Sony WRR-802A User manual

3-867-234-23 (1)
Operating Instructions
Bedienungsanleitung
Wireless Channel Lists/Übertragungskanallisten
WRR-802A
© 1999 Sony Corporation
UHF Synthesized
DiversityTuner
[CE62] [CE69]
GB
DE

Luxembourg 800 - 814 MHz
Germany 800 - 814 MHz
Norway 800 - 814 MHz
Denmark 800.1 - 814 MHz
France 800 - 814 MHz
Italy 800 - 814 MHz
Sweden 800 - 814 MHz
Switzerland 800 - 814 MHz
Finland 800 - 814 MHz
Iceland 800 - 814 MHz
Hereby, Sony Corporation, declares that this WRR-802A is in
compliance with the essential requirements and other
relevant provisions of Directive 1999/5/EC.
Sony Corporation déclare par la présente que ce WRR-802A
est conforme aux exigences fondamentales et aux autres
dispositions applicables de la Directive 1999/5/CE.
Hiermit erklärt die Sony Corporation, daß das Modell
WRR-802A die grundlegenden Anforderungen und sonstigen
relevanten Bestimmungen der Richtlinie 1999/5/EU erfüllt.
Por la presente, Sony Corporation, declara que este
WRR-802A cumple con los requisitos esenciales y otras
disposiciones pertinentes de la Directiva 1999/5/EC.
Notice for customers in Europe
Spécifications particulières pour les consommateurs européens
Hinweis für Kunden in Europa
Aviso para los usuarios en Europa

1
GB
English
GB
Precautions............................................................... 1
Overview ...................................................................2
Features ................................................................. 2
System Configuration ........................................... 3
Channel Plan ......................................................... 4
Location of Parts and Controls............................... 5
Front Panel ............................................................ 5
Display .................................................................. 6
Rear Panel ............................................................. 7
Channel Setting........................................................ 8
Operation ................................................................10
Muting Functions ................................................ 12
Error Messages ......................................................12
Specifications......................................................... 13
Wireless Channel Lists........................................ L-1
PrecautionsTable of Contents
On operation
• The unit must be used within a temperature range of 0°C to
40°C. Avoid using the unit for extended periods at
extremely high temperatures or placing it in direct sunlight,
especially outdoors because this may damage the finish of
the case. Never install the unit on or near a heat source,
such as lighting equipment or power amplifiers.
• Avoid using in very humid or dusty places, because such
use may shorten the life of the unit.
• To avoid degradation of the signal-to-noise ratio, do not
use the unit in noisy places or in locations subject to
vibration, such as the following:
— near electrical equipment, such as motors, transformers
or dimmers
— near air conditioning equipment or places subject to
direct air flow from an air conditioner
— near public address loudspeakers
— where adjacent equipment might knock against the unit
• Switching lights on or off may produce electrical
interference over the entire frequency range. Position the
unit and the wireless microphones so that interference is
minimized.
• The unit is precisely adjusted at the factory and no
adjustment before use is necessary. Do not touch the
inside of the unit or try to repair it by yourself.
On cleaning
Clean the unit with a dry, soft cloth. Never use thinner,
benzene, alcohol or any other chemicals, since these may
damage the finish.

2
GB
CE69 model
An 8 MHz frequency band is assigned to the WRR-802A/
CE69 model, permitting it to operate on any of 64 receiving
frequencies in 125-kHz steps of Sony original channel plan
in the range of TV channel 69 or 14 receiving frequencies in
25-kHz steps of UK General Use.
The selectable wireless channels and frequencies for this
model are listed on page L-12 and L-13.
Features
Phase Locked Loop (PLL) synthesized system
The WRR-802A has a refined phase locked loop (PLL)
synthesizer circuit.
Preprogrammed wireless channel plan for
simultaneous multichannel operation
The WRR-802A has many preprogrammed, easily settable
channels in a simultaneous multichannel operation.
Overview
The WRR-802A is a reliable UHF synthesized diversity
tuner for the 800-MHz-band Sony UHF wireless
microphone system which uses the frequency bands
allocated for UHF TV broadcasting.
This unit is designed to enable simultaneous use of multiple
channels when channels are selected according to the
channel plan.
In building up a UHF wireless microphone system, be sure
to combine a microphone/transmitter and a tuner having the
same TV channel number (62 or 69).
CE62 model
A 14 MHz frequency band is assigned to the WRR-802A/
CE62 model, permitting it to operate on any of 111
receiving frequencies in 125-kHz steps of Sony original
channel plan or 561 receiving frequencies in 25-kHz steps of
German User Group in the range of TV channels 62 and 63.
The selectable wireless channels and frequencies for this
model are listed pages L-3 through L-11.

3
GB
Frequency band Model name
TV channel Transmitter or
microphone
Frequency
(MHz)
62 WRT-805A (62)
WRT-807A (62)
WRT-822A (62)
800.000 to
814.000 WRR-805A (62) WRR-802A (62)
MB-806A with
WRU-806A (62)
69 854.125 to
862.000 WRT-805A (69) WRT-807A (69)
WRT-822A (69)
WRR-805A (69)
WRR-802A (69)
MB-806A with
WRU-806A (69)
Tuner
Versatile display
A liquid-crystal display provides a variety of information,
including the levels of the reception channels, RF
information and transmitter battery alarm.
Space diversity reception system
The WRR-802A provides stable signal reception with
minimum dropout.
Tone squelch circuit for noise elimination
A built-in squelch circuit eliminates noise and signal
interference when the WRR-802A is in signal reception
standby mode.
Compander system
A compander (compressor/expander) system enables
stabilized wireless transmission over a wide dynamic range.
Adjustable audio output level
You can adjust the audio output level by volume.
System Configuration
The unit can be used with a Sony UHF synthesized wireless
microphone or UHF synthesized transmitter among the
models listed in the table below.
Sony 800 MHz-band system models

4
GB
Channel Plan
The unit stores several groups of channels. See “Overview
of Channel Plan” in the “Wireless Channel Lists” section.
Channel groups other than group 00 are designed so that all
channels of one group can be used simultaneously within the
same UHF wireless microphone system without causing
intermodulation. It is therefore recommended that you
usually use a channel group other than group 00 unless the
use of group 00 is specifically necessary.
Overview

5
GB
Location of Parts and Controls
Front Panel
1POWER switch
Turns the power on and off.
2ANTENNA A, B (antenna A, B) connectors (BNC
type)
Connect the supplied antennas.
The DC power voltage is not output from the antenna
connector.
3GP (group) button
To change the group, press the + or – button while holding
this button down.
4CH (channel) button
To change the channel in a group, press the + or – button
while holding this button down.
5+ button
To go to a higher group or channel, press this button while
holding the GP or CH button.
Press this button changes the indication from GP/CH to
frequency.
ON ANTENNA A VOL. ANTENNA B
OFF
POWER
MIN MAX
CH
GP +
–
GP CH
BATTAF
RF
1POWER switch 2ANTENNA A, B connectors
3GP button
4CH button
5+ button 6– button
7Display
8VOL. Control

6
GB
6– button
To go to a lower group or channel, press this button while
holding the GP or CH button.
7Display
Displays the status of this unit and the groups and channels
assigned to the unit.
For details, see the following section “Display”.
8VOL. (volume) control
Adjusts the volume of the tuner output.
Display
Location of Parts and Controls
1AF (audio frequency) indicator
2AF (audio frequency) level indications
The indicator lights and the indications appear when the
audio output level is higher than the reference level.
3BATT (battery) indicator
4BATT (battery) indication
Indicate the condition of the wireless microphone transmitter
batteries. The indicator and indication appear and start
flashing about one hour before the transmitter batteries go
flat. The time at which flashing begins will depend on the
type of battery used in the transmitter, and its condition.
5GP/CH (group/channel) indication
Shows the reception channel group and respective channel
number.
Pressing the + button changes this indication to the frequency
indication.
6RF (radio frequency) level indications
7RF (radio frequency) indicator
The indicator lights and the indications (dots) appear when
the antenna reception is optimal. Depending on the RF input
level, the number of dots changes.
GP CH
BATTAF
RF
5GP/CH indication
1AF indicator
2AF level indications
3BATT indicator
4BATT indication
6RF level indications
7RF indicator

7
GB
1TUNER OUTPUT (tuner sound output) connector
(XLR type)
Supplies audio signals. You can connect this to the audio
input connector of a mixer, amplifier, or similar equipment.
2OUTPUT LEVEL switch
Select the output level of the XLR type connector as –20
dBm or –58 dBm. (0 dBm=0.775 Vrms)
Set this switch according to the input level of the equipment
connected to the tuner.
Rear Panel
TUNER OUTPUT
LINE LEVEL –20dBm
TRS PHONE BALANCED
LEVEL
LINEMIC
–58dBm –20dBm
DC IN 9V
¥
1TUNER OUTPUT connector
3TUNER OUTPUT connector
2OUTPUT LEVEL switch
3TUNER OUTPUT (tuner sound output) connector
(ø6.3 phone balanced (TRS))
Supplies audio signals. You can connect this to the audio
input connector of a mixer, amplifier, or similar equipment.
Output level is fixed at –20 dBm.
4DC IN 9V (9 V DC power input) connector
Connect the supplied AC power adaptor.
5Cord clamp
Attaches the cord of the AC power adaptor.
4DC IN 9V connector
5Cord clamp

8
GB
Channel Setting
1 3,4 2 2,3,4
Note
Turn the POWER switch on after reducing the volume
of equipment connected to the TUNER OUTPUT
connector. Otherwise, noise will be heard when the
power is turned on.
2While holding down the GP button, press the + or –
button to select a group.
Each time you press the + or – button, the GP indication
changes as shown in the following figure. To change the
indication continuously, press and hold down the + or –
button.
+–
Here is explained channel setting for the CE62 model as
an example.
Take the following precautions to prevent interference and
noise.
• If there is a TV broadcasting station nearby, to avoid
possible interference from its broadcasting, do not use that
station’s channel.
• When simultaneously using two or more tuners, always set
the tuners to different channels within the same group
(other than group 00).
1Turn the POWER switch on.
The message “CE62” appears on the display, and then
the current status of this unit is displayed.
GP CH GP CH

9
GB
GP CH GP CH
The CH indication shows the lowest frequency channel
of the selected group. For group 00, however, the
channel selected last is displayed.
Releasing the buttons automatically cancels the group
selection mode, and the currently displayed group is
selected.
For the CE69 model, the indication will cycle from
group 00 through H.
Refer to “Overview of Channel Plan” in the “Wireless
Channel Lists” section.
3While holding down the CH button, press the + or –
button to select a channel.
Similar to step 2, each time you press the + or – button,
the CH indication changes in the order shown in the
group and reception channel list. (See “Wireless
Channel Lists”.)
If you press the + button when the last channel of the
selected group is displayed, the first channel of the
group will be displayed.
+–
GP CH GP CH
Selecting the reception channel by frequency
Press the + button.
This changes the GP/CH indication to a frequency
indication.
To change a frequency, press the + or – button while
keeping the CH button pressed. (A higher or lower
frequency will be displayed.)
Press the + button again to change the frequency
indication back to a GP/CH indication.
4If the desired channel or frequency is displayed, release
the CH button and + or – button.
The selected channel is set.
To store the selected group and channel
Leave the indication unchanged for 1 second.
The group and channel set in the procedure explained above
are stored in memory.
+
–

10
GB
Operation
1Connect the supplied antennas and make the antenna
tips point upward.
2Connect the supplied AC power adaptor to the DC IN
9V connector and an audio mixer or amplifier to the
TUNER OUTPUT connector.
3Turn the POWER switch on.
Note
Turn the POWER switch on after reducing the volume
of the equipment connected to the TUNER OUTPUT
connector. Otherwise, noise will be heard when the
POWER switch is turned on.
4Set the reception channel.
For details on setting the channels, see page 8.
5Turn on the wireless microphone or transmitter.
Use the wireless microphone or transmitter to which the
same channel is assigned as to this unit.
If noise is heard
Depending on the environment where the system is
installed, outside noise or radio wave may disrupt the
transmission of certain channels.
To select a channel under this circumstance, turn off the
wireless microphone or transmitter. Then select a channel at
which the RF indicator is off. (A channel free from noise or
radio wave interference is selected.) Set the same channel on
the microphone or transmitter.
5
34
1
2
+
–
ANTENNA A, B
Audio mixer, amplifier
AC power adaptor
UHF synthesized
transmitter
UHF
synthesized
wireless
microphone
DC IN 9V
TUNER OUTPUT

11
GB
Notes on using with a WD-820A
• This unit does not supply the internal booster of the
optional AN-820A UHF Antenna through the ANTENNA
A,B connectors. It is impossible to connect the AN-820A
directly.
• When adding the WRR-802A by cascade connection to a
tuner system containing the WD-820A UHF Antenna
Divider, use a coaxial cable (5D-2V, RG-212/U or
equivalent) with length of 30 m as shown in the figure.
• To avoid noise, remove the transmitter from the antennas
as far as possible when setting the channel or waiting with
the transmitter powered.
Notes
• Do not simultaneously use two or more microphones and
transmitters that are set to the same channel.
• Separate the reception antennas and the transmitter by
more than 3 meters.
• The number of wireless microphone channels actually
usable in a multi-channel system may be smaller than the
normal capacity of that system if there is interference from
TV broadcasting or other RF signals.
• When operating two or more UHF wireless microphone
systems using the same wireless channel in the same
group, ensure that the systems are at least 100 m1) apart as
far as they are installed within sight of each other.
WRR-802A
AN-820A
WD-820A
Tuner
a) Coaxial cable (30 m)
a) a)
1) The distance depends on the operating environment and conditions.

12
GB
Meaning Remedy
Err 01
Message
An error has occurred in
the backup memory data. The memory data is
initialized. Reset the
group and channel
settings.
Contact your nearest
Sony dealer.
The PLL-synthesized
circuit has a malfunction.
Err 02
NO TONE As no tone signal is
available or a tone signal
other than 32.768 kHz is
being received, the audio
signal output is muted.
Make sure that the
transmitter is turned on.
If it is, then the problem
lies in the transmitter’s
tone signal generator or
the tuner’s tone squelch
circuit. Contact your
nearest Sony dealer.
Error Messages
Apart from the normal indications, the following error
messages may appear on the display.
Muting Functions
This unit has the following three muting functions, which
work in combination.
(1) Muting by RF input level
As sufficient S/N for the audio output may not be obtained if
no RF signal is received or the RF input level is low, the
audio output can be muted when the RF input level falls
below the muting level.
(2) Tone squelch
The audio output is obtained only when the unit receives an
RF signal which includes a specified tone signal. The audio
output is muted to eliminate noise which may be heard when
the transmitter is turned on/off or the unit receives an
interference RF signal.
(3) Noise squelch
The audio output is muted to eliminate noise which may be
heard when there is such excessive interference RF signal
that the tone squelch does not work.
To turn off the muting functions
While holding down the GP and CH buttons, turn the
POWER switch to ON. All indications momentarily appear,
then go off. “OFF” is then displayed. This procedure cancels
all three muting functions at the same time.
To turn on the muting functions
Turn the POWER switch to OFF, then to ON again. The
three muting functions are activated at the same time.
Operation

13
GB
Specifications
Tuner
Reception type F3E
Circuit system Dual conversion superheterodyne
Reception frequencies
CE62 model: 800.000 to 814.000 MHz
CE69 model: 854.125 to 862.000 MHz
Local oscillatorsCrystal controlled PLL synthesizer
Selectivity 60 dB or more (at ±250 kHz detuned)
Spurious rejection ratio
70 dB or more
Image rejection ratio
60 dB or more
Muting level 30 dBµ 1)
Antenna connectors
BNC-R type (2), 50 ohms
Frequency response
100 to 15,000 Hz ±3 dB
De-emphasis 50 µsec
Signal-to-noise ratio
40 dB or more at an A-weighted RF input
level of 20 dBµ
60 dB or more at an A-weighted RF input
level of 60 dBµ
(±5 kHz deviation at 1 kHz modulation)
Distortion 1% or less (±40 kHz deviation at 1 kHz
modulation)
Tone signal frequency
32.768 kHz
Output level –20 dBm2) or –58 dBm (±5 kHz deviation at
1 kHz modulation)
Output impedance
150 ohms
Output connector
ø6.3 phone balanced (TRS)
XLR-3-12C
1) 0 dBµ=1 µV
2) 0 dBm=0.775 Vrms (600 ohms loaded)
General
Power requirements
9 V DC
Current consumption
Approx. 600 mA
Operating temperature
0°C to 40°C
Storage temperature
–20°C to +55°C
Dimensions 218 ×44 ×210 mm (w/h/d)
Mass Approx. 1.6 kg
Accessories supplied
AC power adaptor (1)
Antennas (2)
Operating Instructions (1)
Design and specifications are subject to change without
notice.

VORSICHT
Um Feuergefahr und die Gefahr eines elektrischen Schlages
zu vermeiden, darf das Gerät weder Regen noch
Feuchtigkeit ausgesetzt werden.
Um einen elektrischen Schlag zu vermeiden, darf das
Gehäuse nicht geöffnet werden. Überlassen Sie
Wartungsarbeiten stets nur einem Fachmann.

1
DE
DE
Deutsch
Inhaltsverzeichnis
Zur besonderen Beachtung ....................................1
Überblick................................................................... 2
Merkmale .............................................................. 2
Bestandteile........................................................... 3
Kanalplan .............................................................. 4
Lage und Funktion der Teile ................................... 5
Vorderseite............................................................ 5
Display .................................................................. 6
Rückseite............................................................... 7
Kanalwahl .................................................................8
Betrieb..................................................................... 10
Rauschsperre ....................................................... 12
Fehlermeldungen ...................................................12
Technische Daten ..................................................13
Übertragungskanallisten ..................................... L-1
Zur besonderen Beachtung
Betrieb
• Das Gerät ist für Umgebungstemperaturen zwischen 0 °C und
40 °C ausgelegt. Betreiben Sie es nicht längere Zeit bei hohen
Temperaturen. Insbesondere beim Betrieb im Freien sollte darauf
geachtet werden, daß das Gerät keinem prallen Sonnenlicht
ausgesetzt ist. Starkes Sonnenlicht schadet dem Gehäuse. Stellen
Sie das Gerät auch nicht in die Nähe von Lampen, Verstärkern
oder anderen wärmeabstrahlenden Geräten.
• Halten Sie das Gerät von Feuchtigkeit und Staub fern, um eine
lange Lebensdauer sicherzustellen.
• Achten Sie darauf, daß das Gerät keinen Vibrationen ausgesetzt
ist. Stellen Sie es nicht an folgende Plätze, da sonst
Störgeräusche auftreten können:
— Nähe von Motoren, Transformatoren, Dimmern oder anderen
elektrischen Komponenten
— Nähe von Klimaanlagen und Luftauslässen von Klimaanlagen
— Nähe von Lautsprechern
— Plätze, an denen das Gerät an andere Komponenten anstößt
• Beim Ein- und Ausschalten des Lichtes können auf allen
Frequenzen Störgeräusche auftreten. Betreiben Sie den Tuner
und die Mikrofone an Plätzen, an denen solche Störgeräusche
möglichst gering sind.
• Das Gerät wurde werkseitig exakt abgeglichen. Vor dem Betrieb
sind keinerlei Einjustierungen erforderlich. Öffnen Sie das Gerät
nicht und versuchen Sie nicht, das Gerät selbst zu reparieren.
Reinigung
Verwenden Sie zum Reinigen ein trockenes, weiches Tuch.
Verdünner, Benzin, Alkohol und Chemikalien dürfen nicht
verwendet werden, da sie das Gehäuse angreifen.

2
DE
Modell CE69
Die Kanäle des Modells WRR-802A/CE69 erstrecken sich
über einen 8 MHz breiten Frequenzbereich.
Dieses Modell besitzt 64 Empfangsfrequenzen mit 125-kHz-
Raster im TV-Kanal 69 (nach Sony Kanalplan) bzw. 14
Empfangsfrequenzen mit 25-kHz-Raster (nach Kanaplan für
allgemeine Verwendung in Großbritannien).
Die wählbaren Kanäle und die Frequenzen dieses Modells
funden Sie in den Tabellen von Seite L-12 und L-13.
Merkmale
PLL-Synthesizersystem (Phase Locked Loop)
Der WRR-802A ist mit einem modernen PLL-Synthesizer-
Schaltkreis ausgestattet.
Fest gespeicherter Kanalplan für simultanen
Mehrkanalbetrieb
Eine große Anzahl von Kanälen ist im WRR-802A fest
einprogrammiert. Mit den Bedienungselementen auf der
Vorderseite können diese Kanäle bequem eingestellt
werden.
Überblick
Der UHF-WRR-802A arbeitet im 800-MHz-TV-Band und
dient zum Empfang der Signale eines Sony UHF-
Mikrofonsystems. Dank der Diversity-Funktion
gewährleistet der Tuner einen zuverlässigen Empfang.
Wenn die Kanäle entsprechend des Kanalplans gewählt
werden, ist ein simultaner Betrieb auf mehreren Kanälen
möglich.
Achten Sie bei der Zusammenstellung eines UHF-
Mikrofonsystems darauf, daß Mikrofon/Sender und Tuner
dieselbe TV-Kanalnummer (62 oder 69) besitzen.
Modell CE62
Die Kanäle des Modells WRR-802A/CE62 erstrecken sich
über einen 14 MHz breiten Frequenzbereich. Dieses Modell
besitzt 111 Empfangsfrequenzen mit 125-kHz-Raster (nach
Sony Kanalplan) bzw. 561 Empfangsfrequenzen mit 25-
kHz-Raster im Bereich der TV-Kanäle 62 und 63 (nach der
deutschen Benutzergruppe).
Die wählbaren Kanäle und die Frequenzen dieses Modells
finden Sie in den Tabellen von Seite L-3 bis L-11.

3
DE
Kanäle und Frequenzbereich Modell
TunerSender bzw.
Mikrofon
TV-Kanal Frequenzbereich
(MHz)
62 800,000 bis
814,000 WRT-805A (62) WRT-807A (62)
WRT-822A (62)
WRR-805A (62)
WRR-802A (62)
MB-806A mit
WRU-806A (62)
69 854,125 bis
862,000 WRT-805A (69) WRT-807A (69)
WRT-822A (69)
WRR-805A (69)
WRR-802A (69)
MB-806A mit
WRU-806A (69)
Informatives Display
Das Flüssigkristalldisplay zeigt verschiedene Informationen
wie beispielsweise die Empfangs-Feldstärke und eine
Warnmeldung bei schwacher Sendebatterie an.
Diversity-Funktion für stabilen Empfang in großen
Räumen
Dank der Diversity-Funktion ermöglicht der WRR-802A
auch in großen Räumen einen stabilen Empfang ohne
Aussetzer.
Effektive Rauschsperre
Der eingebaute Squelch-Schaltkreis unterdrückt das
Rauschen und Interferenzstörungen, wenn sich der WRR-
802A in Empfangsbereitschaft befindet.
Compander-System
Das Compander-System (bestehend aus Kompressor und
Expander) gewährleistet auch bei Signalen mit großem
Dynamikumfang eine hohe Übertragungsqualität.
Aussteuern des Audioausgangspegels
Der Audioausgangspegel läßt sich mit dem Lautstärkeregler
aussteuern.
Bestandteile
Dieser Tuner eignet sich für die in der folgenden Tabelle
aufgeführten Sony UHF-Mikrofone und UHF-Sender.
Das 800-MHz-Band-Übertragungssystem von Sony

4
DE
Kanalplan
Es können mehrere Kanalgruppen gespeichert werden. Siehe
„Überblick über die Kanäle“ in Abschnitt
„Übertragungskanallisten“.
Bei den Gruppen anders als 00 sind die Abstände zwischen
den Kanälen so groß, daß auf allen Kanälen ein simultaner
Betrieb von UHF-Mikrofonen möglich ist, ohne daß es zu
Interferenzstörungen kommt. Die Gruppe 00 bietet zwar die
größte Anzahl an Kanälen, sie sollte jedoch nur dann
verwendet werden, wenn es unbedingt erforderlich ist.
Überblick
