Operating

Instructions

STR-DE425

STR-DE325

ET

WARNING

To

prevent

fire

or

shock

hazard,

do

not

expose

the

unit

to

rain

or

moisture.

00

NOT

REMOVE

COVER

(OR

BACK

NO

USER-SERVICEABLE

PARTS

INSIDE

REFER

BERVICANG

TO

QUALIFIED

SERVICE

PERSONNEL.

This

symbol

is

intended

to

alert

the

user

to

the

presence

of

uninsulated

“dangerous

voltage”

within

the

product’s

enclosure

that

may

be

of

sufficient

magnitude

to

constitute

a

risk

of

electric

shock

to

persons.

A

This

symbol

is

intended

to

alert

the

user

to

the

presence

of

important

operating

and

maintenance

(servicing)

instructions

in

the

literature

accompanying

the

appliance.

IMPORTANT

This

equipment

has

been

tested

and

found

to

comply

with

the

limits

for

a

Class

B

digital

device,

pursuant

to

Part

15

of

the

FCC

Rules.

These

limits

are

designed

to

provide

reasonable

protection

against

harmrul

interference

in

a

residential

installation.

This

equipment

generates,

uses,

and

can

radiate

radio

frequency

energy

and.

if

not

installed

and

used

in

accordance

with

the

instructions,

may

cause

harmful

interference

to

radio

communications.

However,

there

is

no

guarantee

that

interference

will

not

occur

in

a

particular

installation.

If

this

equipment

does

cause

harmful

interference

to

radio

or

television

reception,

which

can

be

determined

bv

turning

the

equipment

off

and

on,

the

user

is

encouraged

to

try

to

correct

the

interference

by

one

or

more

of

the

following

measures:

-

Reorient

or

relocate

the

receiving

antenna.

-

Increase

the

separation

between

the

equipment

and

receiver.

-

Connect

the

equipment

into

an

outlet

on

a

circuit

different

from

that

to

sWhich

the

receiver

is

connected.

-

Consult

the

dealer

or

an

experienced

radio/TV

technician

for

help.

CAUTION

You

are

cautioned

that

any

change

or

modifications

not

expressly

approved

in

this

manual

could

void

your

authority

to

operate

this

equipment.

Note

to

CATV

system

installer

This

reminder

is

provided

to

call

the

CATV

system

installer’s

attention

to

Article

820-40

of

the

NEC

that

provides

guidelines

for

proper

grounding

and,

in

particular,

specifies

that

the

cable

ground

shall

be

connected

to

the

grounding

system

of

the

building,

as

close

to

the

point

of

cable

entry

as

practical.

Owner's

record

The

model

and

serial

numbers

are

located

on

the

rear

of

the

unit.

Record

the

serial

number

in

the

space

provided

below.

Refer

to

them

whenever

you

call

upon

your

Sony

dealer

regarding

this

product.

Model

No.

STR-DE425/STR-DE325

Serial

No.

ee

aE

eee

Precautions

On

safety

*

Should

any

solid

object

or

liquid

fall

into

the

cabinet,

unplug

the

receiver

and

have

it

checked

by

qualified

personnel

before

operating

it

anv

further.

On

power

sources

*

Before

operating

the

receiver,

check

that

the

operating

voltage

is

identical

with

your

local

power

supply.

The

operating

voltage

is

indicated

on

the

nameplate

at

the

rear

of

the

receiver.

*

The

receiver

is

not

disconnected

from

the

AC

power

source

(MAINS)

as

long

as

it

is

connected

to

the

wall

outlet,

even

if

the

receiver

itself

has

been

turned

off.

*

If

you

are

not

going

to

use

the

receiver

for

a

long

time,

be

sure

to

disconnect

the

receiver

from

the

wail

outlet.

To

disconnect

the

AC

power

cord,

grasp

the

plug

itself;

never

pull

the

cord.

¢

One

blade

of

the

plug

is

wider

than

the

other

for

the

purpose

of

safety

and

will

fit

into

the

wall

outlet

only

one

way.

If

you

are

unable

to

insert

the

plug

fully

into

the

outlet,

contact

your

dealer.

(US

model

only)

*

Should

the

AC

power

cord

need

to

be

changed,

have

it

done

at

a

qualified

service

shop

only.

On

placement

¢

Place

the

receiver

in

a

location

with

adequate

ventilation

to

prevent

heat

build-up

and

prolong

the

life

of

the

receiver.

*

Do

not

place

the

receiver

near

heat

sources,

or

in

a

place

subject

to

direct

sunlight,

excessive

dust

or

mechanical

shock.

*

Do

not

place

anything

on

top

of

the

cabinet

that

might

block

the

ventilation

holes

and

cause

malfunctions.

On

operation

*

Before

connecting

other

components,

be

sure

to

turn

off

and

unplug

the

receiver.

On

cleaning

*

Clean

the

cabinet,

panel

and

controls

with

a

soft

cloth

slightly

moistened

with

a

mild

detergent

solution.

Do

not

use

any

tvpe

of

abrasive

pad,

scouring

powder

or

solvent

such

as

alcohol

or

benzine.

For

detailed

safety

precautions,

see

the

“IMPORTANT

SAFEGUARDS”

leaflet.

If

vou

have

any

question

or

problem

concerning

your

receiver,

please

consult

your

nearest

Sony

dealer.

os

i

a

A a

ee

About

This

Manual

The

instructions

in

this

manual

are

for

models

STR-DE425

and

STR-DE325.

Check

your

model

number

by

looking

at

the

upper

right

corner

of

the

front

panel

or

lower

right

corner

of

the

remote.

In

this

manual,

the

STR-DE425

is

the

model

used

for

illustration

purposes,

any

difference

in

operation

is

clearly

indicated

in

the

text,

for

example,

“STR-DE425

only”.

Type

of

differences

Model

DE425

=

DE325

Feature

MIx

AUDIO

QUT

:

WOOFER

e

5.1/DVD

INPLT

e

VIDEO

MONITOR

Conventions

The

instructions

in

this

manual

describe

the

controls

on

the

receiver.

You

can

also

use

the

controls

on

the

remote

if

they

have

the

same

or

similar

names

as

those

on

the

receiver.

¢

A

“Quick

Reference

Guide”

is

supplied

on

page

23.

*

The

“Remote

Button

Descriptions”

section

on

page

22

provides

an

overview

of

the

remote

buttons.

¢

The

following

icons

are

used

in

this

manual:

=]

Indicates

that

you

can

use

only

i

the

remote

to

do

the

task.

Indicates

hints

and

tips

for

making

the

task

easier.

wt

.

fo

This

receiver

has

the

Dolby

Surround

system.

;

Manufactured

under

license

from

Dolby

Laboratories

Licensing

Corporation.

“Dolby

,”

“Pro

Logic”

and

the

double-D

symbol

00

are

trademarks

of

Dolby

Laboratories

Licensing

Corporation.

TABLE

OF

CONTENTS

Getting

Started

Unpacking

4

Hookup

Overview

4

Antenna

Hookups

5

Audio

Component

Hookups

5

Speaker

System

Hookups

6

Video

Component

Hookups

7

AC

Hookups

8

Before

You

Use

Your

Receiver

8

Receiver

Operations

Selecting

a

Component

8

Receiving

Broadcasts

11

Presetting

Radio

Stations

12

Recording

13

Using

the

Sleep

Timer

13

Choosing

a

Surround

Mode

14

Getting

the

Most

Out

of

Dolby

Pro

Logic

Surround

Sound

15

Additional

Information

Troubleshooting

17

Specifications

18

Glossary

19

Index

20

Rear

Panel

Descriptions

21

Remote

Button

Descriptions

22

Quick

Reference

Guide

23

Getting

Started

Unpacking

Check

that

vou

received

the

following

items

with

the

receiver:

¢

FM

wire

antenna

(1)

¢

AM

loop

antenna

(1)

¢

Remote

controller

(remote)

(1)

¢

Size

AA

(R6)

batteries

(2)

Inserting

batteries

into

the

remote

Insert

two

size

AA

(R6)

batteries

in

accordance

with

the

+

and

-

markings

on

the

battery

compartment.

When

using

the

remote,

point

it

at

the

remote

sensor

on

the

receiver.

‘

ae

When

to

replace

batteries

Under

normal

use,

the

batteries

should

last

for

about

6

months.

When

the

remote

no

longer

operates

the

receiver,

replace

both

batteries

with

new

ones.

Notes

-

5

Do

not

leave

the

remote

in

an

extremely

hot

or

humid

place.

Do

not

use

a

new

battery

with

an

old

one..

Do

not

expose

the

remote

sensor

to

direct

sunlight

or

lighting

apparatuses.

Doing

so

may

cause

a

malfunction.

¢

If

you

don’t

use

the

remote

for

an

extended

period

of

time,

remove

the

batteries

to

avoid

possible

damage

from

battery

leakage

and

corrosion.

ee

Hookup

Overview

The

receiver

allows

you

to

connect

and

control

the

following

audio/video

components.

Follow

the

hookup

procedures

for

the

components

that

you

want

to

connect

to

the

receiver

on

the

pages

specified.

To

learn

the

locations

and

names

of

each

jack,

see

“Rear

Panel

Descriptions”

on

page

21.

DVD

player/AC-3

decoder

(STR-

DE425

only)

Video

Component

Hookups

(7)

TV

monitor

(STR-DE425

Antenna

Hookups

(5)

only)

Speaker

AM/FM

antenna

Hookups

(6)

DBS

(Digital

broadcasting

system)

Tape/MD

deck

Audio

Component

Hookups

(5)

Before

you

get

started

¢

Turn

off

the

power

to

all

components

before

making

any

connections.

Do

not

connect

the

AC

power

cords

until

all

of

the

connections

are

completed.

:

Be

sure

to

make

connections

firmly

to

avoid

hum

and

noise.

~

.

When

connecting

an

audio/video

cable,

be

sure

to

match

the

color-coded

pins

to

the

appropriate

jacks

on

the

components:

Yellow

(video)

to

Yellow;

White

(left,

audio)

to

White;

and

Red

(right,

audio)

to

Red.

SSS

ae

Antenna

Hookups

Overview

This

section

describes

how

to

connect

AM

and

FM

antennas

to

the

receiver.

If

you

want

to

receive

radio

broadcasts

with

the

receiver,

complete

these

connections

first,

then

go

to

the

following

pages.

For

specific

locations

of

the

terminals,

see

the

illustration

below.

ANTENNA

What

antennas

will

|

need?

¢

FM

wire

antenna

(supplied)

(1)

¢

AM

loop

antenna

(supplied)

(1)

Hookups

FM

wire

antenna

Receiver

After

connecting

|

fe)

the

wire

antenna,

keep

it

as

horizontal

as

possible.

ANTENNA

coy

If

you

have

poor

FM

reception

Connect

a

75-ohm

coaxial

cable

(not

supplied)

to

an

FM

outdoor

antenna.

Receiver

}_—_________]

ANTENNA

Getting

Started

ce

If

you

have

poor

AM

reception

Connect

a

20

to

50

ft.

(6

to

15-meter)

insulated

wire

(not

supplied)

to

the

AM

antenna

terminal

in

addition

to

the

AM

loop

antenna.

Try

to

extend

the

wire

outdoors

and

keep

it

horizontal.

Connecting

a

ground

wire

To

prevent

hum,

connect

a

ground

wire

(not

supplied)

to

the

-+

ground

terminal.

If

you’ve

connected

an

outdoor

antenna,

be

sure

to

connect

the

ground

for

lightning

protection.

Receiver

hh

SIGNAL

GND

|

+

to

ground

Where

do

|

go

next?

If

you

want

to

connect

other

components,

go

on

to

the

If

you're

only

planning

to

use

the

receiver

to

listen

to

the

radio,

go

to

“Speaker

System

Hookups”

on

pages

6

and

7.

ee

Audio

Component

Hookups

Overview

This

section

describes

how

to

connect

your

audio

components

to

the

receiver.

If

you

want

to

use

the

receiver

as

an

amplifier,

complete

these

connections.

For

specific

locations

of

the

jacks,

see

the

illustration

below,

TAPE/MD

What

cords

will

|

need?

Audio

cords

(not

supplied)

(1

for

CD

player;

2

for

each

tape

deck

or

MD

recorder)

White

i

ee

nol

White

(L)

Red

(R)

<u

mee

Rees)

(continued)

Getting

Started

Hookups

The

arrow

<=»

indicates

signal

flow.

CD

player

Receiver

CD

player

oe

Tape

deck

or

MD

recorder

Receiver

eo)

e)(S

Tape

deck

or

MD

recorder

COVE

CO)

Go

on

to

the

to

connect

the

speakers.

i

Where

do

|

go

next?

Speaker

System

Hookups

Overview

This

section

describes

how

to

connect

your

speakers

to

the

receiver.

Although

front

(left

and

right)

speakers

are

required,

center

and

rear

speakers

are

optional.

Adding

center

and

rear

speakers

will

enhance

the

surround

effects.

Connecting

an

active

woofer

will

increase

bass

response.

For

specific

locations

of

the

terminals,

see

the

illustration

below.

WOOFER

(STR-DE425

only)

MIX

AUDIO

OUT

(STR-DE325

only)

FRONT

SPEAKERS

A

SURROUND

SPEAKER

CENTER

SURROUND

SPEAKERS

REAR

For

optimum

surround

sound

effect,

place

vour

speakers

as

shown

below.

Rear

speaker

wed

BL

(Le

60-90

em

|

as

“yy

a

&

go

=

What

cords

will

|

need?

Speaker

cord

(not

supplied)

(1

for

each

speaker)

Twist

the

stripped

ends

of

the

cord

about

2/3

inch

(15

mm).

Be

sure

to

match

the

speaker

cord

to

the

appropriate

terminal

on

the

components:

+

to

+

and

-

to

-.

If

the

cords

are

reversed,

the

sound

will

be

distorted

and

will

lack

bass.

Hookups

Front

speakers

Front

speaker

Front

speaker

(R)

Receiver

(L)

+

Rear

and

center

speakers

Rear

speaker

Center

speaker

(L)

Rear

speaker

(R)

Receiver

SURROUND

SPEAKERS.

Note

(except

STR-DE425)

Be

sure

to

connect

the

both

rear

speakers

(L

and

R).

No

sound

is

heard

if

only

one

speaker

is

connected.

Active

woofer

STR-DE425

only.

STR-DE325

only

Active

woofer

Receiver

Active

woofer

Note

*

Do

not

connect

any

other

component.

Getting

Started

ce)

If

you

have

an

additional

front

speaker

system

Connect

them

to

the

FRONT

SPEAKERS

B

terminals.

car

If

your

TV

monitor

uses

separate

speakers

You

can

connect

one

of

them

to

the

SURROUND

SPEAKER

CENTER

terminals

for

use

with

Dolby

Pro

Logic

Surround

sound

(see

page

15).

a

Selecting

the

speaker

system

To

drive

the

speakers,

select

the

speaker

system

as

follows:

To

drive

Speaker

system

A

(connected

to

the

FRONT

SPEAKERS

A

terminals)

Speaker

system

B

(connected

to

the

FRONT

SPEAKERS

B

terminals)

Both

speaker

systems

A

and

B

(series

connection)

Depress

SPEAKERS

button

A+B

Notes

*

If

you

want

to

enjoy

the

surround

sound,

be

sure

to

connect

the

front

speakers

to

the

FRONT

SPEAKERS

A

terminal.

*

No

sound

is

heard

when

you

press

SPEAKERS

A+B

without

connecting

speaker

system

B.

Where

do

|

go

next?

To

complete

your

system,

go

to

“AC

Hookups”

on

page

8.

If

you

want

to

connect

video

components

to

enjoy

surround

sound

when

watching/listening

to

TV

programs

or

video

tapes,

go

on

to

the

Nh

ire

ni

ee

Fe

=

wel

Video

Component

Hookups

Overview

This

section

describes

how

to

connect

video

components

to

the

receiver.

For

specific

locations

of

the

jacks,

see

the

illustration

below.

5.1/DVD

INPUT

(STR-DE425

only)

Tv/DBS

MONITOR

(STR-DE425

only)

What

cables

will

|

need?

*

Audio/video

cable

(not

supplied)

(1

for

each

TV

tuner

or

Digital

broadcasting

system;

2

for

the

VCR)

Yellow

<q_2

Yellow

White

(L)

CS

White

(L)

Red

(R)

Red

(R)

*

Video

cable

(not

supplied)

(1

fora

TV

monitor)

Yellow

Hookups

The

arrow

=

indicates

signal

flow.

TV/DBS

TV

tuner

or

Digital

broadcasting

system

Receiver

*

STR-DE425

only

MONITOR

(STR-DE425

only)

TV

monitor

Receiver

VCR

Receiver

VCR

*

STR-DE425

only

DVD

player/AC-3

decoder

(STR-DE425

only)

e

You

can

play

decoded

Dolby

Digital

AC-3

soundtracks

through

the

speakers

connected

to

the

amplifier.

If

you

have

a

Dolby

Digital

AC-3

decoder

you

can

amplify

a

decoded

Dolby

Digital

AC-3

soundtrack

with

the

following

connections.

Dolby

Digital

AC-3

decoder

(etc.)

Receiver

5.1OV0

INPUT

Getting

Started

Where

do

|

go

next?

Go

on

to

the

to

connect

the

AC

power

cord

and

complete

your

home

theater

systent.

AC

Hookups

Connecting

the

AC

power

cord

Connect

the

AC

power

cord

from

this

receiver

and

from

your

audio/video

components

to

a

wall

outlet.

If

you

connect

other

audio

components

to

the

SWITCHED

AC

OUTLET

on

the

receiver,

the

receiver

can

supply

power

to

the

connected

components

so

you

can

turn

on/off

the

whole

system

when

you

turn

on/

off

the

receiver.

SWITCHED

AC

OUTLET

(Australia)

SWITCHED

AC

OUTLET

to

a

wall

(US)

.

outlet

Caution

Make

sure

that

the

power

consumption

of

the

component

connected

to

the

receiver's

AC

outlet

does

not

exceed

120

watts

(US

model)

or

100

watts

(Australian

model).

Do

not

connect

high-wattage

electrical

home

appliances

such

as

electric

irons,

fans,

or

TVs

to

this

outlet.

Where

do

I

go

next?

Before

you

use

the

receiver,

go

to

the

to

make

sure

that

all

the

controls

are

set

to

the

appropriate

positions.

———EEE—

—E———————_—_———————————————

Before

You

Use

Your

Receiver

Before

vou

start

using

your

receiver,

make

sure

that

you

have:

¢

Turned

MASTER

VOLUME

to

the

leftmost

position

(0).

¢

Selected

the

appropriate

speaker

system.

(See

“Selecting

the

speaker

system”

on

page

7.)

¢

Set

BALANCE

to

the

center

position.

Turn

on

the

receiver

and

check

the

following

indicator.

¢

Press

MUTING

or

MUTING

on

the

remote

if

the

MUTING

indicator

turns

on.

Receiver

operations

Selecting

a

Component

To

listen

to

or

watch

a

connected

component,

first

select

the

function

on

the

receiver

or

with

the

remote.

Before

you

begin,

make

sure

you

have:

*

Connected

all

components

securely

and

correctly

as

indicated

on

pages

5

to

8.

¢

Turned

MASTER

VOLUME

to

the

leftmost

position

(0)

to

avoid

damaging

your

speakers.

Function

MASTER

buttons

MUTING

VOLUME

/

(power)

5.1/DVD

INPUT

BASS

(STR-DE425

only)

BOOST

BASS

TREBLE

BALANCE

1)

Press

VO

(power)

to

turn

on

the

receiver.

2

Press

a

function

button

to

select

the

component

you

want

to

use:

To

listen

to

or

watch

Press

Radio

programs

TUNER

Compact

discs

(CD)

CD

Audio

tapes

or

MiniDiscs

TAPE/MD

(MD)

TV

programs

or

Digital

TV/DBS

broadcasting

system

Video

tapes

VIDEO

DVD

player/AC-3

decoder

5.1/DVD

INPUT

(STR-DE425

only)

3

Turnon

the

component,

for

example,

a

CD

player,

and

then

start

playing.

:

To

tune

in

radio

stations

on

this

receiver,

see

“Receiving

Broadcasts”

on

page

11.

4

Turn

MASTER

VOLUME

to

adjust

the

volume.

To

adjust

the

volume

of

the

TV’s

speakers,

use

the

volume

control

on

the

TV.

Receiver

Operations

To

Do

this

Press

MUTING

or

MUTING

on

the

remote.

Press

again

to

restore

the

sound

Mute

the

sound

Reinforce

the

bass

Press

BASS

BOOST

to

ten

on

the

BASS

BOOST

indicator.

Turn

the

BALANCE

control

left

or

right.

Adjust

the

BASS

and

TREBLE

controls.

Adjust

the

balance

Adjust

the

tone

quality

¢

When

you

listen

with

headphones

Connect

the

headphones

to

the

PHONES

jack

and

set

the

SPEAKERS

buttons

to

OFF.

¢

5.1

/

DVD

INPUT

mode

(STR-DE425

only)

When

you

are

listening

to

5.1/DVD

INPUT

mode,

BASS,

TREBLE,

BASS

BOOST

and

SURROUND

do

not

function.

Watching/listening

to

video

programs

When

you

watch/listen

to

TV

or

video

programs,

we

recommend

you

play

audio

portion

through

the

receiver

instead

of

your

TV’s

speaker.

This

lets

you

take

advantage

of

the

receiver's

surround

sound

effects,

like

Dolby

Pro

Logic

Surround

and

lets

you

use

the

receiver’s

remote

to

control

the

audio.

Turn

off

the

speakers

on

your

TV

before

you

start

so

you

can

enjoy

the

surround

sound

from

your

receiver.

To

watch/listen

to

TV

programs,

turn

on

the

TV,

TV

tuner

and

the

receiver

and

press

TV/DBS

on

the

receiver.

To

watch

videos,

do

the

following:

1-

Press

WIDEO

to

select

the

VCR.

2

=

Turnon

the

TV

and

set

the

TV's

video

input

to

match

your

video

component.

3

Turnon

the

VCR,

and

start

playback.

Ss

Using

the

remote

|

(BU

The

remote

lets

you

operate

the

receiver

and

the

Sony

components

that

are

connected

to

it.

TV

CONTROL

SYSTEM

STANDBY

SYSTEM

CONTROL/

FUNCTION

1

Press

one

of

the

SYSTEM

CONTROL/

FUNCTION

buttons

to

select

the

component

you

want

to

use.

The

SYSTEM

CONTROL/FUNCTION

buttons

on

the

remote

are

factory-set

as

follows:

To

listen

to

or

watch

Press

Radio

programs

TUNER

Compact

discs

(CD)

CD

Audio

tapes

or

TAPE/MD

MiniDises

(MD)

(INITIAL-TAPE

B

MODE)

TV

programs

TV

VHS

Video

tapes

(VTR-3

mode)

DVD

Player,

AC-3

CD

and

PHONO

(STR-DE425

decoder

only)

If

you

want

to

change

the

factory

setting

of

a

button,

see

page

10.

The

receiver

and

the

selected

component

turn

on.

If

the

component

does

not

turn

on

Press

the

power

switch

on

the

component.

2.

Start

playing.

Refer

to

“Remote

Button

Descriptions”

on

page

22

for

details.

To

turn

off

the

components

Press

SYSTEM

STANDBY.

You

can

turn

off

the

video

and

audio

components

connected

to

the

SWITCHED

AC

OUTLET

at

the

same

time.

ie

If

you

use

a

Sony

TV

When

you

press

TV

to

watch

a

TV

program,

the

TV

turns

on

and

switches

to

the

TV

input.

The

TV

also

turns

on

when

you

press

VIDEO

and

switches

to

the

appropriate

video

input.

If

the

TV

does

not

switch

to

the

appropriate

input

automatically,

press

TV/

VIDEO.

xe

When

you

watch

TV

without

using

the

receiver

(only

for

Sony

TVs)

Press

TV

CONTROL

to

set

the

remote

to

operate

onlv

the

TV.

When

vou

press

this

button,

the

TV

turns

on

and

switches

to

the

TV

input.

If

the

TV

does

not

switch

to

the

TV

input

automatically,

press

TV/

VIDEO.

(continued)

10

Receiver

Operations

Changing

the

factory

setting

of

a

=

function

button

If

the

factory

settings

of

the

FUNCTION

buttons

(page

9)

don’t

match

your

system

components,

you

can

change

them.

For

example,

if

you

have

two

CD

players

and

you

don’t

have

a

tape

deck

or

an

MD

recorder,

you

can

assign

the

TAPE/MD

button

to

your

second

CD

player.

Note

that

the

settings

of

the

TUNER

and

PHONO

buttons

cannot

be

changed.

SYSTEM

CONTROL/

FUNCTION

Numeric

buttons

1

Hold

down

the

SYSTEM

CONTROL/FUNCTION

button

whose

function

you

want

to

change

(TAPE/MD,

for

example).

2

Press

the

corresponding

numeric

button

of

the

component

you

want

to

assign

to

the

SYSTEM

CONTROL/FUNCTION

button

(1

-

CD

player,

for

example).

The

numeric

buttons

are

assigned

te

select

the

functions

as

follows:

sa

Numeric

button

Operates

1

CD

lage

via

DAT

deck

3

MD

deck

-

4

-

Tape

deck

A

sy

-

Sepeaees

_

6

/

LD

layer

=

VCR

(remote

control

mode

VTR

1*)

“I

8

-

VCR

(remote

control

ede

VIR

2)

—_

9

-

:

VER

ean

control

mode

VTR

34)

be

-

TV

-

S10

OBS

ei

Enter

“pv

D

7

:

;

if

Sony

VCRs

are

operated

with

a

WTR

1,

2

or

3

setting.

These

correspond

to

Beta,

8mm

and

VHS

respectively.

Now

vou

can

use

the

TAPE/MD

button

to

control

a

second

CD

plaver.

To

reset

the

setting

to

the

factory

setting

Repeat

the

above

procedure.

Ss

Receiving

Broadcasts

This

receiver

lets

you

enter

a

station’s

frequency

directly

by

using

the

numeric

buttons

(direct

tuning).

If

you

don’t

know

the

trequency

ot

the

station

ygu

want,

see

“Receiving

broadcasts

by

scanning

stations

(automatic

tuning)”

on

this

page.

Before

you

begin,

make

sure

you

have:

¢

Connected

an

FM/AM

antenna

to

the

receiver

as

indicated

on

page

5.

*

Selected

the

appropriate

speaker

system.

(See

“Selecting

the

speaker

system”

on

page

7.)

He)

DIRECT

(power)

SHIFT

TUNING

Numeric

buttons

MASTER

VOLUME

TUNING

+/-

FM

FM/AM

MODE

TUNER

1

Press

1/

(power)

to

turn

on

the

receiver.

2

Press

TUNER.

The

last

received

station

is

tuned

in.

Press

FM/AM

to

select

FM

or

AM

stations.

4

Press

DIRECT

TUNING.

5

Press

the

numeric

buttons

to

enter

the

frequency.

Example

1:

FM

102.50

MHz

Example

2:

AM

1350

kHz

7)

(You

don’t

have

to

enter

fry

ee

hi

the

last

“0.”)

6

When

you

tune

in

AM

stations,

adjust

the

2

5

J{2

direction

of

the

AM

loop

antenna

for

optimum

reception.

Receiver

Operations

To

receive

other

stations

Repeat

Steps

3

to

5.

If

the

STEREO

indicator

remains

off

Press

FM

MODE

when

an

FM

stereo

broadcast

is

received.

tf

an

FM

stereo

program

is

distorted

The

STEREO

indicator

flashes.

Press

FM

MODE

to

change

to

monaural

(MONO).

You

will

not

have

the

stereo

effect

but

the

distortion

will

be

reduced.

To

return

to

stereo

mode,

press

this

button

again.

If

you

cannot

tune

in

a

station

and

the

entered

numbers

are

flashing

Make

sure

you've

entered

the

right

frequency.

If

not,

press

DIRECT

TUNING

and

re-enter

the

frequency

you

want.

If

the

entered

numbers

still

flash,

the

frequency

is

not

used

in

your

area.

To

watch

FM

simulcast

TV

programs

Make

sure

that

you

tune

in

the

simulcast

program

both

on

the

TV

(or

the

VCR)

and

on

the

receiver

’

if

you

enter

a

frequency

not

covered

by

the

tuning

interval

The

entered

value

is

automatically

rounded

up

or

down

to

the

closest

covered

value.

Tuning

intervals

for

direct

tuning

are:

FM:

50

kHz

intervals

AM:

9

kHz/10

kHz

intervals

(US

model)

9

kHz

intervals

(Australian

model)

Receiving

broadcasts

by

scanning

stations

(automatic

tuning)

If

you

don’t

know

the

frequency

of

the

radio

station

you

want,

you

can

have

the

receiver

scan

all

the

receivable

stations

to

locate

the

one

vou

want.

1

Press

TUNER.

The

last

received

station

is

tuned

in.

Press

FM/AM

to

select

FM

or

AM.

Press

TUNING

+

or

-.

Press

the

+

button

for

a

higher

station

number;

press

the

—

button

for

a

lower

one.

When

you

tune

past

either

end

of

the

band,

the

receiver

automatically

jumps

to

the

opposite

end.

Every

time

a

station

is

received,

the

receiver

stops

scanning.

To

continue

scanning.

press

the

button

again.

11

12

Receiver

Operations

nD

Ee

FS

Presetting

Radio

Stations

You'll

most

likely

want

to

preset

the

receiver

with

the

radio

stations

you

listen

to

often

so

that

you

don’t

have

to

tune

in

the

station

every

time.the

receiver

can

store

a

total

of

30

FM

or

AM

stations.

You

can

store

the

stations

on

preset

numbers

combining

3

characters

(A,

B,

C)

and

numbers

(0

-

9).

For

example,

you

can

store

a

station

as

preset

number

A1,

B6

or

C9,

etc.

PRESET

TUNING

Numeric

buttons

MEMORY

SHIFT

TUNER

1

Press

TUNER.

The

last

received

station

is

tuned

in.

2

=

Tune

in

the

station

you

want.

If

you

are

not

familiar

with

how

to

tune

ina

station,

see

“Receiving

Broadcasts”

on

the

3

Press

MEMORY.

“MEMORY”

appears

for

a

few

seconds.

Do

steps

4

and

5

before

“MEMORY”

goes

out.

4

Press

SHIFT

to

select

a

character

(A,

B

or

C).

Each

time

you

press

SHIFT,

the

letter

“A,”

“B”

or

“C”

appears

in

the

display.

If

“MEMORY”

disappears,

start

again

from

step

3.

5

While

MEMORY

is

displayed,

press

the

number

you

want

to

use

(0

to

9).

6

Repeat

Steps

2

to

5

to

preset

other

stations.

To

change

a

preset

station

Preset

a

new

station

on

the

number

you

want

to

change.

Note

If

the

AC

power

cord

is

disconnected

for

about

one

week,

the

preset

stations

will

be

cleared

from

the

receiver's

memory,

and

you

will

have

to

preset

the

stations

again.

Tuning

preset

stations

(preset

tuning)

You

can

tune

directly

to

a

preset

station

by

entering

its

preset

number.

If

you

don’t

know

which

stations

are

preset

on

which

numbers,

you

can

tune

by

scanning

the

preset

stations.

1

Press

TUNER.

The

last

received

station

is

tuned

in.

2

Press

SHIFT

to

select

a

character

(A,

Bor

C),

then

press

the

number.

For

example,

select

A

and

then

press

7

to

tune

in

the

station

preset

as

A7.

ue

CY:

You

can

tune

by

scanning

the

preset

stations

First

press

TUNER

and

then

press

PRESET

TUNING

+

or

-

to

select

the

station

you

want.

Each

time

you

press

the

buttons,

the

preset

numbers

change

as

follows:

ee

eed

ee

ees

wees

5

Recording

This

receiver

makes

it

easy

to

record

to

and

trom

the

components

connected

to

the

receiver.

You

don’t

have

to

connect

playback

and

recording

components

directly:

once

vou

select

a

program

source

on

the

receiver,

Vou

can

record

and

edit

as

you

normally

would

using

the

controls

on

each

component.

Before

vou

begin,

make

sure

you've

connected

all

components

properly.

Function

buttons

Recording

component

(Tape

deck,

MD

recorder,

VCR)

Playback

component

(program

source)

==%:

Audio

signal

flow

«—™;

Video

signal

flow

(STR-DE425

only)

Recording

on

an

audio

tape

or

MiniDisc

You

can

record

ona

cassette

tape

or

MiniDisc

using

the

receiver.

See

the

instruction

manual

of

your

tape

deck

or

MD

recorder

if

you

need

help.

1

Press

one

of

the

function

buttons

to

select

the

program

source.

2

Set

the

component

to

be

ready

for

playing.

For

example,

insert

a

CD

into

the

CD

player.

3

Insert

a

blank

tape

or

disc

into

the

recording

deck

and

adjust

the

recording

level,

if

necessary.

4

Start

recording

on

the

recording

deck

and

then

start

plaving

the

component.

Receiver

Operations

Recording

on

a

video

tape

You

can

record

TV

program

or

digital

broadcasting

system

using

the

receiver.

You

can

also

add

audio

from

a

variety

of

audio

sources

when

editing

a

video

tape.

See

your

VCR’s

instruction

manual

if

you

need

help.

1°

Press

TV/DBS

to

select

the

program

source.

2

Set the

component

to

be

ready

for

plaving.

For

example,

turn

on

the

TV

and

TV

tuner.

3°

Insert

a

blank

video

tape

into

the

VCR

for

recording.

4

Start

recording

on

the

VCR.

gy

You

can

replace

audio

while

editing

a

video

tape

At

the

point

you

want

to

start

adding

difterent

sound,

press

another

function

button

(for

example,

CD)

and

start

playback.

The

sound

from

the

selected

component

will

be

recorded

over

the

original

audio.

To

resume

recording

the

original

sound,

press

the

TV/DBS

function

button.

Note

You

cannot

record

the

audio

and

video

signal

during

5.1/DVD

INPUT

mode

(STR-DE425

only).

Using

the

Sleep

Timer

You

can

set

the

amplifier

to

turn

off

automatically

at

a

time

you

specify.

Press

SLEEP

while

the

power

is

on.

Each

time

you

press

SCEEP,

the

time

changes

as

shown

below.

*

2:00:00

—

1:30:00

—

1:00:00

—

0:30:00

—

OFF

—

The

display

dims

after

vou

specify

the

time.

°C

You

can

check

the

time

remaining

before

the

amplifier

turns

off

Press

SLEEP.

The

remaininy

time

appears

in

the

display.

13

14

S

Using

Surround

Sound

aaa

i

|

Choosing

a

Surround

Mode

You

can

take

advantage

of

surround

sound

simply

by

selecting

one

of

the

pre-programmed

surround

modes

according

to

the

type

of

music

you

wish

to

play.

SURROUND

EFFECT/DELAY

MODE

ON/OFF

SET-UP

SURROUND

ON/OFF

SURROUND

MODE

1

Press

SURROUND

ON/OFF

to

turn

on

the

surround

sound.

:

One

of

the

SUR

(surround)

MODE

indicators

lights

up

in

the

display.

2

=

Press

SURROUND

MODE

repeatedly

until

the

indicator

for

the

surround

mode

you

want

lights

up.

Select

the

appropriate

surround

mode

as

follows:

Select

To

PRO

LOGIC*

Decode

programs

processed

with

Dolby

Surround

and

create

the

atmosphere

of

a

movie

theater.

C.

STUDIO

Add

the

acoustic

reflections

of

a

cinema

studio

to

decoded

Dolby

Surround

signals.

HALL

Reproduce

the

acoustics

of

a

rectangular

concert

hall.

Ideal

for

soft,

acoustic

sounds.

*

“DOLBY”

appears

in

the

display.

“@

When

you

use

the

remote

Each

time

vou

press

SURROUND

MODE,

surround

mode

changes

as

tollows:

STR-DE425

only

PRO

LOGIC*

——

C.

STUDIO

A-+C.

STUDIO

B

—

HALL

+

STR-DE325

only

a

PRO

LOGIC*

—

C.

STUDIO

—

HALL

=|

*

“DOLBY”

appears

in

the

display.

To

turn

off

surround

sound

Press

SURROUND

ON/OFF.

‘©

You

can

find

Dolby

Surround-encoded

software

by

looking

at

the

packaging

However,

some

videos

and

laser

discs

may

use

Dolby

Surround

sound

even

if

it’s

not

indicated

on

the

package.

Note

Make

sure

to

select

speaker

A

with

the

SPEAKERS

A

button,

otherwise,

you

can’t

obtain

the

surround

effect.

Adjusting

the

Effect

Level

(for

C.

STUDIO

and

HALL

only)

You

can

make

the

surround

sound

more

prominent

by

increasing

the

EFFECT

level.

This

control

lets

you

adjust

the

“presence”

of

the

surround

effect

in

six

steps

(1-6).

1

Start

playing

a

programme

source.

2

=

Press

SURROUND

EFFECT

/DELAY

or

EFFECT

/

DELAY

on

the

remote

to

select

the

level

you

prefer.

The

effect

level

(“EFFECT

1”

...

"EFFECT

6”)

appears

on

the

display.

Note

Changing

the

effect

level

may

not

produce

major

variations

in

the

surround

effect

when

used

with

certain

playback

sources.

Rs

Getting

the

Most

Out

of

Dolby

Pro

Logic

Surround

Sound

To

obtain

the

best

possible

Dolby

Pro

Logic

Surround

sound,

first

select

the

center

mode

according

to

the

speaker

system

you

have.

Then,

adjust

each

speaker

volume

and

delay

time.

Note

that

you

must

have

at

least

one

additional

pair

of

speakers

and/or

one

center

speaker

to

do

the

following

adjustments.

SURROUND

CENTER

LEVEL

+/—

EFFECT/DELAY

SURROUND

MODE

coosco

SSea=>

rh

O

900000

—t=e—r

a9

REAR

LEVEL

+/-

SET-UP

SURROUND

ON/OFF

i

MODE

C5

EFFECT/DELAY

TEST

TONE

REAR

LEVEL

+/-

ww

CENTER

LEVEL

+/-

Using

Surround

Sound

Selecting

the

center

mode

The

receiver

offers

you

four

center

modes:

Phantom,

3

Channel

Logic,

Normal,

and

Wide.

Each

mode

is

designed

for

a

different

speaker

configuration.

Select

the

mode

that

best

suits

your

speaker's

system

configuration:

1°

Press

SURROUND

ON

/OFF

to

turn

on

surround

sound.

2

Press

SURROUND

MODE

repeatedly

to

select

the

Dolby

surround

sound

field

(PRO

LOGIC

or

C.

STUDIO

mode).

3

Press

SET-UP

repeatedly

until

the

set-up

vou

want

appears

in

the

display.

Select

the

set-up

as

follows:

ee

If

you

have

Select

Front

and

rear

PHANTOM

speakers,

no

center

speaker

Front

and

center

3

CH

LOGIC

speakers,

no

rear

(3

Channel

So

that

The

sound

of

the

center

channel

is

output

from

the

front

speakers.

The

sound

of

the

rear

channel

is

output

speaker

Logic)

from

the

front

speakers.

Front

and

rear

NORMAL

The

bass

sound

of

the

speakers,

and

a

center

channel

is

small

center

output

from

the

front

speaker

speakers

(because

a

small

speaker

cannot

produce

enough

bass).

Front

and

rear

WIDE

For

“complete”

speakers,

and

a

large

center

speaker

Dolby

Pro

Logic

Surround

sound.

(continued)

15

16

Using

Surround

Sound

,

=

Adjusting

the

speaker

volume

The

test

tone

feature

lets

you

set

the

volume

of

your

speakers

to

the

same

level.

(If

all

of

your

speakers

have

equal

pertormance,

you

don’t

have

to

adjust

the

speaker

volume.)

=

Using

the

controls

on

the

remote

lets

you

test

the

speaker

connection

and

adjust

the

volume

level

from

your

listening

position.

1.

Press

TEST

TONE

on

the

remote.

;

You

will

hear

the

test

tone

from

each

speaker

sequentially.

2

Adjust

the

volume

level

so

that

the

test

tone

from

each

speaker

is

at

the

same

level

from

your

listening

position.

¢

To

adjust

the

level

of

center

speaker,

press

CENTER

LEVEL

+

or

-

on

the

remote.

¢

To

adjust

the

level

of

rear

speakers,

press

REAR

LEVEL

+

or

-

on

the

remote.

3

>

Press

TEST

TONE

on

the

remote

to

turn

off

the

test

tone.

¢

You

can

adjust

all

speakers

at

one

time

Adjust

MASTER

VOL

on

the

remote

or

MASTER

VOLUME

on

the

receiver.

¢

You

can

also

adjust

the

volume

level

with

the

controls

on

the

receiver

*

°

After

pressing

TEST

TONE

on

the

remote,

press

REAR

LEVEL

+

or

-

and

CENTER

LEVEL

+

or

-

to

adjust

the

level

of

the

rear

and

center

speakers

respectively.

During

5.1/DVD

INPUT

(STR-DE425

only)

test

tone

mode,

CENTER

LEVEL

and

REAR

LEVEL

cannot

be

adjusted.

”

You

can

increase

the

output

level

of

the

rear

speakers

The

adjustment

range

of

the

rear

speakers

is

preset

from

-15

to

+10,

but

you

can

shift

the

range

up

5

levels

(-1

to

+15).

Hold

down

SURROUND

MODE

on

the

receiver

while

turning

on

the

power

until

“GAIN

UP”

appears

on

the

display.

The

values

for

the

rear

level

remain

fixed

at

-15

to

+10

in

the

display,

but

you

will

be

able

to

hear

the

difference

in

the

actual

output

level.

To

reset

the

rear

level

adjustment

range,

repeat

this

procedure

to

display

“NORMAL”.

Adjusting

the

delay

time

You

can

make

the

surround

sound

more

effective

by

delaying

the

output

from

the

rear

speakers

(delay

time).

You

can

select

from

three

delay

times,

S

(15

mS),

M

(20

mS),

and

L

(30

mS).

For

example,

if

you’ve

placed

the

rear

speakers

in

a

large

room

or

apart

from

your

listening

position,

set

the

delay

time

shorter.

1°

Start

playing

a

program

source

encoded

with

Dolby

Surround

sound.

2

>

Press

EFFECT/DELAY

on

the

remote

or

SURROUND

EFFECT/DELAY

on

the

receiver

repeatedly

to

choose

the

delay

time

parameter.

The

current

delay

time

appears

in

the

display,

such

as

“DELAY

S,”

“DELAY

M”

or

“DELAY

L.”

Note

Select

the

PRO

LOGIC

mode

when

you

adjust

the

delay

time

using

SURROUND

EFFECT/DELAY

on

the

receiver.

V:Veloltelelal-JMlstielatteyeieyi)

SS

eee

Troubleshooting

If

you

experience

any

of

the

following

difficulties

while

using

the

receiver,

use

this

troubleshooting

guide

to

help

you

remedy

the

problem.

Should

any

problem

persist,

consult

your

nearest

Sony

dealer.

There‘s

no

sound

or

only

a

very

low-level

sound

is

heard.

=>

Check

that

the

speakers

and

components

are

connected

securely.

Make

sure

you

select

the

correct

component

on

the

receiver.

Make

sure

you

set

the

SPEAKERS

selector

correctly.

(see

page

7)

Press

MUTING

or

MUTING

on

the

remote

if

MUTING

LED

is

“ON”.

The

protective

device

on

the

receiver

has

been

Sn

a

activated

because

of

a

short

circuit.

(“PROTECT”

flashes.)

Turn

off

the

receiver,

eliminate

the

short-circuit

problem

and

turn

on

the

power

again.

The

left

and

right

sounds

are

unbalanced

or

reversed.

=>

Check

that

the

speakers

and

components

are

connected

correctly

and

securely.

=>

Adjust

the

BALANCE

control.

Severe

hum

or

noise

is

heard.

=>

Check

that

the

speakers

and

components

are

connected

securely.

=

Check

that

the

connecting

cords

are

away

from

a

transformer

or

motor,

and

at

least

10

feet

(3

meters)

away

froma

TV

set

or

fluorescent

light.

=>

Place

your

TV

away

from

the

audio

components.

=>

Make

sure

you

connect

a

ground

wire

to

the

antenna

ground

terminal.

=>

The

plugs

and

jacks

are

dirty.

Wipe

them

with

a

cloth

slightly

moistened

with

alcohol.

No

sound

is

heard

from

the

center

speaker.

=>

Select

the

appropriate

center

mode

(see

page

15).

=

Adjust

the

speaker

volume

appropriately

(see

page

16).

No

sound

or

only

a

very

low-level

sound

is

heard

from

the

rear

speakers.

=>

Select

the

appropriate

center

mode

(see

page

:

15).

=>

Adjust

the

speaker

volume

appropriately

(see

page

16).

=>

Make

sure

you

turn

on

the

sound

field

surround

mode

function.

Radio

stations

cannot

be

tuned

in.

=>

Check

that

the

antennas

are

connected

securely.

Adjust

the

antennas

and

connect

an

outdoor

antenna

if

necessary.

The

signal

strength

of

the

stations

is

too

weak

(when

you

tune

in

with

automatic

tuning).

Use

direct

tuning.

Make

sure

you

set

the

tuning

interval

correctly

(when

you

tune

in

AM

stations

with

automatic

tuning)

(see

pages

11

and

18).

No

stations

have

been

preset

or

the

preset

stations

have

been

cleared

(when

you

tune

in

with

scanning

preset

stations).

Preset

the

stations

(see

page

12).

Surround

effect

cannot

be

obtained.

=>

Make

sure

you

turn

on

the

sound

field

function.

=>

Make

sure

that

the

front

speakers

are

connected

to

the

SPEAKERS

A

terminal.

=>

Make

sure

that

SPEAKERS

A

and

B

buttons

are

depressed

when

two

sets

of

front

speakers

are

used.

No


or

an

unclear


is

seen

on

the

TV

screen.

=>

Select

the

appropriate

function

on

the

receiver.

=>

Place

your

TV

away

from

the

audio

components.

Recording

cannot

be

made.

-—

—_>

Check

that

the

components

are

connected

correctly.

You

cannot

record

audio

from

a

program

source

connected

to

5.1/DVD

INPUT

jacks

(STR-DE425

only).

The

remote

does

not

function.

—_

—_>

$o:4

Point

the

remote

at

the

remote

sensor

&

on

the

receiver.

Remove

the

obstacles

in

the

path

of

the

remote

and

the

receiver.

;

Replace

both

batteries

in

the

remote

with

new

ones

if

they

are

weak.

Make

sure

you

select

the

correct

function

on

the

remote.

Pressing

TV

CONTROL

sets

the

remote

to

operate

the

TV

only.

In

this

case,

press

one

of

the

SYSTEM

CONTROL

FUNCTION

buttons

before

operating

the

receiver

(etc.).

17

18

yVololhuleyer-Misticlarieleleys)

Le

5

ll

Specifications

Audio

power

specifications

(USA

only)

POWER

OUTPUT

AND

TOTAL

HARMONIC

DISTORTION

With

8-ohm

load,

both

channels

driven,

from

20

-

20,000

Hz,

rated

100

watts

(STR-DE425/DE325)

per

channel

minimum

RMS

power,

with

no

more

than

0.09

%

total

harmonic

distortion

from

250

milliwatts

to

rated

output.

Amplifier

section

Stereo

mode

(Australia

only)

(8

ohms

at

20

Hz

-

20

kHz

less

than

0.09%

total

harmonic

distortion)

100W

+

100W

(STR-DE425)

80W

+

80W

(STR-DE325)

Surround

mode

(8

ohms

at

1

kHz,

THD

0.8

%)

.

US

model:

Front:

STR-DE425:

100

W/ch

STR-DE325:

100°;W/ch

Center:

(Pro

Logic

Mode)

STR-DE425:

100

W

STR-DE325:

100

W

Rear:

STR-DE425:

50

W/ch

STR-DE325:

100

W

Australia

model:

Front:

STR-DE425:

100

W/ch

STR-DE325:

80

W/ch

Center:

(Pro

Logic

Mode)

STR-DE425:

100

W

STR-DE325:

80

W

Rear:

STR-DE425:

50

W/ch

STR-DE325:

80

W

5.1/DVD

INPUT*

(8

ohms

at

1

kHz,

THD

mode

0.8%)

Front:

100

W/ch

Center:

.

100

W

Rear:

50

W/ch

S

ohms:

STR-DE425

150

W

+

150

W

STR-DE325

145

Wo+

145

W

Dynamic

power

output

(For

US

only)

4

ohms:

STR-DE425:

=

200

W

+200

W

STR-DE325:

190

W

+

190

W

Frequency

TV/DBS,

CD,

TAPE/

response

MD,

VIDEO,

5.1/DVD

INPUT*

10

Hz

-

50

kHz

+1

dB

Inputs

a

Sensitivity

Impedance

.S/N

(weighting

network,

input

level)

CD,

200

mV

5.1/DVD

INPUT*

50

e

ae

,

kilohms

82

dB"

TAPE/MD,

150

mV

(A,

150

mV)

TV/

DBS,

VIDEO

**'78

THF

Outputs

TAPE/MD

REC

OUT:

Voltage:

150

mV,

Impedance:

10

kilohms

VIDEO

AUDIO

OUT:

Voltage:

150

mV,

Impedance:

10

kilohms

WOOFER

/

MIX

AUDIO

OUT:

Voltage:

2

V

Impedance:

10

kilohms

PHONES:

Accepts

low

and

high

impedance

headphones

*

Muting

Full

mute

BASS

BOOST

+10

dB

at

70

Hz

TONE

+8

dB

at

100

Hz

and

10

kHz

FM

tuner

section

Tuning

range

87.5

-

108.0

MHz

Antenna

terminals

75

ohms,

unbalanced

Mono:

18.3

dBf,

4.5

7V

~

Stereo:

38.3

dBf,

45

7V

Sensitivity

Usable

sensitivity

11.2

UBF,

2

«V

(IHF)

S/N

Mano:

76

dB

Stereo:

70

dB

Harmonic

Mono:

0.3

°o

distortion

at

1

kH2

Stereo:

0.5%

Separation

45

dB

at

1

KHz

Frequency

30

Hz

-

13

kHz

dB

response

Selectivity

60

dB

at

400

KHz

AM

tuner

section

Tuning

range

US

MODEL:

10

kHz

interval**”

530

-

1710

kHz

9

kHz

interval

531-1710

kHz

AUSTRALIAN

MODEL:

531

-

1602

kHz

(9

kHz

interval

)

Antenna

Loop

antenna

Usable

sensitivity

50

dB/m

(at

1,000

kHz

or

999

kHz)

S/N

54

dB

(at

50

mV

m)

Harmonic

0.5

°°

(30

mVim,

distortion

400

Hz)

Selectivity

At9

kHz:

35

dB

At

10

kHz:

40

dB

“*

You

can

change

the

AM

tuning

interval

between

9

kHz

and

10

kHz.

After

tuning

in

any

AM

station,

turn

off

the

receiver.

Hold

down

the

PRESET

+

button

and

press

the

I/

(power)

button.

All

preset

stations

will

be

erased

when

you

change

the

interval.

To

reset

the

interval,

repeat

the

procedure.

Video

section

(STR-DE425

only)

VIDEO,

1\'/

DBS,

5.1/

DVD

INPUT*:

1

Vp-p

75

ohms

Inputs

VIDEO:

1

Vp-p

75

ohms

MONITOR:

1

Vp-p

75

ohms

Outputs

General

System

Tuner

section:

PLL

quartz-locked

digital

senthesizer

system

Preamplitier

section:

Low-noise

NF

tvpe

equalizer

Power

amplifier

section:

Pure-complementary

r

SEPP

Power

US

requirements

120

V

AC,

60

Hz

AUSTRALIA:

240

V

AC,

50

Hz

Power

Us:

consumption

STR-DE425

230

STR-DDE325

190.

W

AUSTRALIA:

STR-DDE425

2

250W

STR-DE325

©

SOW

y:VololhalelseImistatlaitrctelele)

AC

outlets

US

MODEL:

1

switched,

total

120

W/1A

Max

AUSTRALIAN

MODEL:

1

switched,

total

100

W

17x

57/sx

11

*/s

inches

(430

x

148

x

295

mm)

Dimensions

Mass

(Approx.)

STR-DE425:

7.7

kg

(16

Ib

15

oz)

STR-DE325:

7

kg

(15

Ib

7

oz)

FM

wire

antenna

(1)

AM

loop

antenna

(1)

Remote

controller

(remote)

(1)

Size

AA

(R6)

batteries

(2)

Supplied

accessories

*5.1/DVD

INPUT

is

for

STR-DE425

only.

Design

and

specifications

are

subject

to

change

without

notice.

Glossary

Center

mode

Setting

of

speakers

to

enhance

Dolby

Pro

Logic

Surround

mode.

To

obtain

the

best

possible

surround

sound,

select

one

of

the

following

four

center

modes

according

to

your

speaker

system.

*

NORMAL

mode

Select

NORMAL

mode

if

you

have

front

and

rear

speakers

and

a

small

center

*

speaker.

Since

a

small

speaker

cannot

produce

enough

bass,

the

bass

sound

of

the

center

channel

is

output

from

the

front

speakers.

Center

speaker

Front

speaker

(R)

Front

speaker

(L)

|_|

Rear

speaker

(R)

Rear

speaker

(L)

¢

WIDE

mode

Select

WIDE

mode

if

you

have

front

and

rear

speakers

and

a

large

center

speaker.

With

the

WIDE

mode,

you

can

take

full

advantage

of

Dolby

Surround

sound.

Center

speaker

Front

speaker

(L)

speaker

(R)

ce

Ge

Rear

speaker

(L)

Rear

speaker

(R)

*

PHANTOM

mode

Select

PHANTOM

mode

if

you

have

front

and

rear

speakers

but

no

center

speaker.

The

sound

of

the

center

channel

is

output

from

the

front

speakers.

Front Front

speaker

(L)

speaker

(R)

=\=1s

[ee

oa)

of

|

Rear

speaker

(1)

speaker

(R)

¢

3

CH

LOGIC

mode

Select

3

CH

LOGIC

mode

if

you

have

front

and

center

speakers

but

no

rear

speaker.

The

sound

of

the

rear

channel

is

output

from

the

front

speakers

to

let

you

experience

some

of

the

surround

sound

without

using

rear

speakers.

Center

Front

speaker

(R)

Front

speaker

(L)

Dae

fe

Delay

time

Time

lag

between

the

surround

sound

output

from

front

speakers

and

rear

speakers.

By

adjusting

the

delay

time

of

the

rear

speakers,

you

can

obtain

the

feeling

of

presence.

Make

the

delay

time

longer

when

you

have

placed

the

rear

speakers

in

a

small

room

or

close

to

your

listening

position,

and

make

it

shorter

when

you

have

placed

them

ina

large

room

or

apart

from your

listening

position.

Direct

tuning

Tuning

method

to

let

you

directly

enter

a

station’s

frequency

using

the

numeric

buttons.

Use

this

method

if

you

know

the

frequency

of

the

station

you

want.

Dolby

Pro

Logic

Surround

Decoding

system

of

Dolby

Surround

sound

standardized

in

TV

programs

and

movies.

Compared

with

the

former

Dolby

Surround

system,

Dolby

Pro

Logic

Surround

improves

sound


by

using

four

separate

channels:

off-screen

audio

effects,

on-screen

dialog,

left-to-right

panning,

and

music.

These

channels

manipulate

the

sound

to

be

heard

and

enhance

the

action

as

it

happens

on

the

screen.

To

take

advantage

of

Dolby

Pro

Logic,

you

should

have

at

least

one

pair

of

rear

speakers

and/or

one

center

speaker.

You

also

need

to

select

the

appropriate

center

made

to

|

enjoy

a

full

effect.

5.1/DVD

INPUT

.Jacks

used

to

input

the

audio

signals

that

are

decoded

from

the

Dolby

Digital

AC-3

format

audio.

The

jacks

are

usually

connected

with

an

AC-3

decoder

or

a

DVD

player

equipped

with

an

AC-3

decoder.

This

connection

enables

the

amplifier

to

reproduce

5.1

channel

surround

sounds.

Preset

station

A

radio

broadcasting

station

that

is

stored

in

memory

of

the

receiver.

Once

vou

“preset”

stations,

vou

no

longer

have

to

tune

in

the

stations.

Each

preset

station

is

assigned

its

own

preset

number,

which

lets

you

tune

them

in

quickly.

Surround

sound

Sound

that

consists

of

three

elements:

direct

sound,

early

reflected

sound

(early

reflections)

and

reverberative

sound

(reverberation).

The

acoustics

where

you

hear

the

sound

affect

the

way

these three

sound

elements

are

heard.

These

sound

elements

are

combined

in

such

a

way

that

you

can

actually

feel

the

size

and

the

type

of

a

concert

hall.

©

Types

of

sound

Reverberation

Early

reflections

:

¢

Transition

of

sound

from

rear

speakers

Direct

sound

Early

reflections

Reverbe

Reverberation

ia

Early

reflection

time

Time

Level|

;

Test

tone

Signal

given

out

by

the

receiver

for

adjusting

the

speaker

volume.

The

test

tone

will

come

out

as

follows:

*

Ina

system

with

a

center

speaker

(NORMAL/WIDE/3

CH

LOGIC

modes)

The

test

tone

is

output

from

the

front

L

(left),

center,

front

R

(right),

and

rear

speakers

in

succession.

Front

(L)

Center

Front

(R)

r-*!

3

CH

LOGIC

“A

Rear

(L,

R)

qf

at

NORMAL/WIDE

¢

Ina

system

without

a

center

speaker

(PHANTOM

mode)

The-test

tone-is

output

from

the

front

and

the

rear

speakers

alternately.

Front

(L,

R)

PHANTOM

)

Rear

(LR)

12

20

A,

B

Adjusting

delay

time

16

speaker

volume

16

tone

9

volume

8

Antenna

hookups

5

Audio

component

hookups

5

6

Automatic

tuning

11

,

Center

mode

15,

19

NORMAL

mode

_

15,

19

PHANTOM

mode_

15,

19

3

CH

LOGIC

mode

15,

19

WIDE

mode

_

15,

19

Connecting.

See

Hookups

Delay

time

16,

19

Direct

tuning

11,19

Dolby

Digital

AC-3

decoder

7

Dolby

Pro

Logic

Surround

19

getting

the

most

out

of

15

Dolby

Surround

sound

14,

19

center

mode

16,

19

Dubbing.

See

Recording

E,

F,

G

Editing.

See

Recording

H,

I,

J,

K,

L,

M

Hookups

AC

power

cord

8

antennas

5

audio

components

5,6

overview

4

»

Speakers

6,7

video

component

7

N,

O

NORMAL

mode

15,

19

P

PHANTOM

mode

_

15,

19

Preset

station

19

Tuning

12

Presetting

radio

stations

12

Program

source

selecting

8,9

Q

Quick

reference

guide

23

R

Rear

panel

5,6, 7,8,

21

Receiving

broadcasts

directly

11

using

preset

stations

12

Recording

ona

minidisc

13

onatape

13

ona

video

tape

13

Remote

buttons

9,

10,

22

s

T

U

Vv

Scanning

preset

stations

12

radio

stations

11

Selecting

a

program

source

8

using

the

remote

9

Sleep

Timer

13

Speakers

connection

6,7

impedance

18

placement

6

selecting

speaker

system

7

Storing

radio

stations.

See

Presetting

Surround

sound

14,

19

Test

tone

16,

19

3

CH

LOGIC

mode

15,19

Troubleshooting

17

Tuning.

See

Receiving

broadcasts

Unpacking

4

Video

component

hookups

7

W,

X,

Y,

Z

Watching

/listening

to

video

programs

9

WIDE

mode

15,

19

Sony STR-DE425 - Fm Stereo/fm-am Receiver User manual
