Sony Dash HID-C10 Operating manual

HID-C10
Important Information
Guide

Owner’s Record
The model number and serial number are located on the bottom of the
unit. Record the model and serial numbers in the space provided here
and keep it in a secure location. Refer to the model and serial numbers
when you call your Sony Service Center.
Notice
© 2010 Sony Electronics Inc. Reproduction in whole or in part without
written permission is prohibited. All rights reserved. This guide and the
software described herein, in whole or in part, may not be reproduced,
translated, or reduced to any machine-readable form without prior
written approval.
Model Number:
Serial Number:
This product is Wi-Fi Certified and complies
with the interoperability specifications
established by the Wi-Fi Alliance®.
For Your Convenience
Contact Sony Customer Support at: http://www.sony.com/mydash
or to speak with a support representative: 1-866-918-2485
Please Do Not Return the Product to the Store
Please contact Sony directly if you:
Have questionson the use of your unit after reading the Owner’sGuide and Important
Information Guide.
Experience difficulty operating your unit.
Sony will work to resolve your questionsmore quickly than your retailer or place of purchase.
Register your dash™ device at https://www.sony.com/mydash
•
•

WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture. The following caution is located on the AC power
adaptor label.
• To reduce the risk of fire or electric shock, do not expose this
apparatus to dripping or splashing, and do not place objects filled
with liquids, such as vases, on the apparatus.
• Do not install the AC power adaptor in a confined space, such as
a bookcase or built-in cabinet.
• The name plate is located on the bottom exterior of this unit.
• The AC power adaptor is not disconnected from the mains as long as
it is connected to the AC outlet.
• As the main plug of AC power adaptor is used to disconnect the AC
power adaptor from the mains, connect it to an easily accessible AC
outlet. Should you notice any abnormality in it, disconnect it from the
AC outlet immediately.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of elec-
tric shock to persons.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol is intended to alert the user to the
presence of important operating and mainte-
nance (servicing) instructions in the literature
accompanying the appliance.

NOTIFICATION
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interfer-
ence to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
CAUTION
You are cautioned that any changes or modifications not expressly
approved in this guide could void your authority to operate equipment.
HID_C10_Safety.book Page 3 Monday, December 28, 2009 2:11 PM

FCC Radiation Exposure
The available scientific evidence does not show that any health
problems are associated with using low power wireless devices. There
is no proof, however, that these low power Wireless devices are
absolutely safe. Low power wireless devices emit low levels of radio
frequency energy (RF) in the microwave range while being used.
Whereas high levels of RF can produce health effects (by heating
tissue), exposure to low-level RF that does not produce heating effects
causes no known adverse health effects. Many studies of low-level RF
exposures have not found any biological effects. Some studies have
suggested that some biological effects might occur, but such findings
have not been confirmed by additional research.
This device (HID-C10) has been tested and found to comply with the
Federal Communications Commission (FCC) guidelines on RF energy
exposure. The maximum SAR level tested for the AK8HIDC10 has been
shown to be 0.8 W/kg at Body. This transmitter must not be
co-located or operating in conjunction with any other antenna or
transmitter.

Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.

13. Unplug this apparatus during lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been
dropped.
CAUTION
Do not expose batteries or apparatus with battery-installed to excessive
heat such as sunshine, fire or the like.
For the state of California, USA only
Perchlorate Material: Special handling may apply, see
www.dtsc.ca.gov/hazardouswaste/perchlorate
Perchlorate Material: Lithium battery contains perchlorate
HID_C10_Safety.book Page 6 Monday, December 28, 2009 2:11 PM
exposed to rain or moisture, does not operate normally, or has been

Precautions
• To disconnect the AC power adaptor cord (mains lead), pull it out by
the plug, not the cord.
• Do not leave the unit in a location near a heat source such as a
radiator or air duct, or in a place subject to direct sunlight, excessive
dust, mechanical vibration, or shock.
• Allow adequate air circulation to prevent internal heat build up. Do
not place the unit on a surface (a rug, a blanket, etc.) or near
materials (a curtain) which might block the ventilation holes.
• Should any solid object or liquid fall into the unit, unplug the unit and
have it checked by qualified personnel before operating it any further.
• To clean the casing, use a soft cloth dampened with a mild detergent
solution. When cleaning, unplug the unit.
If you have any questions or problems concerning your unit, please
contact Sony customer support.
Notes on LCD screen
• The displayed image on the screen is not identical in picture quality
and colors with the printed image because phosphor methods or
profiles differ. Please regard the displayed image as just a reference.
• Do not press against the LCD screen with excessive force. The
screen may be discolored and that may cause a malfunction.
• Exposing the LCD screen to direct sunlight for long periods may
cause malfunction.
• The LCD screen is manufactured using extremely high-precision
technology, so over 99.99% of the pixels are operational for effective
use. However, there may be some tiny black points and/or bright
points (white, red, blue or green in color) that constantly appear on
the LCD screen. These points are normal in the manufacturing
process and do not affect the printing in any way.
• Images may trail across on the LCD screen in a cold location. This is
not a malfunction.
HID_C10_Safety.book Page 7 Monday, December 28, 2009 2:11 PM

Additional Information
Wireless Network
If unable to establish a reliable connection to the wireless router, please
check the following items.
• The wireless router is on.
• You are connected to the Internet.
• The network settings are correct.
• The device is in a location with a strong wireless signal.
Video quality
depends on the quality of the video provided by the video content
provider as well as your connected bandwidth.
• Black frame appears around the video - Some videos are filmed in
aspect ratios other than 16:9. Your unit will show these videos
surrounded by a black frame.
• Certain programs display a loss of detail, especially during fast
motion or dark scenes. Video quality and picture size varies and is
dependent upon broadband speed and delivery by content providers.
• If you experience problems with the video or audio playback, move
the unit and wireless router closer together.
• Try using a different wireless channel. There are normally three
choices: channel 1, 6, and 11.
• Verify that both the wireless router and the unit are not in close
proximity to a microwave oven.
• Verify that both the wireless router and the unit are not in close
proximity to a cordless phone. Please note that some 5.8GHz
cordless phones can also operate at 2.4GHz frequencies.
• Verify that both the wireless router and the unit are not in close
proximity to a device using Bluetooth, such as cell phones, PCs, etc.
HID_C10_Safety.book Page 9 Monday, December 28, 2009 2:11 PM
• Poor picture - The quality of the video displayed on your unit

No picture
• Make sure the unit’s AC power adaptor cord is connected securely to
the DC input jack.
• Make sure the AC power adaptor cord is connected to the wall securely.
• If a black screen appears, press the MENU/SNOOZE button to turn
the LCD panel back on.
• Check the video file you are playing is a supported video/container
format.
No sound/Poor sound
• Good picture, no sound - Check the volume control.
• Disconnect your headphones.
• Quality depends on content provided by the video content provider
as well as your connected bandwidth.
• Due to the nature of Internet video, not all videos will contain sound.
• Check the file you are playing is a supported audio format.
General
• In the event of a power failure the alarm functions will not work until
the power is restored.
• The unit’s indicator light is orange - Press MENU/SNOOZE button to
turn the LCD panel on.
• Video saved to My Video Links does not play - Videos removed by
the video content provider may no longer be accessible.
• The unit will not play music or video files that contain copy protection.
HID_C10_Safety.book Page 11Monday, December 28, 2009 2:11 PM

Supported Audio formats
*MPEG Layer-3 audio coding technology and patents licensed from Fraunhofer
IIS and Thompson.
*ID3 tag support for only ISO-8859-1.
MPEG-Layer III
(MP3)* Stereo/Mono
(2.0 audio profile)
32/44.1/48KHz
Up to 320kbps
MPEG-4
AAC-LC Stereo/Mono
(2.0 audio profile)
32/44.1/48KHz
Up to 384 kbps
WMA Stereo/Mono
(2.0 audio profile)
32/44.1/48 KHz
Up to 192 kbps(CBR)
Up to 384kbps(VBR)
HID_C10_Safety.book Page 11 Monday, December 28, 2009 2:11 PM

Supported Video Formats
Supported Video Container Formats
AVC BP@L3:
Up to 720x480@30p
Up to 720x576@25p
Up to 720x576@25p
[email protected]:
Up to 1920x1080@24p
Up to 1920x1080i@30i
Up to 1280x720@60p
VC-1(WMV9) MP@HL:
Up to 1280x720@30p
Up to 1920x1080@24p
AP@L2:
Up to 1280x720@30p
WMV Version: v9
Container: ASF
Audio: WMA (Stereo/Mono)
AVC Container: MP4, MOV
Audio: AAC-LC (Stereo/Mono)
Compliance IEEE 802.11b/g compliant
Frequency Range 2400~2483.5MHz
Modulation DSSS: DBPSK, DQPSK, CCK
OFDM: BPSK,QPSK,16QAM,64QAM
Data Rates 1, 2, 5.5, 11, 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Wireless Specifications
HID_C10_Safety.book Page 12 Monday, December 28, 2009 2:11 PM

Notices and Licenses for Excluded Software Used in this
Device
Third party software is used in this device. Such third party software
may change over time. Please visit www.sony.com/linux for (i) an
up-to-date list of the third party software included in each version of the
device; (ii) the license terms applicable thereto; and (iii) where required,
the source code associated therewith and available for download.
Please note, certain third party software included in the dash device
contains copyrighted software that is licensed under various versions of
the General Public License, which may include the General Public
License version 2, General Public License version 3, Lesser General
Public License version 2 or Lesser General Public License version 3
("GPL Software"). A copy of the relevant General Public License is
available in the applicable third party software and on our website at the
following address: www.sony.com/linux. You may obtain the complete
Corresponding Source code (as defined in the relevant General Public
License) from Sony Electronics Inc. for a period which is the longer of
three years after our last shipment of the dash Device or during the
period we offer spare parts or customer support for that product model,
which will end no earlier than 2/28/2013. To obtain the complete
Corresponding Source code on physical media, please contact Sony
Customer Support for the dash device at 866-918-2485.

©2010 Sony Electronics Inc.
Printed in USA
4-172-557-01
http://www.sony.com/mydash
*417255701*
