Soundigital 20000.1 EVOX User manual

OWNER´S MANUAL
20000.1
OWNER´S MANUAL

Introduction .................................................................................................................................................... 3
Package contents...................................................................................................................................... 3
Safety instructions ..................................................................................................................................... 4
Technologies
Vibration Absorption System ..................................................................................... 5
I-Power Supply.................................................................................................................... 5
Low Bass Correction ...................................................................................................... 6
Assembling and Disassembling the plastic cover ................................................................. 7
Panels description
Audio inputs, outputs and controls ........................................................................ 8
Power inputs........................................................................................................................ 9
Electrical Dimensioning ....................................................................................................................... 10
Audio input and output......................................................................................................................... 10
Installation sequence ............................................................................................................................. 11
SD RLC and Gain adjustment procedure ................................................................................. 12
Bass Boost set up .................................................................................................................................. 13
Crossovers set up................................................................................................................................... 13
Wiring Diagram ......................................................................................................................................... 14
Battery connection diagram.............................................................................................................. 15
Technical specs
Parameters ........................................................................................................................ 16
Dimensional data ........................................................................................................... 16
Additional Information........................................................................................................................... 16
TABLE OF CONTENTS
Code document review: 1000750347-002/NOV2023

INTRODUCTION
3
DEAR CUSTOMER,
CONGRATULATIONS ON ACQUIRING A PRODUCT WITH THE HIGHEST
QUALITY AND TECHNOLOGY!
You have just purchased a SounDigital product of the highest technology and
quality, so we thank you for your confidence.
Class D Amplifiers:
Class D amplifiers have as main characteristics the audio quality, efficiency,
application versatility and compact design. Following are the advantages of these
features:
Audio Quality – In the past, Class D products had limited response and for higher
frequencies, Class AB products performed better, but their efficiency was very low.
The new technologies introduced by SounDigital resulted in a Class D amplifier
with high efficiency and superior Class AB performance.
Efficiency – SounDigital Class D amplifiers have total efficiency (output + power
source) greater than 70%, which guarantees lower battery consumption and less
heating.
Application Versatility – The flat full-frequency response of SounDigital
amplifiers allows them to be used in all car sound systems. Meeting the demands
with extreme quality.
Compact Design – The high efficiency and high technology applied, allows
SounDigital amplifiers to be very compact, facilitating installation in vehicles where
space is limited.
IMPORTANT INFORMATIONS
On this manual you will learn about the product, its features and characteristics, in
order to obtain the best result and to be able to enjoy your music with SounDigital
quality and power.
To better understand and take advantage of all the functions of the product and use
it safely, read this manual carefully and if you have any questions, consult our
support by email: [email protected].
PACKAGE CONTENTS
▪ 01 Amplifier20000.1EVOX
▪ 01 Installation quick guide with warranty card
▪ 01 Allen wrench 2.5mm
▪ 01 Allen wrench 3.0mm
▪ 01 Allen wrench 4.0mm
▪ 01 Promotional sticker

SAFETY INSTRUCTIONS
4
THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING
THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE
EQUIPMENT.
Warning!
To avoid injury to the user or damage to the amplifier, read all safety instructions
written on this manual.
Before proceeding with the
installation of any electric
equipment on your vehicle,
u n p l u g t h e n e g a t i v e ( - )
terminal of the battery to avoid
fires, injuries or damages;
Use your sound system safely.
The continuous exposure to
sound pressures over 85dB
m a y c a u s e i r r e v e r s i b l e
hearing damage;
This equipment is for use in
a u t o m o t i v e D C v o l t a g e
batteries between 12.6 and
14.4 volts. Before installing the
equipment, check voltage of
the batteries;
Do not install the amplifier in
places exposed to water, dirt
or humidity;
Choose a ventilated place to
install the amplifier and avoid
blocking the side ventilation
windows;
Fix the amplifier properly and
firmly. Avoid fixing to metallic
parts of the vehicle, as this
procedure may cause ground
looping (noise);
When passing cables through
metallic walls, use rubber
O-rings to avoid cable cutting
and short-circuits;
Make sure that the chosen
loca tion for the amplifi er
installation does not affect the
operation of the vehicle;
T h i s p r o d u c t m a y r e a c h
t e m p e r a t u r e s o v e r 6 0 ° C
(140°F). Make sure it is cold
before touching it;
Clean the amplifier periodically
with brush or dry cloth to
assure the thermal efficiency
of the heatsink;
Be careful when making holes
in the vehicle. Make sure you
are not making holes in the
fuel t a n k , b r a ke lines o r
electrical cables of the vehicle;
Make sure the cables are
properly secured throughout
the installation;
Wear gloves, safety glasses
and all necessary PPE during
the installation of SounDigital
amplifiers.
X XX
X XX
The installation of this product
must be done by a qualified
professional. In case of any
doubt, please contact our
technical support;

5
TECHNOLOGIES
*Efficiency measured at power supply only.
SounDigital amplifiers are known for their low
consumption of battery, and this feature was
improved on the EVOX Line. The new
I-POWER SUPPLY is even more modern,
which replaces the old toroidal transformers
by a new generation of "E-E" core transformers
delivers efficiency above 90%*, ensuring more
hours of sound without battery recharge.
I-POWER SUPPLY
VIBRATION ABSORPTION
®
SYSTEM - VAS
Our Technology reduces all impact caused by vibration on the electronic
®
VAS
circuit board. This can include road vibration and even vibration caused by
sound waves, increasing the reliability of our amplifiers.

34"
8.9"
6
TECHNOLOGIES
REDUCED SIZE
The technology used in our amplifiers
bring both high performance and
power a compact chassis, providing
flexible installation solutions for
vehicles with limited space.
The design of the EVOX line of amplifiers aims to give users the feeling of the
smooth and deep bass, without compromise! Our Low Bass Correction
technology compares the input signals to the amplifier against the output after
the amplification stage, making real time correction of the signal, delivering a
deeper bass with less distortion.
LOW BASS CORRECTION
*Merely illustrative image.
An intelligent layout, with great use of
the PCB area and the use of modern
components with reduced structure
guarantee SounDigital products a
compact design, at the same time
robust and with excellent thermal
efficiency.
ULTRA COMPACT PCB

7
ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER
The plastic covers finish and hid the amplifier fixing screws. To are used to off e ’s
disassembl and assembl them, follow the instructions below.e e
1 2
21
DISASSEMBLING OF THE PLASTIC COVER
ASSEMBLING THE PLASTIC COVER
1. Carefully pull out the top of the plastic cover to release the upside latches, as shown in picture 1.
2. Slide up the plastic cover in a continuous movement to remove it.
1. To fit the plastic cover back, carefully insert the point A of the plastic cover into point B of the
amplifier, slowly sliding it down.
2. Gently press the sides of the top of the plastic cover towards the bottom of the amplifier until
you hear a clicking noise.
EN
B
A
*Merely illustrative images.
*Merely illustrative images.

9
2
8
1 3 4 9 10 11 12
5 6 7 148
PANELS DESCRIPTION
"POWER ON" LED indicator
"CLIP" LED indicator
"PROTECTION" LED indicator
10
9
11 Red
Blue
Yellow
Variable Bass Boost Level Control (0dB ~ +12dB)
Variable Bass Boost Frequency Control (35Hz ~ 55Hz)
Variable Low Pass filter control (50Hz ~ 500Hz)
Variable Subsonic filter control (3Hz ~ 30Hz)
Variable Gain control
RCA Connectors
5
7
12
8
14
6
2
1Audio input
-
-
-
-
-
Audio output
-
Speaker output connector
Remote level control connector
Minimun speaker load allowed (impedance)
4
3
-
13
13
Negative
Positive

+12V
+12V +12V
+12V
-
9
18
17
16 19 21 24
15 23
22
20
17
-
-
16
15
-
-
19
18
-
22
-
-
24
23
-
-
21
20
PANELS DESCRIPTION
Remote power supply connector (REM)
Negative power supply connector (GND)
Negative power supply connector (GND)
Positive power supply connector (+12VDC)
Positive power supply connector (+12VDC)
Remote power supply connector (REM)
Negative power supply connector (GND)
Negative power supply connector (GND)
Positive power supply connector (+12VDC)
Positive power supply connector (+12VDC)

We recommend the use of only OFC (Oxygen Free Copper) cables on the
installation of our products.
Copper-clad aluminum wire (CCAW) must not be used.
ELECTRICAL DIMENSIONING AND AUDIO INPUTS
ELECTRICAL DIMENSIONING
For proper operation of your SounDigital amplifier, you need the proper
dimensioning of the electrical system and the cables used.
The table below shows the minimum section of GND cables, +12VDC cables
and speaker output cables according to the power generated by the amplifier.
RCA INPUTS
Example of two RCA cables connection (mono input).
Example of one RCA cable connection only
POWER CABLE (+12VDC)
GROUND CABLE (GND)
SPEAKER CABLE
20000
WRMS
90mm² (000 AWG)
2 x 21mm² (4 AWG)
Example of one RCA cable connection only and using the RCA output to
connect another amplifier.
10

11
ØMount the amplifier in such a way you have access to the connectors;
ØInstall the power cables in the vehicle properly, starting from the battery to the fuse holder
or circuit breaker, use the cable with the appropriate size. Make all connections, install fuse
holders or circuit breakers, but without placing the fuses or with the circuit breakers in the
"OFF" position;
ØConnect the power cables in to the amplifier, observing the polarity. Connect all the positive
cables from the fuse holder or circuit breaker to the positive conector of the amplifier (+)
and all the negative power cables from the batteries to the negative connector of the
amplifier;
ØThe ground cable must be as short as possible and must be connected to the vehicle
chassis and the battery negative;
ØInstall the signal input cables in a proper way, distant from the power cables;
ØConnect the RCA or the high level signal input cables to the head unit and amplifiers;
ØInstall the audio output cables with the appropriate section, distant from the power and
audio input cables;
ØConnect the audio output cables to the amplifier and speakers respecting the positive (+)
and negative (-) polarities;
ØInstall the remote cable with the power cables, using 1.5mm² (15 AWG) cable or thicker;
ØConnect the remote power cable to the amplifier's "REM" terminal at the main unit's remote
power output (when not using the high level signal inputs);
ØBefore powering the system, verify all the connections and make sure there are no
mistakes or short-circuits on the power and ground cables;
Ø;Reconnect the ground of the batteries
ØCheck if the head unit is turned off and then place the fuses in the fuse holders or switch the
circuit breakers on;
ØTurn on the main unit and the amplifier will turn on the "POWER ON" LED indicating that it is
in operation.
INSTALLATION SEQUENCE
Remove the paint
between the terminal
and chassis
THE MAXIMUM DISTANCE FOR THE INSTALLATION OF THE FUSE/CIRCUIT BREAKER
IS 12 INCHES (30cm) AWAY FROM THE BATTERY.
BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL
FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE
USER HIMSELF.
X XX
Minimum recommended
i n s t a l l a t i o n d i s t a n c e
between amplifiers*.
1.18in (30mm)
*For installations with more than one amplifier, second unit not included. Merely illustrative images.
Warning!
Warning!
Warning!

SD RLC / GAIN SETTING
POWER CLIP
LEVEL
SD REMOTE
LEVEL CONTROL*
EXTERNAL LEVEL CONTROL - SD RLC (*Not included)
The SD RLC is an easy-to-install external level
control accessory that allows you to tune the
level of SOUNDIGITAL amplifiers that have
remote level control.
In SD RLC, you can adjust the amplifier level
without having to lean over and adjust the gain
setting on the amplifier and can monitor the
“CLIP” LED which is also available on the
accessory. *Sold separately
GAIN SETTING
12
Download the tracks for set up in https://soundigitalusa.com/tracks-for-set-up/
Necessary equipament:
ØDigital AC voltmeter;
ØMedia with sine wave test tone 60Hz
recorded at 0db;
ØScrewdriver 1/8" ( for gain setting).
Set up procedure:
Turn the gain control all the way
Ø
down;
ØDisconnect the output cables from
the amplifier outputs;
ØTurn off all processing (bass, treble,
loudness, EQ, etc.);
ØSet the audio player volume to 3/4 of
full volume;
ØSet the audio player fader control to
center position (left and right fader
controls);
ØSet the variable "LOW" crossover in
500Hz and the "HIGH" in 3Hz;
Ø Use a 60 Hz sine wave;
ØIncrease the gain control until the
"CLIP" LED starts blinking;
ØReturn the gain to the limit where the
"CLIP" LED stops blinking and
remains off;
ØO n c e y o u h a v e a d j u s t e d t h e
amplifier to the correct voltage
output, turn off the source unit and
reconnect the speaker(s).

Reproduce your favorite song and set the variable frequency control to the
frequency you want boost between 35Hz and 55Hz. Set boost intensity between
0dB and +12dB at the variable control Level.
CROSSOVER AND BASS BOOST SET UP
Set in the "HIGH" variable control between 3Hz and 30Hz ("A") where you want to
perform the high pass cut filter;
Set in the "LOW" variable control between 50Hz and 500Hz ("B") where you want
to perform the low pass cut filter;
Using Bass Boost
The Amplifier Bass Boost setting enables the user to boost the sound intensity
at low frequencies of the sound system, where boost intensity can be adjusted,
as well as the frequency of the region to be boosted, as indicated in the chart .
This is a semi-parametric equalizer type circuit with "Q" value for the fixed filter,
with an intensity boost adjustment from 0 to + 12dB (16 times), and a central
frequency adjustment of the filter between 35 and 55Hz, making it versatile for
several types of sound systems.
Bass Boost Chart
How to Adjust Bass
Boost
How to Adjust the
Crossovers
Bass Boost Level
12dB
dB
Hz
0dB
3dB
0
9dB
6dB
Boost
Frequency
-3dB
c/2
ƒ
High
Pass
c
ƒ
High
Pass
A
0dB
-12dB
dB
Hz
-6dB
0dB
-24dB
Low
Pass
B
c
ƒc*2 ƒ
Low
Pass
dB
Hz
13

GND
+12V
+12V
POWER CLIP
LEVEL
SD REMOTE
LEVEL CONTROL*
14
MAIN UNIT REMOTE OUTPUT
POWER CONNECTIONS
AUDIO INPUT AND OUTPUT CONNECTIONS
REMOTE INPUT CONNECTIONS
FUSES
FUSE
*Sold separately
WIRING DIAGRAM
Unplug the negative (-) terminal of the battery before proceeding
with any eletrical installation in the vehicle to avoid fire starts,
wounds or damage to the amplifier.
In case of connections with
more than one battery, see
the installation diagram on
page 15.

When necessary the association of one or more battery banks to supply the
necessary current to the amplifier, it is recommended to use batteries of the same
brand, model, and if possible the same manufacturing lot so that the system has
the maximum performance.
For an ideal energy performance, we recommend that all batteries be connected to
positive and negative busbars and the busbars connected to the amplifier, as
shown in the diagram below:
1
2
BATTERY CONNECTION DIAGRAM
2
3
1
Battery connections without the use of a busbar,
as shown in the example below, must be avoided.
This setting decreases the efficiency of supplying
power to the system.
All cables, positive and negative,
connected from the battery to the
busbar must be the same length.
Likewise the cables connected from
the busbar to the amplifier.
15
FUSE
FUSE
FUSE
FUSE
It is mandatory to install the fuse at a
maximum distance of 12 inches from the battery.
It is mandatory to install the fuse at a
maximum distance of 12 inches from the battery.
FUSE
FUSE
BUSBAR
BUSBAR
*Merely illustrative image.

833.7mm (32.8")
204.4mm (8.0")
863.2mm (34.0")
224.8mm (8.9")
71.5mm (2.8")
Gross Weight
14.64 kg (32.27 lb)
Net Weight
12.57 kg (27.71 lb)
3Hz ~ 500Hz
2 x 21mm² (4 AWG)
3Hz ~ 30Hz
980A
1960A
71%
200
90mm² (000 AWG)
1000A
1000Ah
RMS Power @ 2Ω**
76dB
Operating Voltage
SNR
Input Sensitivity (RCA)
Current Draw (music)
Current Draw (max.)
Total Efficiency
Damping Factor (@100Hz nominal impedance)
Power Cable
Speaker Cable
Recommended Fuse* (music)
Recommended Battery (minimum)
Low Pass Filter (12dB/octave)
Frequency Response (-3dB)
High Pass Filter (12dB/octave)
RMS Power @ 4Ω**
PARAMETERS
RMS Power @ 1Ω**
Bass Boost Level
Bass Boost Frequency 35Hz ~ 55Hz
0dB ~ +12dB
1 x 13200W
1 x 20000W
1 x 8712W
TECHNICAL SPECS
**POWER RATING ACCORDING TO
CTA-2006 INDUSTRY STANDARDS.
**Power at 14.4V @ 60Hz with a maximum THD of 1%.
*It is mandatory to install the fuse at a maximum distance of 12 inches from the battery.
DIMENSIONAL DATA
16
ADDITIONAL INFORMATION
The values presented are based on measurements performed in
SounDigital's laboratories. All the equipment used in the assays, tests,
measurements and gauging of the technical parameters of SounDigital
products were calibrated in certified laboratories, thus ensuring the
performance and standard of excellence of the developed products.
The Manufacturing Process may present variations, and the electronic
components may also present changes in values in relation to their
nominal parameters. Thus, causing small differences between
measurements taken. Small variations in the values presented and
divulged by SounDigital are recognized.
The images presented in this document are representative and
merely illustrative; therefore, they do not necessarily correspond to the
actual product/model.
Updates of information made in this document will always be
published and made available for consumer consultation, free of
charge, on the brand's websites. The user is advised to search for
the manual in its latest version when necessary.
1.5mm² (15 AWG)
Remote Cable
20000.1 1Ω
9V ~ 16V
0.8V ~ 4V
50Hz ~ 500Hz

Document revision code: 1000750347-002/NOV2023
