HCD-FC7

US Model

Canadian Model

E Model

Australian Model

SERVICE MANUAL

SACD/DVD RECEIVER

Sony Corporation

Home Audio Company

Published by Sony Engineering Corporation

9-961-034-01

2003H1678-1

HCD-FC7istheamplifier, DVD/SACDandtuner

section in DAV-FC7.

Ver 1.0 2003. 08

Model Name Using Similar Mechanism HCD-C770

Mechanism Type

CDM69-DVBU16

Base Unit Name DVBU16

Optical Pick-up Name

TDP022W

SPECIFICATIONS

AUDIO POWER SPECIFICATIONS POWER

OUTPUT AND TOTAL HARMONIC

DISTORTION:

With 4 ohm loads, both channels driven, from 20 –

20,000 Hz; rated 75 watts per channel minimum RMS

power, with no more than 0.7 % total harmonic

distortion. (from 250 milli watts to rated output)

Amplifier section

Stereo mode 100 W + 100 W (4 ohms

at 1 kHz, THD 10 %)

Surround mode Front:

100

W +

100

W

centre*:

100

W

Surround*:

100

W +

100

W (4 ohms at 1 kHz,

THD 10 %)

Subwoofer*:

100

W

(4 ohms at 100 Hz, THD

10 %)

* Depending on the sound field settings and the source,

there may be no sound output.

Inputs VIDEO 1:

Sensitivity: 150 mV

Impedance: 50 kilohms

VIDEO 2:

Sensitivity: 300 mV

Impedance: 50 kilohms

Outputs

VIDEO 1 (AUDIO

OUT):

Voltage: 1 V

Impedance: 1 kilohm

PHONES:

Accepts stereo

headphones only.

Super Audio CD/DVD system

Laser emiconductor laser

(Super Audio CD/DVD:

= 650 nm)

(CD: = 780 nm)

Emi

λ

ssion duration:

continuous

Signal format system NTSC or NTSC/PAL

Frequency response (at 2 CH STEREO mode)

DVD (PCM): 2 Hz to

22 kHz (±1.0 dB)

CD: 2 Hz to 20 kHz

(±1.0 dB)

Harmonic distortion Less than 0.03 %

Tuner section

System PLL quartz-locked digital

synthesizer system

FM tuner section

Tuning range

North American models: 87.5 – 108.0 MHz

(100 kHz step)

Other models: 87.5 – 108.0 MHz

(50 kHz step)

Antenna FM wire antenna

Antenna terminals 75 ohms, unbalanced

Intermediate frequency 10.7 MHz

AM tuner section

Tuning range

North American models: 531 – 1,710 kHz (with the

interval set at 9 kHz)

530 – 1,710 kHz (with the

interval set at 10 kHz)

Other models: 531 – 1,602 kHz (with the

interval set at 9 kHz)

530 – 1,710 kHz (with the

interval set at 10 kHz)

Antenna AM loop antenna

Intermediate frequency 450 kHz

Video section

Inputs Video: 1 Vp-p 75 ohms

Outputs Video: 1 Vp-p 75 ohms

S video:

Y: 1 Vp-p 75 ohms

C: 0.286 Vp-p 75 ohms

COMPONENT:

Y: 1 Vp-p 75 ohms

P

B

/C

B

, P

R

/C

R

: 0.7 Vp-p

75 ohms

General

Power requirements

North American models: 120 V AC, 60 Hz

Australian and Asian models:

220 – 240 V AC, 50/60 Hz

Power consumption

North American models: 135 W

Australian and Asian models:

135 W

Dimensions (approx.) 380 70 345 mm

(15 2

7

/

8

13

5

/

8

inches)

(w/h/d) incl. projecting

parts

Mass (approx.) 4.8 kg (10 lb 10 oz)

Operating temperature 5°C to 35°C (41°F to 95°F)

Operating humidity 5 % to 90 %

S

××

× ×

Design and specification are subject to change without

notice.

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

2

HCD-FC7

LEAKAGE

The AC leakage from any exposed metal part to earth Ground and

from all exposed metal parts to any exposed metal part having a

return to chassis, must not exceed 0.5 mA (500 microampers).

Leakage current can be measured by any one of three methods.

1. A commercial leakage tester, such as the Simpson 229 or RCA

WT-540A. Follow the manufacturers’ instructions to use these

instruments.

2. A battery-operated AC milliammeter. The Data Precision 245

digital multimeter is suitable for this job.

3. Measuring the voltage drop across a resistor by means of a

VOM or battery-operatedAC voltmeter. The “limit” indication

is 0.75 V, so analog meters must have an accurate low-voltage

scale. The Simpson 250 and Sanwa SH-63Trd are examples of

a passive VOM that is suitable. Nearly all battery operated

digital multimeters that have a 2V AC range are suitable. (See

Fig. A)

Fig. A. Using an AC voltmeter to check AC leakage.

0.15

µ

F

To Exposed Metal

Parts on Set

1.5k

Ω

AC

voltmete

r

(0.75V)

Earth Ground

CAUTION

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous

radiation exposure.

Notes on chip component replacement

•Never reuse a disconnected chip component.

•Notice that the minus side of a tantalum capacitor may be

damaged by heat.

Flexible Circuit Board Repairing

•Keep the temperature of soldering iron around 270˚C

during repairing.

•Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

•Be careful not to apply force on the conductor when soldering

or unsoldering.

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer:

Check the antenna terminals, metal trim, “metallized” knobs, screws,

and all other exposed metal parts forAC leakage. Check leakage as

described below.

Laser component in this product is capable of emitting radiation

exceeding the limit for Class 1.

This appliance is classified as

a CLASS 1 LASER product.

The CLASS 1 LASER

PRODUCT MARKING is

located on the rear exterior.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH

MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

Unleaded solder

Boards requiring use of unleaded solder are printed with the lead-

free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed with

the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

•Unleaded solder melts at a temperature about 40°C higher than

ordinary solder.

Ordinary soldering irons can be used but the iron tip has to be

applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set to

about 350°C.

Caution: The printed pattern (copper foil) may peel away if the

heated tip is applied for too long, so be careful!

•Strong viscosity

Unleaded solder is more viscous (sticky, less prone to flow) than

ordinary solder so use caution not to let solder bridges occur such

as on IC pins, etc.

•Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder may

also be added to ordinary solder.

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!

LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES

DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT

CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE

REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY

DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU

DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

3

HCD-FC7

TABLE OF CONTENTS

1. SERVICING NOTE ·························································· 4

2. GENERAL ·········································································· 7

3. DISASSEMBLY ······························································ 10

3-1. FRONT PANEL SECTION,

SIDE PANEL (L)/(R) SECTION ································· 11

3-2. DDCON BOARD, LED BOARD, FL BOARD ·········· 12

3-3. KEY BOARD ······························································ 12

3-4. POWER BOARD ························································· 13

3-5. AMP BOARD ······························································ 13

3-6. DVD BOARD, DC FAN ·············································· 14

3-7. CD MECHANISM DECK (CDM69-DVBU16) ········· 15

3-8. SELECTOR BOARD, VIDEO BOARD,

LF BOARD ·································································· 16

3-9. AUDIO BOARD, S-VIDEO BOARD ························· 16

3-10. BASE UNIT (DVBU16) ············································ 17

3-11. PICK-UP UNIT (TDP022W)····································· 17

3-12. SW BOARD, BRACKET (TOP) ASSY ···················· 18

3-13. RELAY BOARD ························································ 18

3-14. MOTOR (STOCKER) ASSY (STOCKER)(M761) ··· 19

3-15. MOTOR (STOCKER) ASSY (ROLLER)(M781) ····· 19

3-16. MOTOR (STOCKER) ASSY (MODE)(M771) ········· 20

3-17. RUBBER ROLLER (SLIDER) ASSY ······················· 20

3-18. TIMING BELT (FRONT/REAR) ······························ 21

3-19. CAM (GEAR) ···························································· 21

3-20. SENSOR BOARD ····················································· 22

4. ASSEMBLY······································································ 10

4-1. HOW TO INSTALL THE CAM (EJECT LOCK) ······· 23

4-2. HOW TO INSTALL THE CAM (GEAR) ··················· 23

4-3. HOW TO INSTALL THE GEAR (MODE 2)·············· 24

4-4. HOW TO INSTALL THE GEAR (MODE CAM)······· 24

4-5. HOW TO INSTALL

THE ROTARY ENCODER (S702),

GEAR (STOCKER COMMUNICATION) ················· 25

4-6. HOW TO INSTALL THE STOCKER ASSY ·············· 25

5. TEST MODE···································································· 26

6. ELECTRICAL ADJUSTMENT ·································· 36

7. DIAGRAMS

7-1. CIRCUIT BOARDS LOCATION ······························· 35

7-2. BLOCK DIAGRAMS – RF/SERVO SECTION – ······ 36

– AUDIO SECTION – ················································· 37

– AUDIO OUT SECTION – ······································· 38

– VIDEO SECTION – ················································· 39

– POWER SECTION – ··············································· 40

7-3. PRINTED WIRING BOARD – RF SECTION – ········ 41

7-4. SCHEMATIC DIAGRAM – RF SECTION – ············· 42

7-5. PRINTED WIRING BOARD

– CHANGER SECTION – ·········································· 43

7-6. SCHEMATIC DIAGRAM

– CHANGER SECTION – ·········································· 44

7-7. PRINTED WIRING BOARD

– DVD SECTION (SIDE A) – ···································· 45

7-8. PRINTED WIRING BOARD

– DVD SECTION (SIDE B) – ···································· 46

7-9. SCHEMATIC DIAGRAM

– DVD SECTION (1/10) – ·········································· 47

7-10.SCHEMATIC DIAGRAM

– DVD SECTION (2/10) – ·········································· 48

7-11.SCHEMATIC DIAGRAM

– DVD SECTION (3/10) – ·········································· 49

7-12.SCHEMATIC DIAGRAM

– DVD SECTION (4/10) – ·········································· 50

7-13.SCHEMATIC DIAGRAM

– DVD SECTION (5/10) – ·········································· 51

7-14.SCHEMATIC DIAGRAM

– DVD SECTION (6/10) – ·········································· 52

7-15.SCHEMATIC DIAGRAM

– DVD SECTION (7/10) – ·········································· 53

7-16.SCHEMATIC DIAGRAM

– DVD SECTION (8/10) – ·········································· 54

7-17.SCHEMATIC DIAGRAM

– DVD SECTION (9/10) – ·········································· 55

7-18.SCHEMATIC DIAGRAM

– DVD SECTION (10/10) – ········································ 56

7-19.PRINTED WIRING BOARD

– AMP SECTION (SIDE A) – ···································· 57

7-20.PRINTED WIRING BOARD

– AMP SECTION (SIDE B) – ···································· 58

7-21.SCHEMATIC DIAGRAM

– AMP SECTION (1/2) – ············································ 59

7-22.SCHEMATIC DIAGRAM

– AMP SECTION (2/2) – ············································ 60

7-23.PRINTED WIRING BOARD

– AUDIO SECTION –················································· 61

7-24.SCHEMATIC DIAGRAM

– AUDIO SECTION –················································· 62

7-25.PRINTED WIRING BOARD

– VIDEO SECTION – ················································· 63

7-26.SCHEMATIC DIAGRAM

– VIDEO SECTION – ················································· 64

7-27.PRINTED WIRING BOARD

– DDCOM SECTION – ·············································· 65

7-28.PRINTED WIRING BOARD

– CONTROL SECTION – ·········································· 66

7-29.SCHEMATIC DIAGRAM

– DDCOM/CONTROL SECTION – ·························· 67

7-30.PRINTED WIRING BOARD

– POWER SECTION – ··············································· 68

7-31.SCHEMATIC DIAGRAM

– POWER SECTION – ··············································· 69

7-32.IC BLOCK DIAGRAMS ············································ 71

7-33.IC PIN FUNCTION DESCRIPTION ························· 82

8. EXPLODED VIEWS

8-1. CASE SECTION ······················································· 106

8-2. FRONT PANEL SECTION ······································· 107

8-3. CHASSIS SECTION-1 ············································· 108

8-4. CHASSIS SECTION-2 ············································· 109

8-5. CHASSIS SECTION-3 ············································· 110

8-6. MECHANISM DECK SECTION-1 ························· 111

(CDM69-DVBU16) ··················································· 111

8-7. MECHANISM DECK SECTION-2 ························· 112

(CDM69-DVBU16) ··················································· 112

8-8. MECHANISM DECK SECTION-3 ························· 113

(CDM69-DVBU16) ··················································· 113

8-9. MECHANISM DECK SECTION-4 ························· 114

(CDM69-DVBU16) ··················································· 114

8-10.MECHANISM DECK SECTION-5

(CDM69-DVBU16) ··················································· 115

8-11.MECHANISM DECK SECTION-6

(CDM69-DVBU16) ··················································· 116

8-12.BASE UNIT SECTION (DVBU16) ·························· 117

9. ELECTRICAL PARTS LIST ····································· 118

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

4

HCD-FC7

NOTES ON HANDLING THE OPTICAL PICK-UP BLOCK

OR BASE UNIT

The laser diode in the optical pick-up block may suffer electrostatic

break-down because of the potential difference generated by the

charged electrostatic load, etc. on clothing and the human body.

During repair, pay attention to electrostatic break-down and also

use the procedure in the printed matter which is included in the

repair parts.

The flexible board is easily damaged and should be handled with

care.

NOTES ON LASER DIODE EMISSION CHECK

The laser beam on this model is concentrated so as to be focused on

the disc reflective surface by the objective lens in the optical pick-

up block. Therefore, when checking the laser diode emission,

observe from more than 30 cm away from the objective lens.

LASER DIODE AND FOCUS SEARCH OPERATION

CHECK

Carry out the “S curve check” in “CD section adjustment” and check

that the S curve waveform is output several times.

JIG ON REPAIRING

When repairing this set, etc., connect the extension cable as the

figure shown below.

•Service position of mechanism block

MODEL IDENTIFICATION

— BACK PANEL —

Part No.

SECTION 1

SERVICING NOTE

J-2501-103-A

(1mm/29P/L300)

RF board

RELAY board

J-2501-249-A

(1mm/28P/L300)

Model

US, Canadian models

Singapore model

Australian model

PARTS No.

4-248-520-0s

4-248-520-1s

4-248-520-2s

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

5

HCD-FC7

•Service position of POWER board

POWER board

power cord Power cord is directly connected

without going via LF board .

•Service position of DVD board

DVD board

AMP board J-2501-242-A

(1mm/11P/L300) J-2501-231-A

(1mm/15P/L300

)

POWER board

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

6

HCD-FC7

•Service position of AMP board

AMP board

AMP board cannot be moved unless

it removes side panel and back panel .

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

7

HCD-FC7

SECTION 2

GENERAL

Front Panel

ADisc slot (24)

BDISC 1-5 A(eject)/indicators (24)

CH(play) (24)

DX(pause) (26)

Ex(stop) (26)

F./>, PREV/NEXT (26, 28, 60, 61)

GVOLUME +/– (24, 71)

HBASS LEVEL (50)

IPHONES jack (on the side of the

system) (24)

JSOUND FIELD –/+ (47, 48, 49)

KDISPLAY (40, 43, 61)

LBAND (60, 61)

MFUNCTION (24, 59, 61)

NFront panel display (82)

O(remote sensor) (13)

P"/1(power) switch/STANDBY indicator

(24)

This section is extracted

from instruction manual.

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

8

HCD-FC7

Rear Panel

ASPEAKER jacks (15)

BSCAN SELECT switch (68)

CVIDEO 1 ANALOG OUT jacks (20)

DVIDEO 2 ANALOG IN jacks (20)

EMONITOR OUT (VIDEO/S VIDEO) jacks

(20)

FAM terminals (18)

GFM 75ΩCOAXIAL jack (18)

HVIDEO 2 OPTICAL DIGITAL IN jack (20)

ICOMPONENT VIDEO OUT jacks (20)

JVIDEO 1 ANALOG IN jack (20)

AM

COAXIAL

FM

75

VIDEO OUTAUDIO OUT

SCAN SELECT

SELECTABLE

INTERLACE

VIDEO INAUDIO IN

RL

R

P

B

/C

B

P

R

/C

R

Y

L

VIDEO 2

MONITOR OUT

VIDEO 1

COMPONENT VIDEO OUT

SPEAKER

COMPONENT

VIDEO OUT

VIDEO IN

VIDEO

OPTICAL

DIGITAL

IN

S VIDEO

AUDIO IN

RL

CENTER FRONT LFRONT R

WOOFER SURR LSURR R

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

9

HCD-FC7

Remote

Note

This remote control glows in the dark. However,

before glowing, the remote must be exposed to light for

awhile.

ADISC SKIP (26)

BZ(eject) (26)

CDISPLAY (40, 43, 61)

DFUNCTION (24, 59, 61)

ESTEREO/MONO (61)

FBAND (60, 61)

GPLAY MODE (33, 34, 35)

HCLEAR (34, 35, 36, 38)

ITV (59)

JAUDIO (45)

KANGLE (51)

LSUBTITLE (52)

M./>,PREV/NEXT,PRESET–/+(26,

28, 60, 61)

NH(play) (24, 28, 34, 35)

OX(pause) (26)

PDVD TOP MENU/ALBUM– (27, 29, 31)

QC/X/x/c/ENTER (27, 29, 31, 33, 34, 36,

38, 45, 51, 52, 53, 60, 62, 63, 64, 65)

RDVD DISPLAY (29, 31, 33, 36, 38, 43, 44,

45, 51, 52, 53)

STV CH +/– (58)

TTV VOL +/– (58)

UTV [/1(on/standby) (58)

V"/1(standby) (24, 60)

WREPEAT (34, 36)

XNAME (62)

YSOUND FIELD +/– (47, 48, 49)

ZMEMORY (60)

wj NIGHT MODE (50)

wk Number buttons (27, 28, 34, 38, 51, 53,

55, 58)

wl ENTER (60)

e; m/M// SLOW, TUNING –/+ (32,

37, 60)

ez x(stop) (26, 27, 28, 53)

es MUTING (26)

ed DVD MENU/ALBUM+ (27, 29, 31)

ef VOLUME +/– (61)

eg ORETURN (28, 29, 31, 33, 34, 38, 53,

55, 65)

eh TV/VIDEO (58)

ej BASS LEVEL (50)

ek AMP MENU (63, 64)

el DVD SETUP (55, 65)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

10

HCD-FC7 SECTION 3

DISASSEMBLY

•The equipment can be removed using the following procedure.

FRONT PANEL SECTION,

SIDE PANEL (L)/(R) SECTION

CD MECHANISM DECK

(CDM69-DVBU16)

SW BOARD,

BRACKET (TOP) ASSY

RUBBER ROLLER

(SLIDER) ASSY MOTOR (STOCKER)

ASSY (MODE)(M771) MOTOR (STOCKER)

ASSY (ROLLER)(M781)

TIMING BELT

(FRONT/REAR) CAM (GEAR)

SENSOR BOARD

BASE UNIT

(DVBU16)

PICK-UP UNIT

(TDP022W)

RELAY BOARD

MOTOR (STOCKER)

ASSY (STOCKER)(M761)

SELECTOR BOARD,

VIDEO BOARD, LF BOARD

AUDIO BOARD,

S-VIDEO BOARD

DDCON BOARD, LED BOARD,

FL BOARD

KEY BOARD

POWER BOARD

AMP BOARD

DVD BOARD,

DC FAN

SET

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

11

HCD-FC7

Note: Follow the disassembly procedure in the numerical order given.

3-1. FRONT PANEL SECTION, SIDE PANEL (L)/(R) SECTION

a

1

four screws

(+BV SUMITITE B3)

6

two screws

(+BVTP 3

×

8)

qf

two screws

(+BVTP 3

×

8)

0

screw

(+BTP 3

×

6)

qa

screw

(+PTPWHM 2.6

×

6)

qg

two screws

(+BVTP 3

×

8)

7

two screws

(+BVTP 3

×

8)

2

four screws

(+BV SUMITITE B3)

3

4

wire (flat type)(CN005)

9

connector (CN900)

qd

HP board

qs

connector

(CN901)

8

side panel (L)

qh

side panel (R)

5

front panel section

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

12

HCD-FC7

2

DDCON board

9

FL board

5

LED board

6

power button sub assy

1

four screws

(+BVTP 3

×

8

)

7

four screws

(+BVTP 3

×

8)

qd

three screws

(+BVTP 3

×

8)

0

three screws

(+BVTP 3

×

8)

3

two screws

(+BVTP 3

×

8)

4

two screws

(+BVTP 3

×

8)

8

wire (flat type)

qa

panel top (L)

qf

panel top (R)

qs

band button

qg

front (ml) panel

3-2. DDCON BOARD, LED BOARD, FL BOARD

6

KEY board

7

disc button sub assy

1

three screws

(+BVTP 3

×

8)

8

three screws

(+BVTP 3

×

8)

9

two screws

(+BVTP 3

×

8)

4

four screws

(+BVTP 3

×

8)

5

four screws

(+BTP 2.6

×

6)

2

three screws

(+BVTP 3

×

8)

3

play button

0

slot disc

qa

sheet

qs

slot disc (inside)

qd

cover slot

qf

front (al) panel

3-3. KEY BOARD

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

13

HCD-FC7

3-4. POWER BOARD

9

POWER board

1

screw

(+BVTP 3

×

8)

5

screw

(+BVTP 3

×

8

)

4

two screws

(+BVTP 3

×

8)

3

connector (CN902)

6

connector (CN904)

7

connector (CN903)

2

power sheet

8

power sheet

3-5. AMP BOARD

9

AMP board

2

wire (flat type)

(CN304)

3

wire (flat type)

(CN303)

7

two screws

(+BVTP 3

×

8)

6

two screws

(+BVTP 3

×

8)

1

two screws

(+BVTP 3

×

8)

5

connector (CNP301)

4

connector (CN302)

8

amp sheet

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

14

HCD-FC7

3-6. DVD BOARD, DC FAN

qj

DVD board

3

two screws

(+BVTP 3

×

8)

5

two screws

(+BVTP 3

×

8)

1

two screws

2

DC FAN

8

wire (flat type)(CN001)

9

wire (flat type)(CN004)

qa

wire (flat type)(CN003)

7

wire (flat type)(CN002)

qs

wire (flat type)(CN401)

0

connector (CN008

)

4

sheet

qd

sheet

6

power bracket

qf

sheet

qg

sheet

qh

sheet

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

15

HCD-FC7

3-7. CD MECHANISM DECK (CDM69-DVBU16)

2

two screws (BVTP 3

×

8)

1

two screws (BVTP 3

×

8)

7

CD mechanism dec

k

(CDM69-DVBU16)

3

4

two claws

6

wire (flat type)

(CN002)

5

wire (flat type)

(CN701)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

16

HCD-FC7

3-8. SELECTOR BOARD,VIDEO BOARD, LF BOARD

3

SELECTOR board

0

VIDEO board

qd

LF board

5

two screws

(+BTP 3

×

6)

4

two screws

(+BTP 3

×

6)

1

screw

(+BVTP 3

×

8)

qs

two screws (+BVTP 3

×

8)

9

two screws

(+BVTP 3

×

8)

8

wire (flat type)(CN203)

qa

connector (CN901)

7

connector (CN210)

2

connector (CN205

)

qf

sheet

6

md cover

3-9. AUDIO BOARD, S-VIDEO BOARD

0

tuner unit

8

S-VIDEO board

5

AUDIO board

1

four screws

(+BVTP 3

×

8)

6

two screws

(+BVTP 3

×

8)

9

two screws

(+BTP 3

×

6)

2

wire (flat type)(CN208)

3

wire (flat type)(CN201)

qd

wire (flat type)

qf

ferrite core

4

wire (flat type)(CN202)

7

connector (CN211)

chassis

qa

cord stopper

qs

power cord

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

17

HCD-FC7

3

boss

4

boss

5

boss

6

base unit

(DVBU16)

1

screw

(PTPWHM2.6

)

2

3-10. BASE UNIT (DVBU16)

3-11. PICK-UP UNIT (TDP022W)

6

flexible board

8

insulator

7

insulator

9

insulator

5

connector

(CN003)

2

step screw (M

)

1

step screw (M)

0

pick-up unit (TDP022W)

4

3

step screw (M)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

18

HCD-FC7

3-12. SW BOARD, BRACKET (TOP) ASSY

6

six screws

(BVTP2.6

×

8)

5

SW board (4)

4

SW board (3)

3

SW board (2)

2

SW board (1)

7

bracket (top) assy

1

four

screws

(BTP2.6

×

6)

3-13. RELAY BOARD

1

Remove five solders.

– bottom view –

RELAY board

4

connector

(CN703)

5

connector

(CN702)

2

four screws

(BVTP2.6

×

8)

6

connector

(CN710)

7

connector

(CN706)

8

connecto

r

(CN707)

9

connector

(CN708)

0

RELAY board

3

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

19

HCD-FC7

3-14. MOTOR (STOCKER) ASSY (STOCKER)(M761)

6

STOCKER MOTOR board

3

two screws

(BVTP2.6

×

8)

2

Remove two solders

5

connector

(CN761)

4

7

motor (stocker) assy

(stocker) (M761)

1

belt (stocker)

3-15. MOTOR (STOCKER) ASSY (ROLLER)(M781)

1

belt (roller)

4

ROLLER MOTOR boar

d

2

Remove two solders.

3

two screws

(BVTP2.6

×

8)

5

motor (stocker) assy

(roller) (M781)

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

20

HCD-FC7

3-16. MOTOR (STOCKER) ASSY (MODE)(M771)

1

Remove five solders

of rotary encoder.

2

Remove two solders

of motor (M771)

MODE MOTOR

board

3

two screws

(BVTP2.6

×

8)

4

MODE MOTOR board

5

belt (mode)

6

motor (stocker) ass

y

(mode) (M771)

3-17. RUBBER ROLLER (SLIDER) ASSY

qg

sub chassis

qf

screw

(BVTP2.6

×

8)

8

step screw

qs

step screw

5

step screw

9

tension

spring

(slider 2)

6

tension spring

(base slider 5)

3

tension spring

(base slider 5

)

1

step screw

0

rubber roller

(slider 4) assy

7

rubber roller

(slider 1) assy

4

rubber roller

(slider 5) assy

2

rubber roller

(slider S) assy

qa

rubber roller

(slider 2) assy

qd

rubber roller

(slider 1) assy

w

.

x

i

a

o

y

u

1

6

3

.

c

o

m

Q

3

7

6

3

1

5

1

5

0

9

2

8

9

4

2

9

8

T

E

L

1

3

9

4

2

9

6

5

1

3

9

2

8

9

4

2

9

8

0

5

1

5

1

3

6

7

3

Q

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Sony HCD-FC7 - System Components User manual

Popular Receiver manuals by other brands
