Sony HCD-EC55 - Receiver System User manual

MHC-GX99/EC77/EC55.GB.2-899-084-11(1)
WARNING
To reduce the risk of re or electric shock,
do not expose this apparatus to rain or
moisture.
To prevent re, do not cover the ventilation of the
apparatus with news papers, table-cloths, curtains, etc.
And don’t place lighted candles on the apparatus.
To prevent re or shock hazard, do not place objects lled
with liquids, such as vases, on the apparatus.
Install this system so that the power cord can be
unplugged from the wall socket immediately in the event
of trouble.
Do not install the appliance in a conned space, such
as a bookcase or built-in cabinet.
is appliance is classied
as a CLASS 1 LASER
product. is marking
is located on the rear
exterior.
2-899-084-11(1)
Mini Hi-Fi
Component System
Operating Instructions GB
Owner’s Record
e model and serial numbers are located on the rear of the unit. Record the serial number in the space
provided below. Refer to them whenever you call upon your Sony dealer regarding this product.
Model No. ______________ Serial No. ______________
MHC-GX99
MHC-EC77/EC55
© 2007 Sony Corporation Printed in China
Hooking up the system securely
Don’t throw away the battery with
general house waste, dispose of it
correctly as chemical waste.
NOTICE FOR THE CUSTOMERS IN
THE UNITED KINGDOM
A moulded plug complying with BS1363 is tted to this
equipment for your safety and convenience.
Should the fuse in the plug supplied need to be replaced,
a fuse of the same rating as the supplied one and
approved by ASTA or BSI to BS1362, (i.e., marked with
or mark) must be used.
If the plug supplied with this equipment has a detachable
fuse cover, be sure to attach the fuse cover aer you
change the fuse. Never use the plug without the fuse
cover. If you should lose the fuse cover, please contact
your nearest Sony service station.
NOTICE FOR THE CUSTOMERS IN
THE U.S.A.
is symbol is intended to alert the
user to the presence of uninsulated
“dangerous voltage” within the
product’s enclosure that may be of
sucient magnitude to constitute a risk
of electric shock to persons.
is symbol is intended to alert the
user to the presence of important
operating and maintenance (servicing)
instructions in the literature
accompanying the appliance.
CAUTION
e use of optical instruments with this product will
increase eye hazard.
WARNING
is equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. ese limits are designed
to provide reasonable protection against harmful
interference in a residential installation. is equipment
generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
FM lead antenna
(Extend it horizontally.)
AM loop antenna
Wall socket
When carrying this system
1 Remove all discs to protect the CD mechanism.
2 Hold down CD on the unit, and press until
“STANDBY” appears.
3 After “LOCK”appears, unplug the power cord.
Speakers
Insert only the
stripped portion
of the cord.
Solid (Blue/)
Solid (Black/)
Basic Operations Adjusting the sound
To adjust the volume
Press VOLUME +/– on the remote (or turn the
VOLUME control on the unit) .
To add a sound eect
To Press
Generate a more dynamic
sound (Dynamic Sound
Generator X-tra)
DSGX on the unit.
Set the sound eect EQ .
To turn on the subwoofer (MHC-GX99 only)
Press SUBWOOFER ON/OFF in the lower part of the
subwoofer until the indicator on the subwoofer lights up.
* To adjust the sound output level for the subwoofer, turn the
SUBWOOFER LEVEL in the lower part of the subwoofer. Once you
have made the adjustment, the overall sound level can be adjusted
using VOLUME +/– on the remote (or turn the VOLUME control
on the unit) .
Playing a CD/MP3 disc
1 Select the CD function.
Press CD on the remote (or FUNCTION repeatedly)
.
2 Place a disc.
Press (open/close) on the unit, and place a
disc with the label side up on the disc tray. To place
additional discs, slide the disc tray with your nger as
shown below.
To close the disc tray, press (open/close) on the
unit.
Do not force the disc tray closed with your nger, as
this may damage the unit.
3 Select a disc.
If the discs are currently stopped, press DISC SKIP on
the remote (or DISC SKIP/EX-CHANGE on the unit)
. To change discs while in other functions, press
DISC 1 – 3 on the unit.
4 Start playback.
Press (play) (or CD (play/pause) on the unit)
.
To exchange other discs during playback, press DISC
SKIP/EX-CHANGE on the unit.
To Press
Pause playback (pause) on the remote (or CD
on the unit) . To resume
play, press the button again.
Stop playback (stop) .
Select a folder on an
MP3 disc +/– .
Select a track or le (go back/go forward)
on the remote ( on the
unit) .
Find a point in a
track or le
Hold down /(rewind/fast
forward) during playback, and
release the button at the desired
point.
Select Repeat Play REPEAT on the remote
repeatedly until “REP” or “REP1”
appears.
To change the play mode
Press PLAY MODE repeatedly while the player is
stopped. You can select normal play (no display for all
discs or “1 DISC” for a disc or “ ” for all MP3 les
in the folder on the disc), shue play (“SHUF” for
all discs shue, “1 DISC SHUF” for one disc shue
or “ SHUF*” for folder shue), or program play
(“PGM”).
* When playing a CD-DA disc, (SHUF) Play performs the same
operation as 1 DISC (SHUF) Play.
Notes on Repeat Play
All tracks or les on a disc are played repeatedly up to ve times.
You cannot select “REP” and “SHUF” (all discs shue) at the same
time.
“REP1” indicates that a single track or le is repeated until you stop
it.
Notes on playing MP3 discs
Do not save other types of tracks or les or unnecessary folders on a
disc that has MP3 les.
Folders that have no MP3 les are skipped.
MP3 les are played back in the order that they are recorded onto
the disc.
e system can only play MP3 les that have a le extension of
“.MP3”.
If there are les on the disc that have the “.MP3” le extension,
but that are not MP3 les, the unit may produce noise or may
malfunction.
e maximum number of:
loadable sessions on a single disc is 10.
folders is 150 (including the root folder).
MP3 les is 255.
MP3 les and folders that can be contained on a single disc is 300.
folder levels (the tree structure of les) is eight.
Compatibility with all MP3 encoding/writing soware, recording
device, and recording media cannot be guaranteed. Incompatible
MP3 discs may produce noise or interrupted audio or may not play
at all.
Notes on playing multisession discs
If the disc begins with a CD-DA (or MP3) session, it is recognized
as a CD-DA (or MP3) disc, and playback continues until another
session is encountered.
A disc with a mixed CD format is recognized as a CD-DA (audio)
disc.
Listening to the radio
1 Select “FM” or “AM.”
Press TUNER/BAND repeatedly.
2 Select the tuning mode.
Press TUNING MODE repeatedly until “AUTO”
appears.
3 Tune in the desired station.
Press +/– on the remote (or TUNING + or – on the
unit) .
Scanning stops automatically when a station is tuned
in, and then “TUNED” and “STEREO” (for stereo
programs) appear.
To stop automatic scanning
Press (stop) .
To tune in a station with a weak signal
If “TUNED” does not appear and the scanning does
not stop, press TUNING MODE repeatedly until
“MANUAL” appears and press +/– on the remote (or
TUNING + or – on the unit) repeatedly to tune in the
desired station.
To reduce static noise on a weak FM stereo
station
Press FM MODE on the remote repeatedly until
“MONO” appears to turn o stereo reception.
Playing a tape (Except for North
American model)
1 Select a tape function.
Press TAPE on the remote (or FUNCTION on the
unit repeatedly) .
2 Insert a tape.
Press (stop/eject) on the unit, and insert the
tape into the cassette holder. Make sure there is no
slack in the tape to avoid damaging the tape or the
tape deck.
3 Start playback.
Press (play) on the unit.
To Press
Pause playback (pause) on the unit. To resume
play, press the button again.
Stop playback (stop/eject) on the unit.
Rewind or fast
forward*
/on the unit.
* Be sure to press (stop/eject) on the unit aer the tape has
been wound or rewound to the end.
Note
Do not turn o the system during playback or recording.
Changing the display
To Press
Change
information on the
display*
DISPLAY repeatedly when the
system is turned on.
Change Display
mode (See below.)
DISPLAY repeatedly when the
system is turned o.
* For example, you can view CD/MP3 disc information, such as the
track or le number or folder name during normal play, or the total
playing time while the player is stopped.
e system oers the following display modes.
Display mode When the system is o1),
Power Saving
Mode2)
e display is turned o to conserve
power. e timer and clock continue
to operate.
Clock3) e clock is displayed.
1) e STANDBY indicator on the unit lights up when the system is
o.
2) You cannot set the clock in Power Saving Mode.
3) e clock display automatically turns to Power Saving Mode aer
eight seconds.
Notes on the display information
Characters that cannot be displayed appear as “_”.
e following are not displayed;
total playing time for an MP3 disc.
remaining playing time for an MP3 le.
e following are not displayed correctly;
elapsed playing time of an MP3 le encoded using a VBR (variable
bit rate).
folder and le names that do not follow either the ISO9660 Level
1, Level 2 or Joliet in the expansion format.
e following are displayed;
total playing time for a CD-DA disc when the play mode is “1
DISC”.
remaining playing time for a track.
ID3 tag information for MP3 les when ID3 version 1 and version
2 tags are used (ID3 version 2 tag information display has priority
when both ID3 version 1 and version 2 tags are used for a single
MP3 le).
up to 15 characters of ID3 tag information using uppercase letters
(A to Z), numbers (0 to 9), and symbols (‘< > * + , – / @ [ \ ] _).
CAUTION
You are cautioned that any changes or modications
not expressly approved in this manual could void your
authority to operate this equipment.
Disposal of Old Electrical & Electronic
Equipment
(Applicable in the European Union and
other European countries with separate
collection systems)
is symbol on the product or on its packaging indicates
that this product shall not be treated as household
waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and
electronic equipment. By ensuring this product is
disposed of correctly, you will help prevent potential
negative consequences for the environment and human
health, which could otherwise be caused by inappropriate
waste handling of this product. e recycling of materials
will help to conserve natural resources. For more detailed
information about recycling of this product, please
contact your local Civic Oce, your household waste
disposal service or the shop where you purchased the
product.
Note on DualDiscs
A DualDisc is a two sided disc product which mates
DVD recorded material on one side with digital
audio material on the other side. However, since the
audio material side does not conform to the Compact
Disc (CD) standard, playback on this product is not
guaranteed.
Music discs encoded with copyright
protection technologies
is product is designed to playback discs that conform
to the Compact Disc (CD) standard. Recently, various
music discs encoded with copyright protection
technologies are marketed by some record companies.
Please be aware that among those discs, there are some
that do not conform to the CD standard and may not be
playable by this product.
MPEG Layer-3 audio coding technology and patents
licensed from Fraunhofer IIS and omson.
Subwoofer
(MHC-GX99 only)
Connect the subwoofer
to the SUBWOOFER
OUT jack with the
subwoofer cable
(supplied).
MHC-EC55 only
Subwoofer (MHC-GX99 only)
Place the subwoofer vertically to obtain a better bass reproduction.
Also, position the subwoofer:
on a solid oor where resonance is unlikely to occur.
at least a few centimeters away from the wall.
away from the center of the room or place a bookshelf against a wall, to avoid
generating a standing wave.
Speaker pads
Attach the supplied speaker pads to the bottom of the front speakers
and subwoofer to prevent slipping.
Front speakers:
4 pads for each speaker
Subwoofer:
4 pads (MHC-GX99 only)
Left speaker (High freq.)
Solid (Red/)
Solid (Gray/)
Right speaker
(High freq.)
Power
Connect the power cord to a wall socket.
If the plug does not t the wall socket,
detach the supplied plug adaptor (only
for models equipped with an adaptor).
Right speaker
(Low freq.)
Left speaker (Low freq.)
* Except for North American model
Before using the system
To use the remote
Slide and remove the battery compartment lid , and
insert the two R6 (size AA) batteries (supplied), side
rst, matching the polarities shown below.
Notes on using the remote
With normal use, the batteries should last for about six months.
Do not mix an old battery with a new one or mix dierent types of
batteries.
If you do not use the remote for a long period of time, remove the
batteries to avoid damage from battery leakage and corrosion.
Batteries installed devices shall not be exposed to excessive heat such
as sunshine, re or the like.
To set the clock
1 Turn on the system.
Press (on/standby) .
2 Select the clock set mode.
Press CLOCK/TIMER SET on the remote. If the
current mode appears on the display, press /
on the remote repeatedly to select “CLOCK,” and
then press ENTER on the remote.
3 Set the time.
Press /on the remote repeatedly to set
the hour, and then press ENTER on the remote.
Use the same procedure to set the minutes.
e clock settings are lost when you disconnect the
power cord or if a power failure occurs.
Selecting a music source
Press the following buttons (or press FUNCTION
repeatedly).
To select Press
CD CD on the remote.
Tuner TUNER/BAND .
Tape1) TAPE on the remote.
Component2) (connected
using an audio cord)
FUNCTION repeatedly
(or AUDIO IN3) on
the remote) until
“AUDIO IN” appears.
1) Except for North American model.
2) If the component has the AVLS (Automatic Volume Limiter System)
or BASS BOOST function, turn o the function to avoid distorted
sound from the speakers.
3) North American model only.
*
Using optional audio components
To connect an optional headphones
Connect headphones to the PHONES jack on the
unit.
To connect an optional component
Connect additional audio source components to the
AUDIO IN jack on the unit using an analog audio
cord (not supplied). Turn down the volume on the
system, and then select the AUDIO IN function.
Antennas
Find a location and an orientation that provide good
reception, and then set up the antenna.
Keep the antennas away from the speaker cords and the
power cord to avoid picking up noise.
Voltage selector
For models with a voltage selector, set
VOLTAGE SELECTOR to the local
power line voltage.
*Saudi Arabian model: 120 – 127 V/220 – 240 V/
NO OPERATION

MHC-GX99/EC77/EC55.GB.2-899-084-11(1)
Creating your own CD program
(Program Play)
Use buttons on the remote to create your own program.
1 Press CD to select the CD function.
2 Press PLAY MODE repeatedly until “PGM” appears
while the player is stopped.
3 Press DISC SKIP to select a disc.
4 Press /(or /on the unit)
repeatedly until the desired track number appears.
When programing MP3 les, press +/–
repeatedly to select the desired folder, and then select
the desired le.
Selected track or le number
Total playing time of the
selected track
5 Press ENTER to add the track or le to the
program.
6 Repeat steps 3 through 5 to program additional
tracks or les, up to a total of 25 tracks or les.
7 To play your program of tracks or les, press (or
CD on the unit) .
e program remains available until you open the disc
tray. To play the same program again, select the CD
function, and press (or CD on the unit) .
To cancel Program Play
Press PLAY MODE repeatedly until “PGM”
disappears while the player is stopped.
To delete the last track or le of the program
Press CLEAR on the remote while the player is
stopped.
To view program information, such as total
track number of the program
Press DISPLAY repeatedly.
Presetting radio stations
You can preset your favorite radio stations and tune
them in instantly by selecting the corresponding preset
number.
1 Tune in the desired station (See “Listening to the
radio”
)
.
2 Press TUNER MEMORY on the remote.
Preset number
3 Press +/– (or TUNING + or – on the unit)
repeatedly to select your desired preset number.
If another station is already assigned to the selected
preset number, the station is replaced by the new
stations.
4 Press ENTER on the remote.
5 Repeat steps 1 through 4 to store other stations.
You can preset up to 20 FM and 10 AM stations. e
preset stations are retained for about half a day even
if you disconnect the power cord or if a power failure
occurs.
6 To call up a preset radio station, press TUNING
MODE repeatedly until“PRESET” appears, and
then press +/– (or TUNING + or – on the unit)
repeatedly to select the desired preset number.
Other Operations Recording onto a tape (Except for
North American model)
Use a TYPE I (normal) tape only.
You can record just the portions you like from a sound
source, including connected audio components.
Use buttons on the unit to control tape recording.
1 Insert a recordable tape into the cassette holder
with the side you want to record facing up.
2 Prepare the recording source.
Select the desired source to record.
Place the disc you want to record and press DISC
SKIP/EX-CHANGE to select a disc.
When recording a folder from an MP3 disc, press
PLAY MODE repeatedly to select “ ,” and then
press +/– repeatedly to select the desired
folder.
To record only your favorite CD tracks or MP3 les in
your desired order, perform steps 2 to 5 of “Creating
your own CD program.”
3 Start recording.
Press (record) , and then start playing the
desired recording source.
e CD starts playing automatically aer 10 seconds
have passed.
If there is noise while recording from the tuner,
reposition the appropriate antenna to reduce the
noise.
While recording, you cannot listen to other sources.
To stop recording
Press .
Tip
We recommend that you press rst, and then press to
avoid noise being recorded when you stop recording.
Using the timers
e system oers two timer functions. If you use both
timers, the Sleep Timer has priority.
Sleep Timer:
You can fall asleep to music. is function works even if
the clock is not set.
Press SLEEP on the remote repeatedly. If you select
“AUTO,” the system automatically turns o aer the
current disc or tape stops or in 100 minutes.
If the tape deck is still playing or recording at the set
time, the system turns o aer the tape deck stops.
Play Timer:
You can wake up to CD or tuner at a preset time.
Use buttons on the remote to control the Play Timer.
Make sure you have set the clock.
1 Prepare the sound source.
Prepare the sound source, and then press VOLUME
+/– to adjust the volume.
To start from a specic CD track or MP3 le, create
your own CD program.
2 Press CLOCK/TIMER SET .
3 Press /repeatedly to select “PLAY,” and
then press ENTER .
“ON TIME” appears, and the hour indication ashes.
4 Set the time to start playing.
Press /repeatedly to set the hour, and
then press ENTER .
e minute indication ashes. Use the procedure
above to set the minutes.
5 Use the same procedure as in step 4 to set the time
to stop playing.
6 Select the sound source.
Press /repeatedly until the desired
sound source appears, and then press ENTER . e
display shows the timer settings.
7 Press to turn o the system.
If the system is on at the preset time, the Play Timer
will not play.
To activate or check the timer again
Press CLOCK/TIMER SELECT , press /
repeatedly until “PLAY SEL” appears, and then press
ENTER .
To cancel the timer
Repeat the same procedure as above until “OFF” appears,
and then press ENTER .
To change the setting
Start over from step 1.
Tip
e Play Timer setting remains as long as the setting is not canceled
manually.
Troubleshooting
1 Make sure the power cord and speaker cords are
correctly and rmly connected.
2 Find your problem in the checklist below, and take
the indicated corrective action.
If the issue persists, contact your nearest Sony dealer.
If the STANDBY indicator ashes
Immediately unplug the power cord, and check the
following item.
If your system has a voltage selector, is the voltage
selector set to the correct voltage?
Aer the STANDBY indicator on the unit stops
ashing, reconnect the power cord, and turn on the
system. If the issue persists, contact your nearest Sony
dealer.
General
The system does not turn on.
Is the power cord plugged in?
Is the voltage selector set correctly to match the
local power line voltage? Saudi Arabian models also
may not turn on when the voltage selector is set to
NO OPERATION.
There is no sound.
Are the + and – speaker cords short-circuited?
Are you using only the supplied speakers?
Is anything blocking the ventilation holes on the back
of the system?
Sound comes from one channel, or the left and
right volumes are unbalanced.
Place the speakers as symmetrically as possible.
Connect only the supplied speakers.
Severe hum or noise.
Move the system away from sources of noise.
Connect the system to a dierent wall socket.
Install a noise lter (available separately) to the power cord.
The remote does not function.
Remove any obstacles between the remote and the
remote sensor on the unit, and position the unit
away from uorescent lights.
Point the remote at the system’s sensor.
Move the remote closer to the system.
CD/MP3 player
The sound skips, or the disc will not play.
Wipe the disc clean, and replace it.
Move the system to a location away from vibration (for
example, on top of a stable stand).
Move the speakers away from the system, or place them
on separate stands. At high volume, speaker vibration
may cause the sound to skip.
Play does not start from the rst track.
Return to Normal Play by pressing PLAY MODE
repeatedly until both “PGM” and “SHUF” disappear.
Starting playback takes more time than usual.
e following discs take a longer time to start playback.
a disc recorded with a complicated tree structure.
a disc recorded in multisession mode.
a disc that has not been nalized (a disc to which data
can be added).
a disc that has many folders.
The disc tray does not open and“LOCKED”
appears.
Contact your Sony dealer or local authorized Sony
service facility.
Tuner
Severe hum or noise, or stations cannot be
received. (“TUNED” or “STEREO” ashes on the
display.)
Connect the antenna properly.
Find a location and an orientation that provide good
reception, and then set up the antenna again.
Keep the antennas away from the speaker cords and the
power cord to avoid picking up noise.
Turn o nearby electrical equipment.
Tape deck (Except for North American
model)
The sound exhibits excessive wow or utter or
dropout.
Clean the capstans and pinch rollers. Also, clean and
demagnetize the tape heads. See “Precautions” for details.
To change the AM tuning interval
e AM tuning interval is factory-preset to 9 kHz or
10 kHz (for some areas: this function is not available on
the European, Russian and Saudi Arabian models).
Use buttons on the unit to change the AM tuning
interval.
1 Tune in any AM station, and then turn o the
system.
2 Press DISPLAY to display the clock.
3 While holding down TUNING + , press (on/
standby) .
All the AM preset stations are erased. To reset the
interval to the factory preset, repeat the procedure.
To improve tuner reception
Turn o CD player power by using the CD power
management function. By default, CD power is turned on.
Discs that have labels printed using ink that feels tacky
when touched
Notes on discs
Before playing, wipe the disc with a cleaning cloth from
the center out to the edge.
Do not clean discs with solvents, such as benzine
thinner, or commercially available cleaners or anti-
static spray intended for vinyl LPs.
Do not expose discs to direct sunlight or heat sources
such as hot air ducts, nor leave it in a car parked in
direct sunlight.
On safety
e unit is not disconnected from the AC power source
(mains) as long as it is connected to the wall outlet,
even if the unit itself has been turned o.
Completely disconnect the power cord (mains lead)
from the wall socket (mains) if it is not going to be used
for an extended period of time. When unplugging the
unit, always grip the plug. Never pull the cord itself.
Should any solid object or liquid get into the system,
unplug the system, and have it checked by qualied
personnel before operating it again.
e AC power cord can be changed only by a qualied
service facility.
On placement
Do not place the system in an inclined position or in
locations that are extremely hot, cold, dusty, dirty, or
humid or lacking adequate ventilation, or subject to
vibration, direct sunlight or a bright light.
Be careful when placing the unit or speakers on
surfaces that have been specially treated (for example,
with wax, oil, polish) as staining or discoloration of the
surface may result.
If the system is brought directly from a cold to a warm
location or is placed in a very damp room, moisture
may condense on the lens inside the CD player, and
cause the system to malfunction. In this situation,
remove the disc, and leave the system turned on for
about an hour until the moisture evaporates.
On heat buildup
Heat buildup on the unit during operation is normal
and is not cause for alarm.
Do not touch the cabinet if it has been used
continuously at a high volume because the cabinet may
have become hot.
Do not obstruct the ventilation holes.
On the speaker system
is speaker system is not magnetically shielded, and
the picture on nearby TV sets may become magnetically
distorted. In this situation, turn o the TV, wait 15 to 30
minutes, and turn it back on.
If there is no improvement, move the speakers far away
from the TV.
Cleaning the cabinet
Clean this system with a so cloth slightly moistened
with a mild detergent solution. Do not use any type
of abrasive pad, scouring powder, or solvent, such as
thinner, benzine, or alcohol.
To prevent a tape from being accidentally
recorded over
Break o the cassette’s overwrite protection tab from side
A or B as illustrated.
Break o the cassette
tab
To later reuse the tape for recording, cover the broken tab
with adhesive tape.
About a tape longer than 90 minutes
e use of the tape with more than 90 minutes of play
time is not recommended except for long, continuous
recording or playback.
Cleaning the tape heads
Use dry- or wet-type cleaning cassette (available
separately) aer every 10 hours of use, before you start an
important recording, or aer playing an old tape. Failure
to clean the tape heads can cause degraded sound quality
or an inability of the unit to record or play tapes. For
details, refer to the instructions of the cleaning cassette.
Demagnetizing the tape heads
Use a demagnetizing cassette (available separately) aer
every 20 to 30 hours of use. Failure to demagnetize
the tape heads can cause an increase in noise, a loss of
high frequency sound, and an inability to completely
erase tapes. For details, refer to the instructions of the
demagnetizing cassette.
Specications
Main unit
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(MHC-GX99, MHC-EC77 e United States model only)
Low channel
With 8 ohm loads, both channels driven, from 120 – 10,000 Hz; 60 watts
per channel minimum RMS power, with no more than 0.7% total harmonic
distortion from 250 milliwatts to rated output.
High channel
With 8 ohm loads, both channels driven, from 2,000 – 13,000 Hz; 60 watts
per channel minimum RMS power, with no more than 0.7% total harmonic
distortion from 250 milliwatts to rated output.
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC DISTORTION:
(MHC-EC55 e United States model only)
With 6 ohm loads, both channels driven, from 120 – 10,000 Hz; 45 watts
per channel minimum RMS power, with no more than 0.7% total harmonic
distortion from 250 milliwatts to rated output.
Amplier section
MHC-GX99
Front speaker:
RMS output power (reference):
Low channel
95 W + 95 W (per channel at 8 Ω, 1 kHz, 10% THD)
High channel
95 W + 95 W (per channel at 8 Ω, 8 kHz, 10% THD)
Subwoofer:
RMS output power (reference):
150 W (at 6 Ω, 80 Hz, 10% THD)
MHC-EC77
North American model:
RMS output power (reference):
Low channel
95 W + 95 W (per channel at 8 Ω, 1 kHz, 10% THD)
High channel
95 W + 95 W (per channel at 8 Ω, 8 kHz, 10% THD)
European and Russian models:
Power output (rated):
Low channel
45 W + 45 W (at 8 Ω, 1 kHz, 1% THD)
High channel
45 W + 45 W (at 8 Ω, 8 kHz, 1% THD)
RMS output power (reference):
Low channel
65 W + 65 W (per channel at 8 Ω, 1 kHz, 10% THD)
High channel
65 W + 65 W (per channel at 8 Ω, 8 kHz, 10% THD)
Other models:
e following are measured at AC 120, 127, 220, 240 V, 50/60 Hz
Power output (rated):
Low channel
50 W + 50 W (at 8 Ω, 1 kHz, 1% THD)
High channel
50 W + 50 W (at 8 Ω, 8 kHz, 1% THD)
RMS output power (reference):
Low channel
70 W + 70 W (per channel at 8 Ω, 1 kHz, 10% THD)
High channel
70 W + 70 W (per channel at 8 Ω, 8 kHz, 10% THD)
MHC-EC55
North American model:
RMS output power (reference):
65 W+ 65 W (per channel at 6 Ω, 1 kHz, 10% THD)
European and Russian models:
Power output (rated): 45 W + 45 W (at 6 Ω, 1 kHz, 1% THD)
RMS output power (reference):
65 W + 65 W (per channel at 6 Ω, 1 kHz, 10% THD)
Other models:
e following are measured at AC 120, 127, 220, 240 V, 50/60 Hz
Power output (rated): 45 W + 45 W (at 6 Ω, 1 kHz, 1% THD)
RMS output power (reference):
65 W + 65 W (per channel at 6 Ω, 1 kHz, 10% THD)
Inputs
AUDIO IN (stereo mini jack): Sensitivity 800 mV, impedance 47 kilohms
Outputs
PHONES (stereo mini jack): Accepts headphones with an impedance of 8 Ω
or more
SPEAKER: Accepts impedance of 6 to 8 Ω
SUBWOOFER OUT (MHC-GX99 only)
CD player section
System: Compact disc and digital audio system
Laser: Semiconductor laser (=770 – 810 nm)
Emission duration: continuous
Frequency response: 20 Hz – 20 kHz
Signal-to-noise ratio: More than 90 dB
Dynamic range: More than 88 dB
Tape deck section (Except for North American model)
Recording system: 4-track 2-channel, stereo
Tuner section
FM stereo, FM/AM superheterodyne tuner
Antenna:
FM lead antenna
AM loop antenna
FM tuner section:
Tuning range
North American model: 87.5 – 108.0 MHz (100 kHz step)
Other models: 87.5 – 108.0 MHz (50 kHz step)
Intermediate frequency: 10.7 MHz
AM tuner section:
Tuning range
Pan-American and Australian models:
530 – 1,710 kHz (with 10 kHz tuning interval)
531 – 1,710 kHz (with 9 kHz tuning interval)
European, Russian and Saudi Arabian models:
531 – 1,602 kHz (with 9 kHz tuning interval)
Other models:
530 – 1,610 kHz (with 10 kHz tuning interval)
531 – 1,602 kHz (with 9 kHz tuning interval)
Intermediate frequency: 450 kHz
Speaker
SS-EC77 for MHC-GX99/EC77
Speaker system: 3-way, 3-unit, bass-reex type
Speaker units
Woofer: 13 cm × 2, cone type
Tweeter: 4 cm, horn type
Nominal impedance: 8 Ω
Dimensions (w/h/d): Approx. 220 × 360 × 220 mm
Mass: Approx. 3.6 kg net per speaker
Subwoofer SA-WG99 for MHC-GX99 only
Speaker system: bass-reex type
Speaker units
Woofer: 20 cm, cone type
Nominal impedance: 6 Ω
Dimensions (w/h/d): Approx. 280 × 306 × 405 mm
Mass: Approx. 8.7 kg
SS-EC55S/SS-EC55 for MHC-EC55
Speaker system: 2-way, 2-unit, bass-reex type
Speaker units
Woofer: 16 cm, cone type
Tweeter: 4 cm, horn type
Nominal impedance: 6 Ω
Dimensions (w/h/d): Approx. 215 × 306 × 215 mm
Mass: Approx. 2.8 kg net per speaker
General
Power requirements:
North American model: AC 120 V, 60 Hz
European and Russian models: AC 230 V, 50/60 Hz
Australian model: AC 230 – 240 V, 50/60 Hz
Mexican model: AC 127 V, 60 Hz
Argentine model: AC 220 V, 50/60 Hz
Korean model: AC 220 V, 60 Hz
Saudi Arabian model: AC 120 – 127, 220 – 240 V, 50/60 Hz, adjustable with
voltage selector
Other models: AC 120, 220 or 230 – 240 V, 50/60 Hz, adjustable with voltage
selector
Power consumption:
MHC-GX99
USA model: 190 W
Canadian model: 245 VA
SA-WG99 (Subwoofer)
USA model: 115 W
Canadian model: 155 VA
MHC-EC77
USA model: 190 W
Canadian model: 245 VA
European and Russian models: 140 W
0.5 W (in Power Saving Mode)
Other models: 150 W
MHC-EC55
USA model: 95 W
Canadian model: 130 VA
European and Russian models: 95 W
0.5 W (in Power Saving Mode)
Other models: 95 W
Dimensions (w/h/d) (excl. speakers):
Approx. 200 × 306 × 410 mm
Mass (excl. speakers):
MHC-GX99
North American model: Approx. 6.1 kg
MHC-EC77
North American and European models: Approx. 6.1 kg
Other models: Approx. 6.4 kg
MHC-EC55
North American model: Approx. 5.0 kg
Other models: Approx. 5.3 kg
Supplied accessories: Remote Commander (1)/R6 (Size AA) batteries (2)/FM
lead/AM loop antenna (1)/Speaker pads MHC-GX99 (8) and for SA-WG99
(Subwoofer) (4), MHC-EC77/EC55 (8)/Subwoofer cable (MHC-GX99 only)
(1)
Design and specications are subject to change without notice.
Standby power consumption: 0.5 W
Halogenated ame retardants are not used in the
certain printed wiring boards.
Halogenated ame retardants are not used in cabinets.
(Except for the United States model)
1 Press CD on the remote (or FUNCTION repeatedly)
to select the CD function.
2 Press to turn o the system.
3 After “STANDBY” stops ashing, press DISPLAY
to display the clock and then press while
holding down on the unit.
“CD POWER OFF” appears. With CD player power
turned o, disc access time is increased. To turn on
CD player power, repeat the procedure until “CD
POWER ON” appears.
To reset the system to factory settings
If the system still does not operate properly, reset the
system to factory settings.
Use buttons on the unit to reset the unit to its factory
default settings.
1 Disconnect and reconnect the power cord, and then
turn on the system.
2 Press PLAY MODE , FUNCTION , and at
the same time.
All user-congured settings, such as preset radio
stations, timer, and the clock, are deleted.
Messages
CANNOT LOCK : e system cannot be locked aer
you have done the procedure of “When carrying this
system.”
COMPLETE : e preset operation ended normally.
FULL : You tried to program more than 25 tracks or les
(steps).
LOCKED : e disc tray does not open. Contact your
nearest Sony dealer.
NO DISC : ere is no disc in the player, or you have
loaded a disc that cannot be played.
NO STEP : All of the programed tracks have been erased.
NOT USED : You pressed an invalid button.
OVER : You have reached the end of the disc while
pressing during playback or pause.
PUSH SELECT : You tried to set the clock or timer during
timer operation.
PUSH STOP : You pressed PLAY MODE during
playback.
READING : e system is reading information from the
disc. Some buttons are not available.
SET CLOCK : You tried to select the timer when the clock
is not set.
SET TIMER : You tried to select the timer when the Play
Timer is not set.
TIME NG : e Play Timer start and end times are set to
the same time.
Display examples
Display indicates
2 (two)
5 (ve)
6 (six)
8 (eight)
0 (zero)
A
B
D
G
H
K
M
O
Q
R
S
Z
,
@
Precautions
Discs that this system CAN play
Audio CD
CD-R/CD-RW (audio data/MP3 les)
Discs that this system CANNOT play
CD-ROM
CD-R/CD-RW other than those recorded in music CD
format or MP3 format conforming to ISO9660 Level
1/Level 2, Joliet
CD-R/CD-RW recorded in multisession that have not
ended by “closing the session”
CD-R/CD-RW of poor recording quality, CD-R/
CD-RW
that have scratches or are dirty, or CD-R/CD-
RW recorded with an incompatible recording device
CD-R/CD-RW which is nalized incorrectly
Discs containing les other than MPEG 1 Audio Layer-
3 (MP3) les
Discs of non-standard shape (for example, heart,
square, star)
Discs that have adhesive tape, paper, or sticker attached
to them
Rental or used discs with attached seals where the glue
extends beyond the seal
Other manuals for HCD-EC55 - Receiver System
3
This manual suits for next models
5
Other Sony Stereo System manuals

Sony
Sony MHC-GX8000 - Mini Stereo System User manual

Sony
Sony CMT-SX2D User manual

Sony
Sony RDH-GTK37iP User manual

Sony
Sony HCD-HP7 - Hi Fi Components User manual

Sony
Sony DAV-FC9 - Dvd Dream System User manual

Sony
Sony CMT-GPX9DAB User manual

Sony
Sony MHC-RXD10AV User manual

Sony
Sony MHC-g880 User manual

Sony
Sony SRS-BTX300 User manual

Sony
Sony CMT-GPX6 - Micro Hifi Component System User manual
