Sony VPL-CS1 User manual

Projection system 3 SVGA LCD panels, 1 lens projection system
LCD panels 0.7-inch p-Si TFT SVGA LCD panels,
1,440,000 (480,000 x 3) pixels
Lamp 120 W UHP
Projection lens 1.3 times zoom lens, F 1.7 to 2.1, f 28.74 to 37.36 mm
Screen coverage 40 to 150 inches (viewable area, measured diagonally)
Light output 600 ANSI lumens*1
Throwing distance
40-inch 1580 to 2010 mm (62
1/4
to 78
25/32
inches)
60-inch 2390 to 3060 mm (94
1/8
to 120
1/2
inches)
80-inch 3210 to 4100 mm (126
1/2
to 161
1/2
inches)
100-inch 4030 to 5150 mm (158
11/16
to 202
7/8
inches)
120-inch 4850 to 6200 mm (191 to 244
1/8
inches)
150-inch 6080 to 7780 mm (239
1/2
to 306
3/8
inches)
Optical
Model Memory
No.
1 Video 60 Hz 15.734 59.940 N/N
2 Video 50 Hz 15.625 50.000 N/N
3 15 K RGB/Component 60 Hz 15.734 59.940 S on G
4 15 K RGB/Component 50 Hz 15.625 50.000 S on G
5
6 640 x 350 VGA mode 1 31.469 70.086 P/N
7 VGA VESA 85 Hz 37.861 85.080 P/N
8 640 x 400 PC-9801 Normal 24.823 56.416 N/N
9 VGA mode 2 31.469 70.086 N/P
10 VGA VESA 85 Hz 37.861 85.080 N/P
11 640 x 480 VGA mode 3 31.469 59.940 N/N
12 Macintosh 13" 35.000 66.667 S on G
13 VGA VESA 72 Hz 37.861 72.809 N/N
14 VGA VESA 75 Hz 37.500 75.000 N/N
15 VGA VESA 85 Hz 43.269 85.008 N/N
16 800 x 600 SVGA VESA 56 Hz 35.156 56.250 P/P
17 SVGA VESA 60 Hz 37.879 60.317 P/P
18 SVGA VESA 72 Hz 48.077 72.188 P/P
19 SVGA VESA 75 Hz 46.875 75.000 P/P
20 SVGA VESA 85 Hz 53.674 85.061 P/P
21 832 x 624 Macintosh 16" 49.724 74.550 N/N
22 1024 x 768 XGA VESA 43 Hz 35.524 43.479 P/P
23 XGA VESA 60 Hz 48.363 60.004 N/N
24 XGA VESA 70 Hz 56.476 70.069 N/N
25 XGA VESA 75 Hz 60.023 75.029 P/P
26 XGA VESA 85 Hz 68.677 84.997 P/P
27 1152 x 864 SXGA VESA 70 Hz 63.995 70.016 P/P
28 SXGA VESA 75 Hz 67.500 75.000 P/P
29 SXGA VESA 85 Hz 77.487 85.057 P/P
30 1152 x 900 Sunmicro LO 61.795 65.960 N/N
31 Sunmicro HI 71.713 76.047 C Neg
32 1280 x 960 SXGA VESA 60 Hz 60.000 60.000 P/P
33 SXGA VESA 75 Hz 75.000 75.000 P/P
34 1280 x 1024 SXGA VESA 43 Hz 46.433 43.436 P/P
35 SGI-5 53.516 50.062 S on G
36 SXGA VESA 60 Hz 63.974 60.013 P/P
37 SXGA VESA 75 Hz 79.976 75.025 P/P
38 SXGA VESA 85 Hz 91.146 85.024 P/P
Specifications Preset Data of Input Signals
Optional Accessories
Color system NTSC, PAL, SECAM, NTSC4.43, PAL-M, PAL-N
(automatically/manually selected)
Resolution 600 TV lines (video), 800 x 600 pixels (RGB)
Acceptable signals RGB (fH: 15 to 91 kHz, fV: 43 to 85 Hz),
15 kHz component 50/60 Hz system, composite video, Y/C video
Signals
Speakers Max. 0.5 W x 2 (stereo)
Power requirements AC 100 to 240 V, 50/60 Hz
Power consumption Max. 190 W, standby 4.2 W
Operating temperature 0 to 35 °C (32 to 95 °F)
Operating humidity 35 to 85%
Dimensions 277 (W) x 70 (H) x 214 (D) mm (11 x 2 7/8x 8 1/2inches)
Mass Approx. 2.9 kg (6 lb 6 oz)
Heat dissipation 648.4 BTU
General
UL1950, CSA No.950, FCC Class B, IC Class B,
EN 60 950 (NEMCO), CE, C-Tick, CCIB, VCCI Class B
Projector lamp
LMP-C120
(for replacement)
Remote control unit
RM-PJ610
Monitor cables
SMF-400
SMF-410
Signal cable
SMF-402
Macintosh®adaptor
ADP-20 (Macintosh to VGA)
50-inch portable screen
VPS-50C*
LMP-C120
Safety regulations
Remote control unit RM-PJM1, Monitor cable SMF-410 (2 m):
HD D-sub 15-pin to HD D-sub 15-pin, PS/2 Mouse cable (2 m),
USB cable A type to B type, USB application software
“ PROJECTOR STATION ’’ , Carrying bag, AAA size battery (x 2),
Air filter, Operating manual, Quick reference sheet
*1 ANSI lumens is a measuring method of the American National Standards Institute IT7.228.
Supplied accessories
VIDEO
Composite Phono type, 1.0 Vp-p ±2 dB, sync negative, 75 Ω
VIDEO
Y/C IN Mini DIN 4-pin
Y 1 Vp-p ±2 dB, sync negative, 75 Ω
C Burst 0.286 Vp-p ±2 dB (NTSC), 75 Ω
or 0.3 Vp-p ±2 dB (PAL), 75 Ω
INPUT A
Analog RGB/Component HD D-sub 15-pin (female)
R/R-Y 0.7 Vp-p ±2 dB, positive, 75 Ω
G 0.7 Vp-p ±2 dB, positive, 75 Ω
G with Sync/Y 1.0 Vp-p ±2 dB, sync negative, 75 Ω
B/B-Y 0.7 Vp-p ±2 dB, positive, 75 Ω
SYNC/HD
Composite sync 1 to 5 Vp-p, high impedance positive/negative
Horizontal sync 1 to 5 Vp-p, high impedance positive/negative
VD
Vertical sync 1 to 5 Vp-p, high impedance positive/negative
MOUSE IN 6-pin (female)
USB HUB UP (B type female) x 1, Down (A type female) x 1
AUDIO IN Stereo mini jack, 500 mV rms, impedance more than 47 kΩ
Inputs/Outputs
Distributed by
Printed in Japan
Printed on recycled paper
MK7421V1SMC99OCT
©1999 Sony Corporation. All rights reserved.
Reproduction in whole or in part without permission is prohibited.
Features and specifications are subject to change without notice.
All non-metric weights and measures are approximate.
Sony is a registered trademark of Sony Corporation.
Macintosh and Mac are registered trademarks of Apple Computer, Inc.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
All other trademarks are the property of their respective owners.
H/V
Polarity
fV
(Hz)
fH
(kHz)
Preset Signal
VPL-CS1
Your PresentationsWillTake on aWhole New Look.
LCD Data Projector
VPL-CS1
* Not available in some areas. For details, please contact your nearest Sony office.

Ultra-compact and extremely lightweight
Thanks to newly developed 0.7-inch LCD panels and
a unique design, the VPL-CS1 is ultra-compact and
weighs approx. 2.9 kg (6.4 lbs.). What’s more, this
projector comes with a carrying case and has an
easy-to-grip handle and detachable strap that allow
you to take it anywhere.
600 ANSI lumens brightness
Despite its compact dimensions, the VPL-CS1
incorporates advanced Sony technologies that provide
an impressive 600 ANSI lumens of
brightness. A new 120 W UHP lamp
and brighter lens, together with
Sony’s unique 0.7-inch SVGA LCD
panels and optical unit produce
industry-leading levels of image clarity.
Quiet operation
Thanks to its new cooling structure, the VPL-CS1
operates with a low noise level. The use of sapphire
glass on the polarizer dramatically reduces heat
buildup, making only two internal fans necessary.
Exquisite form, handy function
The sleek front hood not only protects the lens from
damage but also serves as the projector’s front
stand when flipped open. The rear stand extends
simultaneously when the front hood is opened.
Computer friendly
With a hot plug-and-play USB hub and Sony
“PROJECTOR STATION” software*, the VPL-CS1
makes for professional presentations. The projector is
fully controllable from a computer, and presentation
files registered in the software can be opened by
pressing the function keys on the supplied RM-PJM1
remote control unit.
*PROJECTOR STATION software requirements:
Microsoft®Windows®98 operating system.
RM-PJM1
Various inputs
The VPL-CS1 accepts various input signals: Composite
video, S video, Y/Cb/Cr and RGB.
Advanced APA
The new APA (Auto Pixel Alignment) algorithm covers
not only dot phase but also size and shift adjustments.
Just press the
APA button to
automatically
adjust dot phase
and image size
or shift to their
optimal settings.
Digital keystone adjustment
Keystone distortion can be electronically corrected
with this function. The adjustable range of 20 degrees
can be controlled via the on-screen display menu.
The correction data is stored in the unit when
the KEYSTONE MEMORY menu is set to ON.
Impressive stereo sound
For excellent audio performance, the compact VPL-CS1
comes fully equipped with stereo speakers.
User-friendly menus
On-screen menus guide you every step of the way in
projector control – in seven languages of your choice:
English, French, Spanish, German, Italian, Japanese or
Chinese.
Digital zoom function
The 4-times digital zoom function can be easily
controlled from the optional RM-PJ610 remote control
unit.
Connector
Control panel
Multiscan converter
The VPL-CS1 accepts a wide variety of input signals,
with 37 preset signal formats covering any video
format used worldwide and PC signals up to SXGA.
Just plug in your computer with the supplied cable
and you get a great picture with no need for complex
adjustments.
