The Bio Tuner
Model BT9 Manual
Contents
WELCOME TO SOTA..................................................................................................... 2
BEFORE USING ............................................................................................................... 2
LEARN MORE ................................................................................................................. 2
COMPLETE UNIT INCLUDES...................................................................................... 2
DO NOT USE.................................................................................................................... 3
CAUTIONS ....................................................................................................................... 3
SUMMARY OF LIGHTS ................................................................................................. 3
HOW TO USE THE BIO TUNER................................................................................... 4
How it Should Feel...................................................................................................... 6
Typical Use................................................................................................................... 6
Replacing the Conductive Rubber Electrodes .........................................................7
OUTPUT OF SIX MODES............................................................................................... 7
ELECTRICAL SPECIFICATIONS ................................................................................. 8
Power Requirements................................................................................................... 8
Optional Power Input................................................................................................. 8
Output Specications.................................................................................................. 8
TROUBLESHOOTING.................................................................................................... 9
COUNTRIES THAT PARTICIPATE IN MANUFACTURING................................. 9
REPLACEMENT ACCESSORIES.................................................................................. 9
WARRANTY..................................................................................................................... 9
REPAIRS............................................................................................................................ 9

© 2015-2022 SOTA Instruments Inc. Page 2 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
WelCome to sotA
Thank you for allowing us to be a part of your wellness team.
The Bio Tuner is a consumer product designed to be used as part of a Wellness
Lifestyle. A commitment to healthy lifestyle choices is an important factor in the
journey to Wellness.
The SOTA Bio Tuner supports the mind-body connection by offering harmonic
frequencies that help create an inner sense of calm, balance and tranquility.
The Bio Tuner is designed to be used independently, but can also be used together
with any of the SOTA Products.
With proper care, your Bio Tuner should provide you many years of trouble-free use.
Please understand that results will vary.
Before Using
Please read the manual thoroughly before using your Bio Tuner.
We’ve made every effort to ensure the information in your manual is up-to-date at
the time of printing ... since that time however, new information may have become
available. For the most up-to-date manual, please visit our website www.sota.com/
manuals.
leArn more
To learn more about the Bio Tuner we invite
you to visit the SOTA website:
www.sota.com
The website offers How to Videos, Frequently
Asked Questions, The SOTA Products User
Guide, SOTA News ... and more.
Complete Unit inClUdes
• One (1) Bio Tuner Unit
• One (1) Pair of Ear Clips with Conductive Rubber Electrodes
• Two (2) Pair Conductive Rubber Electrodes
• One (1) Cord
• One (1) Arm Band and Clip

© 2015-2022 SOTA Instruments Inc. Page 3 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
• One (1) 9-Volt Alkaline Battery
• One (1) Packaging Box
• One (1) Product Manual
do not Use
1.Do not use in the following situations as safety has not been explored:
a. In the case of pregnancy.
b. With an implanted device such as a pacemaker, etc.
2.As with all electrical products do not use near water, when driving a car or when
operating heavy equipment.
3.Do not:
a. Suddenly increase the intensity to the maximum level. The intensity should be
increased gradually to a comfortable level to ensure safety.
b. Connect the Bio Tuner Cord to any other USB outlet, such as a computer or power
supply. Do not plug any other USB connections into the Bio Tuner, other than the
Bio Tuner Cord.
CAUtions
1.If you are on psychiatric medication, have a neurological condition or seizures,
please consult your health care provider prior to using the Bio Tuner.
2.If you experience an increase in tinnitus or ringing in the ears, please discontinue use.
3.If you experience headaches or nerve pain when using the unit, consider Modes
4, 5 or 6 as they have a gentler output. If headaches or nerve pain persist, please
discontinue use.
4.While this technology is generally considered safe, there exists potential for rare
individual reactions that cannot reasonably be foreseen. Therefore, your use of the
SOTA Products constitutes your agreement that you are responsible for your
decision to use the technology and that you hold SOTA harmless for any injuries or
damage believed to arise from using the SOTA Products.
sUmmAry of lights
GREEN: Indicates which Mode is selected.
RED: Indicates the battery is low and will soon need replacing.

© 2015-2022 SOTA Instruments Inc. Page 4 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
YELLOW: Used for testing to ensure the ow of current through the Unit, Cord and
Ear Clips.
hoW to Use the Bio tUner
1.Place the 9-Volt Alkaline battery in the unit.
a. On the back of the unit, slide off the battery cover.
b. Position the 9-Volt Alkaline battery so the positive
(+) and negative (-) terminals line up as in
image 1.
Note: The smaller circle on the battery matches
the smaller circle in the case … the larger battery
circle matches the larger circle in the case.
c. Slide the 9-Volt Alkaline battery into the case and
push down.
d.Slide the cover back onto the unit.
2. Clean ear lobes to remove oils from the skin. This will
allow for better conductivity.
3. Slide the Arm Band up the arm to a comfortable
position. Tighten the band to secure it in place as in
Image 2.
Options:
a. If preferred the unit can be placed in a pocket.
b.If the Arm Band is too
large a shorter Arm Band
is available.
4. Insert the cord into the jack on the unit as in image
3. The USB symbol on the plug should be facing up.
When the plug is positioned correctly, it will slide in
gently. Do not force.
5.Slide the clip on the back of the Bio Tuner onto the
holding clip on the Arm Band as in image 4.
6.Insert the pins on the cord into the Ear Clips.
3
1
2

© 2015-2022 SOTA Instruments Inc. Page 5 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
7. Wet the conductive rubber on the Ear Clips with water
or conductive gel.
8. Place one Ear Clip on each ear lobe, positioning the Ear
Clip with the conductive rubber at the back of the ear lobe
and close to the jaw as in image 5.
9. Turn the unit ON by rotating the ON/OFF switch
clockwise.
All the lights will ash once and the unit will beep, before
starting the unit in Mode 1. If the lights do not come on,
the battery may not be placed correctly.
10. Gradually turn up the intensity to a comfortable level.
See ‘How It Should Feel’ on page 6.
11.Change modes by pushing the Mode button. The GREEN light indicates which
Mode is selected and that the timing has started. See Mode information on page 7.
12.The unit will beep twice when the 20-minute timed session has ended. The unit will
automatically cycle into Sleep Mode and the GREEN Mode
light will ash every 2 seconds.
a. While in Sleep Mode, the battery is still being used. To
save your battery, turn the unit OFF.
b. To turn the unit OFF, rotate the ON/OFF switch
counter clockwise until it clicks. Do not force the ON/
OFF switch past its natural stopping point.
13.To do additional sessions, the unit will need to be turned
off and restarted as per step 9. Wet the Ear Clips between
each timed cycle.
14.Unplug the Cord. Do not store the unit with the Cord
plugged in as this can damage the Cord.
Notes:
Ear Clips: The Ear Clips may feel more comfortable with the use of either a
conductive gel or aloe vera gel rather than water. Over time, the Conductive Rubber
Electrodes in the Ear Clips may lose their conductivity and will need to be replaced.
Changing Modes: When the Mode is changed during a timed session, the timing
5
4

© 2015-2022 SOTA Instruments Inc. Page 6 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
continues without interruption to complete a
session of approximately 20 minutes.
Output: The YELLOW light is used to test the
output of the unit. During normal operation,
when the unit is turned ON and the Ear Clips
are positioned correctly, the YELLOW light may
or may not come on. As long as the current is
felt, the unit is operating correctly, regardless of
the YELLOW light.
Care of Bio Tuner Cord and Ear Clips:
Occasionally, remove the conductive rubber
from the Ear Clips to clean in a mild soap
solution. Rinse thoroughly. If necessary, gently
wipe the metal pins of the Bio Tuner Cord.
Low Battery Warning: The RED light comes on and the unit will beep when the
battery is low. This means the battery will soon need to be replaced.
Replacement Batteries: When purchasing replacement 9-Volt batteries, take the Bio
Tuner with you to ensure a proper t, as 9-Volt batteries vary in size. Alkaline or
rechargeable batteries are recommended.
hoW it shoUld feel
1. The sensation is a pleasant buzzing. It is not necessary to turn the intensity up to
an uncomfortable level. If it feels prickly or unpleasant, try the following:
a. Wet the conductive rubber of the Ear Clips again.
b. Apply conductive gel or aloe vera gel to the ear lobes.
c. Clean the Conductive Rubber Electrodes.
d.Replace the Conductive Rubber Electrodes.
2. With repeated use, the buzzing sensation may not be felt as much. The intensity
may be turned up if desired.
3. You may feel a sensation on one side more than the other.
4. In rare instances, some individuals may not feel the current.
typiCAl Use
Length of session: One cycle is timed for ~20-minutes. One session can be 20 to 40
minutes or more.

© 2015-2022 SOTA Instruments Inc. Page 7 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
The unit can be used daily or as often as needed throughout the day. It often takes at
least 30 consecutive days of use to experience benets.
Length of Use: The SOTA Products User Guide available at www.sota.com/spug
offers suggestions for Focused, Basic and Ongoing Wellness Plans.
General Guideline: The unit should be used daily, for a minimum of 4 weeks or
longer. After benets have been achieved, simply use the unit as needed.
Intensity Level: The intensity should always be set to a comfortable level. Be sure to
reduce the intensity before changing modes. After the new mode is selected, readjust
the intensity.
Sensitive skin: During the rst few weeks of use, the skin may become irritated.
Over time, irritation usually decreases or disappears. Apply a healing lotion after use
if the ear lobes become red or irritated.
Drink plenty of water: It’s important to drink enough water when using the unit.
Drinking ozonated water is especially helpful.
Stop Gradually: Reduce the amount of time each day for the last week of use.
replACing the CondUCtiVe rUBBer eleCtrodes
1. Remove the Ear Clips from the Cord.
2. Gently pull the black Conductive Rubber
Electrodes out of the Ear Clips.
3. Insert the new Conductive Rubber Electrodes
into the Ear Clips. Press the Electrode into
place.
oUtpUt of siX modes
The Bio Tuner provides six different comfort
Modes to experiment with and discover which feels or works best. Try the different
Modes to determine which one feels most comfortable. One Mode is not considered
more benecial than another.
In all Modes, the base frequency of 1,000 Hz pulse-modulated by 111.11 Hz is present.
Modes 4, 5, and 6 have a more gentle feel.
See Table of Modes on page 8.

© 2015-2022 SOTA Instruments Inc. Page 8 of 9|www.sota.com
The Bio Tuner Model BT9 Manual
eleCtriCAl speCifiCAtions
poWer reqUirements
Use a 9–Volt Alkaline battery for optimal operation.
optionAl poWer inpUt
The Bio Tuner can also be operated using rechargeable batteries. When purchasing
rechargeable batteries, it is suggested to take the unit with you to ensure the batteries
will t the enclosure.
oUtpUt speCifiCAtions
Maximum <1.5mA Peak ~40 Volts Peak-Peak into typical 4k ohm load. Minimum
<~10uA, 10 Volt Peak-Peak at lowest setting. Output impedance ~20k ohm.
1,000 Hz (+/- 1%) pulse-modulated by 111.11 Hz (+/- 1%). Waveforms are Quartz
Crystal-Controlled for precise frequency output. There is also a broad range of
harmonic frequencies delivered in each pulse as observed on a frequency domain
spectrum analyzer.
Bio tUner modes
MODE 1-3 (550 uS pulse width)
Mode 1: 1,000 Hz modulated by 111.11 Hz,
Output = Continuous
Mode 2: 1,000 Hz modulated by 111.11 Hz,
Output = 1 Second ON, 1 Second OFF (0.5 Hz)
Mode 3: 1,000 Hz modulated by 111.11 Hz,
Output = Amplitude Modulated by 7.83 Hz Schumann (Earth) Sine Wave
MODE 4-6 (220 uS PULSE WIDTH)
Mode 4: 1,000 Hz modulated by 111.11 Hz,
Output = Continuous
Mode 5: 1,000 Hz modulated by 111.11 Hz,
Output = 1 Second ON, 1 Second OFF (0.5 Hz)
Mode 6: 1,000 Hz modulated by 111.11 Hz,
Output = Amplitude Modulated by 7.83 Hz Schumann (Earth) Sine Wave

Made in China. Designed and Engineered in Canada.
• The SOTA units are consumer products designed to be used as part of a Wellness Lifestyle • The SOTA units are not medical devices nor are they
intended to diagnose, treat or cure any medical or health condition • The use, safety or eectiveness of the SOTA units has not been approved by any
government agency • Please consult a health practitioner for any medical or health condition • Results using the SOTA Products will vary for each
person • Please note that all purchases of SOTA Products are deemed to be made in Penticton, BC, Canada •
© 2015-2022 SOTA Instruments Inc. Page 9 of 9 |www.sota.com
The Bio Tuner Model BT9 Manual
Pulses are an alternating current (AC) output with no direct current (DC) or offset
bias. Output is transformer coupled so that no DC can appear at electrodes.
troUBleshooting
A Troubleshooting Guide for the Bio Tuner is available at
www.sota.com/manuals. This Guide is a great tool to check if you are experiencing
any issues with your unit.
CoUntries thAt pArtiCipAte in mAnUfACtUring
The manufacturing of the SOTA Products is a global collaboration. The following
countries have participated in the making of the Bio Tuner (listed in alphabetical
order): Canada, China, Hong Kong, Malaysia, Taiwan, Thailand and the USA.
replACement ACCessories
To replace your accessories, contact your supplier.
WArrAnty
The Bio Tuner Model BT9 is covered by a three (3) year parts and labor warranty on all
internally mounted components. Please keep proof of purchase. Warranty is void if the
failure is due to abuse or negligence.
repAirs
Please contact your supplier for return instructions. For information about your closest
repair depot, contact [email protected] or call 1.250.770.2023 or 1.800.224.0242 (toll-free
in Canada & USA).
