Sony VPH-G90E User manual

VPH-G90E
VPH-G90M
VPH-G90U
VPH-G90E/VPH-G90M/VPH-G90U
Multiscan Projector
©1998 by Sony Corporation
3-865-264-13 (2)
GB
FR
ES
Installation Manual for Dealers
Manuel d’installation destiné aux revendeurs
Manual de instalación para proveedores
CAUTION
THIS INSTALLATION MANUAL IS FOR USE BY QUALIFIED PERSONNEL
ONLY.
IMPORTANT
CE MANUEL D’INSTALLATION EST DESTINÉ AUX PROFESSIONNELS
SEULEMENT.
IMPORTANTE
ESTE MANUAL DE INSTALACIÓN ES PARA SER USADO POR PERSONAL
CUALIFICADO SOLAMENTE.

Table of contens
2 (GB) Table of Contents
Table of Contents
Installation
Installation Procedures ...............................................5 (GB)
Before Installation ....................................................... 6 (GB)
Using the Handles to Carry the Projector ........................ 6(GB)
Necessary Clearance for Installation and Maintenance ... 7(GB)
Notes on Screen ............................................................. 10(GB)
Installation Diagrams ................................................12 (GB)
Floor Installation Using Front Projection Flat Screen ... 12 (GB)
Ceiling Installation Using Front Projection Flat
Screen........................................................................ 14(GB)
Floor Installation Using Rear Projection Flat Screen .... 16 (GB)
Modifying Parts..........................................................18 (GB)
Opening the Upper Cover .............................................. 18 (GB)
Using the Adjusters ........................................................ 19 (GB)
Changing the Polarity..................................................... 20 (GB)
Adjusting the CRT Conversion Angle ........................... 22 (GB)
Connections
Location and Function of the Rear Panel................24 (GB)
Switching the 75-ohmTerminate Connectors
(VPH-G90M/G90U only) ........................................27 (GB)
Connecting Directly to the Projector .......................29 (GB)
Connecting Multiple Projectors................................30 (GB)
Using the PC-3000 Signal Interface Switcher .........32 (GB)
Confirming the System Construction............................. 37 (GB)
Using the PC-1271/1271M Signal Interface
Switcher .................................................................38 (GB)
Before Adjustment
For Remote Control ...................................................42 (GB)
Preparation of the Remote Commander......................... 42(GB)
Keys on the Remote Commander .................................. 46 (GB)
Using the MENU.........................................................50 (GB)
Basic Menu Operation...............................................50 (GB)
Menu Modes .................................................................. 51(GB)
The PIC CTRL (Picture Control) Menu......................... 55 (GB)
The PIC SETTING 1 (Picture Setting 1) Menu............. 57 (GB)
The PIC SETTING 2 (Picture Setting 2) Menu............. 58 (GB)
The INPUT SETTING Menu......................................... 59 (GB)
The SET SETTING 1 Menu .......................................... 62 (GB)
The SET SETTING 2 Menu .......................................... 63 (GB)
English

Table of Contents 3 (GB)
The INPUT INFO (Information) Menu ......................... 65 (GB)
The INPUT MEM. (memory) OPTION Menu .............. 66 (GB)
The SET INFO (information) Menu .............................. 68 (GB)
The SERVICE SETTING 1 Menu ................................. 68 (GB)
The SERVICE SETTING 2 Menu ................................. 69 (GB)
The SERVICE SETTING 3 Menu ................................. 70 (GB)
The PIC ORBITING Menu............................................ 71(GB)
The INT. OSC (internal oscillation) SETTING Menu... 71 (GB)
The TIMER Menu.......................................................... 72 (GB)
The UNIFORMITY Menu ............................................. 72(GB)
The ABL (Automatic Brightness Limiter) LINK
Menu ......................................................................... 74 (GB)
Test Patterns..............................................................75 (GB)
Test Patterns ................................................................... 75 (GB)
Test Patterns in Each Mode............................................ 76 (GB)
Warm-up before adjustment .....................................77 (GB)
Adjustments
Adjustment Procedure ..............................................78 (GB)
Adjusting the Lens Focus and Scheimpflug...........81 (GB)
Preparation ..................................................................... 81 (GB)
Adjusting the Green Lens Focus and Scheimpflug........ 81 (GB)
Adjusting the Red Lens Focus and Scheimpflug ........... 85(GB)
Adjusting the Blue Lens Focus and Scheimpflug .......... 86 (GB)
Adjusting the Magnetic Focus .................................87 (GB)
Saving the Standard Magnetic Focus Data .................... 92(GB)
Adjusting the Registration........................................93 (GB)
Preparation ..................................................................... 93 (GB)
Keys for Adjusting ......................................................... 94 (GB)
Adjusting the Green Registration................................... 95 (GB)
Adjusting the Red Registration .................................... 108 (GB)
Adjusting the Blue Registration................................... 119 (GB)
Saving the Standard Registration Data ........................ 121 (GB)
Fine Adjustment for Each Input Signal..................122 (GB)
Selecting the Input Signal ............................................ 122 (GB)
Fine Magnetic Focus and AQP/DQPAdjustments ...... 122 (GB)
Fine Registration Adjustment....................................... 122 (GB)
SIZE Adjustment.......................................................... 123 (GB)
SHIFT Adjustment ....................................................... 123 (GB)
Blanking Adjustment.................................................... 124 (GB)
Adjusting the White Balance ....................................... 125 (GB)
(continued)
GB
English

Table of contens
4 (GB) Table of Contents
Adjusting the Picture Quality .................................129 (GB)
Saving the Adjustment Data...................................130 (GB)
Memory Blocks............................................................ 130(GB)
Saving the Data to the Service Block........................... 132 (GB)
Input Memory .............................................................. 133(GB)
Video Memory ............................................................. 137(GB)
Resetting the Data ...................................................138 (GB)
Resetting the Item in Adjustment Only
(Normal Reset)........................................................ 138 (GB)
Resetting Multiple Items Simultaneously
(All Data Reset) ...................................................... 139(GB)
Others
Setting the Index Numbers .....................................141 (GB)
Link Functions ......................................................... 145 (GB)
Using the Linked ABL Function .................................. 145(GB)
Using the Linked Picture Orbiting Function................ 148 (GB)
Self-diagnosis Function ..........................................151 (GB)
List of the Projection Distance by Angle
of Optical Axis.....................................................153 (GB)
Index .........................................................................159 (GB)

Installation 5 (GB)
Installation
Installation
Installation Procedures
By default, this projector is adjusted for 120-inch front projection on the
floor/desk. If you install the projector in other conditions, you have to
change some settings. Therefore, installation procedures depend on the
screen size or type, and installation method.
1Verify the conditions of installation, such as angle of optical axis,
projection distance, height of the projector and screen.
.
2Change the polarity according to the projection patterns. (page 20(GB))
.
3Install the projector and screen. (page 12(GB))
.
4Adjust the lens focus approximately. (page 81(GB))
.
5Reset the registration data to the factory setting. (page 138(GB))
.
6Adjust the CRT conversion angle. (page 22(GB))
.
7Connect external video equipment. (page 24(GB))
.
The installation is completed.
Then perform the adjustments following the adjustment
procedure.
(page 78 (GB) )

Before Installation
6 (GB) Installation
Installation
Using the Handles to Carry the Projector
Carry the projector with four persons or more by using the front, rear and
side (right and left) handles.
Using the handles
Pull out the front and rear handles or the side handles.
Putting away the handles
Push the handle release lever under each handle. The handle is
automatically retracted.
Before Installation

Installation 7 (GB)
Installation
Necessary Clearance for Installation and Maintenance
Make sure to provide enough room for maintenance service. Install the
projector, making reference to the dimensions below.
Note
There should be a space of at least 30 cm (1 3/16 inches) around the
ventilation holes at the rear. Never block the holes with any material.
Front
Rear
Unit: mm (inches)
Remote control
detector
Unit: mm (inches)
Ventillation holes
LED window
226 (9)
Remote control detector
70.5 (2 7/8)
Mass: 110 kg (242 lb 8 oz) 774 (30 1/2)
21.5 (7/8)
STANDBY indicator
ON indicator
Ventillation holes
198.5 (7 7/8)
601.5 (23 3/4)35 (1 7/16)
99 (4) 39 (1 9/16)
96.8
(3 7/8)
167.4
(6 5/8)
750 (29 5/8)

Before Installation
8 (GB) Installation
Installation
Bottom
The standard hole for installation on the bottom surface is useful for
reference when measuring for installation. There are seven holes on the
bottom surface of the projector. For ceiling installation using the optional
PSS-90 Projector Suspension Support, use five holes to attach the PSS-90.
The other two holes are spare ones.
Notes
•Use only the M8 meter screws of 10 mm (13/32 inches) to 30 mm (13/16
inches) long for the attachment holes for the PSS-90.
•When attaching the PSS-90, use the M8 meter screws of 20 mm (25/32
inches) supplied with the PSS-90.
Unit: mm (inches)
Hole for attaching an
adjuster
(M10 meter screw,
Max 30 mm (1 3/16
inches))
679 (26 3/4)
Spare holes for
installation
40 (1 5/8)
Holes for attaching
the PSS-90
(M8 meter screws,
20 mm (25/32 inches))
Receptacles for the
projections on the PSS-
90
40 (1 5/8)
174 (6 7/8)
340.5 (13 1/2)
322 (12 3/4)
211.5 (8 3/8)
384 (15 1/8)
573 (22 5/8)
4-∅60
308.5
(12 1/4)547 (21 5/8)
1031.6 (40 5/8)50 (2)
90
(3 5/8)
35 (1 7/16)90
(3 5/8)35 (1 7/16)
550 (21 3/4)
580 (22 7/8)
16.5 (21/32)
50 (2)
Holes for attaching
the PSS-90
(M8 meter screws,
20 mm (25/32 inches))
Hole for attaching
the PSS-90
(M8 meter screw, 20
mm (25/32 inches))
(Standard hole for
installation)
50 (2)
25 (1)

Installation 9 (GB)
Installation
Side
With the covers open
Location of the standard hole for installation
Center of projection balance
R 411
(
16
1
/
4
)
Center of projection balance
11.9°
Location of the standard
hole for installation
1066 (42)
∅157.5
(6
1
/
4
)
385.5 (15 1/4)
289 (11 1/2)
308.5 (12 1/4)168
(6 5/8)16.5 (21/32)
Unit: mm (inches)
354 (14)
401.2 (15 7/8)
415.8 (16 3/8)
R 196
(
7
3
/
4
)
340 (13 1/2)
385.3 (15 1/4)

Before Installation
10 (GB) Installation
Installation
Notes on Screen
Screens with an aspect ratio other than
4:3
When the height is greater
Calculate the screen size with 4:3 aspect ratio from the
screen height as shown below. Install the projector and
screen in accordance with the screen size obtained.
--- : Screen whose aspect ratio is 4:3
Screen size (inch) = (height (mm) ×5/3) ×1/25.4
Example: When the screen height is 1500 mm
(1500 (mm) ×5/3) ×1/25.4 = Approx. 98 inches
When the width is greater
Calculate the screen size with 4:3 aspect ratio from the
screen width as shown below. Install the projector and
screen in accordance with the screen size obtained.
---: Screen whose aspect ratio is 4:3
Screen size (inch) = (width (mm) ×5/4) ×1/25.4
Example: When the screen width is 2000 mm
(2000 (mm) ×5/4) ×1/25.4 = Approx. 98 inches
Screen size
The screen size is the diagonal length of the screen in
inches, while the aspect ratio of the screen is 4:3. The
ratio of the screen height, width, and diagonal is 3:4:5.
4
35
If you use a screen with 4:3 aspect ratio whose size is
not given in the table below, you can calculate the
screen height and width from the screen size (inches)
as follows.
Calculate at the conversion rate of 25.4 mm to the
inch.
Height (mm) = Screen size ×25.4 ×3/5
Width (mm) = Screen size ×25.4 ×4/5
Screen size and dimensions
Screen size (inches)
(Diagonal) Height (mm) Width (mm)
90 1372 1829
100 1524 2032
120 1829 2438
150 2286 3048
180 2743 3658
200 3048 4064
250 3810 5080
300 4572 6096

Installation 11 (GB)
Installation
Types of screen
Rear projection screen
A screen manufactured using two sheets, the fresnel
and lenticular, is recommended for a bright and clear
full-screen picture projection.
White screen
When viewers watch the projected picture in a wide
area, you can obtain a picture that appears equally
bright from all parts of the room using the white screen
for both floor and ceiling installations. Note that you
will not be able to get a clear picture in this case unless
the room is dark.
Front projection screen for floor installation
The bead screen is recommended. A screen of this type
reflects the brightest light.
Front projection screen for ceiling installation
The silver screen is recommended. You can get a
picture that is two to four times brighter than that of
the white screens.
Bead
screen Center of the screen
Brightest picture
Projector
Silver
screen
Center of the screen Brightest picture
Projector
Projector
Screen Horizontal viewing area
Projector

Before Installation
12 (GB) Installation
Installation
Floor Installation Using Front Projection Flat Screen
Be sure that the projector is level to the floor.
The distances in gray are the factory preset settings. Unit:mm (inches)
Screen size 90 100 120 150 180 200 250 300
(inches)
A (Vsize) 1372 1524 1829 2286 2743 3048 3810 4572
(54 1/8) (60) (72 1/8) (90) (108) (120) (150) (180)
B (Hcent) 899 959 1084 1296 1497 1630 1950 2294
(35 1/2) (37 7/8) (42 3/4) (51 1/8) (59) (64 1/4) (76 7/8) (90 3/8)
C (Width)
D (TD) 2587 2847 3373 4285 5137 5702 7065 8533
(101 7/8) (112 1/8) (132 7/8) (168 3/4) (202 1/4) (224 1/2) (278 1/4) (336)
E (Xlens) 2514 2767 3278 4165 4993 5542 6867 8294
(99) (109) (129 1/8) (164) (196 5/8) (218 1/4) (270 3/8) (326 5/8)
F (Lhole) 2764 3017 3528 4415 5243 5792 7117 8544
(108 7/8) (118 3/4) (138 7/8) (173 7/8) (206 3/8) (228) (280 1/4) (336 3/8)
G (Lmax) 3520 3773 4284 5171 5999 6548 7873 9300
(138 5/8) (148 5/8) (168 3/4) (203 5/8) (236 1/4) (257 7/8) (310) (366 1/4)
H (Lfront) 2455 2708 3219 4106 4934 5483 6808 8235
(96 5/8) (106 5/8) (126 3/4) (161 5/8) (194 1/4) (215 7/8) (268) (324 1/4)
a) Sony VPS-100FM
b) Sony VPS-120FH and VPS-120FM
28a) 32b)
(1 1/8) (1 5/16)
Installation Diagrams
B: Difference in height between the projector’s bottom surface and the center of the screen
E: Horizontal distance between the center of the screen and the center of the green lens
F: Horizontal distance between the center of the screen and the standard hole for installation
H: Horizontal distance between the center of the screen and the projector’s front surface
Tolerances
B: ±5%
Other measurements: 0% to +5%
A
B
Center of the green lens
D
G
E
13.6˚
Center of the screen
C
F
Floor
Standard hole
for installation
Wall
H

Installation 13 (GB)
Installation
When the Screen Size is not Mentioned in the Tables
You can calculate the installation measurements described below when
you use the screen whose size is not mentioned in the tables on pages
12(GB) and 14 (GB).
Check your installation conditions:
•Screen size to be used (S)
•Installation measurements at the end of the manual, ES and BS for
smaller screen size and EL and BL for larger screen size
See the tables on pages 153(GB) to 158(GB).
Now you can calculate the installation measurements as follows:
E (mm) = ES + ((S – smaller screen size) ×(EL – ES) ×0.1)
B (mm) = BS + ((S – smaller screen size) ×(BL – BS) ×0.1) + 289
Example: when using 124-inch screen
According to the tables on page 154 (GB), the values E and B are as
follows:
ES = 3279, BS = 791 (As the smaller screen size is 120 inch.)
EL = 3570, BL = 861 (As the smaller screen size is 130 inch.)
Therefore,
E (mm) = 3279 + ((124 –120) ×(3570 – 3279) ×0.1) = 3395.4 (mm)
B (mm) = 791 + ((124 – 120) ×(861 – 791) ×0.1) + 289 = 1108 (mm)
E
BCenter of the screen
E: Projection distance
B: Screen heights
Center of the green lens

Before Installation
14 (GB) Installation
Installation
Ceiling Installation Using Front Projection Flat Screen
Use the PSS-90 Projector Suspension Support (not supplied).
Unit:mm (inches)
Screen size 90 100 120 150 180 200 250 300
(inches)
A (Vsize) 1372 1524 1829 2286 2743 3048 3810 4572
(54 1/8) (60) (72 1/8) (90) (108) (120) (150) (180)
B (Hcent) 990 1050 1175 1387 1588 1721 2041 2385
(39) (41 3/8) (46 3/8) (54 5/8) (62 5/8) (67 7/8) (80 3/8) (94)
D (TD) 2587 2847 3373 4285 5137 5702 7065 8533
(101 7/8) (112 1/8) (132 7/8) (168 3/4) (202 1/4) (224 1/2) (278 1/4) (336)
E (Xlens) 2514 2767 3278 4165 4993 5542 6867 8294
(99) (109) (129 1/8) (164) (196 5/8) (218 1/4) (270 3/8) (326 5/8)
F (Lhole) 2932 3185 3696 4583 5411 5960 7285 8712
(115 1/2) (125 1/2) (145 5/8) (180 3/8) (213) (234 5/8) (286) (342)
G (Lmax) 3520 3773 4284 5171 5999 6548 7873 9300
(138 5/8) (148 5/8) (168 3/4) (203 5/8) (236 1/4) (257 7/8) (310) (366 1/4)
H (Lfront) 2455 2708 3219 4106 4934 5483 6808 8235
(96 5/8) (106 5/8) (126 3/4) (161 5/8) (194 1/4) (215 7/8) (268) (324 1/4)
Necessary parts modifications
Changing the polarity used for “Ceiling installation, front projection”
For details, see “Changing the Polarity” on page 20(GB).
Installation Diagrams
A
H
E
F
Ceiling
D
B
Center of the green lens
13.6˚
Center of
the screen
G
Rotation axis of
the PSS-90
Wall
380 (15)
E: Horizontal distance between the center of the screen and the center of the green lens
H: Horizontal distance between the center of the screen and the projector’s front surface
Tolerances
B: ±5%
Other measurements: 0% to +5%

Installation 15 (GB)
Installation
Attaching the PSS-90 Projector Suspension Support
Attach the projector mounting bracket to the bottom surface of the
projector.
Use five each of the M8×20 bolts, M8 washers and spring washers, all of
which are supplied with the PSS-90.
1Align the two projections on the projector mounting bracket with the
receptacles on the bottom surface of the projector.
2Fasten the five bolts and washers to fix the mounting bracket to the
five holes for attaching the PSS-90 on the bottom surface of the
projector.
For attaching the PSS-90 to the ceiling, refer to the Installation Manual of the
PSS-90 Projector Suspension Support.
M8×20 bolt
Spring washer
M8 washer
Projector
mounting
bracket
Installation dimensions 254 (10) 254 (10)
415.8 (16 3/8)
476.3 (
18
7
/
8
)
333.7
(13
1
/
4
)
114.8
(4 5/8)
Unit: mm (inches)

Before Installation
16 (GB) Installation
Installation
Floor Installation Using Rear Projection Flat Screen
What is the optical axis angle?
The optical axis angle is the angle between the horizontal level line and the
straight line from the center of the projector’s green lens to the center of
the screen. When using a rear projection screen, you can get the brightest
picture when the center of the screen is aligned with a straight line
extension of the center of the green lens.
Therefore, the most suitable optical axis angle varies depending on the
height of the screen and your line of sight.
When the optical axis angle is 2°
Unit: mm (inches)
Screen size 90 100 120 150 180 200 250 300
(inches)
A (Vsize) 1372 1524 1829 2286 2743 3048 3810 4572
(54 1/8) (60) (72 1/8) (90) (108) (120) (150) (180)
B (Hcent) 95 86 67 36 6 –13 –60 –111
(3 3/4) (3 1/2) (2 3/4) (1 7/16)(
1/4) (– 17/32) (–2 3/8) (–4 3/8)
E (Xlens) 2567 2826 3348 4252 5097 5659 7011 8467
(101 1/8) (111 3/8) (131 7/8) (167 1/2) (200 3/4) (222 7/8) (276 1/8) (333 3/8)
F (Lhole) 2873 3132 3653 4558 5402 5964 7316 8772
(113 1/8) (123 3/8) (143 7/8) (179 1/2) (212 3/4) (234 7/8) (288 1/8) (345 3/8)
G (Lmax) 3594 3853 4375 5279 6124 6686 8038 9494
(141 1/2) (151 3/4) (172 1/4) (207 7/8) (241 1/8) (263 1/4) (316 1/2) (373 7/8)
Necessary parts modifications
Changing the polarity used for “Floor installation, rear projection”
For details, see “Changing the Polarity” on page 20(GB).
Wall
Floor
G
Center of the screen
E
F
B0
+
2°
14.6°A
–
Optical axis
angle
Standard hole for
installation
Installation Diagrams

Installation 17 (GB)
Installation
Wall
+3°
+13.6°
: Optical axis
: Horizontal line
Wall
–13.6°
+2°
: Optical axis
: Horizontal line
Floor
Ceiling
Variable Range of the Optical Axis Angle in Rear Projection
You can change the optical axis angle within the following ranges by
adjusting the scheimpflug.
For adjusting the scheimpflug, see page 83(GB).
On floor installation
You can install the projector within an angle of optical axis –13.6°to +2°.
On ceiling installation
You can install the projector within an angle of optical axis +3°to +13.6°.

18 (GB) Installation
Installation
Modifying Parts
Modifying Parts
Opening the Upper Cover
Most modifications can be performed only by opening the
upper cover.
1Turn off the main power of the projector.
2Unlock the two screws on the projector by using a screwdriver, and
then open the upper cover.
To remove the supplied tool
The tool is located on the back of the upper cover.
Loosen the screw by using a screwdriver and remove the tool.
Tool
Locked Unlocked

Installation 19 (GB)
Installation
Using the Adjusters
When the projector installation location is not horizontal, adjust the
adjusters so that the projector is placed horizontally.
Use the supplied tool to turn the adjuster.
Note
The supplied tool can rotate the screw in one direction only. To rotate the
screw in the reverse direction, turn the tool upside down.
Caution
Do not turn the tool forcibly when the screw has fully rotated. Otherwise,
the tool may slip out and injure your hand.
Turn counterclockwise
To raise Turn clockwise To lower
Supplied tool Supplied tool

20 (GB) Installation
Installation
Modifying Parts
Changing the Polarity
The polarity of the projector is adjusted at the factory to use the projector
for front projection on the floor.
When the projector is installed on the ceiling or used in rear projection, it
is necessary to change the settings of the polarity switches.
How to change the polarity
1Turn off the power of the projector.
2Open the control panel cover, loosen the screw, and open the cover of
the polarity switches.
3Change the position of the polarity switches (V and H switches), if
necessary.
4Close the cover of the polarity switches, tighten the screw and close
the control cover.
Note
If the cover of the polarity switches does not shut firmly, the power of the
projector is not turned on in order to protect the CRTs.
Loosen
Open
Push the control panel cover and
slide it to open.
V switch
H switch
L
R
L
R
Upper
Right
Left
Lower
