Sony CMT-EH10 User manual

CMT-EH10
MicroHi-FiComponentSystem
10WattsTotal:5WattsperChannelx2(RMS10%THD)
PC/AudioInforDigitalMusicPlayersorPCInput
CD-R/RWwithMP3PlaybackCompatible
1
SynchronizedCD/CassetteDubbing
BassReflexSpeakerDesign
30-stationRandomMemoryPreset
3-WayTimer(Play/Sleep)

LastUpdated:02/06/2007
CMT-EH10
MicroHi-FiComponentSystem
PleasevisittheDealerNetworkforcurrentinformationatwww.sony.com/dn
Features
10 Watts Total: 5 Watts per Channel x 2 (RMS 10% THD) Plenty of
power for small rooms or offices.
Top- Loading Single CD Player Provides direct access to insert or
replace CD’s.
CD-R/RW with MP3 Playback Compatible The player will decode
and play back MP3 files that have been recorded onto a CD-R/RW
disc. This allows the customer to record hours of music from their
PC onto a CD-R/RW disc.
1
Synchronized CD/Cassette Dubbing Starts cassette recording when
compact disc playback begins
Bass Reflex Speaker Design A speaker enclosure that includes a
"tuned" port to increase and extend bass response (by releasing
some of the energy created by the inward movement of the woofer
cone).
PC/Audio In for Digital Music Players or PC Input An exciting new
feature that takes music playback beyond tape and CD. It allows
simple plug-and-play integration with a digital music device or PC
via a 2.5 mm jack.
Specifications
General
Type of Use: Desktop Micro System
Tray Type: Top Loading Single CD (Semiconductor Laser 780nm)
Disc Capacity: 1
Audio
Digital -to-Analog Converter: 1 Bit
Frequency Response: CD: 20-20000Hz
Format(s) Supported: CD-DA, CD-R/RW, CDs with MP3 Playback
Capability
Tuning: Auto Scan Radio
Antenna System: AM: Loop Antenna, FM: Lead Antenna
Tape System: 4 Track, 2 Channel Stereo Cassette, Synchronized
CD/Cassette Dubbing
Frequency Range: AM: 530-1710kHz; FM: 87.5-108.0MHz
CD Play Mode(s): Program, Shuffle, Repeat
Station Preset(s): 30 (10 AM, 20 FM)
Sound Enhancer: DSGX (Dynamic Sound Generator X-tra), Mega Bass®
Equalizer: 7 Presets (Rock, Jazz, Classic, Hall, Live, Movie, Flat)
Tape Operation: Single Cassette Deck
Tuner Type: FM/AM Superheterodyne Tuner
Convenience Features
Timer Events: Record/Play/Sleep (Wake-up or Fall Asleep To Music-
Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Power
Power Requirements: AC 120V, 60Hz
Output Power: 10W Total (5W + 5W (6 ohms at 1 kHz, 10% THD))
Dimensions
Weight: Speaker: 3 lbs 1 oz (1.4 Kg) (each x 2); Main Unit: 6 lbs 3 oz (2.8
Kg)
Measurements: Speaker: 5 5/7 x 9 1/4 x 6 1/10" (145 x 235 x 155mm)
(each x 2); Main Unit: 6 5/11 x 9 1/4 x 10 7/16" (164 x 235 x 265mm)
Supplied Accessories
Instruction Manual
Remote Commander®Remote Control (RM-SC1)
Batteries x 2
FM Lead Antenna
UPC Code: 027242683532
1.CD - R/RWmedia/formatsarenotuniversallycompatible.
©2006SonyElectronicsInc.
Reproductioninwholeorinpartwithoutwrittenpermissionisprohibited.Allrightsreserved.SonyandRemote
CommanderaretrademarksofSony.Allothertrademarksarepropertyoftheirrespectiveowners.
Featuresandspecificationsaresubjecttochangewithoutnotice.Non - metricweightsandmeasuresare
approximate.
