SERVICE MANUAL
ACTIVE SUPER WOOFER
US Model
SA-W303/W305
Canadian Model
AEP Model
UK Model
SA-W305
E Model
SA-W11/W305
Australian Model
SA-W305
Chinese Model
SA-W11
SPECIFICATIONS
SA-W11/W303/W305
Photo: SA-W305
Power requirements
Where purchased Power requirements
US, Canadian model 120 V AC, 60 Hz
AEP, UK, German, 220 – 230 V AC, 50/60 Hz
East European model
E, Australian, Chinese, 110 – 120/220 – 240 V AC,
Malaysia, Singapore model adjustable, 50/60 Hz
Ver 1.1 2001.11
9-922-813-12 Sony Corporation
2001K0500-1 Home Audio Company
C2001.11 Published by Sony Engineering Corporation

– 2 –
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized” knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
TheAC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers.).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit” indica-
tion is 0.75 V, so analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex-
amples of a passive VOM that is suitable. Nearly all battery
operated digital multimeters that have a 2V AC range are suit-
able. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k Ω 0.15 µF
AC
voltmete
r
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground

1 2 3 4 5 6 7 8
OVER LOAD DET
F/F
OFFSET DET
LATCH/
AUTORESET
VCC ON
MUTE
AC OFF
DET
VCC
SECTION 1
GENERAL
• Location of Controls
REAR
• IC Block Diagram
IC302 µPC1237HA
SECTION 2
DIAGRAMS
LINE
IN OUT
IN OUT
+
–
+
–
+
–
+
–
SPEAKER
L
R
L
R
LINE
IN/OUT jack
SPEAKER IN/OUT
terminal
VOLTAGE SELECTOR switch
(E, Australian, Singapore,
Chinese, Malaysia)
FRONT
–3 ––4 –
POWER
switch LEVEL knob CUT OFF FREQ knob PHASE button
Note on Schematic Diagram:
•All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•2: nonflammable resistor.
•C: panel designation.
Note on PrintedWiring Boards:
•X: parts extracted from the component side.
Abbreviation:
AUS : Australian
CH : Chinese
CND : Canadian
EE : East European
G : German
MY : Malaysia
SP : Singapore
•U: B+ Line.
•V: B–Line.
•Voltages are dc with respect to ground under no-signal
conditions.
•Voltages are taken with aVOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Signal path.
F
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is each block.)
Note:
The components identi-
fied by mark 0or dotted
line with mark 0arecriti-
cal for safety.
Replace only with part
number specified.
Note:
Lescomposants identifiéspar
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.

Ref. No. Location
D301 B-7
D302 B-7
D303 A-8
D401 C-4
D402 D-4
IC101 C-9
IC102 D-8
IC302 A-9
IC401 C-7
IC402 D-7
Q101 C-10
Q401 A-9
–5 ––6 –
SA-W11/W303/W305
2-1. PRINTED WIRING BOARDS • See page 4 for Note.
• Semiconductor
Location
(MAIN Board)

SA-W11/W303/W305
2-2. SCHEMATIC DIAGRAM • See page 4 for Note. • See page 4 for IC Block Diagram.
–7 ––8 –
The components identified by mark 0or dotted
line with mark 0are critical for safety.
Replaceonly withpart numberspecified.
Lescomposants identifiésparune marque0sont
critiques pourla sécurité. Neles remplacer que
par une piéce portant le numéro spécifié.

–9 ––10 –
SECTION 3
EXPLODED VIEW
Les composants identifiés par une
marque 0sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Hardware (# mark) list and accessories are
given in the last of the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
• Abbreviation
AUS : Australian G : German
CH : Chinese MY : Malaysia
CND: Canadian SP : Singapore
EE : East European
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SECTION 4
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AUS : Australian G : German
CH : Chinese MY : Malaysia
CND: Canadian SP : Singapore
EE : East European
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
Les composants identifiés par une
marque 0sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
1 X-4949-571-1 FRAME ASSY, GRILLE (W11: E, MY/S305)
1 X-4950-129-1 FRAME ASSY, GRILLE (W303)
1 X-4950-219-1 FRAME ASSY, GRILLE (W11: SP, CH)
2 X-4950-289-1 PANEL ASSY, FRONT (W305)
2 X-4950-290-1 PANEL ASSY, FRONT (W303)
2 X-4950-291-1 PANEL ASSY, FRONT (W11)
*3 1-669-259-11 CONTROL BOARD
4 4-973-938-01 KNOB (A), PUSH (W11: E, MY/W303/W305)
4 4-973-938-31 KNOB (A), PUSH (W11: SP, CH)
5 4-999-482-01 KNOB (VOL) (W11: E, MY/W303/W305)
5 4-999-482-11 KNOB (VOL) (W11: SP, CH)
*6 A-4384-984-A CABINET ASSY, SPEAKER
(W305: US, CND, UK)
*6 A-4384-985-A CABINET ASSY, SPEAKER (W11: E, MY/W305:
AEP, G, EE, SP, AUS/W303)
*6 A-4411-176-A CABINET ASSY, SPEAKER (W11: SP, CH)
*7 4-999-088-11 PANEL, REAR (US, CND)
*7 4-999-088-23 PANEL, REAR (E, SP, MY, AUS, CH)
*7 4-999-088-31 PANEL, REAR (AEP, UK, G, EE)
8 3-710-901-11 SCREW, TAPPING
09 1-696-845-31 CORD, POWER (AUS)
09 1-696-571-21 CORD, POWER (UK)
09 1-782-464-21 CORD, POWER (E, CH)
09 1-782-603-11 CORD, POWER (AEP, G, EE, SP, MY)
09 1-783-531-21 CORD, POWER (US, CND)
*10 3-703-244-00 BUSHING (2104), CORD
*11 A-4407-548-A MAIN BOARD, COMPLETE (US, CND)
*11 A-4407-550-A MAIN BOARD, COMPLETE (AEP, UK, G, EE)
*11 A-4407-551-A MAIN BOARD, COMPLETE
(E, SP, MY, AUS, CH)
*12 1-670-254-11 POWER IC BOARD
13 4-999-093-01 PACKING
014 1-569-008-11 ADAPTOR, CONVERSION 2P (SP, MY)
SP301 1-505-925-11 SPEAKER (16cm)
0T1 1-431-774-11 TRANSFORMER, POWER (US, CND)
0T1 1-431-775-11 TRANSFORMER, POWER (AEP, UK, G, EE)
0T1 1-431-776-11 TRANSFORMER, POWER (E, SP, MY, AUS, CH)
*1-669-259-11 CONTROL BOARD
**************
< CAPACITOR >
0C1 1-113-924-11 CERAMIC 0.0047uF 20% 250V
C201 1-136-169-00 FILM 0.22uF 5% 50V
C202 1-136-169-00 FILM 0.22uF 5% 50V
C203 1-136-170-00 FILM 0.27uF 5% 50V
C204 1-136-165-00 FILM 0.1uF 5% 50V
C205 1-126-963-11 ELECT 4.7uH 20% 50V
C206 1-126-964-51 ELECT 10uF 20% 50V
C207 1-126-963-11 ELECT 4.7uH 20% 50V
C208 1-104-664-11 ELECT 47uF 20% 25V
C209 1-104-664-11 ELECT 47uF 20% 25V
C210 1-126-963-11 ELECT 4.7uH 20% 50V
C211 1-126-965-11 ELECT 22uF 20% 50V
C212 1-126-964-51 ELECT 10uF 20% 50V
< CONNECTOR >
*CN3 1-770-314-11 PIN, CONNECTOR 2P
CN201 1-784-980-11 PLUG, CONNECTOR 9P
< DIODE >
D201 8-719-046-42 DIODE SEL5421E-TH8F (POWER)
< IC >
IC201 8-759-634-50 IC M5218AL
IC202 8-759-634-50 IC M5218AL
< TRANSISTOR >
Q201 8-729-178-59 TRANSISTOR 2SC2785
< RESISTOR >
R201 1-249-425-11 CARBON 4.7K 5% 1/4W
R202 1-249-425-11 CARBON 4.7K 5% 1/4W
R203 1-249-427-11 CARBON 6.8K 5% 1/4W
R204 1-249-427-11 CARBON 6.8K 5% 1/4W
R205 1-249-429-11 CARBON 10K 5% 1/4W
R206 1-249-429-11 CARBON 10K 5% 1/4W
R207 1-249-429-11 CARBON 10K 5% 1/4W
R208 1-249-429-11 CARBON 10K 5% 1/4W
R209 1-249-429-11 CARBON 10K 5% 1/4W
R210 1-249-429-11 CARBON 10K 5% 1/4W
R211 1-249-439-11 CARBON 68K 5% 1/4W
R212 1-249-417-11 CARBON 1K 5% 1/4W
R213 1-249-435-11 CARBON 33K 5% 1/4W
R214 1-247-887-00 CARBON 220K 5% 1/4W
R215 1-249-421-11 CARBON 2.2K 5% 1/4W
< VARIABLE RESISTOR >
RV201 1-223-905-11 RES, VAR, CARBON 20K/20K (CUT OFF FREQ)
RV202 1-223-905-11 RES, VAR, CARBON 20K/20K (LEVEL)
< SWITCH >
0S1 1-554-920-11 SWITCH, PUSH (1 KEY)(POWER)
S201 1-554-522-00 SWITCH, PUSH (1 KEY)(PHASE)
************************************************************
*A-4407-548-A MAIN BOARD, COMPLETE (US, CND)
*A-4407-550-A MAIN BOARD, COMPLETE (AEP, UK, G, EE)
*A-4407-551-A MAIN BOARD, COMPLETE
(E, SP, MY, AUS, CH)
*********************
1-533-233-11 HOLDER, FUSE
< CAPACITOR >
C101 1-136-167-00 FILM 0.15uF 5% 50V
C102 1-136-159-00 FILM 0.033uF 5% 50V
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C301 1-164-159-11 CERAMIC 0.1uF 50V
C303 1-126-933-11 ELECT 100uF 20% 16V
C304 1-162-215-31 CERAMIC 47PF 5% 50V
C305 1-126-967-11 ELECT 47uF 20% 50V
C306 1-126-967-11 ELECT 47uF 20% 50V
C307 1-136-169-00 FILM 0.22uF 5% 50V
C308 1-136-169-00 FILM 0.22uF 5% 50V
C309 1-104-665-11 ELECT 100uF 20% 10V
C310 1-126-963-11 ELECT 4.7uF 20% 50V
C311 1-104-664-11 ELECT 47uF 20% 25V
C401 1-136-165-00 FILM 0.1uF 5% 50V
C402 1-136-165-00 FILM 0.1uF 5% 50V
C403 1-119-940-51 ELECT 4700uF 20% 50V
9
9
9
9
9
14
10
7
11
13
12
3
4
1
2
5
6
4
SP301
not supplied
supplied with
RV201, 202
#2
not
supplied
not
supplied
#1
#2
#5
#5
#5
not
supplied
not
supplied
T1
not
supplied
#3
#3
#2
#4 #2
#2
#6
#4
8
UK
E, CH
AEP, G,
EE, MY,
SP
US, CND
AUS
MY, SP
CONTROL MAIN
Ver 1.1

– 11 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C404 1-119-940-51 ELECT 4700uF 20% 50V
C405 1-126-964-11 ELECT 10uF 20% 50V
C406 1-126-964-11 ELECT 10uF 20% 50V
C407 1-104-664-11 ELECT 47uF 20% 25V
C408 1-104-664-11 ELECT 47uF 20% 25V
< CONNECTOR >
CN1 1-564-321-00 PIN, CONNECTOR 2P
CN2 1-580-230-11 PIN, CONNECTOR (PC BOARD) 2P
CN101 1-785-093-11 PIN, CONNECTOR 8P
*CN301 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D401 8-719-025-03 DIODE RBA-402-SL
D402 8-719-991-33 DIODE 1SS133T-77
< FUSE >
0F1 1-532-500-31 FUSE (T0.63AL/250V) (AEP, UK, G, EE)
0F1 1-532-502-31 FUSE (T1.25AL/250V) (E, SP, MY, AUS, CH)
0F1 1-533-417-11 FUSE, GLASS CYLINDRICAL (DIA.5)
(1.25A/125V) (US, CND)
0F2 1-532-500-31 FUSE (T0.63AL/250V) (E, SP, MY, AUS, CH)
< IC >
IC101 8-759-634-50 IC M5218AL
IC102 8-759-634-50 IC M5218AL
IC302 8-759-111-68 IC uPC1237HA
IC401 8-759-077-92 IC NJM78L15A-T3
IC402 8-759-077-83 IC NJM79L15A-T3
< JACK >
J101 1-770-157-11 JACK, PIN 2P (LINE)
< TRANSISTOR >
Q101 8-729-178-59 TRANSISTOR 2SC2785
Q401 8-729-029-66 TRANSISTOR DTC114ESA
< RESISTOR >
R101 1-249-429-11 CARBON 10K 5% 1/4W
R102 1-249-429-11 CARBON 10K 5% 1/4W
R103 1-249-417-11 CARBON 1K 5% 1/4W
R104 1-249-417-11 CARBON 1K 5% 1/4W
R105 1-249-429-11 CARBON 10K 5% 1/4W
R106 1-249-429-11 CARBON 10K 5% 1/4W
R107 1-247-883-00 CARBON 150K 5% 1/4W
R108 1-247-883-00 CARBON 150K 5% 1/4W
R109 1-249-417-11 CARBON 1K 5% 1/4W
R110 1-249-417-11 CARBON 1K 5% 1/4W
R111 1-249-422-11 CARBON 2.7K 5% 1/4W
R112 1-249-426-11 CARBON 5.6K 5% 1/4W
R113 1-249-436-11 CARBON 39K 5% 1/4W
R114 1-249-435-11 CARBON 33K 5% 1/4W
R115 1-249-417-11 CARBON 1K 5% 1/4W
R116 1-249-424-11 CARBON 3.9K 5% 1/4W
R117 1-249-440-11 CARBON 82K 5% 1/4W
R118 1-249-417-11 CARBON 1K 5% 1/4W
R119 1-249-417-11 CARBON 1K 5% 1/4W
R301 1-249-427-11 CARBON 6.8K 5% 1/4W
R302 1-249-433-11 CARBON 22K 5% 1/4W
R303 1-249-412-11 CARBON 390 5% 1/4W
R304 1-249-433-11 CARBON 22K 5% 1/4W
R305 1-249-433-11 CARBON 22K 5% 1/4W
R307 1-260-069-81 CARBON 2.7 5% 1/2W
0R308 1-215-868-00 METAL OXIDE 680 5% 1W F
R309 1-249-441-11 CARBON 100K 5% 1/4W
R310 1-249-441-11 CARBON 100K 5% 1/4W
R311 1-249-430-11 CARBON 12K 5% 1/4W
R312 1-249-439-11 CARBON 68K 5% 1/4W
R313 1-249-427-11 CARBON 6.8K 5% 1/4W
0R401 1-215-869-11 METAL OXIDE 1K 5% 1W F
0R402 1-215-869-11 METAL OXIDE 1K 5% 1W F
R403 1-260-107-11 CARBON 4.7K 5% 1/2W
R404 1-260-107-11 CARBON 4.7K 5% 1/2W
R405 1-249-429-11 CARBON 10K 5% 1/4W
0R406 1-215-894-11 METAL OXIDE 2.2K 5% 2W F
< RELAY >
RY301 1-515-920-11 RELAY (24V)
< SWITCH >
0S2 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (E, SP, MY, AUS, CH)
< TRANSFORMER >
0T1 1-431-774-11 TRANSFORMER, POWER (US, CND)
0T1 1-431-775-11 TRANSFORMER, POWER (AEP, UK, G, EE)
0T1 1-431-776-11 TRANSFORMER, POWER (E, SP, MY, AUS, CH)
< TERMINAL >
TM101 1-537-922-11 TERMINAL BOARD (SP) (SPEAKER IN, OUT)
************************************************************
*1-670-254-11 POWER IC BOARD
**************
< CAPACITOR >
C302 1-162-286-31 CERAMIC 220PF 10% 50V
< CONNECTOR >
CN303 1-785-088-11 PIN, CONNECTOR 6P
< IC >
IC301 8-759-299-54 IC LM3886TF
< RESISTOR >
R306 1-249-435-11 CARBON 33K 5% 1/4W
************************************************************
The components identified by
mark 0or dotted line with
mark 0are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
MAIN POWER IC

– 12 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
SA-W11/W303/W305
MISCELLANEOUS
**************
09 1-696-571-21 CORD, POWER (UK)
09 1-696-845-31 CORD, POWER (AUS)
09 1-782-464-21 CORD, POWER (E, CH)
09 1-782-603-11 CORD, POWER (AEP, G, EE, SP, MY)
09 1-785-531-21 CORD, POWER (US, CND)
014 1-569-008-11 ADAPTOR, CONVERSION 2P (SP, MY)
SP301 1-505-925-11 SPEAKER (16cm)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-665-79 SCREW +BVTP 4X25 TYPE2 N-S
#2 7-685-647-79 SCREW +P 3X10 TYPE2 NON-SLIT
#3 7-685-664-79 SCREW +PTP 4X20 TYPE1
#4 7-685-663-79 SCREW +BVTP 4X16 TYPE2 N-S
#5 7-685-648-79 SCREW +P 3X12 TYPE2 NON-SLIT
#6 7-685-660-19 SCREW +BVTP 4X10 TYPE2 N-S
************************************************************
ACCESSORIES
************
1-751-598-11 CORD, CONNECTION (PIN-PIN)
1-769-433-11 CORD, SPEAKER
3-862-214-11 MANUAL, INSTRUCTION (ENGLISH)
(W303/W305: US, AEP, EE, E)
3-862-214-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(W11/W305: CND, UK, G, SP, AUS)
3-862-214-31 MANUAL, INSTRUCTION (GERMAN, SPANISH,
PORTUGUESE, DUTCH, ITALIAN, SWEDISH,
FINNISH, DANISH, CHINESE)
(W11/W305: G, SP)
The components identified by
mark 0or dotted line with
mark 0are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Ver 1.1

SA-W11/W303/W305
13
MEMO

SA-W11/W303/W305
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.1 2001.11 Correction of Part No. for power cord (US, Canadian model) (SPM-01047)
1.0 1998.04 New
