KV-24FS100 MODEL:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
24" Wega®
Monitor/Receiver
27 3/4 "x 20 5/8" x 18 1/2"
77 lbs 3 oz
120VAC
60Hz
145w
1w(stby)
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
FRONT VIEW
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX [phone] • b2b.sel.sony.com
RM-Y173S REMOTE CONTROL
27 3/4"
20 5/8"
SIDE VIEW
TOP VIEW
REMOTE
SENSOR 1 3/4"
13 1/8"
19 1/4"
14 1/2"
13 1/8"
18 1/2"
15 1/4"
Video
VIDEO IN
Audio L
MONO
R
S Video
1
AUDIO
OUT COMPONENT
IN
Y
Pb
Pr
IN
VHF/UHF
JACK PACK
4"
18 1/2 "
