Soundcore Zero User manual

Model No.: Z5180
V01
Soundcore Model Zero
User Manual
Uživatelská příručka | Brugervejledning | Benutzerhandbuch | Manual del usuario
Käyttöopas | Manuel de l’utilisateur | Manuale utente | Manual do Usuário
Användarhandbok | Gebruikershandleiding | Brukerhåndbok
取扱説明書 | 사용 설명서 | 用户手册 | 使用者手冊
Руководство пользователя |  | 

EN
01 02
EN EN
Safety Instructions
• Avoid dropping.
• Do not disassemble.
• Do not submerge in water.
• Avoid extreme temperatures.
• Do not use the device outdoors during thunderstorms.
• Use original or certified cables.
• Do not use any corrosive cleaner/oil to clean.
What’s Included
User's manual
The adapter vary by region.
T
At a Glance
2 3 4 5
bass
76
10
9
8
AUX POWER
1
1BassUp button / BassUp indicator 6Power button
2Volume down control 7Power indicator
3Multi-function button 83.5mm audio input port (AUX)
4Volume up control Power port
5Bluetooth button / Bluetooth indicator Charging indicator

EN
01 02
EN EN
Safety Instructions
• Avoid dropping.
• Do not disassemble.
• Do not submerge in water.
• Avoid extreme temperatures.
• Do not use the device outdoors during thunderstorms.
• Use original or certified cables.
• Do not use any corrosive cleaner/oil to clean.
What’s Included
User's manual
The adapter vary by region.
T
At a Glance
2 3 4 5
bass
76
10
9
8
AUX POWER
1
1BassUp button / BassUp indicator 6Power button
2Volume down control 7Power indicator
3Multi-function button 83.5mm audio input port (AUX)
4Volume up control Power port
5Bluetooth button / Bluetooth indicator Charging indicator

03 04
EN EN
Using Your Soundcore Model Zero
1. Turn On / O
ON Press and hold for more than 2 seconds.
OFF Press and hold for more than 2 seconds
a. Bluetooth mode
Bluetooth ON
Soundcore
Model Zero
4
× 1
bass
×
1
Enter Bluetooth Pairing Mode
Flashing Blue Bluetooth Pairing Mode
Solid Blue Connected to a device
2Enter True Wireless Stereo Group Mode / Disconnect True Wireless
Stereo
Double Flashing
White True Wireless Stereo Group Mode
Solid White Connected to True Wireless Stereo
bass bass
2 2
With True Wireless Stereo technology, you can pair your Soundcore
Model Zero with another Soundcore Model Zero to explore the best
sound eects with le and right sound channels separated on both
speakers.
T

03 04
EN EN
Using Your Soundcore Model Zero
1. Turn On / O
ON Press and hold for more than 2 seconds.
OFF Press and hold for more than 2 seconds
a. Bluetooth mode
Bluetooth ON
Soundcore
Model Zero
4
× 1
bass
×
1
Enter Bluetooth Pairing Mode
Flashing Blue Bluetooth Pairing Mode
Solid Blue Connected to a device
2Enter True Wireless Stereo Group Mode / Disconnect True Wireless
Stereo
Double Flashing
White True Wireless Stereo Group Mode
Solid White Connected to True Wireless Stereo
bass bass
2 2
With True Wireless Stereo technology, you can pair your Soundcore
Model Zero with another Soundcore Model Zero to explore the best
sound eects with le and right sound channels separated on both
speakers.
T

05 06
EN EN
×
1
Play / Pause
×
2
Play Next Song
×
1
Press to turn Bass Up on and o
×
1
Answer Call / End Call / Switch between a call on hold and an active
call
2s Reject Call
2s End current call and answer incoming call / End current call and
switch to call on hold
2s Switch audio source between Speaker and Phone
×
1
Put current call on hold and answer incoming call
2s Activate Siri / Other Voice Control Soware
Volume Up / Down
Solid White (Bluetooth indicator) On a Call
Flashing Blue (Bluetooth indicator) Incoming Call
When turned on, Soundcore Model Zero will automatically connect
to the last connected device if available. If not, press the Bluetooth
pairing button to activate pairing mode.
To pair a dierent device, press the Bluetooth button to re-enter
pairing mode. Then repeat the pairing steps.
Having connection problems? Remove Soundcore Model Zero from
your device’s Bluetooth history and ensure it’s less than 3 feet away.
Then try pairing again. To get the best sound quality, make sure
there is a clear line of sight between the connected device and your
speaker.
T
b. Multi-point play
1. Connect the first mobile phone to your Soundcore Model Zero, press the
Bluetooth button once on Soundcore Model Zero aer the connection is
successful.
2. Press the Bluetooth button on Soundcore Model Zero twice to enter
Bluetooth pairing mode.
3. Connect the second mobile phone to Soundcore Model Zero. Once the
second mobile phone is connected to Soundcore Model Zero, turn on the
Bluetooth of the first mobile phone, then find Soundcore Model Zero in your
pairing list. Click it for connection, make sure the connection is successful.
Note: Soundcore Model Zero can only play the music on one mobile phone at
a time.

05 06
EN EN
×
1
Play / Pause
×
2
Play Next Song
×
1
Press to turn Bass Up on and o
×
1
Answer Call / End Call / Switch between a call on hold and an active
call
2s Reject Call
2s End current call and answer incoming call / End current call and
switch to call on hold
2s Switch audio source between Speaker and Phone
×
1
Put current call on hold and answer incoming call
2s Activate Siri / Other Voice Control Soware
Volume Up / Down
Solid White (Bluetooth indicator) On a Call
Flashing Blue (Bluetooth indicator) Incoming Call
When turned on, Soundcore Model Zero will automatically connect
to the last connected device if available. If not, press the Bluetooth
pairing button to activate pairing mode.
To pair a dierent device, press the Bluetooth button to re-enter
pairing mode. Then repeat the pairing steps.
Having connection problems? Remove Soundcore Model Zero from
your device’s Bluetooth history and ensure it’s less than 3 feet away.
Then try pairing again. To get the best sound quality, make sure
there is a clear line of sight between the connected device and your
speaker.
T
b. Multi-point play
1. Connect the first mobile phone to your Soundcore Model Zero, press the
Bluetooth button once on Soundcore Model Zero aer the connection is
successful.
2. Press the Bluetooth button on Soundcore Model Zero twice to enter
Bluetooth pairing mode.
3. Connect the second mobile phone to Soundcore Model Zero. Once the
second mobile phone is connected to Soundcore Model Zero, turn on the
Bluetooth of the first mobile phone, then find Soundcore Model Zero in your
pairing list. Click it for connection, make sure the connection is successful.
Note: Soundcore Model Zero can only play the music on one mobile phone at
a time.

07 08
EN EN
c. AUX-In mode
AUX
AUX
AUX POWER
*SoundLine AUX cable sold separately.
Plugging in an audio cable will automatically switch to AUX mode.
When using AUX mode, control audio playback via the connected
device.
T
Charging your Soundcore Model Zero
AUX POWER
POWER
Slow Flashing Red (Power indicator) Low Battery
Solid Red (Power indicator) Charging
O Fully Charged
Use the included adapter to charge your Soundcore Model Zero and
make sure it is fully charged before its first use.
Disconnect your speaker from the charger when fully charged. Do not
charge your speaker for extended periods.
When not in use, store your speaker in a cool place.
T

07 08
EN EN
c. AUX-In mode
AUX
AUX
AUX POWER
*SoundLine AUX cable sold separately.
Plugging in an audio cable will automatically switch to AUX mode.
When using AUX mode, control audio playback via the connected
device.
T
Charging your Soundcore Model Zero
AUX POWER
POWER
Slow Flashing Red (Power indicator) Low Battery
Solid Red (Power indicator) Charging
O Fully Charged
Use the included adapter to charge your Soundcore Model Zero and
make sure it is fully charged before its first use.
Disconnect your speaker from the charger when fully charged. Do not
charge your speaker for extended periods.
When not in use, store your speaker in a cool place.
T

09 10
EN EN
Specifications
Specifications are subject to change without notice.
T
Input: 15 V 3A
Audio output: 15 W x 2 + 15 W x 2
Battery capacity : max. 6700 mAh
Charging time : 3.0 hours
Play time (varies by volume level and music content): 10 hours
Size: 256 x 128 x 240mm
Weight (without packaging): 3.9 kg / 138 oz
Bluetooth version: V5.0
Bluetooth range : 20 m / 66 
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong
Kong
Product Number Z5180
Bluetooth Speaker / Soundcore Model Zero
For FAQs and more information, please visit:
Please note that your rights under applicable law governing the sale of
consumer goods remain unaected by the warranties given in this Limited
Warranty.

09 10
EN EN
Specifications
Specifications are subject to change without notice.
T
Input: 15 V 3A
Audio output: 15 W x 2 + 15 W x 2
Battery capacity : max. 6700 mAh
Charging time : 3.0 hours
Play time (varies by volume level and music content): 10 hours
Size: 256 x 128 x 240mm
Weight (without packaging): 3.9 kg / 138 oz
Bluetooth version: V5.0
Bluetooth range : 20 m / 66 
Anker Innovations Limited
Room 1318-19, Hollywood Plaza, 610 Nathan Road, Mongkok, Kowloon, Hong
Kong
Product Number Z5180
Bluetooth Speaker / Soundcore Model Zero
For FAQs and more information, please visit:
Please note that your rights under applicable law governing the sale of
consumer goods remain unaected by the warranties given in this Limited
Warranty.
