Mini Hi - Fi Shelf System
Index:
The Sony ® MHC - EC69i Mini Hi - Fi Music System
packs 100 watts of total power (50W x 2) into a
complete, easy to use system designed to fit your
lifestyle. Charge, play, and control your iPod ® .
The system also includes a CD player that plays
audio CDs, CD - R/RW discs and MP3 CDs.
3
2
1
Key FeaturesKey FeaturesKey FeaturesKey Features
Detailed FeaturesDetailed FeaturesDetailed FeaturesDetailed Features
SpecificationsSpecificationsSpecificationsSpecifications
Weights & MeasuresWeights & MeasuresWeights & MeasuresWeights & Measures
Supplied AccessoriesSupplied AccessoriesSupplied AccessoriesSupplied Accessories
FootnotesFootnotesFootnotesFootnotes See Larger ImageSee Larger ImageSee Larger ImageSee Larger Image
MHC - EC69I
IndexIndexIndexIndex

❍Made for iPod ® : charge, play and control your
iPod
❍Single disc CD player with CD - R/RW and MP3
playback capability
❍Audio - in for use with MP3 player, PC and more
❍100W (RMS) Total Power Output (50W x 2)
❍AM/FM tuner with 30 station presets
Key Features
2
1
3
Detailed Features
Made for iPod®
2
Charge, play, and control your compatible iPod.
Single Disc CD Player
With CD, CD - R/RW and MP3 Playback.
Accommodates not only factory - pressed CD - Audio
discs, but also consumer - recorded CD - R and CD -
RW discs .
1
MHC - EC69I
IndexIndexIndexIndex

2-way 2-driver, Bass Reflex Speaker
System
Woofer: 130 mm, cone type
Tweeter: 40mm, horn type
AM/FM Tuner with 30 Station Presets
Provides accurate, drift - free tuning of AM/FM
stations and allows you to preset up to 30 of your
favorite stations: 10 AM and 20 FM.
100W (RMS) Total Power Output (50W x 2) .
3
Remote Control with Full iPod® Menu
Control
Allows you to control your iPod from across the
room.
MHC - EC69I
IndexIndexIndexIndex

Convenience Features
Audio
Specifications
Timer Events: Play/Sleep
Power Save Mode: Yes
Digital - to - Analog Converter: 44.1kHz/24bit
Format(s) Supported: CD, CD - R, CD - RW, MP3
Antenna System: Simple Type
Impedance: 6 ohms
CD Play Mode(s): Normal, Shuffle, Program,
Repeat
Station Preset(s): FM 20/AM 10
Equalizer: Preset EQ: 7
Audio Power Output: Channel - wise Amp
Measurement: 50W x 2
Speaker Type: 2way
MHC - EC69I
IndexIndexIndexIndex

Speaker
Power
Inputs and Outputs
General -Power
Band: FM/AM
Woofer Size(s): 13cm
Tweeter: Unit: Horn, 4cm
Output Power: 100W Total
Battery Type: Remote Battery Size/Type:
AA/Manganese
PC Audio Input(s): Yes
Analog Audio Input(s) (Total): Audio Line:
3.5mm
Power Save Mode: Yes
MHC - EC69I
IndexIndexIndexIndex

Amplifier -Convenience
Amplifier -Convenience Features
Amplifier -Equalizer
Amplifier -Function
Timer: Play/Sleep (Tuner); Play/Sleep (CD
Timer)
Power Save Mode: Yes
Bass Boost function: DSGX
Preset Equalizer: 7
CD: Yes
Tuner: Yes
iPod1: Yes
Audio: Yes
DMPORT: Yes
MHC - EC69I
IndexIndexIndexIndex

Amplifier -Inputs and Outputs
Amplifier -Audio Power Output (Both
Channel )
Tuner -Audio Specs
Tuner -Audio Features
Front Speaker -General Features
Audio Line IN: 1 (3.5mm)
DIGITAL MEDIA PORT (Connector): Yes
Analog Audio Input(s): Audio Line: 3.5mm
Headphone Jack: Yes (3.5mm)
Front (RMS 10%THD): 50W x 2
Preset Channel: 20 (FM); 10 (AM)
Band: FM/AM
External Antenna: Simple Type
Speaker Terminal: pig tale
MHC - EC69I
IndexIndexIndexIndex

Front Speaker -Weight and
Measurements
Subwoofer -General Features
DVD/SA-CD/VCDCD Player -D/A Converter
DVD/SA-CD/VCDCD Player -Decoding
Format(s) for Sound
System: 2 - way
Length of Supplied Cable: 1.5m
Tweeter Unit Size: Horn, 4cm
Woofer Unit Size: 16cm
System: 2 - way
Audio: 44.1kHz/24bit
8cm Disc (CD): Yes
CD: Yes
CD - R: Yes
CD - RW: Yes
MHC - EC69I
IndexIndexIndexIndex

DVD/SA-CD/VCDCD Player -Play Mode(s)
DVD/SA-CD/VCDCD Player - Text
Information
UPC Code
MP3: Yes
Normal: 1 Disc; 1 Folder
Program: Yes
Repeat: Yes
Shuffle: 1 Disc; 1 Folder
ID3Tag Ver. 1.1: Yes
ID3Tag Ver. 2.0: Yes
MP3 File name: Yes
027242752276
MHC - EC69I
IndexIndexIndexIndex

Weights & Measurements
Dimensions (Approx.): Main Unit:200 x 306 x
415 (WHD); Front Speaker: 220 x 306 x 195
(WHD); Front Speaker: 220 x 306 x 195 (WHD)
Weight (Approx.): Main Unit: 5.3Kg; Front
Speaker: 2.3Kg; Front Speaker: 2.3Kg
Cord Length (Approx.): Supplied Cable:1.5m
Supplied Accessories
-
RM - AMU009 Remote Control
-
TDM - iP10 Digital Media Port
Footnotes
1. Not all WMA and MP3 files may play back due to file variations.
Playback depends on recording conditions.
2. Compatible with iPod touch, iPod nano 3rd generation, iPod classic,
iPod nano 2nd generation, iPod 5th generation, iPod nano 1st
generation, iPod 4th generation, iPod mini.
3. Unit audio output tested at 6 ohms in frequency range 120 Hz to 10
kHz with a Total Harmonic Distortion of 0.07 percent.
