SoundCraft GIGRAC User manual

GREAT SOUND MADE EASY
User Guide
Soundcraft
Harman International Industries Ltd
Cranborne House, Cranborne Road, Potters Bar, Herts, EN6 3JN, UK
TEL: [phone] FAX: [phone] EMAIL: [email protected]
Soundcraft USA
8500 Balboa Blvd., Northridge, CA 91329, USA
TEL: [phone] FAX: [phone] EMAIL: [email protected]
www.gigrac.com
Soundcraft reserves the right to improve or otherwise alter any information supplied in this document or any other documentation supplied hereafter. E&OE 11/03.
This equipment complies with the EMC Directive 89/336/EEC
#15713 GIGRAC User Guide Cover 17/11/03 3:03 pm Page 1

2
IMPORTANT
Please read this manual carefully before using
your mixer for the first time.
© Harman International Industries Ltd. 2003
All rights reserved
Parts of the design of this product may be protected by worldwide
patents.
Part No. ZM10107-01
Issue: 1
Soundcraft is a trading division of Harman International Industries Ltd.
Information in this manual is subject to change without notice and does
not represent a commitment on the part of the vendor. Soundcraft
shall not be liable for any loss or damage whatsoever arising from the
use of information or any error contained in this manual.
No part of this manual may be reproduced, stored in a retrieval system,
or transmitted, in any form or by any means, electronic, electrical,
mechanical, optical, chemical, including photocopying and recording, for
any purpose without the express written permission of Soundcraft.
Harman International Industries Limited
Cranborne House
Cranborne Road
POTTERS BAR
Hertfordshire
EN6 3JN
UK
Tel: [phone]
Fax: [phone]
http://www.soundcraft.com

3
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS ........................ 4
Introduction ............................................................ 7
Quick Start Guide .................................................... 8
A Note on Channel Use ........................................... 14
Front and Rear Panels ............................................ 15
Master Section GigRac 600.................................... 18
Master Section GigRac 300.................................... 24
Rear Panel GigRac 600 .......................................... 28
Rear Panel GigRac 300 .......................................... 30
Rackmounting Your GigRac ...................................... 32
Connectors and Leads ............................................ 33
Block Diagram GigRac 600 ..................................... 34
Block Diagram GigRac 300 ..................................... 35
Warranty .............................................................. 36
Gigrac 300 / 600 Specifications .............................. 37
Your Notes: ........................................................... 38
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.

4
IMPORIMPOR
IMPORIMPOR
IMPORTT
TT
TANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONSANT SAFETY INSTRUCTIONS
ANT SAFETY INSTRUCTIONS
CAUTIONS
•To avoid the risk of fire, replace the mains fuse only with the correct
type and value fuse, as marked on the rear of the product.
•ATTENTION: - Afin de réduire le risque de feu remplacer seulement avec
fusible de même type.
•MAINS VOLTAGE SELECTION
This setting is NOT User Adjustable.
The units are capable of operating at either 230V AC or 115V AC
mains voltages ±10%.
•REPLACING MAINS FUSE
Remove the mains lead from the connector. Use a small screwdriver
to unscrew the fuse carrier from its location to the left of the
mains power connector. Check the fuse is of the correct type and
value and replace if necessary; also check that the voltage rating
as marked on the rear panel is correct for the mains supply level
before switching the unit ON again.
If the mains fuse fails repeatedly this may be because an electrical
safety hazard exists. The unit must be taken out of service and
referred to the Soundcraft dealer from where the equipment was
purchased.
•THIS UNIT MUST BE EARTHED
Under no circumstances should the mains earth be disconnected
from the mains lead.
•ATTENTION: - Cet appareil doit être branché à la terre.
The wires in the mains lead are coloured in accordance with the following
code:
UK & EU US & CAN
Earth / Ground: Green and Yellow Green and Yellow
Neutral: Blue White
Live: Brown Black

5
As the colours of the wires in the mains lead may not correspond
with the coloured markings identifying the terminals in your plug,
proceed as follows:
The wire which is coloured Green and Yellow must be connected
to the terminal in the plug which is marked with the letter E
or by the earth / ground symbol:
The wire which is coloured Blue or White must be connected
to the terminal in the plug which is marked with the letter N.
The wire which is coloured Brown or Black must be connected
to the terminal in the plug which is marked with the letter L.
Ensure that these colour codings are followed carefully in
the event of the plug being changed.
Replacement Part No: FJ8016 (UK) : FJ8017 (EU) : FJ8018 (US &
CAN)
•Do not install near any heat sources such as radiators, heat
resistors, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not use this apparatus near water. The apparatus must
not be exposed to dripping or splashing. Objects containing
liquid must not be placed on the apparatus.
•The disconnect device is the mains plug or the appliance
connector: either one must remain accessible so as to be
readily operable in use.
•Do not defeat the safety purpose of the polarized or grounding
type plug.
A polarized plug has two blades with one wider than the other.
A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. When the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs and convenience receptacles.
•Only use cables and hardware specified by the manufacturer.

6
•Unplug this apparatus during lightning storms or when unused
for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way
such as, the power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, the
apparatus does not operate normally or has been dropped.
•It is recommended that all maintenance and service on the
product should be carried out by Soundcraft or its authorised
agents. Soundcraft cannot accept any liability whatsoever
for any loss or damage caused by service, maintenance or
repair by unauthorised personnel.
•If a trolley is used, use caution when moving the trolley /
apparatus combination to avoid injury from tip-over.
WARNINGS
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•This unit contains no user serviceable parts. Refer all servicing
to a qualified service engineer, through the appropriate
Soundcraft dealer.
•Clean the apparatus only with a dry cloth.
•DO NOT block any of the ventilation openings. DO NOT install
where air cannot flow over the rear of the unit. DO Install in
accordance with the manufacturers instructions.

7
IntrIntr
IntrIntr
Introductionoduction
oductionoduction
oduction
Firstly we’d like to thank you for choosing the Soundcraft GigRac. We
hope you have many happy years together!
Features
8 Microphone Inputs
48V Phantom Power for condenser microphones (Inputs 1-4 only)
PAD buttons for controlling loud input signals (Inputs 1-4 only)
4 Stereo compatible inputs
Treble and Bass controls
Individual volume controls on each channel for Monitor level.
Individual volume controls on each channel for Main level.
Individual send controls for GiGFX on each channel
7 Band Graphic Equaliser
8 x Digital Effects (24 Bit/48 kHz)
Record Output
FX bypass switch
FX bus output socket
Submix input
Amplifier ‘Clip’warning light
10 segment LED output level meter
The GigRac case.
Your GigRac is cased in a structural foam copolymer polypropylene resin,
which gives an optimum combination of strength and impact resistance.
This material also helps to keep the shell in good condition as it very
resistant to dents and scratches.
The nature of the moulding process leaves the irregular streaky surface
finish that gives the GigRac its tough and unique look.
Amplifier Power Ratings
GigRac 300 GigRac 600
1 x 300W @ 4 Ohms 2 x 300W @ 4 Ohms
1 x 220W @ 8 Ohms 2 x 220W @ 8 Ohms

8
Quick StarQuick Star
Quick StarQuick Star
Quick Start Guidet Guide
t Guidet Guide
t Guide
If like most people you can’t wait to use your GigRac for the first time,
then use the Quick Start Guide to get things started. The Quick Start
Guide covers the following:
1. Connecting up your loudspeakers to the GigRac
2. Plugging in a vocal microphone
3. Adding Treble or Bass to the signals
4. Plugging in a guitar or stereo keyboard
5. Apply one of the 8 GigFX digital effects to the signals
Note: We recommend that you read through the entire
GigRac user guide to familiarise yourself with all of the
features on offer.

9
GigRac 600 shown.

10
1. Connecting up your loudspeakers to the GigRac
Note: Make sure your GigRac is not powered up. This
is very important to prevent any damage to either the
GigRac or your loudspeakers!
Using good quality speaker cables connect the loudspeakers to the
Speaker outputs on the rear of the GigRac.
If you have cables equipped with Neutrik Speakon connectors then use
the Speakon connectors on the rear of the GigRac. Alternatively if you
have cables equipped with jack plugs then use the jack sockets on the
rear of the GigRac.
Note: Because the GigRac 300 and GigRac 600 are
mono mixers there is no difference between the signals
sent to the Left or Right speakers i.e. both speakers
will receive the same signal equally all of the time.
Make sure that the Main Master Volume control (1) is turned fully down
Now switch the GigRac on using the Power switch on the rear of the
unit.
2. Plugging in a vocal microphone
Note: Before connecting a microphone to channels 1-4,
make sure that the 48V phantom power switch is
switched off (The red LED should not be illuminated)
Connect the microphone cable to one of the first four inputs on the
front of the GigRac.
(The inputs on the GigRac can receive either 3-Pin XLR or standard Jack
connectors.)
