors ................................................................. 100
SECTION 4: EXPLODED VIEWS...................................................... 101
4-1. Rear Cover Assembly and Stand Assembly ...................... 101
4-2. Chassis .............................................................................. 102
4-3. Connectors......................................................................... 103
4-4. Speakers ............................................................................ 104
4-5. Bezel Assembly and LCD Panel
(KDL-40VL130 Only).......................................................... 105
4-6. Bezel Assembly and LCD Panel
(KDL-52W3000/52WL130 Only) ........................................ 106
4-7. Bezel Assembly and LCD Panel
(KDL-52WL135 Only)......................................................... 107
SECTION 5: ELECTRICAL PARTS LIST.......................................... 108
APPENDIX A: ENCRYPTION KEY COMPONENTS..........................A-1

5
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SPECIFICATIONS
Design and specifications are subject to change without notice.
120V-240V AC, 50/60Hz
220W (KDL-40VL130 Only)
295W (All except KDL-40VL130)
Less than 0.4W
VIDEO (IN) 1/2/3:
S Video (4-Pin Mini DIN (VIDEO 1 Only)
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
C: 0.286 Vp-p (Burst signal), 75 ohms
Video
1.0 Vp-p, 75ohms unbalanced, sync negative
Audio
500 mVrms (100% modulation)
Impedance:47 kilohms
COMPONENT IN 1/2:
YPBPR(Component Video)
Y:1.0 Vp-p, 75 ohms unbalanced, sync negative
P
B:0.7 Vp-p, 75 ohms
P
R:0.7 Vp-p, 75 ohms
Signal format: 480i, 480p, 720p, 1080i, 1080p
AUDIO
500 mVrms (100% modulation)
Impedance: 47 kilohms
Power Requirements
Power Consumption (W)
In Use (Max)
In Standby
HDMI IN 1/2/3:
HDMI: Video:480i, 480p, 720p, 1080i,1080p, 1080/24p
Audio: Two channel linear PCM 32, 44.1 and
48 kHz, 16, 20 and 24 bits, Dolby Digital
AUDIO (for HDMI IN 1):
500 mVrms (100% modulation) (Fixed)
Impedance: 47 kilohms
AUDIO OUT:
500 mVrms (100% modulation) (Fixed)
1 Vrms at the maximum volume setting (Variable)
DIGITAL OUT (OPTICAL):
Optical Digital Audio Ouput (PCM/Dolby digital)
PC IN:
D-sub 15-pin, analog RGB, 0.7 Vp-p, 75 ohms, positive
PC AUDIO INPUT:
Stereo mini jack, 500 mVrms 1(100% modulation)
Impedance: 47 kilohoms
HEADPHONES:
Stereo mini jack
Impedance: 16 ohms
Trademark Information
As an ENERGY STAR®Partner, Sony
Corporationhasdeterminedthatthis product
meets the ENERGY STAR®guidelines for
energy efficiency.
ENERGY STAR®is a U.S. registered mark. This TV incorporates High-
Definition Multimedia Interface
(HDMI™) technology. HDMI, the HDMI logo and High-
Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
This TV is manufactured under license from Dolby
Laboratories. “Dolby” and the double-D symbol are
trademarks of Dolby Laboratories.
Blu-ray Disc is a trademark.
“BRAVIA” and , BRAVIA ENGINE EX, “XMB”
and “XrossMediaBar”, S-Force, BRAVIA Theatre Sync, , DMx,
BRAVIA Internet Video Link Ready and “PS3” are trademarks
or registered marks of Sony Corporation and/or
Son
y
Computer Entertainment Inc.

6
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
Television system
NTSC American TV Standard
ATSC (8VSB terrestrial) ATSC compliant 8VSB
QAM on cable ANSI/SCTE 07 2000
Channel coverage
Analog
2-69 Terrestrial
1-125 Cable
Digital
2-69 Terrestrial
1-135 Cable
Antenna
75-ohm external terminal for VHF/UHF
Panel System
LCD (Liquid Crystal Display) Panel
Display Resolution (horizontal x vertical):
1,920 dots x 1,080 lines
Screen Size (measured diagonally)
KDL-40VL130 - ~40 inches
KDL-52W3000/52WL130/52WL135 - ~52 inches
Supplied Accessories
Remote Commander RM-YD014 (KDL-40VL130/52WL135 Only)
Remote Commander RM-YD017 (KDL-52W3000/52WL130 Only)
Two Size AA (R6) Batteries
75-ohm coaxial cable
AC Power Cord
HD15-HD15 Cable
Suport Belt (Lock Assy, Rudder) Securing Screw,
and Wood Screw
(See Bag Assy, Rudder Lock in the Accessories and Packing
section of the Electrical Parts List in this manual.)
Cable Holder (1 attached to the TV)
Operating Instructions
Quick Setup Guide
Warranty Card
Optional Accessories
Headphones Plug Adaptor
Connecting Cables
Wall-Mount Bracket
SU-WL500
TV-Stand
RHT-G800
SU-FL300M (KDL-40VL130 Only)
SU-FL300L (KDL-52W3000/52WL130/52WL135 Only)
All measurements are approximations.
KDL-40VL130
Speakers
Output
Full Range (2) 15/8 x 57/8 inches
(2) 42 x 150 mm
Tweeter
Dimensions (W x H x D)
with stand 391/8 x 271/8 x 101/2 inches
992 x 688 x 265 mm
without stand 391/8 x 253/8 x 47/8 inches
992 x 643 x 122 mm
wall-mount hole pattern 300 x 200 mm
Mass
with stand 56 lbs.
25.0 kg
without stand 48 lbs.
21.5 kg
11W + 11W
KDL-52W3000/52WL130/52WL135
(2) 2 6/8 X 5 1/8 inches
(2) 70 X 130 mm
(2) 1 5/8 inches
(2) 40 mm
35.5 kg
400 x 300 mm
50 3/8 x 34 1/2 x 15 1/8 inches
1278 x 874 x 384 mm
50 3/8 x 32 7/8 x 4 7/8 inches
1278 x 832 x 123 mm
95 lbs.
43 kg
79 lbs.

7
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
WARNINGS AND CAUTIONS
CAUTION
These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing other
than that contained in the operating instructions unless you are qualified to do so.
CARRYING THE TV
To avoid dropping the TV and causing serious injury,
be sure to follow these guidelines:
sBefore carrying the TV, disconnect all cables.
sCarrying the large size TV requires two or more people.
sWhen you carry the TV, place your hand as
illustrated and hold it securely.
Do not put stress on the LCD panel.
sWhen lifting or moving the TV, hold it firmly from the bottom.
Place your palm directly under the panel.
sWhen carrying, do not subject the TV to shocks or vibration,
or excessive force.
KDL-52W3000/52WL130/52WL135
KDL-40VL130
WARNING!!
An isolation transformer should be used during any service to avoid possible shock hazard, because of live chassis. The chassis of this receiver is
directly connected to the ac power line.
!SAFETY-RELATED COMPONENT WARNING!!
Components identified by shading and ! mark on the schematic diagrams, exploded views, and in the parts list are critical for safe operation. Replace
these components with Sony parts whose part numbers appear as shown in this manual or in supplements published by Sony. Circuit adjustments that
are critical for safe operation are identified in this manual. Follow these procedures whenever critical components are replaced or improper operation is
suspected.
ATTENTION!!
Ces instructions de service sont à l’usage du personnel de service qualifié seulement. Pour prévenir le risque de choc électrique, ne pas faire
l’entretien autre que celui contenu dans le Mode d’emploi à moins que vous soyez qualifié faire ainsi.
POUR TRANSPORTER LE TÉLÉVISEUR
KDL-52W3000/52WL130/52WL135
KDL-40VL130
Assurez-vous de suivre ces consignes pour éviter de laisser
tomber le téléviseur et de provoquer des blessures graves:
sAvant de transporter le téléviseur,
débranchez tous les câbles.
sLe transport du téléviseur doit être
effectué par au moins deux personnes.
sLorsque vous le transportez, placez vos
mains tel que cela est illustré et tenez solidement l’appareil.
N’appliquez pas de pression surl’écran ACL.
sLorsque vous levez ou déplacez le téléviseur, assurez-vous de tenir
solidement de la base. Placez la paume des mains directement sous
sLorsque vous transportez le téléviseur, ne le soumettez pas à des
chocs ou vibrations, ni à une force excessive.
le panneau.
Afin d’eviter tout risque d’electrocution provenant d’un chássis sous tension, un transformateur d’isolement doit etre utilisé lors de tout dépannage. Le
chássis de ce récepteur est directement raccordé à l’alimentation du secteur.
!ATTENTION AUX COMPOSANTS RELATIFS A LA SECURITE!!
Les composants identifies par une trame et par une marque ! sur les schemas de principe, les vues explosees et les listes de pieces sont d’une
importance critique pour la securite du fonctionnement. Ne les remplacer que par des composants Sony dont le numero de piece est indique dans le
present manuel ou dans des supplements publies par Sony. Les reglages de circuit dont l’importance est critique pour la securite du fonctionnement
sont identifies dans le present manuel. Suivre ces procedures lors de chaque remplacement de composants critiques, ou lorsqu’un mauvais
fonctionnement suspecte.

8
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SAFETY-RELATED COMPONENT WARNING
There are critical components used in LCD color TVs that are important for safety. These components are identified with shading and
!
mark on the schematic diagrams and the electrical parts list. It is essential that these critical parts be replaced only with the part number
specified in the electrical parts list to prevent electric shock, fire, or other hazard.
NOTE: Do not modify the original design without obtaining written permission from the manufacturer or you will void the original parts and
labor guarantee.
USE CAUTION WHEN HANDLING THE LCD PANEL
When repairing the LCD panel, be sure you are grounded by using a wrist band.
When installing the LCD panel on a wall, the LCD panel must be secured using the 4 mounting holes on the rear cover.
To avoid damaging the LCD panel:
 do not press on the panel or frame edge to avoid the risk of electric shock.
do not scratch or press on the panel with any sharp objects.
do not leave the module in high temperatures or in areas of high humidity for an extended period of time.
do not expose the LCD panel to direct sunlight.
avoid contact with water. It may cause a short circuit within the module.
disconnect the AC adapter when replacing the backlight (CCFL) or inverter circuit.
(High voltage occurs at the inverter circuit at 650Vrms.)
always clean the LCD panel with a soft cloth material.
use care when handling the wires or connectors of the inverter circuit. Damaging the wires may cause a short.
protect the panel from ESD to avoid damaging the electronic circuit (C-MOS).
LEAKAGE CURRENT HOT CHECK CIRCUIT

9
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
The circuit boards used in these models have been processed using
Lead Free Solder. The boards are identified by the LF logo located
close to the board designation e.g. H1 etc [ see example ]. The
servicing of these boards requires special precautions to be taken as
outlined below.
example 1
It is strongly recommended to use Lead Free Solder material in order to guarantee optimal quality of new solder joints.
Lead Free Solder is available under the following part numbers :
Due to the higher melting point of Lead Free Solder the soldering iron tip temperature needs to be set to 370 degrees centigrade.
This requires soldering equipment capableof accuratetemperature control coupledwith agood heatrecovery characteristics.
For more information on the use of Lead Free Solder, please refer to http://www.sony-training.com
rebmuntraP retemaiD skrameR
91-500-046-7mm3.0gK52.0
02-500-046-7mm4.0gK05.0
12-500-046-7mm5.0gK05.0
22-500-046-7mm6.0gK52.0
32-500-046-7mm8.0gK00.1
42-500-046-7mm0.1gK00.1
52-500-046-7mm2.1gK00.1
62-500-046-7mm6.1gK00.1

10
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
1. Check the area of your repair for unsoldered or poorly soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched” or
touching high-wattage resistors.
3. Check that all control knobs, shields, covers, ground straps, and
mounting hardware have been replaced. Be absolutely certain that
you have replaced all the insulators.
4. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
5. Look for parts which, though functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
6. Check the line cords for cracks and abrasion. Recommend the
replacement of any such line cord to the customer.
7. Check the antenna terminals, metal trim, “metallized” knobs, screws,
and all other exposed metal parts for AC leakage. Check leakage as
described below.
Leakage Test
The AC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’ instructions to use these
instructions.
2. A battery-operated AC milliampmeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a VOM
or battery-operated AC voltmeter. The “limit” indication is 0.75
V, so analog meters must have an accurate low voltage scale.
The Simpson’s 250 and Sanwa SH-63TRD are examples of
passive VOMs that are suitable. Nearly all battery-operated digital
multimeters that have a 2 VAC range are suitable (see Figure A).
How to Find a Good Earth Ground
A cold-water pipe is a guaranteed earth ground; the cover-plate
retaining screw on most AC outlet boxes is also at earth ground. If the
retaining screw is to be used as your earth ground, verify that it is at
ground by measuring the resistance between it and a cold-water pipe
with an ohmmeter. The reading should be zero ohms.
If a cold-water pipe is not accessible, connect a 60- to 100-watt
trouble- light (not a neon lamp) between the hot side of the receptacle
and the retaining screw. Try both slots, if necessary, to locate the hot
side on the line; the lamp should light at normal brilliance if the screw
is at ground potential (see Figure B).
To Exposed Metal
Parts on Set
0.15 μF
Earth Ground
AC
Voltmeter
(0.75V)
Trouble Light
AC Outlet Box Ohmmeter
Cold-water Pipe
Figure A. Using an AC voltmeter to check AC leakage. Figure B. Checking for earth ground.

11
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SELF-DIAGNOSTIC FUNCTION
Self Diagnosis
Supported model
Control Buttons
PIC OFF/TIMER STANDBY POWER
PIC OFF/TIMER STANDBY POWER
Description of LED Indictors
LED LED Type Description
* Light when the TV set is on
* If LED blinks continuously, this may indicate
that the TV needs servicing.
STANDBY LED
PIC OFF/
TIMER
LED
* Lights up in red when TV is in PC standby mode.
* Lights up in green when Picture Off is activated
* Lights up in orange when the timer is set
When timer is set, the LED remains lit even
when the TV is turned off.
POWER LED
Green or Orange
LED
Green LED
Red LED

12
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY LED automatically begins to flash. The number of times
the LED flashes translates to a probable source of the problem. A definition of the STANDBY LED flash indicators is listed in the instruction manual for
the user’s knowledge and reference. If an error symptom is difficult to reproduce use the Remote Commander to display the record that is stored at the
internal NVM to specify the cause.
Number of times LED Flash
POW_ERR1 3 times
BACKLITE 6 times
LED ON : 0.3sec
LED OFF : 0.3sec LED OFF
3.0 sec
LED OFF
3.0 sec
Example Diagnosis
- One flash is not used for self-diagnosis.
Diagnostic Indicators
When an error occurs, the STANDBY LED flashes a set number of times to indicate the possible cause of the problem. If there is more than one error,
the LED will identify the first of the problem areas. If the errors occur simultaneously, the one that corresponds to the fewest flashes is identified first.
(Results for all of the following diagnostic items are displayed on screen. No error has occurred if the screen displays a “00”)
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a second of each other:
DISPLAY Channel
5Volume
-
TV POWER .
The Self Check list displays.
This differs from accessing Service Adjustments.
alpsiDDEL
y
stnetnoC
:000 ------------------------------------==== 00 ====
PVO_WOP:200 ------------------------------------ PVOrewoP00
1RRE_WOP:300 ------------------------------------ rorrErewoP00
NOC_T:500 ------------------------------------ rorrENOC-T00
ETILKCAB:600 ------------------------------------ rorrEthgilkcaBdetcetedsawrorreonsetacidni000
PMETLNAP:700 ------------------------------------ rorrEpmeTlenaPdetcetedsawrorrenasetacidni110
TORP_DUA:800 ------------------------------------ rotcetorPoiduA00
RRE_NAF:900 ------------------------------------ sledomesehtnidesUtoN00
RRE_TTD:010 ------------------------------------ 00
:110 ------------------------------------==== 00 ====
RECNALAB:310 ------------------------------------ rorrElenaP00
TDW_TTD:101 ------------------------------------ 00 sremiTgoDhctaW-TDW
TDW_MVT:201 ------------------------------------ sremiTgoDhctaW(00
TDW_MEB:301 ------------------------------------ kcartotdesuera00 ,srossecorporcim ).srorredrocerottonemitnoitarepodnatnuoctooB0000-35000-97200
KCEHCFLES
Operating Hours
(max 65535)
Panel Hours
(max 65535)
Information Indicator displays time of last 3 events
(Not used in FIX2 models)
Boot count
(max 65535)
Resetting the Diagnostic Indicators
After completing the repair of the set, reset the Self Check screen to set all the display results to “00”.
1. TV must be in standby mode. (Power off).
2. Press DISPLAY Channel
5Volume
-
TV POWER .
3. Press Channel 8, then press Channel 0. To exit press TV POWER .
☛

13
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
SECTION 1: DISASSEMBLY
1-1. REAR COVER REMOVAL
1Remove 4 screws(KDL-40VL130 Only),
8 screws (ALL EXCEPT KDL-40VL130) from Arms (Brackets), +PSW M5X8
2Remove 4 screws from Stays and Stand, +PSW M5X12
1From Rear Cover, remove 15 screws (KDL-40VL130 Only),
19 screws (ALL EXCEPT KDL-40VL130), +BVTP2 4X16
2Remove 2 screws from Rear Cover arm positions, +PSW M5X12
3Remove 2 screws from Terminals, +BVTP 3X12 TYPE2 IT-3
1-2. ARM (BRACKET) AND STAND REMOVAL
12
3
Rear Cover
1
2
Arm (L)
Arm (R)
Stand Assembly
Stay
Stay

14
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1Remove 6 screws, +BVTP2 4X16 (ALL EXCEPT KDL-40VL130)
2Slide out Loudspeakers from Bezel
3Remove 2 screws, +KTT 3X10
4Disconnect one connector from HW3 Board
5Release hook and remove HW3 Board
1-5. UB2 BOARD REMOVAL (KDL-52WL135 ONLY)
1-3. SPEAKERS, HW3 BOARD, AND AC INLET REMOVAL
1-4. HW1 BOARD REMOVAL
5
1
1
2
2
3
4
Speaker (Tweeter)
Loud Speaker
Speaker (Tweeter)
HW3 Board
AC Inlet
1
2
3
Multi button Assembly
HW1 Board
3
12
UB2 Board
UB2 Shield
1Remove from bezel
2Disconnect one connector
3Release hooks and remove HW1 Board
1Remove 4 screws, +PSW 3X8
2Remove one screw, +PSW 3X8
3Disconnect 2 connectors.

15
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1-6. HV2 BOARD REMOVAL (KDL-40VL130 ONLY) OR
HW2 BOARD REMOVAL (ALL EXCEPT KDL-40VL130)
1Slide out Card Bracket
2Remove 2 screws, +PSW M3X5
3Remove 2 HEX screws
4Remove 4 screws, +BVST 3X8
5Remove 7 screws, +BVST 3X8
6Disconnect 7 connectors
7Disconnect 7 connectors
8Remove 9 screws, +BVST 3X8
9Remove 8 screws, +PSW M3X5
1Remove three screws, +BVTP 3X12 TYPE2 IT-3
2Disconnect two connectors
3Remove 2 screws to remove the HV2 Board, +PVST 3X8
(KDL-40VL130 Only)
Remove 2 screws to remove the HW2 Board, +PSW M3X5
(All Except KDL-40VL130)
1-7. AU BOARD AND FB1 BOARD (ALL EXCEPT KDL-40VL130)
2
3
1HV2 Board (KDL-40VL130 Only)
HW2 Board (All Except KDL-40VL130)
Side Terminal Bracket
4
1
23
7
8
5
6
9
AU Board
Chassis Bracket
FB Shield (Top)
Card Bracket
FB1 Board
(All Except KDL-40VL130 Only)
FB3 Board
(KDL-40VL130 Only)
OR FB3 BOARD (KDL-40VL130 ONLY) REMOVAL

16
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1-8. TUU2 BOARD REMOVAL
1Remove 2 screws, +BVST 3X8
2Remove one Hex nut from Tuner
3Remove Tuner Bracket
4Disconnect one connector
5Remove 5 screws, +BVST 3X8
6Remove 4 screws, +BVST 3X8
1-9. DF1 BOARD AND GF1 BOARD REMOVAL (KDL-40VL130 ONLY)
1Disconnect 4 connectors
2Remove 4 screws, +PSW 3SG
3Disconnect 7 connectors
4Remove 4 screws, +PSW 3SG
2
4
3
5
1
6
Chassis Bracket
TUU Shield (Top)
TUU Shield (Bottom)
TUU2 Board
Tuner Bracket
2
1
4
3
G/D Bracket
GF1 Board
DF1 Board

17
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1-10. DF4 BOARD, DF5 BOARD, AND GF2 BOARD REMOVAL
1Remove 5 screws, +PSW 3SG
2Disconnect 3 connectors
3Disconnect 4 connectors
4Remove 4 screws, +PSW 3SG
5Disconnect 7 connectors
6Remove 4 screws, +PSW 3SG
1-11. STAY REMOVAL
1Remove 2 screws, +PSW M5X8
2Remove 2 screws, +BVTP2 4X16
3Remove 4 screws, +PSW M5X8
4Remove 4 screws, +BVTP2 4X16
5Remove 4 screws, +BVTP 4X8
6Remove 3 screws, +BVTP2 4X16
(All Except KDL-40VL130)
4
3
2
1
Upper Stay (Left)
Stand Holder
Stand Holder
Lower Stay (Left)
Upper Stay (Right)
Lower Stay (Right)
Under Cover
6
5
(ALL EXCEPT KDL-40VL130)
12
4
3
6
5
G/D Bracket
GF2 Board
DF4 Board
DF5 Bracket
DF5 Board

18
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1-12. LCD PANEL REMOVAL
1Remove 1 screws, +BVTP2 4X16
2Remove 4 screws, +BVTP2 4X16
3Pop off from Speaker Cover
1
2
3
LED Guide
LCD Panel
Bezel
Speaker Cover

19
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
1-13. (BALANCER BOARDS) ETC-INVERTER MT BOARD REMOVAL
CAUTION:
Be sure to identify the inverter cover screws before proceeding. DO NOT remove the screws securing the plastic strip holding the lamp
sockets.
1Remove screws securing the (Balancer) Inverter Cover.
2Remove screws securing the inverter board
3Disconnect the connectors from the (Balancer) Inverter board you are removing.
4For 52” models only,
to remove the lower board, disconnect 1 connector.
to remove the upper board, disconnect 2 connectors.
INVERTER BOARD REMOVAL
WARNING
NEVER REMOVE THE
SCREWS SECURING THE
PLASTIC STRIP HOLDING
THE LAMP SOCKETS
DAMAGE TO THE
BACKLIGHT TUBES WILL
Only remove the screws securing the inverter
cover which may be metal or plastic. The
remaining plastic strip contains sockets for the
fluorescent backlights and should never be
loosened. The backlights will pop out of the
sockets and/or break the backlight requiring a
LCD panel replacement. The example shown
is a 32” model but applies to all models.
REMOVE
CONNECTOR AND
PULL BOARD TO
THE RIGHT
!
.
OCCUR!
BACKLIGHT
END VIEW
SOCKET
3
3
Plastic Strip
holding
Lamp Socket
NOTE: For the 52” models, the connector that attaches the
Left Upper (Balancer) Inverter board to the DF5 board has a strip of white tape
at both ends of the connector. The connector that attaches the
Right Upper (Balancer) Inverter board to the DF4 board has a strip of red tape
at both ends of the connector.
DO NOT
REMOVE
BACKLIGHT
SCREWS
(Balancer) Inverter Cover
1
Plastic Strip
holding
Lamp Socket
2
4

20
KDL-40VL130/52W3000/52WL130/52WL135
KDL-40VL130/52W3000/52WL130/52WL135
2-1. REMOTE ADJUSTMENT BUTTONS AND
INDICATORS
NOTE: RM-YD014 is for KDL-40VL130 & KDL-52WL135 Only, and
RM-YD017 is for KDL-52W3000 & KDL-52WL130 Only. Since the
buttons on the remote contols are in the same area, RM-YD017 is used
below to indicate their location.
TV POWER
Onscreen cursor
and select button
DISPLAY
RM-YD017
5
VOLUME+
JUMP
SECTION 2: SERVICE ADJUSTMENTS
2-2. ACCESSING SERVICE ADJUSTMENTS
To adjust various set features, use the Remote Commander to put the set
into service mode to display the service menus.
1. TV must be in standby mode. (Power off).
2. Press the following buttons on the Remote Commander within a
second of each other:
DISPLAY Channel
5Volume
+
TV POWER .
The first service menu (TV) displays.
3. To display the service menu that contains the category you want to
adjust, press JUMP on the Remote Commander.
CHASSIS SERVICE
000 GR
000 GRMD 0
SUB SERVICE
000 VERS
000 MODEL
MODEL ID: XXXXXXXXXX
Press JUMP
BEM SERVICE
BOOT: 0. 026W00AU
MAIN: 0. 050W00AU
DATA: 0. 049A00LUW
Press JUMP
Press JUMP
DIGITAL
001 OP 000000 VERS
<SUB><DIGITAL> SMO.100W00AADM0. 159A00AA SD0.010W00AADD0.000A00LU SB1.000W00AA
<BE>
BM0.050W00AU
BD0.049A00LUW
BB0.029W00AU
M2.001C
Press JUMP
SERVICE
