Sony STR-DN1040 Guide User manual

4-454-447-11(1) (GB-SI-CR-BS-SR-MK-AL)
STR-DN1040
Multi Channel
AV Receiver
Reference Guide GB
Referenčni priročnik SI
Referentni priručnik CR
Referentni vodič BS
Referentni vodič SR
Упатство на препораки MK
Udhëzuesi i referencës AL

2GB
To reduce the risk of fire or electric
shock, do not expose this apparatus
to rain or moisture.
To reduce the risk of fire, do not cover the
ventilation opening of the appliance with
newspapers, tablecloths, curtains, etc.
Do not expose the appliance to naked flame
sources (for example, lighted candles).
To reduce the risk of fire or electric shock, do
not expose this appliance to dripping or
splashing, do not place objects filled with
liquids, such as vases, on the appliance.
Do not install the appliance in a confined
space, such as a bookcase or built-in cabinet.
As the main plug is used to disconnect the unit
from the mains, connect the unit to an easily
accessible AC outlet. Should you notice an
abnormality in the unit, disconnect the main
plug from the AC outlet immediately.
Do not expose batteries or appliances with
battery-installed to excessive heat, such as
sunshine and fire.
The unit is not disconnected from the mains
as long as it is connected to the AC outlet, even
if the unit itself has been turned off.
Excessive sound pressure from earphones and
headphones can cause hearing loss.
This symbol is intended to
alert the user to the presence
of the Hot Surface that may be
hot if it is touched during the
normal operation.
This equipment has been tested and found to
comply with the limits set out in the EMC
Directive using a connection cable shorter
than 3 meters.
For customers in Europe
Disposal of Old
Electrical & Electronic
Equipment (Applicable
in the European Union
and other European
countries with separate
collection systems)
This symbol on the product or on its
packaging indicates that this product shall not
be treated as household waste. Instead it shall
be handed over to the applicable collection
point for the recycling of electrical and
electronic equipment. By ensuring this
product is disposed of correctly, you will help
prevent potential negative consequences for
the environment and human health, which
could otherwise be caused by inappropriate
waste handling of this product. The recycling
of materials will help to conserve natural
resources. For more detailed information
about recycling of this product, please contact
your local Civic Office, your household waste
disposal service or the shop where you
purchased the product.
Disposal of waste
batteries (applicable in
the European Union
and other European
countries with separate
collection systems)
This symbol on the battery or on the
packaging indicates that the battery provided
with this product shall not be treated as
household waste.
On certain batteries this symbol might be used
in combination with a chemical symbol. The
chemical symbols for mercury (Hg) or lead
(Pb) are added if the battery contains more
than 0.0005% mercury or 0.004% lead.
By ensuring these batteries are disposed of
correctly, you will help prevent potentially
negative consequences for the environment
and human health which could otherwise be
WARNING

3GB
caused by inappropriate waste handling of the
battery. The recycling of the materials will
help to conserve natural resources.
In case of products that for safety,
performance or data integrity reasons require
a permanent connection with an incorporated
battery, this battery should be replaced by
qualified service staff only.
To ensure that the battery will be treated
properly, hand over the product at end-of-life
to the applicable collection point for the
recycling of electrical and electronic
equipment.
For all other batteries, please view the section
on how to remove the battery from the
product safely. Hand the battery over to the
applicable collection point for the recycling of
waste batteries.
For more detailed information about
recycling of this product or battery, please
contact your local Civic Office, your
household waste disposal service or the shop
where you purchased the product.
Notice for customers: The
following information is only
applicable to equipment sold in
countries applying EU Directives.
This product has been manufactured by or on
behalf of Sony Corporation, 1-7-1 Konan
Minato-ku Tokyo, 108-0075 Japan. Inquiries
related to product compliance based on
European Union legislation shall be addressed
to the authorized representative, Sony
Deutschland GmbH, Hedelfinger Strasse 61,
70327 Stuttgart, Germany. For any service or
guarantee matters, please refer to the
addresses provided in the separate service of
guarantee documents.
Hereby, Sony Corp., declares that this
equipment is in compliance with the essential
requirements and other relevant provisions of
Directive 1999/5/EC.
For details, please access the following URL:
http://www.compliance.sony.de/
This receiver incorporates Dolby* Digital and
Pro Logic Surround and the DTS** Digital
Surround System.
* Manufactured under license from Dolby
Laboratories. Dolby, Pro Logic, Surround
EX, and the double-D symbol are
trademarks of Dolby Laboratories.
** Manufactured under license under U.S.
Patent Nos: 5,956,674; 5,974,380;
6,226,616; 6,487,535; 7,212,872; 7,333,929;
7,392,195; 7,272,567 & other U.S. and
worldwide patents issued & pending.
DTS-HD, the Symbol, & DTS-HD and the
Symbol together are registered trademarks
& DTS-HD Master Audio is a trademark of
DTS, Inc. Product includes software.
© DTS, Inc. All Rights Reserved.
This receiver incorporates High-Definition
Multimedia Interface (HDMI™) technology.
The terms HDMI and HDMI High-Definition
Multimedia Interface, and the HDMI Logo are
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
AirPlay, iPhone, iPod, iPod classic, iPod nano,
and iPod touch are trademarks of Apple Inc.,
registered in the U.S. and other countries.
All other trademarks and registered
trademarks are of their respective holders. In
this manual, ™and ®marks are not specified.
“Made for iPod” and “Made for iPhone” mean
that an electronic accessory has been designed
to connect specifically to iPod or iPhone,
respectively, and has been certified by the
developer to meet Apple performance
standards.
On copyrights

4GB
Apple is not responsible for the operation of
this device or its compliance with safety and
regulatory standards. Please note that the use
of this accessory with iPod or iPhone may
affect wireless performance.
DLNA™, the DLNA Logo and DLNA
CERTIFIED™are trademarks, service marks,
or certification marks of the Digital Living
Network Alliance.
“Sony Entertainment Network” logo and
“Sony Entertainment Network” are
trademarks of Sony Corporation.
Wake-on-LAN is a trademark of International
Business Machines Corporation in the United
States.
Windows and the Windows logo are either
registered trademarks or trademarks of
Microsoft Corporation in the United States
and/or other countries.
This product is protected by certain
intellectual property rights of Microsoft
Corporation. Use or distribution of such
technology outside of this product is
prohibited without a license from Microsoft
or an authorized Microsoft subsidiary.
MPEG Layer-3 audio coding technology and
patents licensed from Fraunhofer IIS and
Thomson.
“x.v.Color (x.v.Colour)” and “x.v.Color
(x.v.Colour)” logo are trademarks of Sony
Corporation.
“BRAVIA” is a trademark of Sony
Corporation.
“PlayStation” is a registered trademark of
Sony Computer Entertainment Inc.
“WALKMAN” and “WALKMAN” logo are
registered trademarks of Sony Corporation.
MICROVAULT is a trademark of Sony
Corporation.
VAIO and VAIO Media are registered
trademarks of Sony Corporation.
PARTY STREAMING and PARTY
STREAMING logo are trademarks of Sony
Corporation.
The Wi-Fi CERTIFIED Logo is a certification
mark of the Wi-Fi Alliance.
MHL, Mobile High-Definition Link and the
MHL Logo are trademarks or registered
trademarks of MHL Licensing, LLC.
InstaPrevue™is a trademark or registered
trademark of Silicon Image, Inc. in the United
States and other countries.
FLAC Decoder
Copyright (C)
2000,2001,2002,2003,2004,2005,2006,2007
Josh Coalson
Redistribution and use in source and binary
forms, with or without modification, are
permitted provided that the following
conditions are met:
– Redistributions of source code must retain
the above copyright notice, this list of
conditions and the following disclaimer.
– Redistributions in binary form must
reproduce the above copyright notice, this
list of conditions and the following
disclaimer in the documentation and/or
other materials provided with the
distribution.
– Neither the name of the Xiph.org
Foundation nor the names of its
contributors may be used to endorse or
promote products derived from this
software without specific prior written
permission.
THIS SOFTWARE IS PROVIDED BY THE
COPYRIGHT HOLDERS AND
CONTRIBUTORS “AS IS” AND ANY
EXPRESS OR IMPLIED WARRANTIES,
INCLUDING, BUT NOT LIMITED TO, THE
IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR
A PARTICULAR PURPOSE ARE
DISCLAIMED. IN NO EVENT SHALL THE
FOUNDATION OR CONTRIBUTORS BE
LIABLE FOR ANY DIRECT, INDIRECT,

5GB
INCIDENTAL, SPECIAL, EXEMPLARY, OR
CONSEQUENTIAL DAMAGES
(INCLUDING, BUT NOT LIMITED TO,
PROCUREMENT OF SUBSTITUTE GOODS
OR SERVICES; LOSS OF USE, DATA, OR
PROFITS; OR BUSINESS INTERRUPTION)
HOWEVER CAUSED AND ON ANY
THEORY OF LIABILITY, WHETHER IN
CONTRACT, STRICT LIABILITY, OR
TORT (INCLUDING NEGLIGENCE OR
OTHERWISE) ARISING IN ANY WAY OUT
OF THE USE OF THIS SOFTWARE, EVEN
IF ADVISED OF THE POSSIBILITY OF
SUCH DAMAGE.
Precautions
On safety
Should any solid object or liquid fall into
the cabinet, unplug the receiver and have it
checked by qualified personnel before
operating it any further.
On power sources
• Before operating the receiver, check that
the operating voltage is identical with
your local power supply.
The operating voltage is indicated on the
nameplate on the back of the receiver.
• The unit is not disconnected from the AC
power source (mains) as long as it is
connected to the wall outlet, even if the
unit itself has been turned off.
• If you are not going to use the receiver for
a long time, be sure to disconnect the
receiver from the wall outlet. To
disconnect the AC power cord (mains
lead), grasp the plug itself; never pull the
cord.
• The AC power cord (mains lead) must be
changed only at a qualified service shop.
On heat buildup
Although the receiver heats up during
operation, this is not a malfunction. If you
continuously use this receiver at a large
volume, the cabinet temperature of the top,
side and bottom rises considerably. To
avoid burning yourself, do not touch the
cabinet.
On placement
• Place the receiver in a location with
adequate ventilation to prevent heat
buildup and prolong the life of the
receiver.
• Do not place the receiver near heat
sources, or in a place subject to direct
sunlight, excessive dust, or mechanical
shock.
• Do not place anything on top of the
cabinet that might block the ventilation
holes and cause malfunctions.
• Do not place the receiver near equipment
such as a TV, VCR, or tape deck. (If the
receiver is being used in combination
with a TV, VCR, or tape deck, and is
placed too close to that equipment, noise
may result, and picture quality may
suffer. This is especially likely when using
an indoor antenna (aerial). Therefore, we
recommend using an outdoor antenna
(aerial).)
• Use caution when placing the receiver on
surfaces that have been specially treated
(with wax, oil, polish, etc.) as staining or
discoloration of the surface may result.
On operation
Before connecting other equipment, be
sure to turn off and unplug the receiver.
On cleaning
Clean the cabinet, panel, and controls with
a soft cloth slightly moistened with a mild
detergent solution. Do not use any type of
abrasive pad, scouring powder, or solvent,
such as alcohol or benzine.

6GB
If you have any questions or problems
concerning your receiver, please consult
your nearest Sony dealer.
Specifications
Amplifier section
Minimum RMS Output Power1)
(6 ohms, 20 Hz – 20 kHz, THD 0.09%)
100 W + 100 W
Stereo Mode Output Power1)
(6 ohms, 1 kHz, THD 1%)
120 W + 120 W
Surround Mode Output Power1) 2)
(6 ohms, 1 kHz, THD 0.9%)
165 W per channel
1) Measured under the following conditions:
Power requirements: 230 V AC, 50 Hz
2) Reference power output for front, center,
surround, surround back and front high
speakers. Depending on the sound field settings
and the source, there may be no sound output.
Frequency response
Analog
10 Hz – 100 kHz, +0.5/–2 dB (with
sound field and equalizer bypassed)
Input
Analog
Sensitivity: 500 mV/50 kilohms
S/N3): 105 dB (A, 500 mV4))
Digital (Coaxial)
Impedance: 75 ohms
S/N: 100 dB (A, 20 kHz LPF)
Digital (Optical)
S/N: 100 dB (A, 20 kHz LPF)
Output (Analog)
ZONE 2
Voltage: 500 mV/1 kilohm
SUBWOOFER
Voltage: 2 V/1 kilohm
Equalizer
Gain levels
±10dB,1dBstep
3) INPUT SHORT (with sound field andequalizer
bypassed).
4) Weighted network, input level.
FM tuner section
Tuning range
87.5 MHz – 108.0 MHz (50 kHz step)
Antenna (aerial)
FM wire antenna (aerial)
Antenna (aerial) terminals
75 ohms, unbalanced
AM tuner section
Tuning range
531 kHz – 1,602 kHz (9 kHz step)
Antenna (aerial)
Loop antenna (aerial)
Video section
Inputs/Outputs
Video:
1 Vp-p, 75 ohms
COMPONENT VIDEO:
Y: 1 Vp-p, 75 ohms
PB: 0.7 Vp-p, 75 ohms
PR: 0.7 Vp-p, 75 ohms
80 MHz HD Pass Through

7GB
HDMI Video
Input/Output (HDMI Repeater block)
* These formats are supported by MHL when you connect a MHL-compatible source device to the
HDMI/MHL (VIDEO 2 IN) jack.
MHL section
Supported MHL version
Incorporates MHL 2
Maximum current
900 mA
iPod/iPhone section
DC 5V 1.0 A MAX
USB section
Supported format*
MP3 (MPEG 1 Audio Layer-3):
32 kbps – 320 kbps, VBR
AAC:
16 kbps – 320 kbps, CBR, VBR
WMA9 Standard:
40 kbps – 320 kbps, CBR, VBR
WAV:
8 kHz – 192 kHz, 16 bit PCM
8 kHz – 192 kHz, 24 bit PCM
Format 2D
3D
Frame
packing
Side-by-Side
(Half)
Over-Under
(Top-and-Bottom)
4096 × 2160p @ 23.98/24 Hz a–– –
3840 × 2160p @ 29.97/30 Hz a–– –
3840 × 2160p @ 25 Hz a–– –
3840 × 2160p @ 23.98/24 Hz a–– –
1920 × 1080p @ 59.94/60 Hz a–aa
1920 × 1080p @ 50 Hz a–aa
1920 × 1080p @ 29.97/30 Hz a*aa*a*
1920 × 1080p @ 25 Hz a*aa*a*
1920 × 1080p @ 23.98/24 Hz a*aa*a*
1920 × 1080i @ 59.94/60 Hz a*aa*a*
1920 × 1080i @ 50 Hz a*aa*a*
1280 × 720p @ 59.94/60 Hz a*aa*a*
1280 × 720p @ 50 Hz a*aa*a*
1280 × 720p @ 29.97/30 Hz a*aa*a*
1280 × 720p @ 23.98/24 Hz a*aa*a*
720 × 480p @ 59.94/60 Hz a*– – –
720 × 576p @ 50 Hz a*– – –
640 × 480p @ 59.94/60 Hz a*– – –

8GB
FLAC:
8 kHz – 192 kHz, 16 bit FLAC
44.1 kHz – 192 kHz, 24 bit FLAC
* Compatibility with all encoding/writing
software, recording devices and recording
media cannot be guaranteed.
Transfer speed
High-speed
Supported USB device
Mass Storage Class
Maximum current
500 mA
NETWORK section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
Compatible standards:
IEEE 802.11 b/g
Security:
WEP 64 bit, WEP 128 bit, WPA/
WPA2-PSK (AES), WPA/WPA2-
PSK (TKIP)
Radio frequency:
2.4 GHz
General
Power requirements
230 VAC, 50/60 Hz
Power consumption
240 W
Power consumption (during standby mode)
0.3 W (When “Control for HDMI”, “Pass
Through”, and “Network Standby” are
set to “Off”, and the receiver in zone 2 is
turned off.)
Dimensions (width/height/depth) (Approx.)
430 mm × 172 mm × 329.4 mm
including projecting parts and controls
Mass (Approx.)
10.0 kg
Design and specifications are subject to
change without notice.

9GB
END-USER LICENSE AGREEMENT FOR SONY SOFTWARE
You should carefully read the following agreement before using the SONY SOFTWARE (defined
below). Using the SONY SOFTWARE indicates your acceptance of the agreement. If you do not agree
with it, you are not authorized to use the SONY SOFTWARE.
IMPORTANT - READ CAREFULLY: This End-User License Agreement (“EULA”) is a legal
agreement between you and Sony Corporation (“SONY”), the manufacturer of your Sony hardware
device (the “PRODUCT”) and the licensor of the SONY SOFTWARE. All Sony software and third party
software (other than such software subject to its own separate license) included with your PRODUCT
and any updates and upgrades thereto shall be referred to herein as the “SONY SOFTWARE”. You may
use the SONY SOFTWARE only with the PRODUCT.
By using the SONY SOFTWARE, you agree to be bound by the terms of this EULA. If you do not agree
to the terms of this EULA, SONY is unwilling to license the SONY SOFTWARE to you. In such event,
you should not use the SONY SOFTWARE.
SONY SOFTWARE LICENSE
The SONY SOFTWARE is protected by copyright laws and international copyright treaties, as well as
other intellectual property laws and treaties. The SONY SOFTWARE is licensed, not sold.
GRANT OF LICENSE
All title, copyright and other rights in and to the SONY SOFTWARE are owned by SONY or its
licensors. This EULA grants you the right to use the SONY SOFTWARE for personal use only.
DESCRIPTION OF REQUIREMENTS, RESTRICTIONS, RIGHTS AND LIMITATIONS
Limitations. You may not copy, modify, reverse engineer, decompile or disassemble the SONY
SOFTWARE in whole or in part.
Separation of Components. The SONY SOFTWARE is licensed as a single product. Its component
parts may not be separated.
Use on Single PRODUCT. The SONY SOFTWARE may only be used with a single PRODUCT.
Rental. You may not rent or lease the SONY SOFTWARE.
Software Transfer. You may permanently transfer all of your rights under this EULA only when the
SONY SOFTWARE is transferred together with and as part of the PRODUCT, provided that you retain
no copies, transfer all of the SONY SOFTWARE (including but not limited to all copies, component
parts, media, instruction manuals, other printed materials, electronic documents, recovery disks and
this EULA) and the recipient agrees to the terms of this EULA.
Termination. Without prejudice to any other rights, SONY may terminate this EULA if you fail to
comply with the terms of this EULA. In such event, when requested by SONY, you must send the
PRODUCT to an address designated by SONY, and SONY will send back the PRODUCT to you as
soon as practicable after the SONY SOFTWARE has been deleted from the PRODUCT.
Confidentiality. You agree to keep confidential information contained in SONY SOFTWARE which is
not publicly known and not to disclose such information to others without SONY’s prior written
approval.
HIGH RISK ACTIVITIES
The SONY SOFTWARE is not fault-tolerant and is not designed, manufactured or intended for use or
resale as on-line control equipment in hazardous environments requiring fail-safe performance, such as
in the operation of nuclear facilities, aircraft navigation or communication systems, air traffic control,
direct life support machines or weapons systems, in which the failure of the SONY SOFTWARE could
lead to death, personal injury or severe physical or environmental damage (“High Risk Activities”).
SONY and its suppliers specifically disclaim any express or implied warranty of fitness for High Risk
Activities.

10GB
EXCLUSION OF WARRANTY ON SONYSOFTWARE
You expressly acknowledge and agree that use of the SONY SOFTWARE is at your sole risk. The SONY
SOFTWARE is provided “AS IS” and without warranty of any kind, and SONY, its vendors and SONY’s
licensors (for purposes of this SECTION only, collectively, “SONY”) EXPRESSLY DISCLAIM ALL
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. SONY
DOES NOT WARRANT THAT THE FUNCTIONS CONTAINED IN THE SONY SOFTWARE ARE
FREE FROM ERRORS OR BUGS OR WILL MEET YOUR REQUIREMENT, AND SONY DOES NOT
WARRANT THAT THE OPERATION OF THE SONY SOFTWARE WILL BE CORRECTED.
FURTHERMORE, SONY DOES NOT WARRANT OR MAKE ANY REPRESENTATIONS
REGARDING THE USE OR THE RESULTS OF THE USE OF THE SONY SOFTWARE IN TERMS
OF ITS CORRECTNESS, ACCURACY, RELIABILITY OR OTHERWISE. NO ORAL OR WRITTEN
INFORMATION OR ADVICE GIVEN BY SONY OR A SONY AUTHORIZED REPRESENTATIVE
SHALL CREATE A WARRANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS
WARRANTY. SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OF IMPLIED
WARRANTIES, IN WHICH CASE THE ABOVE EXCLUSION WOULD NOT APPLY TO YOU.
Without limiting any of the foregoing, it is specifically provided that the SONY SOFTWARE is not
designed or intended for use on any product other than the PRODUCT. SONY provides no warranty
that any product, software, content or data created by you or a third party will not be damaged by the
SONY SOFTWARE.
LIMITATION OF LIABILITY
SONY, ITS SUPPLIERS AND SONY’S LICENSOR’S (for purposes of this SECTION ONLY,
collectively, “SONY”) SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES RELATING TO THE SONY SOFTWARE ARISING FROM OR BASED ON BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY, BREACH OF CONTRACT, NEGLIGENCE, STRICT
LIABILITY OR ANY OTHER LEGAL THEORY. SUCH DAMAGES INCLUDE, BUT ARE NOT
LIMITED TO, LOSS OF PROFITS, LOSS OF REVENUE, LOSS OF DATA, LOSS OF USE OF THE
PRODUCT OR ANY ASSOCIATED EQUIPMENT, DOWN TIME AND USER’S TIME,
REGARDLESS OF WHETHER SONY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. IN ANY CASE, SONY’S ENTIRE LIABILITY TO YOU UNDER ANY PROVISION OF
THIS EULA SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID ALLOCABLE TO THE
SONY SOFTWARE.
EXPORTS
If you use or transfer the SONY SOFTWARE in or to a country other than your country of residence,
you shall comply with applicable laws and regulations relating to exports, imports and customs.
GOVERNING LAW
This EULA shall be construed, governed, interpreted and applied in accordance with the laws of Japan,
without regards to any conflict of laws provisions. Any dispute arising out of this EULA shall be subject
to the exclusive venue and jurisdiction of the courts in Tokyo, Japan, and you and SONY hereby
consent to the venue and jurisdiction of such courts. YOU AND SONY WAIVE THE RIGHT TO
TRIAL BY JURY WITH RESPECT TO ANY MATTERS ARISING UNDER OR RELATING TO THIS
EULA.
SEVERABILITY
If any part of this EULA is held invalid or unenforceable, other parts will remain valid.
Should you have any questions in connection with this EULA or the limited warranty provided
hereunder, you may contact SONY by writing to SONY at the designated contact address mentioned in
the warranty card included in the product package.
