SERVICE MANUAL

Model Name Using Similar Mechanism NEW

CD CD Mechanism Type CDM74-K6BD47S

Section Base Unit Name BU-K6BD47S

Optical Pick-up Name KSM-213DCP

TAPE Model Name Using Similar Mechanism HCD-XGR88

Section Tape Transport Mechanism Type CWM43RR23

MiNi Hi-Fi COMPONENT SYSTEM

E Model

HCD-GN600

Ver 1.0 2003.04

9-877-282-01 Sony Corporation

2003D0200-1 Home Audio Company

C2003.04 Published by Sony Engineering Corporation

SPECIFICATIONS

HCD-GN600 is the amplifier, CD player,

tape deck and tuner section in MHC-

GN600.

– Continued on next page –

Amplifier section

The following are measured at AC 127V, 60 Hz (Mexican model only)

The following are measured at AC 120, 220, 240V50/60 Hz

(except Mexican model)

DIN power output (rated) 130 + 130 watts

(6 ohms at 1 kHz, DIN)

Continuous RMS power output (reference)

165 + 165 watts

(6 ohms at 1 kHz, 10% THD)

Inputs

GAME (VIDEO): 1 Vp-p, 75 ohms

(phono jack)

GAME (AUDIO): Voltage 250 mV,

(phono jacks) impedance 47 kilohms

MD/VIDEO (AUDIO) IN: voltage 450 mV/250 mV,

(phono jacks) impedance 47 kilohms

MIC: sensitivity 1 mV,

(phone jack) impedance 10 kilohms

Outputs

VIDEO OUT: max. output level 1 Vp-p,

(phono jacks) unbalanced, Sync.

negative load impedance 75 ohms

PHONES: accepts headphones of

(stereo mini jack) 8 ohms or more

FRONT SPEAKER: accepts impedance of 6 to

16 ohms

CD player section

System Compact disc and digital audio system

Laser Semiconductor laser

(λ=795nm)

Laser Output Max. 44.6 µW*

*This output is the value measured at a

distance of 200 mm from the objective lens

surface on the Optical Pick-up Block with 7

mm aperture.

Frequency response 2 Hz – 20 kHz (±0.5 dB)

Wave length 795 nm

CD OPTICAL DIGITAL OUT

(Square optical connector jack, rear panel)

Wave length 660 nm

Output Level –18 dBm

Tape player section

Recording system 4-track 2-channel stereo

Frequency response 50 – 13,000 Hz (±3 dB),

using Sony TYPE I cassette

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

Notes on chip component replacement

• Never reuse a disconnected chip component.

• Notice that the minus side of a tantalum capacitor may be dam-

aged by heat.

Flexible Circuit Board Repairing

• Keep the temperature of the soldering iron around 270 ˚C dur-

ing repairing.

• Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering

or unsoldering.

CAUTION

Use of controls or adjustments or performance of procedures

other than those specified herein may result in hazardous ra-

diation exposure.

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED

LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS

AND IN THE PARTS LIST ARE CRITICAL TO SAFE

OPERATION. REPLACE THESE COMPONENTS WITH

SONY PARTS WHOSE PART NUMBERS APPEAR AS

SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-

LISHED BY SONY.

This appliance is classified as

a CLASS 1 LASER product.

The CLASS 1 LASER

PRODUCT MARKING is

located on the rear exterior.

Tuner section

FM stereo, FM/AM superheterodyne tuner

FM tuner section

Tuning range 87.5 –108.0 MHz

Antenna FM lead antenna

Antenna terminals 75 ohm unbalanced

Intermediate frequency 10.7 MHz

AM tuner section

Tuning range

North and Latin American

models: 530 –1,710 kHz

(with the interval set at 10 kHz)

531 –1,710 kHz

(with the interval set at 9 kHz)

Middle Eastern models: 531 –1,602 kHz

(with the interval set at 9 kHz)

Other models: 531 –1,602 kHz

(with the interval set at 9 kHz)

530 –1,710 kHz

(with the interval set at 10 kHz)

Antenna AM loop antenna

Antenna terminals External antenna terminal

Intermediate frequency 450 kHz

General

Power requirements

Mexican models: 127 V AC, 60 Hz

Argentina models: 220 V AC, 50/60 Hz

Other models: 120 V, 220 V or 230 - 240 V AC, 50/60 Hz

Adjustable with voltage selector

Power consumption 145 watts

Dimensions (w/h/d) Approx. 280 x 360 x 386.5 mm

Mass : Approx. 10.5 kg

Design and specifications are subject to change without notice.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

TABLE OF CONTENTS

1. SERVICING NOTES ................................................ 4

2. GENERAL

Location of Controls ....................................................... 5

3. DISASSEMBLY

3-1. Case ................................................................................. 8

3-2. Loading (Panel)............................................................... 8

3-3. Front Panel Assy ............................................................. 9

3-4. Tuner Pack, Sub Trans Board ......................................... 9

3-5. CD Mechanism Deck ...................................................... 10

3-6. Game In Board, Tape Mechanism Deck......................... 10

3-7. CD Switch Board, Display Board .................................. 11

3-8. Volume Board.................................................................. 11

3-9. Subwoofer Board, Rear Panel ........................................ 12

3-10. Main Board...................................................................... 12

3-11. Power Amp Board ........................................................... 13

3-12. SW Board, Driver Board................................................. 13

3-13. CD Board, CD Block Assy ............................................. 14

3-14. Sensor Board ................................................................... 14

3-15. Motor (TB) Board ........................................................... 15

3-16. Motor (LD) Board ........................................................... 15

4. TEST MODE.............................................................. 16

5. MECHANICAL ADJUSTMENTS....................... 20

6. ELECTRICAL ADJUSTMENTS

Deck section .................................................................... 20

CD Section ...................................................................... 22

7. DIAGRAMS

7-1. Circuit Board Location ................................................... 26

7-2. Block Diagram –CD Servo Section –........................... 28

Block Diagram –Tuner/Tape Deck Section –............... 29

Block Diagram –Main/Power Section –....................... 30

Block Diagram –Display Section –.............................. 31

7-3. Printed Wiring Board –CD Board –............................. 32

7-4. Schematic Diagram –CD Board –................................ 33

7-5. Printed Wiring Board –CD Mechanism Board –......... 34

7-6. Schematic Diagram –CD Mechanism Board –............ 35

7-7. Printed Wiring Boards –Main Board –......................... 36

7-8. Schematic Diagram –Main Board (1/3) –.................... 37

7-9. Schematic Diagram –Main Board (2/3) –.................... 38

7-10. Schematic Diagram –Main Board (3/3) –.................... 39

7-11. Printed Wiring Boards

–Game In, CD Switch Board –...................................... 40

7-12. Schematic Diagram

–Game In, CD Switch Board –...................................... 41

7-13. Printed Wiring Board –Display Board –...................... 42

7-14. Schematic Diagram –Display Board –......................... 43

7-15. Printed Wiring Board –Power Amp Board –................ 44

7-16. Schematic Diagram –Power Amp Board –................... 45

7-17. Printed Wiring Boards –Trans Board –........................ 46

7-18. Schematic Diagram –Trans Board –............................. 47

7-19. IC Block Diagram ........................................................... 48

7-20. IC Pin Function Description ........................................... 49

8. EXPLODED VIEWS

8-1. Case, Rear Panel Section ................................................ 54

8-2. Front Panel Section ......................................................... 55

8-3. Chassis Section ............................................................... 56

8-4. CD Mechanism Deck Section-1

(CDM74-K6BD47S) ....................................................... 57

8-5. CD Mechanism Deck Section-2

(CDM74-K6BD47S) ....................................................... 58

9. ELECTRICAL PARTS LIST ............................... 59

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

SECTION 1

SERVICING NOTES

NOTES ON HANDLING THE OPTICAL PICK-UP

BLOCK OR BASE UNIT

The laser diode in the optical pick-up block may suffer electro-

static break-down because of the potential difference generated

by the charged electrostatic load, etc. on clothing and the human

body.

During repair, pay attention to electrostatic break-down and also

use the procedure in the printed matter which is included in the

repair parts.

The flexible board is easily damaged and should be handled with

care.

NOTES ON LASER DIODE EMISSION CHECK

The laser beam on this model is concentrated so as to be focused

on the disc reflective surface by the objective lens in the optical

pick-up block. Therefore, when checking the laser diode emis-

sion, observe from more than 30 cm away from the objective lens.

LASER DIODE AND FOCUS SEARCH OPERATION

CHECK

Carry out the “S curve check” in “CD section adjustment” and

check that the S curve waveforms is output three times.

•MODEL IDENTIFICATION

– Back Panel –

MODEL PART No.

E2 model 4-244-103-0[]

E51 model 4-244-103-1[]

Mexican model 4-244-103-2[]

Argentina model 4-244-103-3[]

•Abbreviation

E2 : 120 V AC Area in E model

E51 : Chilean and Peruvian model

PART No.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

SECTION 2

GENERAL

ALBUM+/- qg

AMP MENU rd

CD r;

CD SYNC qj

DECK A wk

DECK B wd

DIRECTION 9

DISC 1~3 3

DISCSKIPEX-CHANGE4

Disc tray 6

DISPLAY ra

Display 2

EDIT9

EFFECT ON/OFFrf

FM MODE 8

GAME eh

GAME EQ ea

GAME INPUT (jacks)wj

GAME MIXING ef

GROOVEed

IR (receptor) rs

ILLUMINATION wl

MD (VIDEO) ej

MIC(jack) wh

MICLEVEL wg

MOVIE EQ qh

MUSIC EQ eg

OPEN/CLOSE Z5

P FILEwa

PHONES (jack) wf

PLAY MODE 7

Power illuminatore;

PUSH ENTERq;

REC PAUSE/START qk

REPEAT 8

SURROUND w;

TAPE A/B ek

TUNER/BAND el

TUNER MEMORY 7

VOLUME ws

SYMBOLS

@/1 (power) 1

hH (play)qa

x(stop) qs

X(pause) qd

.(go backward)qf

> + (go forward) qf

m(rewind) qg

M(fast forward)qg

V/v/B/bq;

AA (Eject A)es

AB (Eject B)ql

ALPHABETICAL ORDER

A - D

M - Q

wfwgwh

4 5 612 3

Mainunit

E - L

R - Z

This section is extracted from

instruction manual.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

RemoteControl

123

CD ql

CLEAR 7

CLOCK/TIMER SELECT 2

CLOCK/TIMER SET 3

D.SKIP 9

ENTER qd

EFFECT ON/OFFqf

GAME w;

MD (VIDEO) q;

PRESET - wd

PRESET + wf

PRESET EQ qj

P FILE qh

SURROUND

SLEEP 1

TAPE A/B qa

TUNER/BAND qk

TUNING - wa

TUNING + ws

VOL +/- 8

SYMBOLS

@/1 (power) 4

nN (play) wg

X(pause) 5

x(stop) 6

.(go backward)wd

>(go forward) wf

m(rewind) wa

M(fast forward)ws

M/m/</,qg

A - M

P - Z

ALPHABETICAL ORDER

This section is extracted from

instruction manual.

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

• This set can be disassembled in the order shown below.

SECTION 3

DISASSEMBLY

CASE

LOADING (PANEL)

SET

FRONT PANEL ASSY

CD SWITCH BOARD,

DISPLAY BOARD

CD BOARD,

CD BLOCK ASSY

OPTICAL PICK-UP

(KSS-213DCP)

VOLUME BOARD

SW BOARD,

DRIVER BOARD MOTOR (TB) BOARD

CD MECHANISM DECK GAME IN BOARD,

TAPE MECHANISM DECK

TUNER PACK,

SUB TRANS BOARD

MOTOR (LD) BOARD

SENSOR BOARD

REAR PANEL

MAIN BOARD

POWER AMP BOARD

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

Note: Follow the disassembly procedure in the numerical order given.

3-1. CASE

3-2. LOADING (PANEL)

Three screws

(case 3 TP2)

Five screws

(+BVTT3 x 6)

Case

Three screws

(case 3 TP2)

Two screws

(+BVTT3 x 6

)

CD mechanismdeck (CDM74-K6BD47S)

Turn the pulley to the arrow direction.

Front side

Pulley

Loading (panel)

Pull out disc tray

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

3-3. FRONT PANEL ASSY

3-4.TUNER PACK, SUBTRANS BOARD

Screw (BVTP3 x 10)

Four screws (BVTP3 x 10)

Front panel ASSY

From CN606 on Game in board

From deck B head

CN402

CN304

From deck A head

From CN607 on

Game in board

Two wires

(flat type)

Screw (BVTP3 x 10)

MAIN boar

Sub trans board

CN971

CN974

CN976

Wire (flat type)

(11 core)

Tuner pack

Two screw (BVTP3 x 10)

Three screws

(BVTP3 x 10)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

HCD-GN600

3-5. CD MECHANISM DECK

3-6. GAME IN BOARD,TAPE MECHANISM DECK

CD mechanism deck

Wire (flat type) (31 core)

Two screws (BVTP3 x 10

)

CN701

MAIN board

CN201

Tape mechanism deck

Three screws

(+BVTP2.6 x 8)

Shield plate (GHX)

Screw (+PTT2 x 4)

Two screws (+BVTP2.6 x 8)

Two screws

(+BVTP2.6 x 8

)

Two screws

(+BVTP2.6 x 8)

GAME IN board

Knob (MIC)

TEL 13942296513 QQ 376315150 892498299

http://www.xiaoyu163.com

Table of contents

Other Sony Stereo System manuals

Popular Stereo System manuals by other brands

Philips

Philips MCM398D/12 user manual

LG OM4560 owner's manual

JVC

JVC UX-G3 instructions

Odys

Odys ODYS - LOOP instruction manual

Aiwa

Aiwa NSX-AJ700 Service manual

Panasonic

Panasonic SC-AK100 operating instructions

Sharp

Sharp CD-G10000V Operation manual

Bogen

Bogen NEARSCAPES 4.1 manual

Panasonic

Panasonic SCPM29 - MINI HES W/CD PLAYER operating instructions

Meyer

Meyer LD-3 operating instructions

THOMSON

THOMSON MIC302U manual

Philips

Philips MCM530 Service manual

Cetacea Sound

Cetacea Sound CVS-II user guide

Denon

Denon UCD-250 Service manual

Exibel

Exibel BDX600-UK user manual

Sanyo

Sanyo DC-F320 Service manual

Philips

Philips FWM583X Specifications

Onkyo

Onkyo CBX 300 - CD / MP3 Clock Radio instruction manual

Sony HCD-GN600 User manual

Popular Stereo System manuals by other brands
