XC-HR Series
B/W Progressive Scan Cameras
SONY52305_XCHR 12/8/06 2:23 PM Page 3

For Demanding Applications That
Require High Frame Rates and
High Resolution, Choose Sony's
XC-HR Series of Progressive Scan
Cameras
Joining Sony's popular XC-HR Camera Series is the new
high-speed/high-resolution XC-HR90. This new camera
incorporates a 1/3“ Progressive Scan IT CCD with SXGA
resolution of 1280 x 960 pixels at a selectable frame rate
of 30 or 15 full frames per second (fps). The XC-HR90
achieves high-rate scanning up to 204.8 fps with 60
effective lines, selectable from 16 vertical divisions.
Camera settings can be made via the camera’s RS-232C
interface (12-pin connector).
Sony's complete line-up of high speed cameras include
the XC-HR50, XC-HR57, XC-HR58, and XC-HR70. All of these
cameras feature the same compact body enabling them to
be easily interchanged to meet your various application
requirements and are ideal for space restricted areas.
The XC-HR57 and XC-HR58 cameras both incorporate
a 1/2“ Progressive Scan IT CCD. The XC-HR57 features
VGA resolution of 648 x 494 pixels at 60 full fps, and
the XC-HR58 features SVGA resolution of 767 x 580
pixels at 50 full fps. Both the XC-HR50 and XC-HR70
cameras incorporate a 1/3“ Progressive Scan IT CCD.
The XC-HR50 features VGA resolution of 648 x 494 pixels
at 60 full fps, and the XC-HR70 provides XGA resolution
of 1024 x 768 pixels at 30 full fps.
In addition, the XC-HR camera series has a high-rate
scanning function that increases their vertical scanning
frequency so that images can be captured from
120 to 240 fps depending on the camera model.
Combining high-resolution and high-speed image
capture capabilities in a compact, robust body, Sony's
XC-HR Camera Series are ideal for demanding
applications such as semiconductor production and
high-speed assembly lines.
COMMON FEATURES
High-Resolution Image Capturing
High-Rate Scanning
Synchronization: Internal/External (HD/VD)
Vertical Binning Function
By combining the image data of every two lines
vertically, these cameras can increase the frame
rate, which minimizes image processing time.
External Trigger Shutter
Allows accurate image capture of fast-moving objects
through shutter speeds of 1/4 to 1/100,000 sec.
High Shock and Vibration Tolerance
RoHS Compliance
Compact, Lightweight Body
C-mount
REAR PANELS
XC-HR50/HR57/HR58/HR70XC-HR90
q
q
w
w
e
r
te
y
q 12-pin connector
w Shutter speed/Mode setting DIP switch
e Manual Gain adjustment
r HD/VD signal I/O switch
t 75^ termination switch
y Mode setting DIP switch
(75^ termination, HD/VD signal I/O, 30 fps/15 fps,
RS-232C ON/OFF)
SONY52305_XCHR 12/8/06 2:23 PM Page 4

DIMENSIONS
1 3/16 (29)
19/32 (14.5)
1/2(12)
1 3/16 (29)
2-M2 depth 3
4-M2 depth 3
3-M3 depth 3
1/2 (12)
1/2(12)
19/32 (15)
21/32 (16.5)
15/16 (23.7)
7/8(22)
1 7/16 (42)
1 3/16 (30)
13/16 (20)
XC-HR50/HR57/HR58/HR70
SPECIFIC CAMERA KEY FEATURES
PIN ASSIGNMENT
XC-HR90
●1/3-type progressive scan CCD
●SXGA resolution (1,280 x 960 pixels) image capturing at a speed of 30 or
15 full fps.
●High-rate scanning
- Readout of center 240 lines at 95.8 fps (set using dip switches)
- Readout of 60 effective lines selectable from 16 vertical divisions at up
to 204.8 fps.
●Horizontal resolution: 960 TV lines
●Partial scan controlled by VD pulse length
●Minimum illumination: 1.0 lx at F1.4
●High S/N ratio: 56 dB
●Electronic shutter: 1/100 to 1/100,000 sec.
XC-HR50
●1/3-type progressive scan CCD
●VGA resolution (648 x 494 pixels) image capturing at a speed of 60 full fps.
●High-rate scanning of up to 240 partial fps.
(100 effective lines at restart/reset ON, binning OFF)
●Horizontal resolution: 500 TV lines
●Partial scan controlled by VD pulse length
●Minimum illumination: 1.0 lx at F1.4
●High S/N ratio: 58 dB
●Electronic shutter: 1/100 to 1/30,000 sec.
XC-HR57
●1/2-type progressive scan CCD
●VGA resolution (648 x 494 pixels) image capturing at a speed of 60 full fps.
●High-rate scanning of up to 240 partial fps.
(100 effective lines at restart/reset ON, binning OFF)
●Horizontal resolution: 500 TV lines
●Partial scan controlled by VD pulse length
●Minimum illumination: 1.0 lx at F1.4
●High S/N ratio: 58 dB
●Electronic shutter: 1/100 to 1/30,000 sec.
XC-HR58
●1/2-type progressive scan CCD
●High SVGA resolution (767 x 580 pixels) image capturing at a speed of
50 full fps.
●High-rate scanning of up to 200 partial fps.
(90 effective lines at restart/reset ON, binning OFF)
●Horizontal resolution: 600 TV lines
●Partial scan controlled by VD pulse length
●Minimum illumination: 1.0 lx at F1.4
●High S/N ratio: 56 dB
●Electronic shutter: 1/100 to 1/30,000 sec.
XC-HR70
●1/3-type progressive scan CCD
●XGA resolution (1,024 x 768 pixels) image capturing at a speed of 29 full fps.
●High-rate scanning of up to 120 partial fps.
(152 effective lines at restart/reset ON, binning OFF)
●Horizontal resolution: 800 TV lines
●Partial scan controlled by VD pulse length
●Minimum illumination: 1.0 lx at F1.8
●High S/N ratio: 56 dB
●Electronic shutter: 1/100 to 1/20,000 sec.
1 3/16 (29)
19/32 (14.5)
1/8(2.5)
1 3/16 (29)
1/2(12)
2-M2 depth 3
4-M3 depth 4
1/2(12) 2 1/2(63.5)
3 (75.5)
19/32 (15)
1/8(3)
1 13/16 (44.5)
ø1 1/8(27.6)
13/16 (20) ø1 1/8(27.3)
XC-HR90
Unit: inch (mm)
Unit: inch (mm)
XC-HR50/HR57/HR58/HR70
Pin No. Camera sync output External sync mode Restart/Reset mode External trigger shutter mode
1 Ground
2 +12 V DC
3 Video output (Ground)
4 Video output (Signal)
5 HD output (Ground) HD input (Ground)
6 HD output (Signal) HD input (Signal)
7 VD output (Signal) VD intput (Signal) Reset (Signal) VD intput (Signal)
8–
9–
10 – – – WEN output (Signal)
11 – – – Trigger pulse intput (Signal)
12 VD output (Ground) VD input (Ground) Reset (Ground) Reset (Ground)
XC-HR90
Pin No. Camera sync output External sync mode Restart/Reset mode External trigger shutter mode
1 Ground
2 +12 V DC
3 Video output (Ground)
4 Video output (Signal)
5 HD output (Ground) HD input (Ground)
6 HD output (Signal) HD input (Signal)
7 VD output (Signal) VD intput (Signal) Reset (Signal) VD intput (Signal)
8 Rx (RS-232C serial communication)
9 Tx (RS-232C serial communication)
10 – – – WEN output (Signal)
11 – – – Trigger pulse intput (Signal)
12 VD output (Ground) VD input (Ground) Reset (Ground) Reset (Ground)
SONY52305_XCHR 12/8/06 2:23 PM Page 5

© 2006 Sony Corporation. All rights reserved.
Reproduction in whole or in part without written permission is prohibited.
Design, features, and specifications are subject to change without notice.
All non-metric weights and measurements are approximate.
Sony is a registered trademark of Sony Corporation.
SPECIFICATIONS
ACCESSORIES
XC-HR50 XC-HR57 XC-HR58 XC-HR70 XC-HR90
Camera adaptor DC-700/700CE
12-pin camera cable CCXC-12P02N (2 m)/12P05N (5 m)/12P10N (10 m)/12P25N (25 m)
Tripod adaptor VCT-333I VCT-55I
IS-1154
MK10384V1 Printed in USA (11/06)
Sony Electronics Inc.
1 Sony Drive
Park Ridge, NJ 07656
www.sony.com/videocamera
XC-HR50 XC-HR57 XC-HR58 XC-HR70 XC-HR90
Image device 1/3-type progressive 1/2-type progressive scan IT CCD 1/3-type progressive scan IT CCD
scan IT CCD
Effective picture elements 659 (H) x 494 (V) 782 (H) x 582 (V) 1,034 (H) x 779 (V) 1296 (H) x 966 (V)
Effective lines 648 (H) x 494 (V) - VGA 767 (H) x 580 (V) - SVGA 1,024 (H) x 768 (V) - XGA 1280 (H) x 960 (V) - SXGA
Cell size 7.4 μm (H) x 7.4 μm (V) 9.9 μm (H) x 9.9 μm (V) 8.3 μm (H) x 8.3 μm (V) 4.65 μm (H) x 4.65 μm (V) 3.75 μm (H) x 3.75 μm (V)
Scanning system Progressive scan
Output signal frequency 59.94 Hz (normal mode), 50.0 Hz (normal mode), 29.2 Hz (normal mode), 30.0 Hz (nomal, 30 fps mode)
119.88 Hz (binning mode) 99.8 Hz (binning mode) 58.4 Hz (binning mode) 15.0 Hz (nomal, 15 fps mode)
54.1 Hz (binning, 30 fps mode)
30.0Hz (binning, 15 fps mode)
Lens mount C mount
Flange back 17.526 mm
Sync system Internal/External (auto)
External sync signal HD/VD (2 to 5 Vp-p 75 ^) HD/VD (2.5 to 5 Vp-p 75 Ω)
Jitter Less than 20 ns
Video output 1.0 Vp-p, sync negative, 75 ^, unbalanced
Horizontal resolution 500 TV lines 600 TV lines 800 TV lines 960 TV lines
Sensitivity 400 lx F 5.6 (γ= OFF, FIX GAIN (0dB))
Minimum illumination 1lx (F 1.4, γ= OFF, GAIN +18dB) 1lx (F 1.8, γ= OFF, GAIN +18dB) 1lx (F 1.4, γ= OFF, GAIN +18dB)
S/N ratio 58 dB (0 dB GAIN) 56 dB (0 dB GAIN)
Gain Manual (0 to 18dB)/FIX (0dB) (adjustable on rear panel) Manual (0 to +18dB)/FIX (0dB)
(adjustable on rear panel or via RS-232C)
Gamma OFF (fixed)
White clip 820 mV ±70 mV (F1.4, FIX GAIN (0dB)) 820 mV ±70 mV (F1.8, FIX GAIN (0dB))
Shutter Normal shutter, Restart/Reset(R/R), External trigger shutter (Mode 1/Mode 2)
Normal shutter speed 1/100, 1/125, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000, 1/15,000, 1/30,000 s 1/100, 1/125, 1/250, 1/500, 1/1,000, 1/100, 1/125, 1/250, 1/500, 1/1,000,
1/2,000, 1/4,000, 1/10,000, 1/2,000, 1/4,000, 1/10,000, 1/25,000,
1/20,000 s 1/50,000, 1/100,000 s
External trigger shutter speed DIP switch settings: 1/100, 1/125, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000, 1/25,000, 1/50,000, 1/100,000 s
Trigger pulse width settings: 1/4 to 1/100,000 s
External trigger Polarity: +, Width: 2 µs to 250ms, Input impedance: 10 kΩor more (H: +2 to +5.0V, L: 0 to 0.6V) Polarity: +, Width: 2 µs to 250ms,
Input impedance: 10 kΩor more
(H: +2.5 to +5.0V, L: 0 to 0.6V)
High-rate scanning R/R mode R/R mode R/R mode Readout of center 480 lines at 56 fps,
binning off: max 240 fps binning off: max 200 fps binning off: max 120 fps Readout of center 240 lines at 95.8 fps
(effective lines: 102 lines) (effective lines: 111 lines) (effective lines: 152 lines) (settable using DIP switches)
binning on: max 362 fps binning on: max 300 fps binning on: max 180 fps
(effective lines: 59 lines) (effective lines: 59 lines) (effective lines: 89 lines)
External trigger shutter mode (MODE 1) External trigger shutter mode (MODE 1) External trigger shutter mode (MODE 1) Readout of 60 effective lines selectable from
binning off: max 240 fps binning off: max 200 fps binning off: max 120 fps 16 vertical divisions at max. 204.8 fps
(effective lines: 100 lines) (effective lines: 109 lines) (effective lines: 153 lines) (settable via RS-232C)
binning on: max 362 fps binning on: max 300 fps binning on: max 180 fps
(effective lines: 57 lines) (effective lines: 57 lines) (effective lines: 90 lines)
Power requirements DC 12 V (+10.5 V to +15 V)
Power consumption 1.8 W 2.0 W 2.8 W
Dimensions 1 3/16 x 1 3/16 x 1 3/16 inches (29 (W) x 29 (H) x 30 (D) mm) (excluding protrusions) 1 3/16 x 1 3/16 x 2 1/2inches
(29 (W) x 29 (H) x 63.5 (D) mm)
(excluding protrusions)
Weight 1.8 oz (50 g) 2.8 oz (80 g)
Operating temperature 23 to 113 °F (-5 to 45 °C)
Storage temperature -22 to 140 °F (-30 to 60 °C)
Operating humidity 20 to 80% (no condensation)
Storage humidity 20 to 95% (no condensation)
Vibration resistance 10 G (20 Hz to 200 Hz)
Shock resistance 70 G
Supplied accessories Lens mount cap (1), Operating instructions (1)
