Sony Wahoo CLM-V55 User manual

SONY:
Clip-on
LCD
Monitor
Moniteur
LCD
avec
attache clip
4-279-123-13(1)
Operating Instructions
GB
Moded'emploi
FR
Auto-lock
Accessory
Shoe
HIGH
DEFINITION
MULTIMEDIA
INTERFACE

English
Before operating the product, please read this manual thoroughly and retain it for
future reference.
WARNING
To
reduce fire
or
shock hazard,
do
not
expose
the
unit
to
rain
or
moisture.
CAUTION
Replace the batterywith the specified type only. Otherwise, fire
or
injurymay
result.
Do not expose the batteries to excessive heat such as sunshine, fire
or
the like.
Excessive
sound
pressure from earphones and headphones can cause hearing loss.
2-GB

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This symbol is intended to alert the user to the presence of
uninsulated "dangerous voltage" within the product's enclosure
that may be
of sufficient magnitude to constitute a risk of electric
shockto persons.
This symbol is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
3-GB

IMPORTANT SAFETY
INSTRUCTIONS
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Do
not use this apparatus near water.
• Clean only with
dry cloth.
• Do
not block anyventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install
near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose
of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a
third grounding prong. The wide blade or the third
prong are providedfor your safety.
If the provided plug does not fit into your
outlet, consult an electrician for replacement
of the obsolete outlet.
• Protect the power cord from being walked on
or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
•
Use onlywith the cart, stand, tripod, bracket, or table specified by the
manufacturer,
or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
• Unplug this apparatus during lightning storms or when unused for long periods
of time.
• Refer all servicing to qualified service personnel. Servicing
is required when the
apparatus has been damaged
in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
4-GB

CAUTION
You
are cautioned that any changes
or
modifications
not
expressly approved in this
manual could void your authority to operate this equipment.
Note:
This equipment has been tested
and
found to complywith the limits for a Class
B digital device, pursuant to Part
15
of
the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses,
and
can radiate radio frequency
energy and,
if
not installed
and
used in accordance with the instructions, may cause
harmful interference to radio communications. However, there
is
no
guarantee that
interference will not occur in a particular installation.
If
this equipment does cause
harmful interference to radio
or
television reception, which can be determined
by turning the equipment off
and
on, the user is encouraged to
try
to correct the
interference by one
or
more
of
the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment
and
receiver.
-Connect the equipment into an outlet
on
a circuit different from that to which
the receiver is connected.
-Consult the dealer
or
an experienced radio/TV technician for help.
5-GB

This product has been tested and found compliant with the limits sets out in the
EMC regulation for using connection cables shorter than 3 meters (9.8 feet).
Notice for the customers in the countries applying EU
Directives
The manufacturer of this product is Sony Corporation, 1-7-1 Konan Minato-ku
Tokyo, 108-0075 Japan.
The Authorized Representative for EMC and product safety
is Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327 Stuttgart, Germany. For any service
or
guarantee matters please refer to the addresses given in separate service or
guarantee documents.
Disposal of Old Electrical & Electronic Equipment
{Applicable in the European Union and other European
countries
with separate collection systems)
6-GB
This symbol on the product or on its packaging indicates
that this product shall
not be treated as household waste.
Instead it shall be handed over to the applicable collection
point for the recycling of electrical and electronic
equipment.
By ensuring this product is disposed of correctly,
you will help prevent potential negative consequences for
the environment and human health, which could otherwise
be caused by inappropriate waste handling
of this product.
The recycling of materials will help to conserve natural
resources. For more detailed information about recycling
of this product, please contact your local Civic Office, your
household waste disposal service or the shop where you
purchased the product.

Table of contents
Precaution ................................................................................................................ 8
Before use ............................................................................................................... 10
Checking the accessories .................................................................................... 10
Features ................................................................................................................... 11
Identifying the parts .......................................................................................... 12
Supplying power ................................................................................................. 14
Attaching the battery........................................................................................... 14
Connecting to an AC adaptor............................................................................ 16
Attaching to the camera .................................................................................. 17
Attaching to the camera...................................................................................... 17
Adjusting the direction of the screen................................................................22
Attaching the sun shade hood ........................................................................... 23
Using the monitor .............................................................................................. 26
Menu and operation............................................................................................26
Available functions.............................................................................................. 28
Troubleshooting .................................................................................................. 32
Specifications ........................................................................................................ 34
7-GB

Precaution
About the battery pack, AC adaptor and charger
A battery pack, AC adaptor and charger are not supplied.
Use a compatible battery pack
or AC adaptor (pages 14, 16).
If you do not have a batterypack or AC adaptor, purchase them separately.
Handling the LCD screen
• Do not leave the LCD screen facing the sun as it can damage the LCD screen.
Take care when you place the
unit bya window.
• Do
not push or scratch the LCD monitor's screen. Do not place a heavy object on
the LCD monitor's screen. This may cause the screen to lose uniformity.
•
If the unit is used in a cold place, horizontal lines or a residual image may appear
on the screen. This is not a malfunction. When the monitor becomes warm, the
screen returns to normal.
•
If a fixed picture such as a frame of a divided picture or time code, or a still
picture is displayed for a long time, an image may remain
on the screen and be
superimposed
as a ghosting image.
• The screen and the cabinet become warm during operation. This
is not a
malfunction.
• The LCD panel fitted to this
unit is manufactured with high precision
technology. Thus a very small proportion
of pixels may be "stuck': either always
off(black), always on (red, green,
or blue), or flashing. In addition, over a long
period
of use, because of the physical characteristics of the liquid crystal display,
such "stuck'' pixels may appear spontaneously. These problems are not a
malfunction.
8-GB

On cleaning
Before cleaning
Be
sure to remove the batteryfirst.
On cleaning
the
monitor
screen
The monitor screen surface is especially treated to reduce reflection
of
light.
As
incorrect maintenance may impair the performance
of
the monitor, take care
with respect to the following:
• Wipe the screen gently with a soft cloth such
as
a cleaning cloth
or
glass cleaning
cloth.
• Stubborn stains maybe removed with a soft cloth such
as
a cleaning cloth
or
glass cleaning cloth lightly dampened with water.
• Never use solvent such as alcohol, benzene
or
thinner,
or
acid, alkaline
or
abrasive detergent,
or
chemical cleaning cloth, as they will damage the screen
surface.
On cleaning
the
cabinet
• Clean the cabinet gently with a soft
dry
cloth. Stubborn stains maybe removed
with a cloth lightly dampened with mild detergent solution, followed bywiping
with a soft
dry
cloth.
• Use
of
alcohol, benzene, thinner
or
insecticide may damage the finish
of
the
cabinet
or
remove the indications
on
the cabinet. Do
not
use these chemicals.
•
If
you rub on the cabinet with a stained cloth, the cabinet may be scratched.
•
If
the cabinet is in contact with a rubber or vinyl resin product for a long period
of
time, the finish
of
the cabinet may deteriorate
or
the coating may come off.
On disposal
• Do not dispose
of
this unit with ordinarygarbage. Do
not
throw the monitor
away with garbage that will be placed in a landfill.
On this unit
• The top
of
this unit
and
the ventilation holes and metal parts may become
hot
after long use.
Be
very careful
if
holding this unit during
or
after use.
Using in an airplane
During take-off
and
landing, follow the onboard instructions concerning this unit.
9-GB

Before use
Read this instruction manual together with the instruction manual
of
your camera.
This
unit
is
not
dust-proof, splash-proof
or
waterproof.
Do
not
place this unit in
the
following locations
Regardless
of
whether this unit is in use
or
in storage, do not place it in any
of
the
following locations. Doing so maylead to a malfunction.
• Placing this unit in locations subject to direct sunlight such
as
on dashboards or
near a heater may cause this
unit
to deform
or
malfunction.
• Locations with excessive vibration
• Locations with strong electromagnetism
• Locations with excessive sand
In locations such
as
the seashore
and
other sandy areas
or
where dust clouds
occur, protect the unit from sand and dust. This maylead to a malfunction.
Checking
the
accessories
Check that the following accessories are supplied.
If
anything
is
missing, contact
your Sony dealer.
• Shoe adaptor (for auto lock accessory shoe and accessory shoe)
10-GB

• Sun shade
hood
• HDMI cable (Approx.
45
em, Type A+-+ Type C)
• Carrying pouch
• Set
of
printed documentation
Features
This unit
is
a portable LCD monitor for use with an Interchangeable Lens Digital
Camera
or
an Interchangeable Lens Digital HD Video Camera Recorder with
an
HDMI terminal
and
live view mode. It can display
HDMI
video output from
the
camera.
The following functions help you to see the image more clearly and take better
pictures.
• Wide viewing angle LCD screen
• Useful functions such as peaking and pixel-by-pixel zoom
• Moveable shoe adaptor enables easy removal when using a camera that has
an
auto lock accessory shoe.
11-GB

Identifying
the
parts
12-GB

[I]
LCD
screen
[2]
Power
lamp
When the power
is
on, this lamp lights up or blinks depending on the status
of
this unit. (Page 15)
~
Power
button
(!)
Press and hold down to turn this unit on or off.
@]
Operation dial
Brings up
and
operates the menu.
Press the dial to the left* Brings up the menu./Executes the selection.
Turn the dial Selects the menu item./Changes the setting
value.
*The function varies depending on the status
of
this unit.
[§]
Battery packterminal
[§]Speaker
This
is
a monaural speaker for checking sound.
[1]
Battery release lever
[ID
Headphonejack
You
can connect headphones with a 3.5
mm
stereo mini-plug to listen to sound.
• No sound comes from the speaker when headphones are connected.
[ID
HDMI (Type
A)
jack
ffQJ
DC
IN jack
[1]
Tripod receptacle
13-GB

Supplying power
This unit can be powered by a Sony rechargeable battery pack
or
a Sony
AC
adaptor.
Attaching the battery
The following Sony rechargeable battery packs (not supplied) can be used with this
unit.
You
cannot use other battery packs because this unit will not work properly
with them.
• NP-FMSOOH
•
NP-QM71D
•
NP-QM91D
U
Note
• When using
the
NP-QM71D or NP-QM91
0,
attach
the
camera
to
a tripod
first.
Push
the
battery
in gently in the direction shown, then slide it
to
the
left
while still pushing.
There
is
a click
as
the battery is fixed into place.
14-GB

To
remove the battery
Slide
the
battery
to
the right while sliding
the
battery
release lever
to
the
left.
The battery pack comes away from this unit.
U Note
•
Be
careful not
to
drop the battery while removing it.
To
check the remaining
battery
power
You
can check the remaining battery power with the power lamp. When the lamp
becomes red, replace the battery pack soon with a fully charged battery pack.
Lighting status
of
the power lamp Status
of
this unit
Green (lit) Power
is
on. (Operated by battery)
Green (flashing slowly) Turning on
or
off. (Operated by battery)
White (lit) Power
is
on. (Operated by
AC
adaptor)
White (flashing slowly) Turning
on
or
off. (Operated by AC
adaptor)
Red (lit) Battery level is low.
Red (flashing rapidly) Batteries have
run
out.
Off
Power
is
off.
U Notes
• Do
not
disconnect or remove
the
battery
or
AC
adaptor
when turning
this
unit
on or
off
(the power lamp flashes slowly).This may cause
malfunction.
• Just before the battery runs out,
the
power
lamp
turns red and flashes
rapidly.The power to this unit automaticallyturns
off
about
1
0 seconds
later.
15-GB

Battery
I
ife
(When using this unit continuously at 25°C (77
°F)
with a
brand-new
battery
attached
and
connecting to the cameravia
HD
MI)
NP-
FMSOOH:
Approx. 3 hours
NP-QM71D: Approx. 5 hours
NP-QM91D: Approx. 8 hours
* The batterylife may differ from the above depending on operation status and
environmental conditions.
Connecting
to
an
AC
adaptor
This unit can
be
powered from the domestic
rower
supply using a Sony AC adaptor
such as the AC-PWlOAM (not supplied).
AC
-PWl
OAM
(not
supplied)
U Notes
• A
battery
packattached
to
this unit
is
not
recharged even when an
AC
adaptor
is
connected.
•
If
this
unit
is
connected
to
an
AC
adaptorwhile a
battery
pack
is
attached,
the
AC
adaptor
power source takes priority.
16-GB

Attaching to the camera
Attaching to the camera
1 Select one of the provided shoe adaptors according to the
shape of the accessory shoe on the camera.
Auto lock
accessory shoe:
U Note
Accessory
shoe:
• Do not attach a shoe adaptor exceptfor this unit.
2 Insert the tripod screw of the shoe adaptor into the tripod
receptacle on the bottom of this unit.
3 Turn the shoe adaptor dial to lock.
~
17-GB

4 Attach (clip) the correct type of shoe adaptor onto the
camera shoe, as illustrated.
If using auto lockaccessory shoe:
G)Insert the foot of the shoe adaptor fully into the auto lock accessory shoe in
the direction illustrated.
®Push the lock lever of the shoe adaptor down to the right to fix it firmly to
the camera.
U Note
• Insert
the shoe adaptor fully until it clicks into place.
If using accessory shoe:
G)Insert the foot of the shoe adaptor fully into the accessory shoe in the
direction illustrated.
@Rotate the dial of the shoe adaptor fully to the left to fix it firmly to the
camera.
18-GB

U Note
• When attaching
to a camera that has an accessory shoe, read the
instruction manual of the camera too.
U Notes
• If using a camera equipped with a pop-up built-in flash, be careful of the
following:
-Always close the built-in flash of the camera. If your camera has a built-in auto
flash function,
turn that function off.
-Before using the flash, remove this
unit from the camera.
• Make sure this unit is firmlyfixed to the camera before use to prevent
this unitfrom falling during shooting.
5 Connect this unit to the camera with the HOMI cable
supplied.
·~·Tip
• If the cable is not long enough, use a Sony HDMI cable Type A- TypeC (not
supplied).
6 Turn on the power to the camera and this unit.
Press and hold down the power button to turn this unit on.
The viewfinder image
of the camera is displayed on the LCD screen of this
unit. Ifyour camera has an HDMI output setting function, set it to AUTO
or
16:9.
19-GB

U Note
When this unit is connected to the camera by the HOMI cable, the following
mayhappen depending on the camera.
-No image appears on the camera's LCD screen.
-
The camera switches to playback mode. (Make sure the camera is in shooting
mode before taking pictures.)
·~·Tip
• After a certain time in either of the following conditions, the backlight of this
unit turns off.
-No HDMI signal is output from the camera
-The
HD MI cable is disconnected
Carrying out the following
turns the backlight on again.
-Press the operation dial
of this unit.
-Operate the camera so that an HDMI signal is output.
-Reconnect the HDMI cable and turn the camera on.
To remove from the camera
Disconnect the HDMI cable and remove this unit as below.
U Note
• When removing, be careful not to dropthis unitor the camera. It is
recommended that you attach the camera to a tripod before removing
this unit.
When using an auto lock accessory shoe:
G) Push the lock lever of the shoe adaptor down to the left to release the lock.
®Keeping the lock lever pressed to the left, slide the shoe adaptor toward you.
20-GB
