Soundstream SDR-342B User manual

SDR-342B
I
SDR-342BT
Flip-down/Detachable 3.4" Monitor
MP3/MP4 Player
AM/FMRadio
Built-in TV
tuner
(only for SDR-342T model)
Owner's Manual
Take the time
to
read
through
this
owner's manual.
Familiarity
with
installation and operation procedures will help you obtain the best
Performance from
your
new device.

• Using the device at temperature below
-1
OOC
may cause the breakage
of
the device.
BEFORE USING PLEASE HEAT UP THE PASSENGER COMPARTMENT TO THE
RECOMMENDED TEMPERATURE!
• Read carefully through this manual to familiarize you with this high-quality sound system.
• Disconnect the vehicle's negative battery terminal while mounting and connecting the unit.
• When replacing the fuse, be sure to use one with an identical amperage rating. Using a fuse
with a higher amperage·
rating may cause serious damage to the unit.
• Make sure that pins or other foreign objects do not get inside the unit; they may cause
malfunctions, or create safety hazards such as electrical shock or laser beam exposure.
• Ifyou have parked the car for a long time
in
hot or cold weather, wait until the temperature
in
the car becomes normal before operating the unit.
• DO NOT open covers and do not repair yourself. Consult the dealer or an experienced
technician for help.
• Make sure you disconnect the power supply and aerial ifyou will not use the system for a long
period or during a thunderstorm.
• Make sure you disconnect the power supply ifthe system appears to be working incorrectly,
(For example: making unusual sounds, smelling strange, emitting smokes from inside or
liquid having gotten inside
it)
Have a qualified technician check the system.
• The unit is designed for negative terminal
of
the battery, which is connected to the vehicle
metal. Please confirm it before installation.
• Do not allow the speaker wires to be shorted together when the unit is switched on. Otherwise
it may overload or burn out the power amplifier.
• Do not install the detachable panel before connecting the wire.
• Don't remove the detachable panel when encoding.
2

Important Safeguards...............................................................................................................2
Contents...................................................................................................................................3
Accessories..............................................................................................................................4
lnstallation/Un-lnstallation ........................................................................................................5
Wiring Connections..................................................................................................................6
Front panel...............................................................................................................................7
Inner panel ...............................................................................................................................7
Remote control.........................................................................................................................8
Remove battery........................................................................................................................8
Main Menu ...............................................................................................................................9
General Operation ...................................................................................................................9
Radio operation......................................................................................................................12
USB/SD/MMC Operation .......................................................................................................13
Bluetooth Section...................................................................................................................14
TV Section (only for SDR-342BT model) ...............................................................................15
Anti-theft system ....................................................................................................................17
Troubleshooting guide ...........................................................................................................17
Specification...........................................................................................................................18
3

Package contains the following accessories for installation and operation
of
the unit.
(1) Washer, Spring
Washer, M5 Nut
(2) Mounting Strap
(3) Bolt
(4) Screw
(5) Mounting Collar
(6) Release Key
(7) Screw
(8) Rubber Cushion
·-·
------·------
--·---··-
·-
-·---·-
·
Remote Control
User
Manual
1
each
1
p o o
c:::>
o o
o)
1
4
1
2
1
1
Warranty card ISO cable
~
II
User Manual 1x front panel protection case Trim ring
Noted:
Product image may vary from the actual delivery
4
external microphone
cable

First complete the electrical connections, and then check them for correctness.
Installation
This unit can be installed in any
dashboard having an opening as
shown on the picture. The
dashboard should be 4. 75 -5.56
mm thick
in order to be able to
support the unit.
1. Insert mounting collar into the
dashboard, and bend the
mounting tabs out with a
screwdriver.
Make sure that lock lever C
*) is
flush with the mounting collar (not
projecting outward).
2. Secure the rear of the unit.
Lock lever ( *)
After fixing mounting bolt and power connector, fix the rear of the unit to the car body by rubber
cushion.
3. Insert trim plate.
When you prepare to insert trim plate, please check its direction. Once it was up side down, it
cannot be fixed.
Un-installation
Remove Trim Ring and insert Release Keys into left and ~
right side-end holes as shown in below picture and pull 0 ..
the unit out of the dashboard.
5

Make sure you have good chassis ground. A good ground connection will eliminate most
electrical noise problems. A good chassis ground requires a tight connection to the vehicle's
metal chassis. The area around the ground connection should be clean, bare metal without rust,
paint, plastic, dust, or dirt for a good electrical connection.
Caution: Do not interchange the connection of the wiring!!!
For some car models you may need to modify wiring
of
the supplied power cord. Contact your
authorized car dealer before installing this unit.
SeUNDSTREAM
USB/SD,MP3/MP4,AM/FM
STEREO
ISO
Speaker
Connection
AJ
FJnWID~
~
mm~
immrr==n
~r
To
co
nn
ect
Pa
rking to see vi
deo
+-+-
--
(GNOJ[B
ro
wn)
A4
To
te
rmin
al
alw
ays supplied
wi
th
pow
er
(M
em
ory B+)(Yell
ow
)
A5
To
sys
tem
contr
ol t er
mi
nal
of
the
pow
er
a
mp
or
Au
to
-an
tenna
contr
ol ter
mmal(
max.
30DmA
12V
DC)(
Blue)
A7
To
el
ec
tric
termina
l con
tr
olled
by ign
it
ion
switch(
1
2V
DC)
ON/
OF
F(
ACC B+](Red)
AS
To
v
ehicl
e (
meta
l)b
ody.(GNO)(Biack)
Fr
ont
speaker
83
Ri
gh
t +
84
Ri
ght
-
85
Left+
86
Left
-
Rear
speaker
81
Ri
ght+
82
Ri
ght
-
87
Left+
88
Left-
Using the ISO Connector
1.
Ifyour car is equipped with the ISO connector, then connect the ISO connectors as illustrated.
2.
For connections without the ISO connectors, check the wiring
in
the vehicle carefully before
connecting, incorrect connection may cause serious damage to this unit.
3.
Cut the connector; connect the colored leads
of
the power cord to the car battery as shown
in
the color code table below for speaker and power cable connections.
Location Function
Connector A Connector B
1 Rear Right(+)---Purple
2 Rear Right(-)---Purple/Black Stripe
3
Parking (GND)---Brown Front Right(+)---Grey
4
Battery 12V (+)---Yellow Front Right(-)---Grey/Black Stripe
5
Auto Antenna---Blue Front Left(+)---White
6
Front Left(-)---White/Black Stripe
7
ACC(
+)---Red Rear Left(+)---Green
8
Ground---Black Rear Left(-)---Green/Black Stripe
6

6 7 8 9
10
1
--t
f-l:!::::i!~
2
--t---
3
4
----.~
11
1)
Power /Mute button
2) EQ /LOUD button
3) SEL button
4) Mode button
5) SCAN button
6) MENU button
7) Volume/OK button
8) AS/PS button
12 13
9)
BAND
I
Media select
I
accept button
Inner panel
18
L.__j
[ SD ( )0
@
, B
~
[
18) SD/MMC card slot
19)
Reset button
20
) Anti-Theft LED flash
14
10
) Play/Pause, Memory /reject button
11) Previous I Reverse button
12
) Next I Forward button
13
) IR sensor
14
) LCD Screen
15
) OPEN button
16
) USB slot
17)
AUXIN
jack/AV IN jack(optional)
19
20
L.__j
mUm
J
D
~@
~(]
0
0 0
B
@s
J
NOTE: When turn
off
the power, the unit will switch to standby mode unless cut the ACC power.
The power light will continue lighting.
7

~!~~!!~ ................. ~ ~ ~
G)--~~===-::1
--- ©
Remove batte
Note:
1: MENU
2: POWER
3: UP
4: BAND/M.SEURDM
5: ENTER
6: LEFT/SEEK-/FAST BACKWARD
7: DOWN
8: REPEAT/INT
9: AS/PS
10: MODE
11:DIGITNUMBER
12:PLAY/PAUSE/ REJECT
13 :MUTE
14: AUDIO/ACCEPT
15: SUBTITLE
16 :RIGHT/SEEK+/FAST FORWARD
17:VOLUME PLUS
18:SET
19: VOLUME MINUS
20: EO/LOUD
21 :SEL
22: SCALE/ROTATE
23:GO TO
• The distance may vary according to the brightness of ambient light.
•
If the remote is not used for an extended period of time, remove the battery to prevent
possible damage from battery leakage and
corrosion.
• Do not place any objects between the remote
control unit and the sensor
on the unit.
• Do not dropthe remote control onto the floor;
it
will damage it beyond repair.
• Do not use the remote control unit, while simultaneously operating the remote control unit
of
any other equipment; they may interfere resulting in improper operation.
• The battery normally last for about one yearalthough depending how often the remote
control is used.
If the remote control unit isn't working even when it is operated near the unit,
replace the battery with a new battery
of the same make and use only a lithium cell battery
type: CR2025 (3V).
• Dispose empty batteries in accordance with your local governmental regulations.
• Do not short-circuit, disassemble, heat or dispose
of fire or flames the battery.
• Keep the battery
out of reach of children, should the battery be swallowed, immediately
consult a doctor.
8

~!~!~
...................
~
~~
The best way to discover the program is to explore each screen in detail, and to find out how to
move from one to another. Read this chapter for a guided tour.
Unit starts by displaying the Main menu.
This is the root
of
the screen hierarchy, you can simply take knowledge
of
the features.
General Operation
Reset the unit
Operating the unit for the first time
or
after replacing the car battery, you must reset the unit.
Press OPEN button on the panel to open the panel and press RESET button to restore the unit
to its original factory settings.
Power on
or
off
Press any button (except open button) to turn on the unit.
Long press POWER button on front panel or press power button on the RC to power offthe unit..
Mode setting
Press the MODE button repeatedly to switch between inputs:
r
RADIO-USB-SD-TV-AUX
IN/AV
IN-SETTING-RADI~
(*available only
if
there is media device in
SO,
USB slot connection is OK.)
Volume/OK
Adjust the volume level by turning the VOL knob on the panel clockwise to increase
or
counterclockwise to decrease or pressing VOL+
or
VOL- on the RC to increase
or
decrease the
volume.
In
any mode, rotate VOL knob to select the file you want to playback, press the OK button to
enter the next menu.
In
Mp3 mode, when playing the music, press the OK button on the front panel, the music will
start from the beginning.
In
Photo mode, when playing the photo, press the OK button on the front panel to enterthe
photo setup menu.
9

~ ~
In Video mode, when playing the video, press the OK button on the front panel, you will see
the track number and running time on the screen
Sound Adjustments
Press the SEL button on the RC to select the audio settings consisting of following items:
EQ: Select the digital sound effect USER-FLAT-CLASSIC-POP-ROCK
BASS: Bass up/down.
TREBLE: Treble up/down.
BALANCE: Left/right Balance control.
FADER: Front/rear Fader control.
LOUDNESS: Set the loudness on or off.
BEEP: Keypad sound setting.
Rotate Volume knob on the front panel
or press up/down arrow on the RC to select any items
and then press OK button on the panel
or Enter button on the RC to confirm the item.
Rotate Volume knob
or press LEFT/RIGHT buttons on the RC to adjust the audio setting. Press
OK button on the panel or Enter button on the RC to confirm and again press SEL button return
to current mode.
Note:
~ If the unit is turned off, all the settings of each mode will be saved.
~ If cutting off battery power or resetting the unit, all the settings will return to factory default
settings.
Mute function
Press POWER/MUTE button on the panel or MUTE button on the RC to turn the sound off. Press
it again to resume the volume.
Loudness
Long press EO/LOUD button on the RC or front panel to set loudness on or off.
EQ
Press the EQ button on the panel to choose sound effect in the sequence of USER- FLAT-
CLASSIC-POP-ROCK.
Menu
Press MENU button on the front panel or the RC to return to previous menu.
Setup
Press SET button on the RC or front panel, or SET icon on the main menu to go to setup pages.
1) Rotate Volume knob on the front panel
or press up/down arrow on the RC to select any items
and then press OK button on the panel or ENTER button on the RC to confirm the item
2) Rotate Volume knob
or press LEFT/RIGHT buttons on the RC to adjust the audio setting.
Press OK button on the panel
or Enter button on the RC to confirm.
3) Press SET button on the RC or front panel again return to current mode.
Sound
SETIINGS 01 23
EQ: select the digital sound effect.
j · souND
EO
FL AT
!_!DISPLAY
Bass
Bass: bass up/down.
CJr' GENERAL
Treble
Treble: treble up/down.
Balance
t·'"l RADIO
Fader
R Balance: Left/right Balance control.
! SYSTEM
Fader: Front/rear Fader control.
10
