SERVICE MANUAL
Sony Corporation
Audio&Video Business Group
Published by Sony Techno Create Corporation
HCD-DH50R/DH70SWR
SPECIFICATIONS
DVD RECEIVER
9-889-569-02
2009G05-1
© 2009.07
AEP Model
HCD-DH50R/DH70SWR
Singapore Model
Taiwan Model
Korean Model
Thai Model
HCD-DH50R
• HCD-DH50R is the amplifier, USB, disc player and
tuner section in CMT-DH50R.
• HCD-DH70SWR is the amplifier, USB, disc player and
tuner section in CMT-DH70SWR.
• When the operation of the HCD-DH70SWR is con-
firmed, it is necessary to connect the SA-WDH70SWR.
Confirm the HCD-DH70SWR and SA-WDH70SWR
are prepared beforehand when you repair.
Model Name Using Similar Mechanism NEW
DVD Mechanism Type CDM86A-DVBU101
Optical Pick-up Block Name KHM-313CAB
Ver. 1.1 2009.07
Photo: HCD-DH50R
• This product incorporates copyright protection technol-
ogy that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technol-
ogy must be authorized by Macrovision, and is intended
for home and other limited viewing uses only unless oth-
erwise authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
• This system incorporates Dolby1) Digital and DTS2)
Digital Surround System.
1) Manufactured under license from Dolby Laboratories.
“Dolby” and the double- D symbol are trademarks of
Dolby Laboratories.
2) Manufactured under license under U.S. Patent
#’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;
6,487,535 & other U.S. and worldwide patents issued
& pending. DTS and DTS 2.0 + Digital Out are regis-
tered trademarks and the DTS logos and Symbol are
trademarks of DTS, Inc. ©1996-2008 DTS, Inc. All
Rights Reserved.
• “DVD+RW,” “DVD-RW,” “DVD+R,” “DVD VIDEO,”
and the “CD” logos are trademarks.
• DivX® is a video file compression technology, developed
by DivX, Inc. DivX, DivX Certified, and associated logos
are trademarks of DivX, Inc. and are used under license.
This product is an official DivX® certified product.
• MPEG Layer-3 audio coding technology and patents li-
censed from Fraunhofer IIS and Thomson.
• This system incorporates High-Definition Multimedia In-
terface (HDMITM) technology. HDMI, the HDMI logo
and High-Definition Multimedia Interface are trademarks
or registered trademarks of HDMI Licensing LLC.
• “BRAVIA” is a trademark of Sony Corporation.
• Control for HDMI is a mutual control function standard
used by CEC (Consumer Electronics Control) for HDMI
(High-Definition Multimedia Interface).
• Windows Media is a registered trademark of Microsoft
Corporation in the United States and/or other countries.
• THIS PRODUCT IS LICENSED UNDER THE MPEG-
4 VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A
CONSUMER FOR
(i) ENCODING VIDEO IN COMPLIANCE WITH THE
MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”)
AND/OR
(ii) DECODING MPEG-4 VIDEO THAT WAS ENCOD-
ED BY A CONSUMER ENGAGED IN A PERSONAL
AND NONCOMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED
BY MPEG LA TO PROVIDE MPEG-4 VIDEO.
NO LICENSE IS GRANTED OR SHALL BE IMPLIED
FOR ANY OTHER USE. ADDITIONAL INFORMA-
TION INCLUDING THAT RELATING TO PROMO-
TIONAL, INTERNAL AND COMMERCIAL USES
AND LICENSING MAY BE OBTAINED FROM MPEG
LA, LLC. SEE http://www.mpegla.com/
HCD-DH70SWR
DIN power output (rated)
45 + 45 watts (5.5 ohms at 1 kHz,
DIN)
Continuous RMS power output (reference)
60 + 60 watts (5.5 ohms at 1 kHz, 10%
THD)
Music power output (reference):
60 + 60 watts (5.5 ohms at 1 kHz, 10%
THD)
HCD-DH50R
DIN power output (rated)
60 + 60 watts (4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference)
80 + 80 watts (4 ohms at 1 kHz, 10%
THD)
Music power output (reference):
80 + 80 watts (4 ohms at 1 kHz, 10%
THD)
Inputs
TV/VIDEO AUDIO IN (phono jack):
voltage 450 mV/250 mV, impedance
47 kilohms
AUDIO IN (stereo mini jack):
voltage 700 mV, impedance
47 kilohms
MIC (mini jack):
sensitivity 0.8 mV, impedance
10 kilohms
FRONT SPEAKER
HCD-DH70SWR: Use only the
supplied speakers SS-CDH70SWR.
HCD-DH50R: Use only the supplied
speakers SS-CDH50R2 (only for
European and Russian models)/SS-
CDH50R (only for Asian models).
SUBWOOFER (HCD-DH70SWR only):
Use only the supplied subwoofer SA-
WDH70SWR.
USB section
Supported bit rate
MP3 (MPEG1 Audio Layer-3):
32 — 320 kbps
WMA: 48 — 192 kbps
AAC: 48 —320 kbps
Sampling frequencies
MP3 (MPEG1 Audio Layer-3):
32/44.1/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
(USB) port:
Maximum current:
500 mA
Disc player section
System:
Compact disc and digital audio and
video system
Laser Diode Properties
Emission duration: Continuous
Laser Output*: Less than 1000μW
is output is the value measurement
*
at a distance of 200mm from the
objective lens surface on the Optical
Pick-up Block with 7mm aperture.
Frequency response
DVD (PCM 48 kHz): 2 Hz —22 kHz
(±1 dB)
CD: 2 Hz — 20 kHz (±0.5 dB)
Video color system format
European and Russian models: PAL
Other models: NTSC and PAL
Amplier section
Outputs
VIDEO OUT (phono jack):
max. output level 1 Vp-p, unbalanced,
Sync negative, load impedance
75 ohms
COMPONENT VIDEO OUT:
Y
PB/CB: 0.7 V
PR/CR: 0.7 V
: 1 Vp-p, 75 ohms
p-p, 75 ohms
p-p, 75 ohms
HDMI OUT: Type A (19 pins)
DIGITAL OUT OPTICAL (square optical
connector jack, rear panel):
Wavelength 660 nm
PHONES (stereo mini jack):
accepts headphones of 8 ohms or
more
– Continued on next page –

HCD-DH50R/DH70SWR
2
NOTES ON CHIP COMPONENT REPLACEMENT
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
FLEXIBLE CIRCUIT BOARD REPAIRING
• Keep the temperature of soldering iron around 270 °C during
repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
SAFETY-RELATED COMPONENT WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous radia-
tion exposure.
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range:
87.5 — 108.0 MHz (50 kHz step)
Antenna:
FM lead antenna
Antenna terminals:
75 ohms unbalanced
Intermediate frequency:
10.7 MHz
AM tuner section
Tuning range:
European and Russian models:
531 — 1,602 kHz (9 kHz step)
Other models:
531 — 1,602 kHz (9 kHz step)
530 — 1,610 kHz (10 kHz step)
Antenna:
AM loop antenna
Antenna terminals:
External antenna terminal
Intermediate frequency:
450 kHz
General
Power requirements
AC 220
Taiwan model:
Other models:
AC 120 V, 50/60 Hz
— 240 V
, 50/60 Hz
Power consumption
HCD-DH70SWR:
50 watts (0.5 W in Power
Saving Mode)
HCD-DH50R: 55 watts (0.5 W in
Power Saving Mode)
Dimensions (w/h/d) (excl. speakers)
HCD-DH70SWR:
Approx. 200 × 171.2 × 210.6 mm
HCD-DH50R:
Approx. 200 × 171.2 × 210.6 mm
Mass (excl. speakers)
HCD-DH70SWR: Approx. 3.0 kg
HCD-DH50R: Approx. 3.0 kg
Supported le format
MP3 (MPEG1 Audio Layer-3)
File extension: .mp3
Bitrate: 32 kbps —320 kbps
Sampling frequencies: 32/44.1/48 kHz
DivX
File extension: .avi/.divx
Video codec: DivX video
Bitrate: 8 Mbps (MAX)
Frame rate: 30 fps
Resolution: 720 × 576
Audio codec: MP3
MPEG4
File format: MP4 File Format
File extension: .mp4/.m4v
Video codec:
(AVC is not compatible.)
Bitrate: 4 Mbps
Frame rate: 30 fps
Resolution: 720 × 576
Audio codec:
AAC-LC
(HE-AAC is not compatible.)
DRM: Not compatible
change without notice.
MPEG4 Simple Prole
Design and specications are subject to
is appliance is classied as aCLASS 1
LASER product. is marking is located
on the rear exterior.
When displaying the version number
on the TV screen
When you turn on the system, the
version number [VER.X.XX] (X is a
number) may appear on the TV screen.
Although this is not a malfunction and
for Sony service use only, normal system
the system, and then turn on the system
again to operate.
Self-diagnosis Function
(When letters/numbers appear in the
display)
When the self-diagnosis function
is activated to prevent the system
from malfunctioning, a 5-character
service number (e.g. C 13 50) with a
combination of a letter and 4 digits
appears on the TV screen or the front
panel display. In this case, check the
following table.
First 3
characters of
the service
number
Cause and corrective
action
tClean the disc with a
the system cannot play.
correctly.
tRestart the system,
then re-insert the
disc correctly.
E XX
C 31
C 13
(XX is a
number)
To prevent a
malfunction, the
system has performed
the self-diagnosis
function.
tContact your nearest
Sony dealer or local
authorized Sony
service facility and
give the 5-character
service number.
Example: E 61 10
Ver. 1.1

HCD-DH50R/DH70SWR
3
1. SERVICING NOTES ............................................. 4
2. DISASSEMBLY
2-1. Disassembly Flow........................................................... 10
2-2. Back Cover, Side_L/R .................................................... 11
2-3. Touch Panel Assy, Top Assy ........................................... 11
2-4. DC Fan (M002)............................................................... 12
2-5. POW-SUPPLY Board ..................................................... 12
2-6. Front Panel Block ........................................................... 13
2-7. SP-CONN Board............................................................. 13
2-8. MAIN board.................................................................... 14
2-9. CDM Cover..................................................................... 14
2-10. DVD Mechanism Deck (CDM86A-DVBU101) ............ 15
2-11. MD (86A) Assy............................................................... 15
2-12. Chassis (Top) .................................................................. 16
2-13. MS-214 Board................................................................. 16
2-14. Holder (BU) Assy ........................................................... 17
2-15. Lever (BU Lock)............................................................. 17
2-16. Close Lever ..................................................................... 18
2-17. Lever (DIR), Gear (IDL-B) ............................................ 18
2-18. Lever (Loading-L/R)....................................................... 19
2-19. Lever (Disc Sensor)/(Disc Stop)..................................... 20
2-20. Gear (IDL-C) .................................................................. 20
3. TEST MODE ............................................................ 21
4. ELECTRICAL CHECK ......................................... 25
5. DIAGRAMS
5-1. Block Diagram - DVD SERVO Section -....................... 26
5-2. Block Diagram - VIDEO Section -................................. 27
5-3. Block Diagram - AUDIO Section -................................. 28
5-4. Block Diagram
- PANEL/POWER SUPPLY Section -............................ 29
TABLE OF CONTENTS
5-5. Printed Wiring Boards - DVD SERVO Section - ........... 31
5-6. Schematic Diagram - DVD SERVO Section (1/4) -....... 32
5-7. Schematic Diagram - DVD SERVO Section (2/4) -....... 33
5-8. Schematic Diagram - DVD SERVO Section (3/4) -....... 34
5-9. Schematic Diagram - DVD SERVO Section (4/4) -....... 35
5-10. Printed Wiring Boards - MAIN Section - ....................... 36
5-11. Schematic Diagram - MAIN Section (1/3) -................... 37
5-12. Schematic Diagram - MAIN Section (2/3) -................... 38
5-13. Schematic Diagram - MAIN Section (3/3) -................... 39
5-14. Printed Wiring Boards - VIDEO/AUDIO Section - ....... 40
5-15. Schematic Diagram - VIDEO-OUT Board -................... 40
5-16. Schematic Diagram - SP-CONN Board - ....................... 41
5-17. Printed Wiring Boards - PANEL Section - ..................... 42
5-18. Schematic Diagram - PANEL Board - ............................ 43
5-19. Schematic Diagram - JACK/USB Boards -.................... 44
5-20. Printed Wiring Board - POW-SUPPLY Board - ............. 46
5-21. Schematic Diagram - POW-SUPPLY Board - ................ 47
6. EXPLODED VIEWS
6-1. Top Panel Section ........................................................... 61
6-2. Rear Panel Section.......................................................... 62
6-3. Front Panel Section......................................................... 63
6-4. MAIN Board Section...................................................... 64
6-5. Chassis Section ............................................................... 65
6-6. Mechanism Deck Section-1 (CDM86A-DVBU101)...... 66
6-7. Mechanism Deck Section-2 (CDM86A-DVBU101)...... 67
6-8. Mechanism Deck Section-3 (CDM86A-DVBU101)...... 68
6-9. Mechanism Deck Section-4 (CDM86A-DVBU101)...... 69
7. ELECTRICAL PARTS LIST .............................. 70
Accessories are given in the last of the electrical parts list.

HCD-DH50R/DH70SWR
4
SECTION 1
SERVICING NOTES
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
• Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
• Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
• Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
The laser diode in the optical pick-up block may suffer electro-
static break-down because of the potential difference generated by
the charged electrostatic load, etc. on clothing and the human body.
During repair, pay attention to electrostatic break-down and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical
pickup block. Therefore, when checking the laser diode emission,
observe from more than 30 cm away from the objective lens.
NOTES OF THE REPLACING THE IC2005 AND IC7004
ON THE DMB20 BOARD
IC2005 and IC7004 on the DMB20 board cannot exchange with
single. When these parts on the DMB20 board are damaged, ex-
change the entire mounted board.
MODEL IDENTIFICATION
PART No.
– Back Panel –
Model Part No.
HCD-DH50R: AEP 4-141-531-0[]
HCD-DH50R: Russian 4-141-531-1[]
HCD-DH50R: Singapore 4-141-531-2[]
HCD-DH50R: Thai 4-141-531-3[]
HCD-DH50R: Taiwan 4-141-531-4[]
HCD-DH50R: Korean 4-141-531-5[]
HCD-DH70SWR: AEP 4-145-041-0[]
HCD-DH70SWR: Russian 4-145-041-1[]
ADVANCE PREPARATION WHEN CONFIRMING OP-
ERATION
When the operation of the HCD-DH70SWR is confirmed, it is nec-
essary to connect the SA-WDH70SWR.
Confirm the HCD-DH70SWR and SA-WDH70SWR are prepared
beforehand when you repair.
RELEASING THE ANTITHEFT LOCK
The disc slot lock function for the antitheft of an demonstration
disc in the store is equipped.
Releasing Procedure:
1. Press the [?/1] button to turn the power on.
2. While pressing the [x] button, press the [Z] button unit “UN-
LOCKED” displayed on the fluorescent indicator tube (around
5 seconds) .
Note: When “LOCKED”is displayed, the disc slot lock is not released by
turning power on/off with the [?/1] button.
Be sure to bridge here, and then disconnect the
wire (flat type) (24 core).
(optical pick-up block will be destroyed without bridging.)
On the contrary at the installation, connect the
wire (flat type) (24 core) first, and then remove the bridge.
Note: For a soldering iron, use the one with a ground wire.
PRECAUTION WHEN REMOVING OPTICAL PICK-UP
BLOCK
Ver. 1.1

HCD-DH50R/DH70SWR
5
HOW TO EJECT THE DISC WHEN POWER SWITCH TURNS OFF
• Please work after taking out DVD mechanism deck of the set.
CAPACITOR ELECTRICAL DISCHARGE PROCESSING
• In checking the POW-SUPPLY board, make a capacitor discharge of C10 for electric shock prevention.
C10
POW-SUPPLY board
800 :/2 W
Turn the gear (IDL-B)
to the direction of the arrow.
DVD mechanism deck
disc
– Bottom view –

HCD-DH50R/DH70SWR
6
POW-SUPPLY BOARD SERVICE POSITION
POW-SUPPLY board
rear side
front side
MAIN BOARD SERVICE POSITION
• Please connect following extension jig.
POW-SUPPLY board
rear side
Connect extension jig 2
to the MAIN board (CN500) and
wire (flat type) (25 core).
Connect extension jig 4
to the MAIN board (CN503) and
wire (flat type) (21 core).
Connect extension jig 1
to the MAIN board (CN511) and
wire (flat type) (13 core).
Connect extension jig 3
to the MAIN board (CN510) and
wire (flat type) (7 core).
MAIN board
CN500
CN503
CN511
CN510
Jig No. Part No. Cores Length (mm)
1J-2501-102-A 13 300
2J-2501-199-A 25 300
3J-2501-241-A 7 300
4J-2501-244-A 21 300

HCD-DH50R/DH70SWR
7
ARRANGEMENT OF POWER CORD
POW-SUPPLY board
(bottom view)
line filter coil (T1)
power cord
15 mm or more
clamp filter
clamp
clamp
Note 3: Turn eight times, bundle the DC fan lead wire,
and fix with the stopper.
Note 1: The wire rod must not leak to the board.
Note 2: Bind CN702 from clamp filter and the wire rod of CN703 with clamp.
CN703 CN702
MAIN board
(rear view)
ARRANGEMENT OF WIRE ROD AND DC FAN LEAD WIRE

HCD-DH50R/DH70SWR
8
ARRANGEMENT OF FLEXIBLE FLAT CABLE
hook
front side
hook
hook
flexible flat cable (5 core)
lead wire flexible flat cable
(11 core) (AEP),
flexible flat cable
(21 core) (RU, SP, TW, KR, TH)
flexible flat cable
(11 core) (AEP),
flexible flat cable
(9 core) (RU, SP, TW, KR, TH)
flexible flat cable (25 core)
front side
• Abbreviation
KR : Korean model
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
Ver. 1.1

HCD-DH50R/DH70SWR
9
ARRANGEMENT OF LEAD WIRE
lead wire
lead wire

HCD-DH50R/DH70SWR
10
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
SET
2-2. BACK COVER,
SIDE_L/R
(Page 11)
2-17. LEVER (DIR),
GEAR (IDL-B)
(Page 18)
2-13. MS-214 BOARD
(Page 16)
2-19. LEVER (DISC SENSOR)/
(DISC STOP)
(Page 20)
2-3. TOUCH PANEL ASSY,
TOP ASSY
(Page 11)
2-4. DC FAN (M002)
(Page 12)
2-10. DVD MECHANISM DECK (CDM86A-DVBU101)
(Page 15)
2-5. POW-SUPPLY BOARD
(Page 12)
2-6. FRONT PANEL BLOCK
(Page 13)
2-9. CDM COVER
(Page 14)
2-11. MD (86A) ASSY
(Page 15)
2-14. HOLDER (BU) ASSY
(Page 17)
2-15. LEVER (BU LOCK)
(Page 17)
2-16. CLOSE LEVER
(Page 18)
2-18. LEVER (LOADING-L/R)
(Page 19)
2-20. GEAR (IDL-C)
(Page 20)
2-12. CHASSIS (TOP)
(Page 16)
2-7. SP-CONN BOARD
(Page 13)
2-8. MAIN BOARD
(Page 14)

HCD-DH50R/DH70SWR
11
Note: Follow the disassembly procedure in the numerical order given.
2-2. BACK COVER, SIDE_L/R
2-3. TOUCH PANEL ASSY, TOP ASSY
3screw
(BVTP3
u8)
1five screws
(BVTP3
u8)
3screw
(BVTP3
u8)
7cushion (10 u20)
7two cushions (10 u20)
7three cushions (10 u20)
8side_R
8side_L
6three claws
4screw
(BV3 3-CR)
5
5
4screw
(BV3 3-CR)
2back cover
6three claws
1screw
(BVTT3
u6)
2two claws
1screw
(BVTT3
u6)
6touch panel assy
7top assy
3
5six screws
(BVTP2.6 3CR)
4flexible flat cable (7 core)
(CN391)

HCD-DH50R/DH70SWR
12
2-4. DC FAN (M002)
2-5. POW-SUPPLY BOARD
1four screws
(BV3
u8)
1three screws
(BV3
u8)
3
7DC fan
(M002)
6rear cover
5two screws
(BVTP3
u8)
4DC fan connector
(CN672)
2screw
(BV/ ring)
2screw
(BV/ring)
(DH70SWR)
4two screws
(BV3
u8)
q; top chassis block
qa fuse (H.B.C.)
(T5AL/250V) (F1)
qs POW-SUPPLY
board
9four screws
(BVTP3
u8)
4two screws
(BV3
u8)
7two connectors
(CN507, CN704)
8connector
(CN901)
5screw
(BVTT3
u6)
5screw
(BVTT3
u6)
2power cord connector
(CN1)
1
6
3power cord block

HCD-DH50R/DH70SWR
13
2-6. FRONT PANEL BLOCK
2-7. SP-CONN BOARD
Note: This illustration sees the set from rear side.
5two screws
(BVTT3
u6)
6two claws
2flexible flat cable (7 core)
(CN510)
1flexible flat cable (13 core)
(CN511)
3screw
(BVTP2.6 3CR)
4terminal
7front panel block
1connector
(DH50R: CN669)
(DH70SWR: CN670)
2connector
(CN667)
4SP-CONN board
3two claws

HCD-DH50R/DH70SWR
14
2-8. MAIN BOARD
Note: This illustration sees the set from rear side.
2-9. CDM COVER
A
A
B
B
C
C
D
D
E
E
F
F
q; three screws
(BVTP3
u8)
qg two screws
(BVTP3
u8)
qh heat sink (S-master)
qj radiation sheet
qk MAIN board
qs screw
(BVTP3
u8)
qa terminal
qd clamp
qf clamp filter
q; two screws
(BVTP3
u8)
8connector
(DH50R: CN669)
(DH70SWR: CN670)
9connector
(CN667)
1flexible flat cable (5 core)
(CN401)
2flexible flat cable (7 core)
(CN510)
3flexible flat cable (13 core)
(CN511)
6flexible flat cable (25 core)
(CN500)
5connector
(CN606)
4flexible flat cable (11 core)
(AEP: CN502),
flexible flat cable (21 core)
(RU, SP, TW, KR, TH: CN503)
7flexible flat cable (11 core)
(AEP: CN505),
flexible flat cable (9 core)
(RU, SP, TW, KR, TH: CN504)
7two screws
(BVTP3
u10)
7screw
(BVTP3
u10)
q; two claws
9
1screw
(BVTT3
u6)
1two screws
(BVTT3
u6)
3two screws
(BV3 3-CR)
2plate_GND_A
2two plates_GND_A
Perform work with this wire (flat type) (24 core) connected, or make a bridge as mentioned above and then disconnect the wire
(flat type) (24 core). (Optical pick-up will be destroyed without bridging.) On the contrary at the installation, connect the wire (flat type)
(24 core) first, and then remove the bridge.
Note: For a soldering iron, use the one with a ground wire.
(Refer to DISASSEMBLY 2-10. DVD MECHANISM DECK (CDM86A-DVBU101)
PRECAUTION WHEN REMOVING WIRE (FLAT TYPE) (24 CORE)
3two screws
(BV3 3-CR)
4
qa CDM cover
5connector
(CN3002)
6Turn over the
mechanism deck block.
8two claws
• Abbreviation
KR : Korean model
RU : Russian model
SP : Singapore model
TH : Thai model
TW : Taiwan model
Ver. 1.1

HCD-DH50R/DH70SWR
15
2-10. DVD MECHANISM DECK (CDM86A-DVBU101)
2-11. MD (86A) ASSY
PRECAUTION WHEN REMOVING GOOD
OPTICAL PICK-UP BLOCK
4Be sure to bridge here, and then
disconnect the wire (flat type) (24 core).
(optical pick-up block will be destroyed
without bridging.)
On the contrary at the installation,
connect the wire (flat type) (24 core) first,
and then remove the bridge.
Note: For a soldering iron, use the one
with a ground wire.
1two claws
2two claws
3Lift up the FFC holder.
5flexible flat cable (7 core)
(CN001)
6connector
(optical pick-up)
7DVD mechanism deck
(CDM86A-DVBU101)
– bottom view –
3wire (flat type) (24 core)
6optical pick-up block
(KHM-313CAB)
1two claws
2FFC holder
4insulator screw
4insulator screw
5insulator
5insulator
4insulator screw
4insulator screw
5insulator
5insulator
7MD (86A) assy

HCD-DH50R/DH70SWR
16
2-12. CHASSIS (TOP)
2-13. MS-214 BOARD
1screw
(B2.6 u8)
4three screws
(B2.6 u8)
3two screws
(B2 u10)
5chassis (top)
2lever (CL UP2)
3Remove two solders.
2two screws
(B2.6 u8)
5MS-214 board
4motor (pully) assy (loading)
(M001)
1belt (MOT)

HCD-DH50R/DH70SWR
17
2-14. HOLDER (BU) ASSY
2-15. LEVER (BU LOCK)
Note: This illustration sees the mechanism deck from bottom side.
1screw
(B2.6 u8)
2lever (CL UP2)
6holder (BU) assy
5floating screw
(PTPWH M2.6)
5floating screw
(PTPWH M2.6)
4LHL support
3two screws
(B2 u6)
3three hooks
4lever (BU lock)
2gear (BU lock)
1gear (cap)

HCD-DH50R/DH70SWR
18
2-16. CLOSE LEVER
Note: This illustration sees the mechanism deck from bottom side.
2-17. LEVER (DIR), GEAR (IDL-B)
Note: This illustration sees the mechanism deck from bottom side.
1washer (3-1-0.4)
2SPR-E lever close
4shaft disc stop
5close lever
3claw
4pulley (gear)
3nylon washer 1.7
2claw
washer
0Lever (DIR)
6gear (IDL-A)
qa gear (IDL-B)
1tension coil spring (DIR)
9stoper
7Loosen the screw.
8Hold the release lever
and change the direction.
5gear (cap)

HCD-DH50R/DH70SWR
19
2-18. LEVER (LOADING-L/R)
2two hooks
4two hooks
– Bottom view –
3lever (loading-L)
5lever (loading-R)
SPT-T (loading-R) SPR-T (loading-L)
1
1
PRECAUTION DURING LEVER (LOADING R/L) INSTALLATION
lever (loading-R)
Align the horizontal position.
lever (loading-L)
Install the both levers so that they move symmetrically.

HCD-DH50R/DH70SWR
20
2-19. LEVER (DISC SENSOR)/(DISC STOP)
2-20. GEAR (IDL-C)
chassis (top)
hole
Install the lever (disc stop) so that the both holes
are aligned.
hole
1gear (cap)
3two claws
5two hooks
6lever (disc stop) lever (disc stop)
4lever (disc sensor)
PRECAUTION DURING DISC STOP LEVER INSTALLATION
2gear (IDL-L)
4three hooks
2two claws
6claw
1gear (IDL-F)
7gear (IDL-C)
3gear (IDL-D)
5lever (gear loading) assy
