Sony HCD-FX10 - Dvd/sacd Component For Dream... User manual

SERVICE MANUAL
Sony Corporation
Home Audio Division
Published by Sony Engineering Corporation
US Model
Canadian Model
DVD RECEIVER
9-879-623-02
2005K16-1
© 2005.11
Ver. 1.1 2005.11
HCD-FX10
HCD-FX10 is the amplifier, DVD/CD and
tuner section in DAV-FX10.
— Continued on next page —
SPECIFICATIONS
Model Name Using Similar Mechanism NEW
Mechanism Type CDM69EH-DVBU101
Optical Pick-up Name KHM-310CAB/C2NP
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND
TOTAL HARMONIC
DISTORTION: With 3 ohm loads, both
channels driven, from
200 – 20,000 Hz; rated
55 watts per channel
minimum RMS power,
with no more than 0.7 %
total harmonic distortion
from 250 milli watts to
rated output.
Amplifier section
Surround mode (reference) music power output
Front: 143 W + 143 W
(with SS-TS43)
Center*: 143 W
(with SS-CT43)
Surround*: 143 W + 143
W
(with SS-TS43B)
Subwoofer*: 285 W
(with SS-WS42)
*Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
VIDEO 1, VIDEO 2 Sensitivity: 450 mV
Impedance: 50 kilohms
Inputs (Digital)
VIDEO 1 (Coaxial) Impedance: 75 ohms
VIDEO 2 (Optical)
Phones Accepts low-and high-
impedance headphones.
Super Audio CD/DVD system
Laser Semiconductor laser
(Super Audio CD/DVD: λ
= 650 nm)
(CD: λ= 790 nm)
Emission duration:
continuous
Signal format system NTSC
Frequency response (at 2 CH STEREO mode)
DVD (PCM): 2 Hz to 22
kHz (±1.0 dB)
CD: 2 Hz to 20 kHz (±1.0
dB)
Tuner section
System PLL quartz-locked digital
synthesizer system
FM tuner section
Tuning range 87.5 – 108.0 MHz
(100 kHz step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range 530 – 1,710 kHz (with the
interval set at 10 kHz)
531 – 1,710 kHz (with the
interval set at 9 kHz)
Antenna (aerial) AM loop antenna (aerial)
Intermediate frequency 450 kHz
Video section
Outputs Video: 1 Vp-p 75 ohms
S video:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
PB/CB, PR/CR: 0.7 Vp-p
75 ohms
Input VIDEO1, VIDEO2: 1 Vp-p
75 ohms
This system incorporates with Dolby*1 Digital and
Dolby Pro Logic (II) adaptive matrix surround decoder
and the DTS*2 Digital Surround System.
*1 Manufactured under license from Dolby Laboratories.
“Dolby,” “Pro Logic,” and the double-Dsymbol are trademarks
of Dolby Laboratories.
*2 Manufacturedunder license fromDigitalTheater Systems,Inc.
“DTS” and “DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
