Sony BRAVIA KDL-32XBR9 User manual

KDL- 32XBR9
32" Class BRAVIA XBR Series LCD TV (31.5" Diagonally)
®
Key Features
16:9 Full HD 1080p Resolution Panel (1920x1080)
Dynamic Contrast Ratio: 40,000:1
Motionflow™120Hz technology
USB with photos and music
BRAVIA ® Link compatibility
BRAVIA Engine™2 fully digital video processor
HD input x 7
BRAVIA ® Sync capable
3
ACE (Advanced Contrast Enhancer)
Light Sensor™technology
24p True Cinema™capable
Favorites Menu
ATSC ™/NTSC tuner with QAM
4
VESA ® compatible hole spacing
Key Technologies
16:9 Full HD 1080p Resolution Panel (1920x1080) 16:9 Full HD 1080p resolution panel (1920x1080)
accepts any HDTV signal and renders it with optimum resolution, so you can take full advantage of
Blu - ray Disc™players and Sony ® PLAYSTATION ® 3 entertainment systems that can deliver 1080p
content.
Dynamic contrast (40,000:1) Advanced Contrast Enhancer (ACE) creates a dynamic contrast
level by working in real time to produce deep blacks in darker scenes, as well as fine details in
shadows and other dark areas of the picture for a difference you can truly see.
Motionflow™120Hz technology Engineered for fast - action sports, movies and games, Motionflow
120Hz technology reduces blurriness and judder. Overall, motion is smoother, sharper, and more
natural when watching your favorite HD content, DVDs, and even broadcast movies and prime - time
programming.
BRAVIA Engine ™ 2 fully digital video processor The BRAVIA Engine 2 fully digital video processor
uses a collection of unique Sony technologies to significantly reduce noise, enhance overall image
detail, and optimize contrast so every scene produces sharp, vibrant, life - like images and color.
HD input x 7 Get versatile HD connection options with seven HD inputs. Four HDMI™inputs (up to
1080/60p capable) let you connect a Sony PLAYSTATION 3 entertainment system, Blu - ray Disc™
player, or any other HDMI - capable equipment and get uncompressed digital video and multi -
channel digital audio on a single cable. An HD component input and an HD combo input (1080/60i
capable) provide added HD - capable connectivity, and a PC input (HD - 15 pin) offers the added
versatility of using your HDTV as a computer monitor.
1
®
®
2
USB with photos and music Connect your camera, USB - enabled MP3 player, or USB storage device
directly to your HDTV's USB input to view photos on the big screen or listen to your favorite MP3’s.
BRAVIA Link compatibility BRAVIA Link compatibility expands your HDTV’s capabilities by letting you
connect optional BRAVIA Link modules, including the BRAVIA DVD Link, BRAVIA Wireless Link, and
BRAVIA Input Link (all sold separately).
®
BRAVIA® Sync capable BRAVIA Sync capability combines the one - touch access and control
functionality of BRAVIA Theatre Sync™with the ability to control CEC - enabled Sony ® Handycam ®
camcorders and Cyber - shot ® digital still cameras using the TV’s remote and an on - screen display.
3

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 06/18/2009
KDL- 32XBR9
32" Class BRAVIA XBR Series LCD TV (31.5" Diagonally)
®
Please visit the Dealer Network for current
information at www.sony.com/dn
Features
General
Hotel Mode Menu: External module
Closed Captions (CC): Analog, Digital
On-Screen Display: Traditional
Finish (Surface Color): Piano Black
Demo Mode: Yes
BRAVIA® Link Module support: DMX-DVD; DMX-WL1;
DMX-SW1
Display
Backlight Type: CCFL
Display Device: LCD
Video
Video Processing: BRAVIA Engine 2 ™Technology
CineMotion® Reverse 3:2 Pulldown Technology: Yes
Game Mode: Yes
Wide Mode: Full, Normal, Wide Zoom, Zoom, Full Pixel
3D Comb Filter: Yes
Auto Wide: Yes
4:3 Default: Yes
24p True Cinema™Technology: Yes
Picture Mode: Vivid, Standard, Cinema, Custom, Photo-
Vivid, Photo-Standard, Photo-Original, Photo-Custom
Advanced Contrast Enhancer (ACE): Yes
Motionflow™Technology: 120Hz
Audio
Digital Amplifier: Standard
Auto SAP: Yes
Auto Mute (on no signal): Yes
Steady Sound® Automatic Volume Control: Yes
Audio Out: Fixed
Stereo System: MTS
Dolby ®: Dolby ® Digital (for broadcasting)
Alternate Audio (Digital): Yes
SRS ®: SRS® TruSurround XT®
Sound Mode: Clear Voice, Dynamic, Custom, Standard
Convenience
Channel Jump: Yes
Favorite Channel: Standard
Multiple Language Display: English, Spanish, French
Info Banner: PSIP, XDS
Sleep Timer: Yes
Input Skip: Manual
Channel Surf: Yes
Channel Block (with password): Yes
Edit Channel Labels: Yes
Label Inputs: Yes
ID-1 Detection: Yes
On/Off Timer: Yes
USB Application(s): Photo Viewer (JPEG), Music Player
(MP3)
Theatre Mode (Theatre Button): Yes
Show/Hide Channels: Yes
Auto Shut-off: Yes
BRAVIA® Sync™: Yes
Parental Control: Yes
BRAVIA® Sync™Menu Button: Yes (on remote control)
Channel Labels: Yes
Control for HDMI™(HDMI™CEC): Yes
Auto Photo Mode: Via USB
On-Screen Clock: Yes
Picture Adjustments Lock: Yes
White Balance: RGB Gain/Bias
Start Up BRAVIA® Logo Display: Yes
Favorites Menu: Graphic
Specifications
General
Television Type: Flat Panel LCD HDTV
Display
Viewing Angle (Right/Left): 178 (89/89)
Viewing Angle (Up/Down): 178 (89/89)
On-screen Contrast Ratio: 4,000:1
Dynamic Contrast Ratio: 40,000:1
Screen Size (measured diagonally): 31.5"
Native Resolution: 1920 x 1080
Display Resolution: 1920 x 1080p (Full HD)
Panel Bit: 8 - bit
Aspect Ratio: 16:9
Color Range (u'v'): 90% OF NTSC
Color Range (xy): 72% of NTSC
TV System
Tuner (Cable): Clear QAM
Tuner (Terrestrial): ATSC™Tuner, NTSC Tuner
Channel Coverage: VHF: 2- 13ch
UHF: 14 - 69ch
CATV (analog): 1- 135ch
CATV (digital) : 1- 135ch
TV System (Analog): M
Number of Tuners (Digital): 1(Hybrid)
TV System (Digital): ATSC
Color System: NTSC
Video
Video Signal: 1080/60p (HDMI ™ / COMPONENT), 1080/60i,
1080/24p (HDMI ™ ONLY), 720/60p, 480/60p, 480/60i
Audio
Audio Power Output: 20W (10W X 2)
Speakers (Total): 2
Speaker Configuration: 2.0
Inputs and Outputs
Component Video (Y/Pb/Pr ) Input(s): 2 (Rear) (1 Fix, 1
Selectable)
Composite Video Input(s): 2 (1 Side, 1 Rear
(Selectable))
Digital Audio Output(s): Optical Digital Output -1 (Rear)
RF Connection Input(s): 1 (Rear)
S -Video Input(s): 1(Side)
Analog Audio Input(s) (Total): 5 (2 Side/3 Rear)
Audio Out: 1 (Rear)
HDMI™Connection(s) (Total): 4 (3 Side, 1 Rear)
PC In (D-Sub) + Audio In (Stereo Mini): 1 (Side) see
owner's manual for supported timings
USB 2.0: 1(Side)
HDMI™PC Input: Yes (see owner's manual for
supported timings)
S -Video Detection: Yes
AC Power Input: 1 (Rear)
Analog Audio Input(s) for HDMI™: 1 (Rear)
USB 1.1: 1 (Rear) (Service only)
Power
Power Consumption (in Standby): Less than 1W
Power Requirements (voltage): AC 120V
Power Requirements (frequency): 60HZ
Power Consumption (in Operation) max.: 120 W max
Regulation and Standard Compliance
VESA ® Hole Spacing Compatible: Yes
VESA ® Hole Pitch: 200X200 M6/12 -16MM
Service and Warranty Information
Limited Warranty Term: 1 Year Labor / 1 Year Parts
Online Instruction Manual (Reference Book): Yes
Energy Saving & Efficiency
LightSensor™Technology: Yes
Power Saving Modes: Yes
Energy Star® compliant: Exceeds Energy Star Version 3.0
Eco Settings: Yes
Dynamic Backlight Control: Yes
Backlight Off Mode: Yes
PC Power Management: Yes
Estimated Annual Energy Consumption (kWh): 175.46 kW
Power Consumption (On Mode) for Energy Star: 95 W
Power Consumption (Standby Mode) for Energy Star: 0.3
W
Recycled & Recyclable Materials
Packaging Materials: Recycled Carton (more than 40%)
Printed Materials: FSC Certified
Dimensions
Weight: 29.6 lbs. (13.4kg) with pedestal; 26.9 lbs. (12.2kg)
without pedestal
Measurements: 31 1/2 x 23 x 9 in (798 x 584 x 227mm)
with pedestal; 31 1/2 x 21 1/4 x 3 5/8 in (798 x 537 x
89mm) without pedestal
Supplied Accessories
Remote Control RM- YD028
Batteries (Type AA x2)
AC Power Cord (attached)
4 Screws (for pedestal)
Operating Instructions
Quick Setup Guide
Warranty Card
Table Top Stand (separate, pre-assembled)
Optional Accessories
Wallmount Bracket SU- WL500
UPC Code: 027242752979
1.HDMI™ connectorrequired and sold separately
2.Limited to resolutions supported by both the PCandtheSony TV.
SeeSonyTVuser'smanual and PC documentation for the supported
resolutions.
3.BRAVIA SyncworkswithselectSonyHDTVs,home theater, and
digital imaging products. Theatre Sync ™ featuremust be in all
products for one - touchaccess and control. Check owner ’ smanuals
forcompatibility.
4.Checkwithyour local TV station or cable company for details on
accessing or subscribing to HD content.
©2009Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpart without written permissionisprohibited.Sony, HDNA, BRAVIA,
BRAVIAEngine,TheatreSync,Cyber - shot,LightSensor,Handycam,
Motionflow,24pTrueCinema,andtheir respective logos are trademarks
of Sony. HDMI, the HDMI logo and High - DefinitionMultimedia Interfaceare
trademarksof HDMI Licensing LLC.PlayStationisa trademark of Sony
ComputerEntertainmentInc.Blu - rayDisc isatrademark.ENERGY STAR
andthe ENERGY STAR markareregisteredU.S. marks. All other
trademarksare trademarks oftheirrespectiveowners. Features and
specifications are subject to change without notice. Non - metricweights
and measures are approximate.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulateddue to environmental considerations. For disposal or
recyclinginformation,pleasecontact your local authorities or the
Electronic Industries Alliance (www.eiae.org).
®
®
®
