REVISION HISTORY AG3E
MODEL
KV-DR29M37
KV-DR34M37
PA RT N O. : 9-872-339-01
NO. SUFFIX DATE SUPP / CORR DESCRIPTION
CHASSIS
1 -01 2002/9 -- 1st. Issue

MODEL COMMANDER DEST. CHASSIS NO.
KV-DR29M37 RM-991 South Afrika
KV-DR34M37 RM-991 South Afrika
TRINITRON ® COLOR TV
SERVICE MANUAL AG3E CHASSIS

– 2 –
KV-DR29M37/DR34M37
RM-991
Power requirements 110-240V AC, 50/60 Hz
Power consumption (W) Indicated on the rear of the TV
Television system B/G, I, D/K, M
Color system PAL, PAL 60, SECAM, NTSC3.58, NTSC4.43
Stereo/Bilingual system NICAM Stereo/Bilingual B/G, I; A2 Stereo/Bilingual B/G
Channel coverage
B/G VHF: E2 to E12
UHF: E21 to E69
CATV: S01 to S03, S1 to S41
IUHF: B21 to B68
CATV: S01 to S03, S1 to S41
D/K VHF: C1 to C12, R1 to R12
UHF: C13 to C57, R21 to R60
CATV: S01 to S03, S1 to S41, Z1 to Z39
MVHF: A2 to A13
UHF: A14 to A79
CATV: A-8 to A-2, A to W+4, W+6 to W+84
8 (Antenna) 75-ohm external terminal
Audio output (Speaker) 6W + 6W
3D WOOFER 15W
Number of terminal
DVideo Input: 4 Output: 1 Phono jacks; 1 Vp-p, 75 ohms
9Audio Input: 4 Output: 1 Phono jacks; 500 mVrms
(S Video) Input : 2 Y: 1 Vp-p, 75 ohms
unbalanced, sync negative
C: 0.286 Vp-p, 75 ohms
(Component Input : 1 Phono jacks:
Video) Y: 1 Vp-p, 75 ohms
sync negative
PB/CB: 0.7 Vp-p, 75 ohms
PR/CR: 0.7 Vp-p, 75 ohms
Audio: 500mVrms
2(Headphone) Output: 1 Stereo minijack
Picture tube 29 in 34 in
Tube size (cm) 72 86 Measured diagonally
Screen size (cm) 68 80 Measured diagonally
Dimension (w/h/d,mm) 786 × 596 × 514 894 ×690 ×569
Mass (kg) 57 85
Design and specifications are subject to change without notice.
SPECIFICATIONS
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY SHADING AND MARK !ON
THE SCHEMATIC DIAGRAMS, EXPLODED VIEWS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
CAUTION
SHORT CIRCUIT THE ANODE OF THE PICTURE TUBE AND
THE ANODE CAP TO THE METAL CHASSIS, CRT SHIELD,
OR CARBON PAINTED ON THE CRT, AFTER REMOVING THE
ANODE.
Note

– 3 –
KV-DR29M37/DR34M37
RM-991
TABLE OF CONTENTS
SELF DIAGNOSTIC FUNCTION ..................................4
1. DISASSEMBLY
1-1. Rear Cover Removal (KV-DR34M37) ...................... 7
1-2. Rear Cover Removal (KV-DR29M37) ...................... 7
1-3. 3D Speaker Box Removal .......................................... 7
1-4. Speaker Removal ........................................................ 7
1-5. Chassis Assy Removal ................................................ 7
1-6. Service Position .......................................................... 7
1-7. Service Position on TV Stand .................................... 8
1-8. Terminal Bracket Removal ......................................... 8
1-9. B3 and D5 Boards Removal ....................................... 8
1-10. F1 Board Removal ...................................................... 9
1-11. BC1 and P Boards Removal ....................................... 9
1-12. H1 and H2 Boards Removal ....................................... 9
1-13. A and D Boards Removal ........................................... 9
1-14. Picture Tube Removal .............................................. 10
2. SERVICE JIG
2-1. Jigs Required For Servicing .................................... 11
3. CIRCUIT BOARDS LOCATION ................................. 11
4. ADVANCE OPERATION
4-1. "RESET" Function ................................................... 12
5. SET-UP ADJUSTMENTS
5-1. Beam Landing .......................................................... 13
5-2. Convergence Adjustment ......................................... 14
5-3. Focus Adjustment ..................................................... 16
5-4. Neck Assy Twist Adjustment ................................... 16
5-5. G2 (SCREEN) and White Balance Adjustment ....... 16
6. CIRCUIT ADJUSTMENTS
6-1. Adjustment With Commander ................................. 17
6-2. Adjustment Method .................................................. 17
6-3. Picture Quality Adjustments .................................... 36
6-4. Sub Hue/Col Adjustments ........................................ 36
6-5. Deflection Adjustments ............................................ 37
6-6. A Board Adjustment After IC003 (MEMORY)
Replacement ............................................................. 38
6-7. Picture Distortion Adjustment .................................. 39
Section Title Page Section Title Page
7. DIAGRAMS
7-1. Block Diagram ......................................................... 40
7-2. Schematic Diagram .................................................. 49
(1) A Board Schematic Diagrams ............................ 50
(2) B3 Board Schematic Diagram ............................ 54
(3) D Board Schematic Diagram.............................. 56
(4) D5 Board Schematic Diagram ........................... 58
(5) C Board Schematic Diagram .............................. 60
(6) BC1 Board Schematic Diagram ......................... 62
(7) H1 Board Schematic Diagram ........................... 64
(8) P and F1 Boards Schematic Diagrams ............... 66
(9) VM Boards Schematic Diagrams ....................... 68
(10) H2 and J Boards Schematic Diagrams ............. 69
7-3. Voltage Measurement and Waveforms ..................... 71
7-4. Printed Wiring Boards and Parts Location .............. 94
7-5. Semiconductors ...................................................... 106
8. EXPLODED VIEWS
8-1. Speaker Bracket ...................................................... 109
8-2. 3D Speaker ............................................................. 109
8-3. Chassis .................................................................... 110
8-4. Picture Tube ............................................................ 111
9. ELECTRICAL PARTS LIST...................................... 112
OPERATING INSTRUCTIONS

– 4 –
KV-DR29M37/DR34M37
RM-991
The units in this manual contain a self-diagnostic function. If an error occurs, the STANDBY/TIMER lamp will automatically
begin to flash.
The number of times the lamp flashes translates to a probable source of the problem. A definition of the STANDBY/TIMER
lamp flash indicators is listed in the instruction manual for the user’s knowledge and reference. If an error symptom cannot
be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past
problems and how often these problems occur.
1. DIAGNOSTIC TEST INDICATORS
When an error occurs, the STANDBY/TIMER lamp will flash a number of times to indicate the possible cause of the
problem. If there is more than one error, the lamp will identify the first of the problem areas.
Result for all of the following diagnostic items are displayed on screen. No error has occured if the screen displays a “0”.
Diagnostic
Item
Description
• Power does not
turn on
• +B overcurrent
(OCP)
• +B overvoltage
(OVP)
• Vertical deflection
failure
• White balance
failure (no
PICTURE)
• Horizontal
deflection failure
• Micro reset
No. of times
STANDBY/TIMER
lamp flashes
Does not light
2 times
3 times
4 times
5 times
6 times
—
Self-diagnostic
display/Diagnostic
result
—
002:000 or
002:001~255
003:000 or
003:001~255
004:000 or
004:001~255
005:000 or
005:001~255
006:000 or
006:001~225
101:00 or
101:001~225
Probable
Cause
Location
• Power cord is not plugged
in.
• Fuse is burned out F1601
(F1 Board)
• H.OUT Q6807 is shorted.
• H.IN Q6810 is shorted.
Q6802 shorted.
• PH6602 faulty.
D6644 faulty, R6651 open.
• 10.5V is not supplied.
(D board)
• V.OUT IC6800 faulty
D6816 faulty
D6817 faulty
D6824 faulty
R6852 open
R6851 open (D board)
• G2 is improperly adjusted.
(Note 2)
• CRT problem.
• Video OUT IC9001, 9002,
9003 are faulty. (C board)
• IC8306 (A board) and
IC4301 (A board) are faulty.
• C6831 is open circuit.
PS6606 open, PS6605
open. (D board)
• CRT Discharge (C Board)
• Static discharge
• External noise
Detected
Symptoms
• Power does not come on.
• No power is supplied to the
TV.
• AC power supply is faulty.
• Power does not come on.
• Load on power line is
shorted.
• Power does not come on.
• Vertical deflection pulse is
stopped.
• Vertical size is too small.
• Vertical deflection stopped.
• No raster is generated.
• CRT cathode current
detection reference pulse
output is small.
• H pulse output is too high.
• Power is shut down shortly,
after this return back to
normal.
• Detect Micro latch up.
Note 1: Refer to screen (G2) Adjustment in section 5-5 of this manual.
SELF DIAGNOSTIC FUNCTION

– 5 –
KV-DR29M37/DR34M37
RM-991
2. DISPLAY OF STANDBY/TIMER LIGHT FLASH COUNT
3. STOPPING THE STANDBY/TIMER FLASH
Turn off the power switch on the TV main unit or unplug the power cord from the outlet to stop the STANDBY/TIMER lamp
from flashing.
4. SELF-DIAGNOSTIC SCREEN DISPLAY
For errors with symptoms such as “power sometimes shuts off” or “screen sometimes goes off” that cannot be confirmed, it
is possible to bring up past occurances of failure for confirmation on the screen:
[To Bring Up Screen Test]
In standby mode, press buttons on the remote commander sequentially in rapid succession as shown below:
[Screendisplay] /channel [5] /Sound volume [-] /Power ON
˘
Note that this differs from entering the service mode (mode volume [+]).
Self-Diagnosis screen display
Lamp ON 0.3 sec.
Lamp OFF 3 sec.
Lamp OFF 0.3 sec.
2 times
3 times
4 times
5 times
6 times
Diagnostic Item Flash Count*
+B overcurrent 2 times
+B overvoltage 3 times
V deflection stop 4 times
White balance failure 5 times
Horizontal Deflection Failure 6 times
* One flash count is not used for self-diagnostic.
002 : 000
003 : 000
004 : 000
005 : 001
Numeral "0" means that no fault has been detected.
Numeral "1" means a fault has been detected.
006 : 002
101 : 000
SELF DIAGNOSTIC
Numeral "2" means two faults have been detected.
STANDBY/SLEEP lamp

–6 –
KV-DR29M37/DR34M37
RM-991
5. HANDLING OF SELF-DIAGNOSTIC SCREEN DISPLAY
Since the diagnostic results displayed on the screen are not automatically cleared, always check the self-diagnostic screen
during repairs. When you have completed the repairs, clear the result display to “0”.
Unless the result display is cleared to “0”, the self-diagnostic function will not be able to detect subsequent faults after
completion of the repairs.
[Clearing the result display]
To clear the result display to “0”, press buttons on the remote commander sequentially as shown below when the diagnostic
screen is being displayed.
Channel [8] /0
[Quitting Self-diagnostic screen]
To quit the entire self-diagnostic screen, turn off the power switch on the remote commander or the main unit.
6. SELF-DIAGNOSTIC CIRCUIT
+B overcurrent (OCP) Occurs when an overcurrent on the +B(135) line is detected by Q6610
and Q6609.
If Q6610 and Q6609 go to ON, the voltage to the pin3 of IC001 go to UP.
The unit will automatically turn off.
+B overvoltage (OVP) Occurs when an overvoltage on the +B(135) line is detected by D6635
and Q6611. If Q6611 go to ON, the voltage to pin6 of IC001 go to UP. The
unit will automatically turn off.
Vertical deflection failure Occurs when an absence of the vertical deflection pulse is detected by
Q6819 and R6832. Shut down the power supply.
White balance failure If the RGB levels do not balance or become low level within 5 seconds.
This error will be detected by IC4301.
TV will stay on, but there will be no picture.
High voltage protector of Horizontal Deflection Occurs when an overvoltage of horizontal pulse is detected by D6809 and
IC6801.
If the voltage of anode D6830, Q6800 and D6825 goes to High, the
voltage to pin34 of IC4301 go to UP. The unit will automatically turn off.
IC4301
RGB JUNGLE
CXA2150AQ
OVP OCP
FROM
CRT (IK)
[V] Q6819, R6832
IC001
SYSTEM
SDA
SDA
IC003
MEMORY
IKIN
H PROT
LED 1
558
34
54
3
6
V PROT
35
[H] D6825, D6830

– 7 –
KV-DR29M37/DR34M37
RM-991
SECTION 1
DISASSEMBLY
1-1. REAR COVER REMOVAL (KV-DR34M37)
1-3. 3D SPEAKER BOX REMOVAL 1-4. SPEAKER REMOVAL
1-5. CHASSIS ASSY REMOVAL
1Two screws
(TP + TWH 4 × 25)
23D Speaker
box assy
1-6. SERVICE POSITION
1Sixteen screws
(+BVTP 4 × 16)
2Rear cover
1-2. REAR COVER REMOVAL (KV-DR29M37)
1Fourteen screws
(+BVTP 4 × 16)
2Rear cover
1Two screws
(+BVTP 4 × 16)
2Two screws
(Washer Head)
(+P4x16)
3Two screws
(+BVTP 4 × 16)

–8 –
KV-DR29M37/DR34M37
RM-991
1-9. B3 AND D5 BOARDS REMOVAL
1-10. F1 BOARD REMOVAL 1-11 . BC1 AND P BOARDS REMOVAL
Note: Access to the B3 board is possible after removal
of the shiledcase. Remove the shiledcase by
removing 2 screws +BVTP 3x16
1-8. TERMINAL BRACKET REMOVAL
2Two screws
(+BVTP 3 ×12)
3One screw
(+BVTP 3 ×12)
3One screw
(+BVTP 3 ×12)
1One screw
(+BVTP 4 ×16)
5Terminal bracket
4Two hooks
2D5 Board
4B3 Board
3Two clips
1Two clips
2BC1 Board
4V2 Board
(Not used for this model)
6P Board
1One clip
3Two clips
5One clip
1-7. SERVICE POSITION ON TV STAND
Note: The picture tube for South Africa model is upside down and
the position for the anode cap and tension springs are
changed accordingly.
1) Remove the Rear Cover (refer 1-1)
- unscrew all screws fixed on the Rear Cover. Hold
the top of the TV Cabinet; lift the Rear Cover slightly
upwards to release the Rear Cover foot from the TV
Stand and slide it backwards from the TV Cabinet.
2) Remove the 3D Speaker Box (refer 1-2)
3) Release the Lead Assy Speaker (left side)
4) Lift up the chassis and place it in the Service Position
as shown:-
Place the front of the main
bracket on to the foot of the
TV Cabinet
Use a non elastic and non
conductive string to tie the
main bracket to the woofer
bracket
Place the Terminal
Bracket edge into the hole
on the TV Stand foot
Caution: 1) In Service Position, make
sure all the TV connections
are connected correctly
before turning on the TV
set.
2) The TV on the TV Stand
without Rear Cover is
unstable. As such be
careful not to push the TV
foward or backward
2F1 Board
1Two hooks

–9 –
KV-DR29M37/DR34M37
RM-991
1-12. H1 AND H2 BOARDS REMOVAL 1-13. A AND D BOARDS REMOVAL
5One screw
(3 ×12)(+)(BVTP)
2Three screws
(3 ×12)(+) BVTP 3Four hooks
5One screw
(3 ×12)(+)(BVTP)
1Five connectors
6Four hooks
7D Board
4A Board
3Three hooks
1Five hooks
4Cover, H
2H1 Board
5H2 Board
$Band, DGC(2) Removal
5Anode Cap Removal For (KV-DR29M37)
Remove Clip, DGC(3)
)Earth Coating Assy(2) Removal
7Loosen the Neck Assembly
fixing screw and remove
9Loosen the Deflection Yoke
fixing screw and remove
6C Board Removal
!Chassis Assy Removal
8VM Board Removal
(Spring Tension(2)
Removal
#Supports, CRT(2) Removal
&DGC(2) Removal
%Holder, DGC(2) Removal
~Nut, Locking (4)
+Nut special CRT (4) "Bracket Woofer(2) Removal
(KV-DR29M37 Only)
1-14. PICTURE TUBE REMOVAL
Note:
The picture tube for South Africa model is upside down and the position for the anode cap and tension springs are
changed accordingly.
•Please make sure the TV set is not in standing position before removing necessary CRT support located on bottom
right and left.
•When removing the Nut Locking: first make sure to hold the Nut special CRT with a spanner while opening the Nut
Locking using a torque driver. Then proceed to remove the Nut special CRT using a torque driver.
1) Place the TV set with the CRT face down on a cushion (jig).
2) Removal the Rear Cover.
3) Removal the 3D Box.
4) Unplug all interconnecting leads from the Deflection Yoke, Neck Assy, Degaussing Coils and CRT grounding strap.

–10 –
KV-DR29M37/DR34M37
RM-991
• REMOVAL OF ANODE-CAP
Note:
•After removing the anode, short circuit the anode of the picture tube and the anode cap to the metal chassis, CRT
shield or carbon paint on the CRT.
•REMOVING PROCEDURES
1Turn up one side of the rubber cap in the direction
indicated by the arrow a.
2Using a thumb pull up the rubber cap firmly in the direc-
tion indicated by the arrow b.
3When one side of the rubber cap is separated from the
anode button, the anode-cap can be removed by
turning up the rubber cap and pulling it up in the
direction of the arrow c.
•HOW TO HANDLE AN ANODE-CAP
1Do not damage the surface of anode-caps with
sharp shaped objects.
2Do not press the rubber too hard so as not to
damage the inside of anode-cap.
A metal fitting called the shatter-hook terminal is
built into the rubber.
3Do not turn the foot of rubber over too hard.
The shatter-hook terminal will stick out or damage
the rubber.
a
a
b
b
c
Anode Button

– 11 –
KV-DR29M37/DR34M37
RM-991
SECTION 2
SERVICE JIG
2-1. JIGS REQUIRED FOR SERVICING
REF NO. DESCRIPTION QUANTITY PART NO. REMARK
J-1 TOOL(20P),SERVICE 1 3-702-763-01 For A to BC1 board extension
1 For A to P board extension
J-2 TOOL(40P),SERVICE 1 3-702-764-01 For A to B3 board extension
J-3 TOOL(50P-A),SERVICE 1 3-702-765-01 For D to D5 board extension
SECTION 3
CIRCUIT BOARDS LOCATION
J-1 J-2
J-3
D Board
D5 Board
B3 Board
J Board
P Board
A Board F1 Board
BC1 Board
H1 Board
VM Board
H2 Board
C Board

– 12 –
KV-DR29M37/DR34M37
RM-991
SECTION 4
ADVANCE OPERATION
4-1. "RESET" FUNCTION
1. Purpose
If a customer faces some setting problem that cannot be solved, using the "RESET" function some items will be
reset to its original setting (shipping condition)
2. How to Operate
There are 2 ways to access to the "RESET" Function:-
a) By pressing "RESET" button on the Remote Commander.
b) By pressing "MENU" button on the Front Key Input and hold it down for 5 seconds.
3. Subsequent of Operation
Sequential to the resetting operation (either methods being used in No. 2), TV set would shut down once and
automatically turn on again. The power-off duration is expected to be about 500msec. An OSD message,
"RESET" tentatively will be displayed for 10 sec after IK status gets stable.
As a result, some items will be reset to an initial condition (shipment condition) wheareas some other remains at
the last selection by user.
Items that remains at the last selection by user
Reset Items
Program No., PIC rotation, OSD Language,
Fine tuning, TV System, Skip
Video input RF
Volume 30
DRC-MF DRC1250
Picture mode DYNAMIC
Sound mode DYNAMIC
Surround mode OFF
Color system(video) AUTO
Multi picture(PIP) OFF
PIP position Bottom-right
OSD recall OFF
Intelligent volume OFF
ECO mode OFF
Color system(RF) AUTO*
Antenna sensitivity HIGH*
Stereo mode STEREO/NICAM*
Bilingual mode MAIN*
High-deviation mode AUTO*
Child lock OFF*
Wide mode OFF
Game mode OFF
Teletext mode OFF
Sleep timer OFF
Wake-up timer OFF
Sound muting OFF
3DNR ON
*= only when in RF mode

– 13 –
KV-DR29M37/DR34M37
RM-991
•The following adjustments should be made when a complete
realignment is required or a new picture tube is installed.
•These adjustments should be performed with rated power
supply voltage unless otherwise noted.
Controls and switches should be set as follows unless otherwise
noted:
PICTURE control ........................................................... normal
BRIGHTNESS control ................................................... normal
Perform the adjustments in the following order :
1. Beam Landing
2. Convergence
3. Focus
4. White Balance
Note : Test Equipment Required.
1. Color-bar/Pattern Generator
2. Degausser
3. Oscilloscope
SECTION 5
SET-UP ADJUSTMENTS
................................................................................................................................................................................................................................
Fig. 5-3
normal
Neck assy
G2G1 G3
Align the edge of
the neck assy with
the edge of the G3 grid.
(KV-DR34M37)(KV-DR29M37)
Neck assy
G2G1 G3
Align the edge of
the neck assy with
the edge of the G2 grid.
Fig. 5-1
Red
Blue
Green
Preparation :
•In order to reduce the influence of geomagnetism on the set's
picture tube, face it east or west.
•Switch on the set's power and degauss with the degausser.
5-1. BEAM LANDING
1. Input a white signal with the pattern generator.
Contrast
Brightness
2. Position neck assy as shown in Fig 5-1.
3. Set the pattern generator raster signal to a green raster.
4. Move the deflection yoke to the rear and adjust with the
purity control so that the green is at the center and the blue
and the red take up equally sized areas on each side.
(See Figures 5-1 through 5-3.)
5. Move the deflection yoke forward and adjust so that the
entire screen is green. (See Figure 5-2.)
6. Switch the raster signal to blue, then to red and verify the
condition.
7. When the position of the deflection yoke has been decided,
fasten the deflection yoke with the screws and DY spacers.
8. If the beam does not land correctly in all the corners, use a
magnet to adjust it.
(See Figure 5-4.)
Fig. 5-2
Fig. 5-4
Purity control
corrects this area. Disk magnets or rotatable
disk magnets correct these
areas (a-d).
Deflection yoke positioning
corrects these areas.
a
b
b
c
c
d
d
a
}

–14 –
KV-DR29M37/DR34M37
RM-991
5-2. CONVERGENCE ADJUSTMENT
Preparation :
• Before starting this adjustment, adjust the focus, horizontal
size and vertical size.
• Receive cross hatch/dot pattern and set picture mode to
"STANDARD".
(1) Horizontal and Vertical Static Convergence
1. (Moving horizontally), adjust the H.STAT control so that the
red, green and blue dots are on top of each other at the center
of the screen.
2. (Moving vertically), adjust the V.STAT magnet so that the
red, green and blue dots are on top of each other at the center
of the screen.
3. Adjust Horizontal Trapezoid with “GEO 11 HTR” in Service
Mode to make H-Trapezoid distortion best.
4. If the H.STAT variable resistor cannot bring the red, green
and blue dots together at the center of the screen, adjust the
horizontal convergence with the H.STAT variable resistor and
the V.STAT magnet in the manner given below.
(In this case, the H.STAT variable resistor and the V.STAT
magnet influence each other, so be sure to perform
adjustments while tracking.)
1V. S TAT
2H. STAT VR
Center dot
R G B
R
G
B
H. STAT VR V. STAT
Magnet
RV702
H. STAT
Y magnet
C Board
RR
GG
BB
a
a
b
b b
R
R
G
G
B
B
a
b
3
R
R
GG
B
B
a
a
b
b
b
V.STAT
Purity
BMC (Hexapole)

–15 –
KV-DR29M37/DR34M37
RM-991
ba
cd
a-d : screen-corner
misconvergence
(3) Screen-corner Convergence
(2) Dynamic Convergence Adjustment
Preparation:
• Before starting this adjustment, adjust the horizontal static
convergence and the vertical static convergence
• Set the PICTURE and BRIGHTNESS to normal.
1. Adjust TLH. (TLH convergence piece)
1Receive the dot/hatch pattern signal and adjust picture quality
by the menu.
2Correct horizontal mis-convergence of red and blue of both
sides on the X axis.
When red is outside insert TLH convergence piece to right
side (TLH +) views from DY neck. And when blue is outside,
insert it to left side (TLH –) and take both sides.
2. Adjust XCV core.
To able to become balance of XCV on the X axis well.
3. Adjust V-TILT.
Correct the vertical mis-convergence of red and blue of
vertically sides on the Y axis.
4. Adjust YCH.
Adjust horizontal mis-convergence of red and blue of
vertically sides on the Y axis. Mentioned above steps 2 to 4
are adjusting respectively perform minuteness tracking.
4BMC (Hexapole) Magnet.
If the red, green and blue dots are not balanced or aligned,
then use the BMC magnet to adjust in the manner described
below.
5Y separation axis correction magnet adjustment.
1. Receive the cross-hatch signal and adjust [PICTURE] to
[MIN] and [BRIGHTNESS] to [STANDARD] .
2. Adjust the Y separation axis correction magnet on the neck
assembly so that the horizontal lines at the top and bottom of
the screen are straight.
Note
1. The Red and Blue magnets should be equally far from the
horizontal center line.
2. Do not separate the Red and Blue magnets too far. (Less than
8 mm)
R
(B)
B
(R)
B
(R)
TLH +
TLH -
R
(B)
XCV
BMC magnet C board
RV9001
VM board
TLV1
YCH
TLV2
RG B R G B R GB
RB
RG
GGB
RB
Blue
Red
VM board
Blue
Red
VM board
Neck assy Neck assy

–16 –
KV-DR29M37/DR34M37
RM-991
5-3. FOCUS ADJUSTMENT
Note
Focus adjustment should be completed before W/B adjustment.
(1) Receive digital monoscope pattern.
(2) Set "A/V CONTROL" to "STANDARD".
(3) Adjust FOCUS VR so that the center of the screen becomes
just focus.
(4) Change the receiving signal to white pattern and blue back.
(5) Confirm MAGENTA RING is not noticeable. In case
MAGENTA RING is obvious, adjust FOCUS VR to balance
between MAGENTA RING and FOCUS adjustment.
5-4. NECK ASSY TWIST ADJUSTMENT
(1) Receive dot/hatch pattern DRC-MF, DRC1250, DYNAMIC.
(2) Turn FOCUS VR fully counter-clockwise.
(3) Confirm the dot shape at the screen center. (Fig. 5-4)
(4) Resume FOCUS VR.
Note
In case of turning NECK ASSY, loosen the screw 3 turns. Do not
move the position.
OK
Turn NECK ASSY clockwise.
Turn NECK ASSY counter clockwise.
Fig. 5-4
Fix a Permalloy assy corresponding to the
misconverged areas.
a
b
c
d
Permalloy assembly
FLYBACK TRANSFORMER (T6803)
Focus
Screen
(No Function)
Lead Assy,
Focus
5-5. G2 (SCREEN) AND WHITE BALANCE
ADJUSTMENT
1. G2 (SCREEN) ADJUSTMENT
1) Set the PICTURE and BRIGHTNESS to normal.
2) Put to VIDEO input mode without signals.
3) Connect R, G and B of the C board cathode to the
oscilloscope.
4) Adjust BRIGHTNESS to obtain the cathode voltage to the
value below.
5) Whilst watching the picture, adjust the screen VR [RV9002]
located on the C board to the point just before the retrace
lines disappear (to the point before cut-off)
0 V
2. WHITE BALANCE ADJUSTMENT
1) Set to Service Mode (Refer Section 6-1: ADJUSTMENTS
WITH COMMANDER).
2) Input white raster signal.
3) Set the following condition.
PICTURE minimum, BRIGHTNESS 50%
4) Select GCT (WHB 08) and BCT (WHB 09) with 1and 4,
and adjust the level with 3and 6for the best white
balance.
5) Set the PICTURE to maximum.
6) Select GDR (WHB 05) and BDR (WHB 06) with 1and
4, and adjust the level with 3and 6for the best white
balance.
7) Write into the memory by pressing [MUTING] then -.
170 V ±2 (VDC)

– 17 –
KV-DR29M37/DR34M37
RM-991
SECTION 6
CIRCUIT ADJUSTMENTS
6-1. ADJUSTMENTS WITH COMMANDER
Service adjustments to this model can be performed using the
supplied Remote Commander RM-991.
a. ENTERING SERVICE MODE
With the unit on standby
The screen display is :
b. CANCELLATION OF SERVICE MODE
Set the standby condition (Press [POWER] button on the commander),
then press [POWER] button again, hereupon it becomes TV mode.
c. METHOD OF WRITE INTO MEMORY
1) Set to Service Mode.
2) Press 1(UP) and 4(DO WN), to select the adjustment
item Name.
3) Press 3or 6to raise/lower the data v alue.
4) Press [MUTING] button to indicate WRITE on the screen.
5) Press -button to write into memory .
d. OTHER FUNCTION VIA REMOTE COMMANDER
7, -All the data becomes the v alues in memory .
8, -All goes to the standard state.
5, -Service data initialization (Be sure not to use
usually.)
[DISPLAY], -Write 50Hz adjustment data to 60Hz, or vice
versa except 3NR category. However, if service
command write 50/60Hz is really needed for
3NR item, then write down all the 3NR service
items related to 50/60Hz, set these data in
service mode and write them separately for
50Hz and 60Hz condition. Press MUTE to write
and -to execute the writing. Do these process
once for 50Hz and once for 60Hz.
2, -Copy and write all data.
Cursor +/– Skip category (device) to category (device)
example : GEO 00 VSZ
DAC 00 HCT
e. MEMORY WRITE CONFIRMATION METHOD
1) After adjustment, pull out the plug from AC outlet, and then
plug into AC outlet again.
2) Turn the power switch ON and set to Service Mode.
3) Call the adjusted items again to confirm adjustments were made.
n[DISPLAY] n5nVOL (+) n[POWER]
Use the same method for all Items.
Note : 1. In [WRITE], the data for all items are written into
memory together.
2. For adjustment items that ha ve different standard data
between 50Hz or 60Hz, be sure to use the respecti ve
input signal after adjustment.
6-2. ADJUSTMENT METHOD
Item Number 00 of de vice GEO
This explanation uses V-size as an example.
1. Select “GEO 00 VSZ” with the 1and 4buttons.
2. Raise/lower the data with the 3and 6buttons.
3. Select the optimum state. (The standard is 1F for P AL
reception.)
4. Press [MUTING] button to indicateWRITE on screen. (The
display from SERVICE (green display) to WRITE (green
display).
5. Execute the writing with the -button. (The WRITE
display changes to red color while e xecuting and then back to
SERVICE (green display).
6. The WRITE e xecution is completed.
Example on screen display :-
29 SERVICE 50VSZ
Adjusted with [3]
and [6] buttons.
GREEN
Write with [MUTING]
Write executed with [0]
GEO 00
59 FF
FF
0 000A
0
1F WRITE 50VSZ
GREEN
GEO 00
59 0 000A
0
1F WRITE 50VSZ
RED
The WRITE
(red display)
return to SERVICE
(green display)
shows write is
executed.
GEO 00
59 FF 0 000A
0
048Q 0.9M
001 27E
08 1
048Q 0.9M
048Q 0.9M
001 27E
08 1
001 27E
08 1
PAL,SECAM:50
NTSC :60
Software version
Suffix No
(OEM Code)
Total Power-On time (hours)
00 VSZ 29 SERVICE
Data
Mode
Item
Name
Item No
p
Marking of new NVM
GEO
048Q 0.9M
001
59 000A
FF 0
0
08 1
Category
50
3D NR
S/N
detection
3D NR
mode
H count
of SYNC
detection
27E
V count
of SYNC
detection
˜

–18 –
KV-DR29M37/DR34M37
RM-991
Adjustment Item Table
GVTytilanoitcnuF laitinIegnaRnoitcnuFetoN&elbaTemaNeciveD
)deliated(eulaVlaitinI
yrogetaCoNemaN CN05CN06CV05CV06 05GORP
CN
06GORP
CN
05GORP
CV
06GORP
CV
OEG00ZSV12F3eziSVCN/CV*06/05QA0512AXC32624262
10SPV72F3noitisopVCN/CV*06/0552227242
20NLV5F0ytiraeniLVCN/CV*06/0570807080
30OCSA0F0noitcerroCSCN/CV*06/0590A090A0
40ZSHE1F3eziSHCN/CV*06/0512B112C1
50SPHF2F3noitisoPH CN/CV*06gorPDVD/05gorPDVD/06/05 A1119101A1A19090
60PAP82F3pmAniPCN/CV*06/05519181B1
70NPU52F3niPrenroCreppUCN/CV*06/0552627282
80NPL32F3niPrenroCrewoLCN/CV*06/0522722282
90 GCU03 tnemtsujdAniPrenroCreppUtsoMCN/CV*06/0510103010
A0 GCL13 tnemtsujdAniPrenroCrewoLtsoMCN/CV*06/0510200020
B0 PCU23 gnitteSnoitisoPnoitcerroCniPrenroCreppUtsoMCN/CV*06/0520202020
C0 PCL23 gnitteSnoitisoPnoitcerroCniPrenroCrewoLtsoMCN/CV*06/0530202020
D0 LOP01 ytiraloPniPrewoL/reppUtsoMCN/CV*06/0500000000
E0HPP42F3tnemtsujdAdiozeparTVCN/CV*06/05*RP/4R/FF029112B1
F0LGAA0F0elgnACFACN/CV*06/05D1D11222
01WOB6F0woBCFACN/CV*06/0581819181
11RTHF0F1lortnoCniaGleveLwaSevaWOwaSVCN/CV*06/05*RP/4R/FF00000000
21DPM4F0lortnoCsaiBCDevaWaraPPMCN/CV*06/05*RP/4R/FF70707070
31 APME0F0lortnoCniaGevaWaraPPMCN/CV*06/05*RP/4R/FF50505050
41PBPF1F3lortnoCniaGleveLwaSevaWaraPtneCHCN/CV*06/05*RP/4R/FF72723252
51ABPF0F1lortnoCniaGevaWaraPtneCHCN/CV*06/05*RP/4R/FFA0B0B0C0
61 SBH11 WSFFO/NOklBHCN/CV*06/05*RP/4R/FF10101010
71 LBH73F3lortnoCnoitisoPklBHtfeL CN/CV*06gorPDVD/05gorPDVD/06/0591429142E192E192
81 RBHC2F3lortnoCnoitisoPklBHthgiR CN/CV*06gorPDVD/05gorPDVD/06/0562826282B2D2B2D2
91 PCP07 gnitteSnoitcerroCnoitrotsiDVHpmAniPCN/CV*06/05*RP/4R/FF00000000
A1 PCA17 gnitteSnoitcerroCnoitrotsiDVHnoitisoPHCN/CV*06/05*RP/4R/FF00000000
B1 PCV83 gnitteSnoitcerroCnoitrotsiDVHlacitreVCN/CV*06/05C0C0C0C0
C1 PCH23 gnitteSnoitcerroCnoitrotsiDVHeziSHCN/CV*06/0570707070
D1 CSU01 FFO/NOedoMpmuJesluPfeRCN/CV*06/05*RP/4R/FF00001010
E1SAVF2F3lortnoCtcepsAVCN/CV*06/05 F2 F20303
F1CSVF1F3lortnoCllorcSVCN/CV*06/05 F1 F1E1F1
02 UBV71 lortnoCnoitisoPpoTklBVCN/CV*06/05*RP/4R/FF4090E0C0
12 LBV71 lortnoCnoitisoPmottoBklBVCN/CV*06/05*RP/4R/FF0090C0F0
22 BKAF0F1gnitteSgnimiTesluPfeRhcBBKACN/CV*06/05C1F0C171
32 SDV11 wSFFO/NOpmuJesluPFERhcBCN/CV*06/05*RP/4R/FF00000000
42 TSR01 gnitteSnoitisoPtratSevirDVfOecarteRCN/CV*06/05*RP/4R/FF00000000
52YPC01 aeraMVNzH06/05llaotatadOEGehtypoC

–19 –
KV-DR29M37/DR34M37
RM-991
GVTytilanoitcnuF laitinIegnaRnoitcnuFetoN&elbaTemaNeciveD )deliated(eulaVlaitinI
yrogetaCoNemaN nommoC0506CNnOocECNffOocECVnOocECVffOocE
CAD00TCH33F7retneCHzH06/055781AXC A4A4
10NLH72F3ytiraeniLHzH06/05 9393
20 HDQF1F3esahPFDzH06/05 3838)73M92RD-VK(
20 HDQF1F3esahPFDzH06/05 0101)73M43RD-VK(
30 STHBBFFgnitteSataDtratSdiozeparTHelbaton 9C
40 OTHE0FFgnitteSataDtesffOdiozeparTHelbaton E0
50 SSNF7FFataDtratSSNelbaton E7
60 OSN90FFataDtesffOSNelbaton 90
70 CBA0FFlortnoCA/DLBACN/CV*ffo/noOCE 00000000
80YPC01 aeraMVNzH06/05llaotatadCADehtypoC
GVT0ytilanoitcnuF laitinIegnaRnoitcnuFetoN&elbaT emaNeciveDnommoC
nommoCoNemaN
BHW00SOY7F0langisYrofrellecnaCtesffOCD QA0512AXC70
10 SOUF1F31bCrofrellecnaCtesffOCD F1
20 SOVF1F31rCrofrellecnaCtesffOCD F1
30RBSF1F3lortnoCssenthgirBbuS 91
40 RDR92F3evirDR 92
50RDG42F3evirDG 42
60RDB52F3evirDB 52
70 TCR92F3ffotuCR 92
80TCG01F3ffotuCG 01
90TCB52F3ffotuCB 01
A0 OBS02F3tesffOssethgirBbuS cimanyDtpecxeedoMerutciPC1
B0 ODRF1F3tesffOevirDR cimanyDtpecxeedoMerutciPF1
C0 ODG91F3tesffOevirDG cimanyDtpecxeedoMerutciP91
D0 ODBB1F3tesffOevirDB cimanyDtpecxeedoMerutciPA1
E0 OCRF1F3tesffOffotuCR cimanyDtpecxeedoMerutciPF1
F0 OCG92F3tesffOffotuCG cimanyDtpecxeedoMerutciPA2
01 OCBA1F3tesffOffotuCB cimanyDtpecxeedoMerutciPD1
